The GE Mark VIe series provides advanced control for turbines and critical machinery. These systems offer precise regulation, high reliability, and easy integration with industrial automation solutions, helping to maintain stable operations and protect assets.
GE Mark VIe
-
General Electric GE DS200TCQCG1BJF Mark V Speedtronic RST Overflow Board
GE DS200TCQCG1BJF Mark V Speedtronic RST Overflow Board The GE DS200TCQCG1BJF, also cataloged as the DS200TCQC RST Overflow Board, operates as a dedicated hardware component for monitoring counter and timer overflow conditions within GE Mark V Speedtronic turbine control platforms. Hardware Specifications Parameter Specification Model DS200TCQCG1BJF Brand GE Origin USA Weight 0.6 kg Dimensions 21 x 15 x 4 cm Operating Temp -10 deg C to +55 deg C Power Consumption 24 VDC +/-10%, 150 mA Input Channels 16 RST overflow signals Input Voltage Range 0-24 VDC Threshold Voltage 12 VDC +/-5% (programmable) Response Time < 1 ms Fault Latching Hardware latch (software reset required) Status Indicators 16 discrete red LEDs Host Interface 34-pin ribbon connector Power Connector 4-pin terminal block Backplane Communication & Deterministic Execution Designed for the GE Mark V Speedtronic turbine architecture, the board interfaces directly with core processor cards via a 34-pin ribbon bus cable. It executes high-speed signal processing on 16 discrete counter channels with a response latched under 1 ms. The card ensures deterministic firmware flash compatibility across Mark V revision updates, preventing bus contention and maintaining real-time fault detection logic without overburdening host processor backplane communication velocity. Frequently Asked Questions Q: Can the DS200TCQCG1BJF board be replaced while the Mark V system is powered? A: No. The board must be de-energized prior to removal or insertion. Hot-swapping risks damaging the 34-pin ribbon bus interface and causing inadvertent fault latching on adjacent system cards. Q: How are latched overflow signals cleared after a fault condition is resolved? A: The board hardware latches the overflow state upon crossing the 12 VDC threshold. Clearing the fault condition requires a software reset command issued from the host processor across the bus connection. Q: What power inputs are required for board operation? A: The board requires a regulated 24 VDC power supply connected via the 4-pin terminal block, consuming a nominal current of 150 mA. Field Installation Guidelines Ensure the Mark V control panel is fully de-energized and locked out before opening the rack enclosure. Observe anti-static precautions. Wear a grounded wrist strap attached to the panel earth ground when handling the board. Verify mechanical mounting alignment on the card cage standoffs using standard hardware to avoid board flexure. Secure the 34-pin ribbon connector fully, ensuring side locking tabs are latched to prevent pin misalignment or intermittent connectivity. Connect power supply wiring to the 4-pin terminal block, maintaining proper polarity (+24 VDC and GND). Ensure shield grounding wires are terminated directly to the cabinet ground bus bar with short, low-impedance leads.
$200.00 $100.00
-
General Electric GE DS200TCPAG1AJD Mark VI Turbine Control Processor
GE DS200TCPAG1AJD Mark VI Turbine Control Processor The GE DS200TCPAG1AJD, also cataloged as the DS200TCPA Turbine Control Processor, operates as a dedicated hardware component for sequencing, protection, and real-time process control within GE Mark VI Turbine Control System networks. Suffix Breakdown & Model Matrix DS200: Standard GE Mark VI circuit board form factor and product line designation. TCPA: Base module functional designation for the Turbine Control Processor board. G1: Group revision index indicating specific component bill-of-materials configuration. AJD: Artwork and functional revision level suffix representing hardware revision iterations. Hardware Specifications Parameter Specification Model DS200TCPAG1AJD Brand GE (General Electric) Origin USA Weight 540 g Operating Temp 0 deg C to +60 deg C Power Consumption Operating via backplane (+5 VDC / +-15 VDC supply rails) System Architecture Mark VI Turbine Control System Communication Protocols IONet Ethernet, RS-232, RS-485 Firmware Management Field-upgradeable via GE Toolbox software Slot Compatibility GE Mark VI and Mark VIe VME rack assemblies Backplane Bus & Deterministic Communication The DS200TCPAG1AJD processes real-time fuel metering, valve actuation, and startup sequencing over a high-speed VME backplane bus structure. Deterministic networking across redundant processor nodes is maintained through high-velocity backplane bus communication velocity Licences and proprietary IONet Ethernet interfaces. The board features hardware-level I/O density scaling alongside firmware flash compatibility to preserve real-time control cycle execution across dual and triple modular redundancy (TMR) control topologies. Frequently Asked Questions Q: How is backplane power delivered to the DS200TCPAG1AJD during system operation? A: Power is sourced directly from the Mark VI backplane assembly via dedicated pin allocations supplying +5 VDC and +-15 VDC regulated rails. Q: Does replacing the DS200TCPAG1AJD require specialized cabinet reconfiguration? A: No, the board functions as a direct drop-in replacement within compatible Mark VI VME rack slots without structural cabinet modifications. Q: How is firmware maintained or updated on the processor card? A: Firmware is flashed directly to on-board non-volatile memory using GE Toolbox software over the dedicated serial or Ethernet communication interface. Field Installation Guidelines ESD Protection: Wear a grounded wrist strap attached to the cabinet chassis ground point prior to handling the circuit board to prevent static discharge damage to sensitive semiconductor logic. Power Isolation: Ensure backplane power supplies are fully de-energized or follow explicit Mark VI online rack swap procedures before inserting or removing the module from the VME chassis. Physical Alignment: Align the top and bottom edge card guides carefully prior to sliding the board into the slot. Engage the card ejector handles completely to lock the backplane connectors into position. Shielding and Grounding: Connect all external communication cables using shielded twisted pair cabling with 360-degree shield termination grounded to the chassis terminal bar. Maintain physical segregation between signal communication lines and high-voltage power conduits.
$200.00 $100.00
-
General Electric GE DS200PTCTG1BAA Mark V PT and CT Signal Conditioner Board
GE DS200PTCTG1BAA Mark V PT and CT Signal Conditioner Board Configured for galvanic isolation and signal conditioning in GE Mark V Speedtronic turbine control platforms, the GE DS200PTCTG1BAA (DS200PTCT PT and CT Signal Conditioner Board) provides direct physical/electrical execution. It scales high-voltage potential transformer (PT) and current transformer (CT) input feedback down to low-voltage internal levels, suppressing noise and processing field signals into discrete digital representations required for real-time turbine protection, continuous monitoring, and governor loop calculations. Hardware Specifications Parameter Specification Model DS200PTCTG1BAA Brand General Electric Origin United States Weight 0.5 kg Operating Temp -30 deg C to +65 deg C Power Consumption +5 VDC @ 6 A Auxiliary Supply Voltage 24 VDC Input Voltage 120 VAC System Frequency 60 Hz Relay Channels 12 Mounting DIN-rail Technology Surface mount Backplane Bus Communication Velocity and Signal Processing The DS200PTCTG1BAA module interfaces directly with the Mark V core system backplane, maintaining strict deterministic timing across high-density I/O configurations. Designed for demanding turbine power feedback environments, the board leverages precise hardware filtering circuits to minimize signal attenuation and latency during transient high-load events. The internal architecture optimizes backplane bus communication velocity and firmware flash compatibility, preventing data jitter and ensuring synchronized sample rates across all 12 relay channels during turbine trip and governor control operations. Frequently Asked Questions Q: What are the primary power rail requirements for the DS200PTCTG1BAA during operation? A: The module requires a primary internal bus supply of +5 VDC at 6 A for digital logic and signal processing circuits, along with an auxiliary 24 VDC power input for onboard relay channel excitation. Q: Can the board accept direct high-voltage potential transformer signals? A: The board is designed to interface with standard instrument potential transformers rated up to 120 VAC at 60 Hz, providing galvanic isolation and onboard signal attenuation before conversion. Q: Is hot-swapping permitted for this module during active turbine operation? A: No. Standard Mark V maintenance protocols require shutting down power to the rack location before removing or inserting the board to prevent arc fault hazards on the 120 VAC PT and 24 VDC supply circuits. Field Installation Guidelines Verify that power to the panel card cage (+5 VDC and 24 VDC supplies) and field PT/CT primary lines (120 VAC) are completely de-energized prior to hardware handling or insertion. Mount the assembly securely on standard DIN-rail infrastructure, ensuring proper mechanical engagement and ground continuity via the mounting hardware. Ensure shield grounding wires for external PT and CT field wiring are terminated at designated single-point earth ground bars to eliminate high-frequency ground loops. Maintain adequate physical spacing around the board perimeter to facilitate natural thermal heat dissipation across the surface-mount component matrix within the -30 deg C to +65 deg C operating envelope.
$200.00 $100.00
-
General Electric GE DS200DCPAG1ABB Mark V Digital Control Processor Card
GE DS200DCPAG1ABB Mark V Digital Control Processor Card The General Electric DS200DCPAG1ABB, also cataloged as the DS200DCPA Digital Control Processor Card, operates as a dedicated hardware component for turbine control logic execution and communication management within GE Mark V Speedtronic systems. Suffix Breakdown & Model Matrix DS200: Standard Mark V system printed circuit board layout and form factor. DCPA: Digital Control Processor Board functional platform abbreviation. G1: Group 1 base board electronic design revision and assembly layout. ABB: Revision level designation indicating specific hardware component artwork updates and firmware compatibility patches. Hardware Specifications Parameter Specification Model DS200DCPAG1ABB Brand General Electric (GE) Origin USA Weight 0.9 kg Dimensions 233 mm x 160 mm x 25 mm Operating Temp -30 to +65 deg C Power Consumption System backplane powered Processor Type Digital Control Processor Redundancy Modes Simplex, Dual, Triple Modular Redundancy (TMR) Component Density 17 integrated circuits, 24 resistor network arrays Onboard Diagnostics Diagnostic status LEDs and watchdog timing monitor Isolation Rating 2500 Vrms Backplane Bus & Deterministic Processing The GE DS200DCPAG1ABB interacts directly with the Mark V core backplane bus to ensure deterministic execution of turbine protection and control algorithms. Designed for tight synchronization, the onboard digital processor executes control logic loops across Simplex, Dual, and TMR architectures. In TMR configurations, the board executes voting algorithms to maintain high system availability and zero-downtime fault tolerance, preventing inadvertent turbine trips caused by single-point hardware faults. Frequently Asked Questions Q: How does the DS200DCPAG1ABB handle power allocation during system hot-swapping? A: The DS200DCPAG1ABB is not designed for unpowered hot-swapping. Power to the rack location must be isolated prior to board insertion or removal to prevent electrical transients across the multi-pin backplane connectors. Q: What onboard hardware mechanisms monitor processor execution health? A: The module incorporates an integrated hardware watchdog timer circuit coupled with front-facing diagnostic status LEDs. If the control loop execution halts or exceeds its cycle window, the watchdog circuit forces the processor state into a defined fault output. Field Installation Guidelines Power down the Mark V rack section and discharge all static potential by attaching a grounded ESD wrist strap prior to touching the board edge. Inspect the multi-pin vertical pin connectors on the board and the corresponding backplane slot for bent pins or debris. Align the board edges with the card guide rails inside the Mark V panel enclosure. Slide the module firmly into the slot until the multi-pin connectors fully seat into the backplane receptacle. Secure all retaining screws on the front faceplate to ensure ground continuity and mechanical stability under operational vibration.
$200.00 $100.00
-
General Electric General Electric DS200DACAG1ACD Mark VIe Series Digital-to-Analog Converter Board
General Electric DS200DACAG1ACD Mark VIe Series Digital-to-Analog Converter Board Configured for precise digital-to-analog signal conversion in GE Mark VIe control platforms, the General Electric DS200DACAG1ACD (DS200DACA Digital-to-Analog Converter Output Board) provides direct physical/electrical execution. Operating as a 16-channel analog output module, it converts digital controller commands into calibrated current and voltage loops for direct actuation of turbine fuel valves, servo positioners, and variable speed drives. The module features embedded channel-level diagnostics and short-circuit protection to maintain loop stability under variable load profiles. Hardware Specifications Parameter Specification Model DS200DACAG1ACD Brand General Electric (GE) Origin USA Weight 0.5 kg Dimensions 27.9 cm x 12.7 cm x 4 cm Operating Temp -40 to +75 deg C Power Consumption +5 VDC (Logic) / +24 VDC (Field Power) Output Channels 16 software-selectable channels Output Signal Ranges 4-20 mA (0-750 ohm load) / 0-10 VDC (>2 kohm load) Resolution 16-bit DAC Signal Accuracy +/-0.05% FS at 25 deg C; +/-0.10% FS (-40 to +75 deg C) Update Rate 800 samples/sec across channels Common Mode Rejection 95 dB CMRR Insulation Coating 100 um conformal coating Industrial Backplane Communication and I/O Density Scaling The DS200DACAG1ACD integrates with the Speedtronic Mark VIe control backplane via a 64-pin connector interface designed for high backplane bus communication velocity and high I/O density scaling. The onboard logic processes 16-bit DAC values delivered deterministically over the system bus, executing updates at an aggregate rate of 800 samples per second across all 16 output channels. To maintain loop integrity across high-density I/O distributions, each channel incorporates hardware-based EMC filtering and individual output monitoring circuits. Firmware flash compatibility checks are performed during backplane initialization to prevent state execution errors caused by revision mismatches across redundant processor sets. Frequently Asked Questions Q: Can the DS200DACAG1ACD module be installed or removed while the backplane is powered? A: No. Power to the rack must be disconnected prior to inserting or extracting the module. Inserting the board into an energized 64-pin backplane can cause pin arcing and damage the onboard logic power traces or field-side driver ICs. Q: How does the channel output behave in the event of a field wiring short circuit? A: Each output channel incorporates independent short-circuit current limiting and thermal protection circuits. If a short circuit occurs across the field terminals, the driver limits the maximum current output to prevent component damage until the fault condition is cleared. Field Installation Guidelines Mount the board using the integrated card guides within the Mark VIe chassis, ensuring the 64-pin edge connector seats completely into the backplane socket. Secure all retention screws to provide a low-resistance chassis ground path for the onboard EMC filters. Field wiring must be terminated at the dual 16-position terminal blocks using shielded twisted-pair cables. Ground all cable shields at a single chassis grounding point on the rack frame to prevent ground loops that compromise DAC accuracy. Maintain a minimum engagement of 5 threads on NPT conduit fittings when routing field cables into the control enclosure, and isolate low-voltage 0-10 VDC / 4-20 mA signal lines from high-voltage AC power cables by at least 30 cm.
$200.00 $100.00
-
General Electric GE DS200TCPDG2BEC Mark V Power Distribution Board
GE DS200TCPDG2BEC Mark V Power Distribution Board Configured for managing regulated DC power routing with integrated protection and diagnostics in GE Mark V Speedtronic systems, the GE DS200TCPDG2BEC (DS200TCPD Power Distribution Module) provides direct physical/electrical execution. As a core power routing component within the Speedtronic platform, this board establishes clean voltage delivery pathways across system backplane nodes, processing cards, and field relay interfaces. It features dedicated onboard bus filtering and real-time LED diagnostics to ensure continuous operational integrity for heavy-duty gas and steam turbine control systems. Hardware Specifications Parameter Specification Model DS200TCPDG2BEC Brand General Electric Origin USA Weight 0.85 kg Operating Temp 0 to +60 deg C Power Consumption Passive distribution node (circuit dependent) System Platform GE Mark V Speedtronic Board Type Power Distribution Module Input Voltage 125 VDC nominal Output Channels 12 isolated DC circuits Current Rating 10 A per channel Circuit Protection Electronic circuit breakers, fuse backup, LED fault indication Humidity Range 5% to 95% non-condensing Mounting VME rack compatible slot Backplane Bus Communication Velocity & Firmware Flash Compatibility The DS200TCPDG2BEC incorporates low-impedance copper bus traces designed to handle rapid transient current shifts without compromising backplane bus communication velocity across adjacent VME control slots. By regulating power lines feeding the processor, relay, and analog I/O modules (such as the DS200TCRAG1A and DS200TCQCG1B), it prevents localized voltage sags that could interfere with high-speed deterministic control loops. Furthermore, its hardware topology maintains passive power bus stability regardless of the firmware flash compatibility status or revision levels running on downstream microprocessor cards, isolating hardware power delivery from software execution states. Frequently Asked Questions Q: What is the primary function of the onboard LEDs on the DS200TCPDG2BEC? A: The onboard LEDs provide visual indication of power distribution state and fault conditions. A blown fuse or tripped electronic circuit breaker triggers an immediate status change, allowing quick visual diagnostics during maintenance or troubleshooting. Q: Does replacing the DS200TCPDG2BEC require complete system de-energization? A: Yes. Because the DS200TCPDG2BEC distributes core 125 VDC control power to primary processing and I/O modules, power must be completely isolated from the distribution rack prior to removing or installing the board to avoid arc flash risks and control processor reset. Field Installation Guidelines Rack Clearance & Mounting: Ensure the VME rack slot is cleared of debris before insertion. Align the card edge connectors precisely with the rack backplane guide rails, applying steady, firm pressure to seat the multi-pin DIN connectors without bending pins. Wiring & Cable Connections: Verify that all high-current DC output lines are properly terminated with correct ring terminals or secure screw clamps. Route input and output cables separately from low-voltage signal wires to prevent inductive noise coupling. Grounding Requirements: Securely bond the board ground connection to the cabinet central chassis ground point. Ensure low-resistance metal-to-metal contact to maintain full noise suppression and surge protection functionality. Fusing & Overcurrent Protection: Inspect all onboard fuses prior to powering up the system. Ensure replacement fuses strictly match the factory current and voltage ratings specified by General Electric for Mark V power distribution circuits.
$200.00 $100.00
-
General Electric GE DS200LDCCH1ANA Drive Control CPU Board
GE DS200LDCCH1ANA Drive Control CPU Board Configured for executing motor control algorithms and SCR firing angle calculations in GE Mark IV LCI systems, the GE DS200LDCCH1ANA (DS200LDCC Drive Control CPU Board) provides direct physical/electrical execution. This module coordinates drive control functions and executes real-time fault detection logic without relying on external supervisor units. Hardware Specifications Parameter Specification Model DS200LDCCH1ANA Brand GE Origin USA Weight 1.20 kg Operating Temp 0 to 50 deg C Power Consumption 15 W at 24 VDC Input Voltage 24 VDC nominal (18-32 VDC range) Processor Dedicated drive control CPU Bus Architecture MARK IV / QDII bus protocol Onboard Memory NVRAM with battery backup Battery Type 3.6 V lithium thionyl chloride Diagnostics Power, Run, Fault, Communication LEDs Brand-Specific Technical Features The DS200LDCCH1ANA interfaces directly through the proprietary QDII backplane bus communication structure to manage high-speed motor control data exchanges. Firmware flash compatibility and onboard NVRAM maintain deterministic execution loops for SCR firing angles, eliminating communication delays across the backplane bus interface. Frequently Asked Questions Q: What is the purpose of the onboard 3.6 V lithium battery? A: The onboard battery provides backup power to the NVRAM, ensuring that calibrated drive parameters and diagnostic fault logs remain intact during system power shutdowns. Q: Can the DS200LDCCH1ANA be hot-swapped while the LCI system is operational? A: No. Power to the rack must be completely isolated before removing or inserting the board to prevent backplane bus disturbance and potential damage to onboard semiconductors. Field Installation Guidelines Power down the drive cabinet and verify zero-voltage state on the 24 VDC supply before board handling. Wear a grounded wrist strap connected to the enclosure frame to prevent electrostatic discharge damage. Align the board edges with the Mark IV card guide slots and slide in until the rear edge connectors seat into the QDII bus backplane. Tighten the retaining screws on the front panel to ensure solid chassis grounding and mechanical stability.
$200.00 $100.00
-
General Electric GE DS200SIOBG1AAA Mark V Speedtronic Serial I/O Board
GE DS200SIOBG1AAA Mark V Speedtronic Serial I/O Board The GE DS200SIOBG1AAA, also cataloged as the DS200SIOBH1A Serial I/O Terminal Board, operates as a dedicated hardware component for serial communication interface and discrete/analog signal processing within Mark V Speedtronic turbine control system platforms. Hardware Specifications Parameter Specification Model DS200SIOBG1AAA / SIOBH1A Brand GE Origin USA Weight 1.2 kg Dimensions 250 mm x 180 mm x 30 mm Operating Temp -30 deg C to +65 deg C Power Consumption +5 VDC (logic circuitry), +24 VDC (field I/O loops) Form Factor Standard Eurocard 6U Serial Interface 1 x RS-232 (DB9), 2 x RS-485 (multi-drop) Discrete Inputs 16 channels, +24 VDC sink/source Discrete Outputs 8 channels, +24 VDC, 0.5 A maximum per channel Analog Inputs 4 channels (4-20 mA or 0-10 VDC configurable) Analog Outputs 2 channels (4-20 mA) Galvanic Isolation 1500 VAC to 2500 VAC (field-to-logic execution) Communication Speed 300 bps to 115.2 kbps (auto-baud detection) Diagnostics Status LEDs (Power, Run, Fault, I/O activity) Backplane Bus Communication Velocity Licences & Network Execution The GE DS200SIOBG1AAA uses optimized backplane bus communication velocity protocols to ensure real-time status exchange with the primary Mark V controller cores (R, S, and T). Serial interfaces process high-speed Modbus RTU telemetry alongside direct hardware discrete/analog mapping. Deterministic backplane cycle timing prevents packet dropping across the serial bridges, while internal bus buffers isolate logic-side processing from external field wiring switching transients. Firmware compatibility checks execute automatically upon backplane initialization to ensure system-wide parity across redundant communication branches. Frequently Asked Questions Q: Can the DS200SIOBG1AAA terminal board be replaced while the Mark V turbine controller is online? A: Hot-swapping of the board is strictly prohibited while backplane logic power is applied. Power to the rack slot (+5 VDC logic supply) and auxiliary +24 VDC field supplies must be isolated prior to removing or inserting the module to avoid damage to backplane bus driver ICs. Q: How is galvanic isolation structured across the discrete and analog I/O circuits? A: The board maintains optocoupler and magnetic isolation barriers rated between 1500 VAC and 2500 VAC between field terminal channels and central logic circuitry, preventing high-voltage ground loops or noise spikes from propagating to the primary controller cores. Field Installation Guidelines Verify that all power sources supplying the rack backplane and I/O field terminal blocks (+5 VDC and +24 VDC lines) are de-energized before board insertion. Ensure proper static discharge prevention protocols are followed; wear a grounded wrist strap attached to the system enclosure frame during handling. Align the 6U Eurocard edge connectors strictly with the rack card guides to avoid pin deflection on the backplane interface. Terminate RS-485 shielding at one single point (earth ground bus) to eliminate ground loop currents across long multi-drop cable spans. Secure all panel locking screws to guarantee frame grounding continuity and physical retention under turbine vibration stress.
$200.00 $100.00
-
General Electric GE DS200TBCBG1AAA Mark V Speedtronic Termination Analog Board
GE DS200TBCBG1AAA Mark V Speedtronic Termination Analog Board The GE DS200TBCBG1AAA, also cataloged as the DS200TBCBG1A 4-20 mA RTD Input Termination Module, operates as a dedicated hardware component for analog and temperature signal termination within GE Mark V Speedtronic Turbine Control System platforms. Suffix Breakdown & Model Matrix DS200: Standard GE Speedtronic Mark V base board designator (factory board level assembly). TBCB: Functional board type identifier representing the Analog Terminal Board assembly. G1: Group revision designator specifying the baseline functional architecture and circuit board revision. AAA: Functional revision codes indicating three sequential A-rated manufacturing/engineering modifications. Hardware Specifications Parameter Specification Model DS200TBCBG1AAA Brand GE (General Electric) Origin USA Weight 0.5 kg Dimensions 300 x 150 x 50 mm Operating Temp 0 to 60 deg C Power Consumption +5 VDC, 6.0 A nominal backplane current draw Input Channels (4-20 mA) 14 dedicated channels + 8 jumper-selectable (4-20 mA or 1 mA) channels Sensor Compatibility PT100 and PT1000 RTD sensors Excitation Voltage Isolated 21 VDC loop supply inputs Signal Output Interfaces JHH connector (milliamp to TCCB), JII connector (RTD to TCCB) Industrial Control & Backplane Performance Features The DS200TBCBG1AAA provides signal condition processing and direct backplane bus communication velocity compatibility required by Mark V Speedtronic controllers. The terminal card processes raw field sensor feedback, isolating input channels via passive RC networks and inline diodes to protect the TCCB core processor interface. High I/O density scaling allows 22 analog channels (including RTD temperature loops) to multiplex into dedicated multi-pin ribbon cables (JHH and JII connectors), preventing cross-channel noise propagation and signal degradation across the internal control rack backplane. Frequently Asked Questions Q: What are the primary signal cable connections on the DS200TBCBG1AAA board? A: The board utilizes multi-pin ribbon cable interfaces: the JHH connector routes processed 4-20 mA milliamp input signals directly to the TCCB core card, while the JII connector routes dedicated RTD temperature signals to the same core processor. Q: How are the selectable input channels configured for different sensor loops? A: The board contains onboard hardware jumper blocks. Eight specific input channels can be toggled between standard 4-20 mA current signals and 1 mA sensor excitation modes by altering the corresponding jumper positions prior to applying field power. Q: Is field-reconfiguration required when replacing older revision boards? A: The AAA revision is fully backward compatible with earlier G1 baseline revisions. However, hardware jumpers on the replacement module must be manually mapped to replicate the exact jumper configuration of the original board before powering up the system. Field Installation Guidelines De-energize all power sources connected to the Mark V control panel prior to servicing the DS200TBCBG1AAA module to prevent arc flash and damage to sensitive CMOS components. Observe anti-static precautions by wearing a grounded ESD wrist strap connected to the frame earth terminal during board removal and handling. Loosen the mounting screws along the edge of the board and verify correct wire terminal labels before disconnecting field wiring from the terminal blocks. Set hardware jumpers on the replacement DS200TBCBG1AAA board to match the exact input modes (4-20 mA vs. 1 mA) configured on the unit being replaced. Align the board into the mounting slots, secure it with the retainers, and connect the JHH and JII ribbon cables firmly to ensure full electrical contact. Ensure shield grounding wires are terminated at the designated earth ground terminal block with standard thread engagement.
$200.00 $100.00
-
General Electric GE DS200DTBCG1AAA Mark V Termination Module
GE DS200DTBCG1AAA Mark V Termination Module Configured for dry contact relay outputs in GE Mark V Speedtronic systems, the GE DS200DTBCG1AAA (DS200DTBC Contact Output Termination Module) provides direct physical/electrical execution. Hardware Specifications Parameter Specification Model DS200DTBCG1AAA Brand GE Origin USA Weight 0.4 kg Operating Temp 0 to +60 deg C Power Consumption 4 W (0.8 A max at +5 VDC) System Platform Mark V Speedtronic Output Channels 16 isolated dry contact relay outputs Contact Rating 2 A at 30 VDC / 0.5 A at 125 VAC Channel Isolation 1500 VAC channel-to-channel Backplane Supply +5 VDC nominal Connectors 2 x 37-pin D-sub connectors On-board Components 16 relays, 16 flyback diodes, 22 uF filter capacitor Visual Diagnostics 16 LED output status indicators Deterministic Relay Execution & Backplane Velocity The board utilizes high-speed backplane bus communication velocity to process incoming control commands from the primary Speedtronic processor card. The onboard logic decodes these backplane instructions into immediate coil excitation across 16 independent relays. Integrated flyback diodes parallel to each relay coil suppress transient inductive voltage spikes during de-energization, maintaining signal integrity across adjacent control lines. Solid-state decoupling via a 22 uF filter capacitor stabilizes the incoming +5 VDC rail during simultaneous multi-channel switching. Frequently Asked Questions Q: Does replacing the DS200DTBCG1AAA require a system power reboot? A: Yes. The module interfaces directly with the Mark V edge connector and VME backplane. Removing or inserting the card while the backplane is energized at +5 VDC can cause bus disruption, command failure, or electrical stress on the edge connectors. Q: What is the primary function of the 16 onboard flyback diodes? A: They function as inductive flyback voltage clamp circuits across each relay coil. When an output channel turns off, inductive energy stored in the solenoid or coil discharges harmlessly through the diode, protecting the upstream control logic and minimizing backplane EMI noise. Q: Can the contact outputs drive higher inductive loads directly without external suppression? A: The maximum rating is strictly 2 A at 30 VDC or 0.5 A at 125 VAC per channel. High-inductance field loads exceeding these thresholds or operating above the voltage limits require external interposing relays or secondary arc suppression across the field terminals. Field Installation Guidelines Power Isolation: Ensure power to the Mark V control rack is completely isolated before servicing or replacing the termination module. Electrostatic Discharge (ESD) Protection: Wear a grounded wrist strap attached to the chassis ground before handling the card to prevent damage to sensitive backplane interface components. Card Slot Alignment: Carefully slide the module into the designated single-slot guide within the Mark V rack. Align the card edge connector with the VME backplane socket and apply firm, even pressure until fully seated. Field Terminal Wiring: Secure external relay field wiring through the 37-pin D-sub cable assemblies. Ensure connector retaining screws are tightened securely to maintain mechanical connection under vibration. Shielding & Grounding: Maintain proper cable shielding across field wiring runs. Ground cable shields at one single point within the enclosure to avoid ground loops that could interfere with low-voltage logic operations.
$200.00 $100.00
-
General Electric GE DS200LDCCH1AJA Drive Control CPU Board
GE DS200LDCCH1AJA Drive Control CPU Board Configured for executing LCI drive control algorithms and motor starting logic in GE Mark IV LCI systems, the GE DS200LDCCH1AJA (DS200LDCCH1A) Drive Control CPU Board provides direct physical execution of SCR firing angle calculations and system coordination. Hardware Specifications Parameter Specification Model DS200LDCCH1AJA Brand GE Origin USA Weight 0.85 kg Dimensions 243.8 x 172.7 x 38.1 mm Operating Temp 0 to 50 deg C Power Consumption 24 VDC bus input Microcontroller 32-bit, 50 MHz clock speed Program Memory 1 MB Flash Data Memory 512 KB SRAM Bus Architecture MARK IV/QDII bus Digital I/O 16 Inputs (24 VDC), 16 Outputs (24 VDC, 0.5 A) Analog I/O 8 Inputs (4-20 mA), 4 Outputs (0-10 V) Communication Interfaces QDII bus, CANbus, RS-485 Deterministic Control & Backplane Bus Execution The board leverages high-speed backplane bus communication velocity to execute real-time SCR firing angle calculations based on motor speed feedback and torque demand limits. Operating across deterministically managed QDII bus and CANbus networks, it achieves synchronized execution across peripheral signal distribution and acquisition cards. The 32-bit microcontroller maintains rigid cyclic control execution without bus arbitration latency, ensuring phase angle alignment and system stability during high-torque turbine starting cycles. Frequently Asked Questions Q: What precautions should be observed regarding on-board capacitor energy storage during maintenance? A: On-board filtering and backup capacitors (220 uF and 100 uF) retain residual electrical energy after main power disengagement. Allow a minimum discharge dwell time before removing the board from the bus frame or handling exposed solder traces. Q: How are parameter retainage settings preserved across control power cycles? A: Static setup parameters and operational logs reside within battery-backed SRAM. Ensure the local battery retention circuit maintains nominal voltage prior to prolonged power interruptions to prevent non-volatile parameter corruption. Field Installation Guidelines Electrostatic Discharge (ESD) Protection: Always wear a grounded wrist strap attached to unpainted cabinet metal before touching card edges or setting jumpers on the CPU board. Bus Edge Alignment: Align the card edges precisely with the MARK IV chassis card guides. Apply uniform pressure to fully seat edge connectors into the backplane, ensuring zero mechanical binding. Cable Strain Relief: Ensure RS-485 and CANbus shield wires are tied directly to local frame ground points. Route low-voltage signal lines away from high-power SCR gate drive wiring to prevent inductive cross-coupling.
$200.00 $100.00
-
General Electric GE DS200LDCCH1AHA Drive Control Card
GE DS200LDCCH1AHA Drive Control Card The GE DS200LDCCH1AHA, also cataloged as the DS200LDCC Drive Control Card, operates as a dedicated hardware component for turbine logic execution and I/O coordination within GE Mark V Speedtronic systems. Hardware Specifications Parameter Specification Model DS200LDCCH1AHA Brand GE Origin USA Weight 0.95 kg Dimensions 160 mm x 233 mm Operating Temp 0 to 60 deg C Power Consumption +5 VDC, +15 VDC, +24 VDC (via rack backplane) Processor 16-bit DSP microprocessor Memory EPROM firmware storage, RAM for logic execution Analog I/O Multiple isolated channels for turbine sensors Digital I/O Optically isolated inputs and relay outputs Communication ARCNET, DLAN, RS-232 diagnostic port Isolation Optical isolation between field and logic signals Form Factor 6U VME board Certifications UL, CSA component level Backplane Bus Communication & Logic Execution The board leverages high-speed backplane bus communication velocity to execute deterministic control loops for gas and steam turbine sequencing. Its internal processing architecture routes real-time data across ARCNET and DLAN interfaces with minimal latency, supporting parallel I/O density scaling throughout the Mark V rack. Onboard EPROM chips manage firmware flash compatibility, preventing revision mismatches during hardware replacement cycles and ensuring consistent timing during critical turbine speed and load transitions. Frequently Asked Questions Q: What power rails must be active on the backplane for proper board initialization? A: The board requires operational +5 VDC, +15 VDC, and +24 VDC rails delivered directly from the Mark V rack backplane bus before logic processing and optical isolation circuits function. Q: Can the board be inserted or removed while the rack backplane is energized? A: No, live insertion or hot-swapping is prohibited. De-energize the rack power supply and await full capacitor discharge prior to inserting or removing the card from the 6U VME chassis. Q: How is diagnostic communication handled during field commissioning? A: An onboard RS-232 port provides local serial diagnostic terminal access, allowing technicians to review hardware status and controller firmware revisions directly without disrupting ARCNET or DLAN bus operations. Field Installation Guidelines Ensure power to the Mark V chassis is fully isolated before handling the board. Observe strict ESD safety protocols by wearing a grounded wrist strap attached to the panel frame. Align the 6U VME board card edges with the chassis guide rails, pressing firmly until the backplane connectors seat completely. Tighten all faceplate retaining screws to maintain chassis grounding integrity and prevent mechanical vibration from unseating the board. Verify all field wiring shields are grounded at a single point to prevent signal noise on analog and digital interface channels.
$200.00 $100.00
-
General Electric GE DS200TCCBG3ANE Mark V/VI Thermocouple/Analog Input Board
GE DS200TCCBG3ANE Mark V/VI Thermocouple/Analog Input Board Configured for precise temperature and sensor signal acquisition in GE Mark V/Mark VI turbine control networks, the GE DS200TCCBG3ANE (DS200TCCB Thermocouple/Analog Input Board) provides direct physical/electrical execution. It directly samples millivolt-level thermocouple outputs, applies per-channel cold junction compensation, and converts field signals to 16-bit digital values across isolated backplane interfaces to ensure stable turbine operation. Hardware Specifications Parameter Specification Model DS200TCCBG3ANE Brand GE Origin USA Weight 0.48 kg Dimensions 170 x 145 x 65 mm Operating Temp -10 to +55 deg C Power Supply 24/48 VDC via backplane Channels 8 isolated thermocouple inputs Input Range +/-100 mV Thermocouple Types J, K, T, E, N, R, S, B (per-channel configurable) Resolution 16-bit Accuracy +/-0.2 deg C (including CJC and linearization) Temperature Drift +/-5 ppm/deg C CJC Method Per-channel precision sensors (+/-0.05 deg C) Isolation 1800 Vrms channel-to-backplane Common Mode Rejection 115 dB (filtered) Digital Filtering Programmable (50 Hz, 60 Hz, 250 Hz, 500 Hz cutoff) Input Impedance >10 M ohm Update Rate 40 ms (all channels synchronized) Mounting VME rack / Mark VI backplane Backplane Bus Communication and Signal Isolation The DS200TCCBG3ANE interfaces directly with the Mark V/VI control core via high-speed backplane bus communication, delivering deterministic sensor telemetry without network latency overhead. To prevent ground loops caused by high-voltage plant potential differences, the card incorporates 1800 Vrms channel-to-backplane galvanic isolation. Channel-density scaling is optimized for dense turbine exhaust configurations, maintaining high signal-to-noise ratios even in extreme electromagnetic environments. Integrated cold junction compensation (CJC) processing hardware converts raw sensor millivolts locally, reducing host processor firmware overhead during real-time turbine trip evaluation cycles. Frequently Asked Questions Q: Can the DS200TCCBG3ANE be hot-swapped during active turbine operation? A: No, hot-swapping the board while the backplane bus is energized is not permitted. Power off the VME rack or designated panel segment before insertion or removal to prevent backplane bus disturbance or damage to sensitive analog conversion components. Q: How does channel-to-backplane galvanic isolation impact sensor wiring safety? A: The 1800 Vrms galvanic isolation barrier prevents high transient voltages on sensor field leads from penetrating the control system backplane, protecting core CPU modules and preventing ground loop currents from degrading 16-bit ADC measurement precision. Q: What grounding method is required for thermocouple signal shielding? A: Thermocouple extension cables must have their individual and overall shields grounded at a single point on the designated system ground bar inside the cabinet. Never ground the shield at both the sensor head and the control cabinet, as ground potential differentials introduce measurement errors. Field Installation Guidelines Ensure the VME rack slot or Mark VI backplane position is fully de-energized prior to seating the module. Verify card edge connectors for bent pins or debris before sliding the board into the card cage guide rails. Tighten the top and bottom retaining screws on the front panel to ensure solid frame grounding and prevent board dislodgement from vibration. Route thermocouple field wiring in separate conduits away from high-voltage AC motor drives and heavy inductive loads to prevent electromagnetic coupling. Terminate shield conductors to the dedicated panel earth bar using short, direct ground leads. Maintain a minimum thread engagement of 5 full turns on NPT ground lugs.
$200.00 $100.00
-
General Electric GE DS200SDCCG1AEC Mark V Speedtronic Drive Control Board
GE DS200SDCCG1AEC Mark V Speedtronic Drive Control Board Configured for high-speed algorithm processing and real-time turbine coordination in Speedtronic control racks, the GE DS200SDCCG1AEC (DS200SDCC Drive Control Board) provides direct physical/electrical execution. The board integrates three 16-bit digital signal processors (DSPs) to administer motor control timing, firing angle calculation for power electronic bridges, and local sub-system diagnostics. It interacts directly with power interface boards and field sensors through specialized signal distribution hardware over dedicated backplane pathways. Hardware Specifications Parameter Specification Model DS200SDCCG1AEC Brand GE Origin United States Weight 0.96 kg Dimensions 160 mm x 233 mm x 20 mm Operating Temp 0 deg C to 60 deg C Power Consumption +5 VDC at 6.0 A, +15 VDC at 0.5 A, +24 VDC at 0.2 A Processing Architecture 3 x 16-bit DSPs (Master, Communications, I/O) Onboard Memory 128 kB Dual-Port RAM, 256 kB EPROM Firmware Analog Outputs 12-bit isolated, -10 VDC to +10 VDC, 5 mA maximum load Servo Channels 2 channels, jumper-selectable 10 mA to 120 mA coil current LVDT Sensor Interface 6 differential inputs, 3-wire or 4-wire selectable Digital Field I/O 64 opto-isolated inputs, 32 relay outputs Bus Communication Interface DLAN, ARCNET, RS-232 TIMN port, Genius Bus support Electrical Isolation 1500 VDC field-to-logic, 2.5 kV optical isolation Backplane Bus Communication Velocity & Firmware Flash Compatibility The DS200SDCC board relies on high-speed deterministic bus communication interfaces to exchange state variables across the drive rack backplane without CPU blocking. Dual-port RAM (DPRAM) buffers data between the internal DSP cores and external fieldbus protocols, eliminating data bus contention. Firmware execution depends on strict flash/EPROM chip set alignment across all three processors. Mismatched firmware versions among the processing nodes cause state desynchronization, triggering fault codes and safe shutdown sequences during boot initialization. Frequently Asked Questions Q: How are the onboard servo channel output currents configured for different valve actuators? A: Coil currents on the 2 servo control channels are established via physical hardware jumper blocks on the printed circuit board. Jumpers must be configured in deactivated-power states to match the target 10 mA to 120 mA rating before connecting actuator leads. Q: Does the board support live hot-swapping inside a powered VME rack? A: No. Replacing the board while the backplane is energized risks voltage transients, corrupted EPROM states, and potential power supply shorts. Always disconnect main power and lock out the supply before extraction. Q: What step is required when transferring configurable settings to a replacement DS200SDCC board? A: Configuration parameters and site-specific operational data are stored in removable EPROM or EEPROM chips. These memory chips must be transferred carefully from the existing board to the new board using anti-static handling tools prior to installation. Field Installation Guidelines ESD Protection Protocols: Wear a grounded wrist strap connected to an unpainted metal chassis ground point before touching the card. Hold the circuit board strictly by its front faceplate or plastic card edges to prevent static discharge into exposed DSP leads. Chassis & Mechanical Mounting: Ensure the target 6U VME rack slot is free of debris. Align the board edges with the card guides and push firmly until the board seats fully into the backplane connectors. Secure the top and bottom retaining screws to achieve solid chassis grounding. Cable Strain Relief & Routing: Route incoming ARCNET, DLAN, and analog sensor field cables away from high-voltage AC lines and switching power leads. Fasten all ribbon and communication cables with mechanical strain relief ties to minimize physical stress on board header pins. Shield Grounding Practices: Field signal cable shields (LVDT, servo feedback, analog outputs) must be grounded at a single point—typically at the designated ground bar in the enclosure—to prevent ground loops and high-frequency noise interference on measurement circuits.
$200.00 $100.00
-
General Electric GE DS200GDPAG1ALF Mark V Turbine Control Series
GE DS200GDPAG1ALF Mark V Turbine Control Series Configured for high-frequency isolation and power distribution in GE Mark V turbine control systems, the GE DS200GDPAG1ALF (DS200GDPA Power Supply Board) provides direct physical/electrical execution. The module converts an incoming nominal 125 VDC bus into six independent floating 24 VDC output channels, establishing power delivery for high-side gate driver circuits operating power semiconductors such as IGBTs and MOSFETs. Hardware Specifications Parameter Specification Model DS200GDPAG1ALF Brand GE Origin USA Weight 0.59 kg Operating Temp -30 deg C to +65 deg C Power Consumption ~69 W at full load Input Voltage Range 100 VDC to 140 VDC (125 VDC nominal) Switching Frequency 80 kHz fixed with slope compensation Output Channels 6 isolated, non-regulated 24 VDC outputs Output Current 0.6 A per channel (2.5 A total combined maximum) Isolation Voltage 2500 V RMS (primary to secondary) Efficiency ~87% at 80% rated load Hold-up Time 25 ms at full load Primary Topology Single-ended forward converter with reset winding Onboard Capacitance 4 x 470 uF 200 V bulk capacitors, 14 ceramic decoupling capacitors Physical Interface 40-pin backplane connector, 8-pin output header Power Electronics Isolation & Firmware Flash Compatibility The board implements a single-ended forward converter topology driven at a fixed 80 kHz switching frequency to manage high-voltage isolation boundaries. Onboard magnetic amplifier regulation maintains cross-regulation tolerances within +/-10% across unbalanced channel loads. Integrated soft-start circuits restrict initial inrush currents to protect primary DC bus lines. Board backplane logic routes through a 40-pin header, interfacing directly with Mark V card guides to preserve signal integrity and eliminate backplane bus communication velocity degradation across adjacent control hardware. Frequently Asked Questions Q: What precautions should be taken regarding hot-swapping the DS200GDPAG1ALF during system operation? A: Hot-swapping this board while the primary 125 VDC bus is energised is strictly prohibited. Disconnecting or seating the 40-pin backplane connector under load induces arc flash risk and can damage primary power semiconductors due to uncontrolled voltage transients across the 24 VDC outputs. Q: How does the power supply handle brief input voltage drops on the 125 VDC bus? A: The board incorporates four 470 uF, 200 V bulk capacitors that store energy to maintain a 25 ms hold-up time at full load, preserving stable 24 VDC output voltages during momentary voltage dropouts. Q: What is the dielectric breakdown limit between the primary input logic and the secondary output header? A: The transformer and physical layout provide galvanic isolation rated to 2500 V RMS continuously between primary power circuits and secondary output lines. Field Installation Guidelines ESD Protection: Wear a grounded wrist strap connected to cabinet earth ground before removing the board from its conductive protective bag. Power De-energization: Ensure the main 125 VDC feeder circuit breaker is locked out and verified at 0 VDC with a calibrated meter prior to installation or maintenance. Mechanical Insertion: Align the board edges strictly with the card guide rails inside the Mark V rack enclosure. Slide the unit inward smoothly until the 40-pin connector mates securely with the backplane header. Wiring Integrity: Secure the secondary output connections using the 8-pin header. Ensure signal wires are routed away from high-voltage AC lines to minimize electromagnetic interference. Maintain a minimum bending radius for wire bundles to avoid mechanical stress on the header pins.
$200.00 $100.00
-
General Electric GE DS215UCVBG1AJ UC2000V Genius Controller Module
GE DS215UCVBG1AJ UC2000V Genius Controller Module The GE DS215UCVBG1AJ, also cataloged as the DS215UCVB UC2000V Genius Controller Module, operates as a dedicated hardware component for communication management, network diagnostics, and data exchange within GE Mark V Speedtronic turbine control systems. Hardware Specifications Parameter Specification Model DS215UCVBG1AJ Brand GE Origin United States Weight 1 kg Operating Temp 0 to +60 deg C Power Consumption Not specified; requires +5 VDC / +12 VDC depending on installation Product Type UC2000V Genius Controller Module System Platform GE Mark V Speedtronic Communication Interface 1 x 10/100 Mbps Ethernet port Network Addressing DLAN node address configurable from 0-255 Configuration 2 DIP switch blocks for setup parameters Indicators Multiple LEDs for communication, status, and diagnostics Data Logging Interface HDD connector for storage attachment Operator Interface Keyboard and monitor support for troubleshooting Form Factor Standard VME rack integration Assembly Type DS215 Special Assembly Functional Acronym UCVB GE Mark V Network Communication and Controller Integration The DS215UCVBG1AJ functions as a communication and diagnostic controller within the GE Mark V Speedtronic architecture. It provides Ethernet connectivity, DLAN node management, and operator interface support while operating separately from direct turbine I/O processing modules. The GE industrial control architecture uses VME-based communication structures and deterministic network interfaces for controller coordination. The module supports firmware flash compatibility within the Mark V platform and maintains network configuration through hardware DIP switch settings. The Ethernet and DLAN functions provide communication paths for SCADA integration, diagnostic data collection, and system monitoring. The configurable node addressing supports distributed network organization and prevents addressing conflicts between connected control devices. Frequently Asked Questions Q: Is the DS215UCVBG1AJ a direct I/O processing module?A: No. The module functions as a communication and diagnostic controller rather than a direct field I/O processor. Q: How is DLAN addressing configured on the DS215UCVBG1AJ?A: DLAN node addressing is configured through onboard DIP switches with an address range from 0-255. Q: What communication interface is provided by this module?A: The module provides one Ethernet port with 10/100 Mbps communication capability. Field Installation Guidelines Install the DS215UCVBG1AJ in the designated GE Mark V VME rack position with system power removed before module insertion or removal. Verify VME connector alignment, power supply connections, DIP switch configuration, and network cable connections before energizing the controller rack. Route Ethernet communication cables separately from high-voltage and high-current wiring to reduce electromagnetic interference. Connect cable shields according to the cabinet grounding design. Confirm DLAN node addressing, Ethernet communication status LEDs, and operator interface connections during commissioning. Ensure HDD connections and data logging functions are configured according to system requirements.
$200.00 $100.00
-
General Electric GE DS2020VME0606CBDDDD8 VME Rack Assembly
GE DS2020VME0606CBDDDD8 VME Rack Assembly The GE DS2020VME0606CBDDDD8, also cataloged as the DS2020VME VME Rack Assembly, operates as a dedicated hardware component for VME board mounting, power distribution, and backplane communication within GE Mark V Speedtronic and EX2000 control systems. Hardware Specifications Parameter Specification Model DS2020VME0606CBDDDD8 Brand GE Origin United States Weight 1 kg Operating Temp 0 to +50 deg C Power Consumption Not specified; distributes +5 V, +/-15 V, and +24 VDC rails Rack Type VME chassis assembly Card Capacity 6 VME card slots Backplane Standard VME bus with GE custom wiring Power Distribution Integrated DC distribution for installed VME boards Cooling Forced-air fan assembly with redundancy Connectors DIN 41612 style VME connectors Storage Temp -20 to +70 deg C Humidity 5-95% RH, non-condensing Compliance IEC 60297 rack standard, UL/CE certified Diagnostics LED indicators for power rails and fan status GE VME Backplane Communication and Industrial Control Integration The DS2020VME0606CBDDDD8 provides the mechanical and electrical infrastructure for GE Mark V and EX2000 VME-based control architectures. The chassis supports processor cards, I/O modules, and protection boards through a six-slot VME backplane configuration. The GE industrial control architecture uses VME bus communication for deterministic board-to-board data exchange. The rack assembly provides backplane connectivity, regulated DC distribution, and card positioning for I/O density scaling across compatible Mark V control configurations. The VME rack design supports firmware flash compatibility of installed control modules by maintaining standard board interfaces and power rail distribution. The integrated fan assembly provides forced-air cooling for installed electronics during continuous control operation. Frequently Asked Questions Q: How many VME boards can the DS2020VME0606CBDDDD8 accommodate?A: The rack assembly provides 6 VME card slots for compatible GE Mark V and EX2000 control boards. Q: What power rails are distributed by this rack assembly?A: The chassis distributes +5 V, +/-15 V, and +24 VDC power rails to installed VME modules. Q: Does the DS2020VME0606CBDDDD8 include backplane communication capability?A: Yes. The assembly includes a VME backplane with GE-specific wiring for communication between installed control cards. Field Installation Guidelines Install the DS2020VME0606CBDDDD8 in the designated GE control cabinet rack location with system power isolated before mechanical installation or board insertion. Verify rack mounting hardware, backplane connector alignment, power distribution connections, and fan wiring before energizing the chassis. Maintain clearance around ventilation paths and avoid blocking forced-air cooling channels. Route power cables separately from low-level signal wiring to reduce electromagnetic interference. Connect cabinet grounding conductors according to the equipment grounding design. Confirm power rail status indicators and fan diagnostics before installing operational control modules.
$200.00 $100.00
-
General Electric GE DS200SDCCG4AGD Drive Control Card
GE DS200SDCCG4AGD Drive Control Card The GE DS200SDCCG4AGD, also cataloged as the DS200SDCC Drive Control Card, operates as a dedicated hardware component for LVDT valve position feedback processing and servo loop execution within GE Mark V Speedtronic turbine control systems. Hardware Specifications Parameter Specification Model DS200SDCCG4AGD Brand GE Origin United States Weight 0.68 kg Operating Temp -25 to +60 deg C Power Consumption Not specified; powered through Mark V control rack interface Product Type Drive Control Card System Platform GE Mark V Speedtronic Servo Channels 8 independent LVDT servo loops Control Algorithm Digital PID with feedforward Servo Outputs +/-10 VDC, 10 mA max per channel Resolution 16-bit, 0.3 mV LVDT Inputs 3-wire or 5-wire per channel LVDT Excitation 2.5 kHz, 2.5 Vrms nominal, adjustable 1-5 Vrms Sensitivity Range 1-25 mV/V/mm Linearity Error <0.1% full scale after calibration Secondary Feedback 4-20 mA per channel Update Rate 1 ms simultaneous update across all channels Discrete Inputs 16 inputs, 24 VDC Processor Architecture 3 CPUs with shared RAM Connectors Dual headers for power supply and I/O interface PCB Coating Normal conformal coating GE Mark V LVDT Servo Control and Industrial Drive Integration The DS200SDCCG4AGD integrates eight independent LVDT servo channels with onboard excitation and demodulation circuits. Each channel processes valve position feedback directly from LVDT devices and executes digital PID control calculations for turbine valve positioning. The GE industrial control architecture uses deterministic control execution, backplane communication, and I/O density scaling for multi-channel servo applications. The three-CPU structure provides separated processing resources for control algorithms, feedback acquisition, and system coordination. The board supports firmware flash compatibility within the Mark V platform and maintains direct interface capability with valve servo circuits through analog outputs, secondary 4-20 mA feedback channels, and discrete status inputs. Frequently Asked Questions Q: How many LVDT servo channels are available on the DS200SDCCG4AGD?A: The board provides 8 independent LVDT servo channels, each with integrated excitation and demodulation functions. Q: What type of feedback signals can the card process?A: The card accepts 3-wire or 5-wire LVDT feedback signals and supports secondary 4-20 mA feedback channels. Q: What control method is used for valve positioning?A: The board executes digital PID control with feedforward processing for servo loop regulation. Field Installation Guidelines Install the DS200SDCCG4AGD in the specified GE Mark V rack location with system power removed before board replacement or inspection. Verify rack connector engagement, I/O header connections, and mechanical mounting before applying control power. Route LVDT signal wiring separately from high-current conductors and switching circuits to minimize electromagnetic interference. Connect cable shields according to the cabinet grounding design. Confirm LVDT wiring configuration, excitation settings, feedback scaling, and servo calibration parameters before returning the turbine control system to operation.
$200.00 $100.00
-
General Electric GE DS200SDCCG1AHD Drive Control Card
GE DS200SDCCG1AHD Drive Control Card The GE DS200SDCCG1AHD, also cataloged as the DS200SDCC Drive Control Card, operates as a dedicated hardware component for turbine and drive regulation, feedback processing, and high-speed control execution within GE Mark V Speedtronic and EX2000 systems. Hardware Specifications Parameter Specification Model DS200SDCCG1AHD Brand GE Origin United States Weight 0.50 kg Dimensions 25.4 cm x 17.8 cm x 3.8 cm Operating Temp 0 to +50 deg C Power Consumption Not specified; powered from 5 VDC and 24 VDC backplane supplies Product Type Drive Control Card System Platform GE Mark V Speedtronic / EX2000 Processor Architecture Triple 16-bit microprocessors with shared dual-port RAM Control Loops 4 control loops: speed, torque, flux, current Feedback Inputs Encoder and resolver compatible Analog I/O 4 analog inputs (4-20 mA, 0-10 V), 2 analog outputs Digital I/O 8 inputs and 4 outputs, 24 VDC Cycle Time 250 us typical Field-to-Logic Isolation 1500 V Connectors 5 front-panel headers J1-J5, 64-pin DIN backplane connector Status Indicators POWER, RUN, FAULT, COM LEDs Storage Temp -20 to +70 deg C Humidity 20-95% RH, non-condensing Energy Storage 330 uF filtering capacitance GE Mark V Drive Control Processing and Communication Features The DS200SDCCG1AHD integrates triple processor architecture for coordinated drive control execution, feedback calculation, and I/O handling. Shared dual-port RAM enables processor-to-processor data exchange within the control card architecture. The board supports GE industrial control characteristics including backplane bus communication, deterministic control timing, and I/O density scaling for turbine and drive applications. Encoder and resolver feedback channels provide position and speed measurement data for closed-loop regulation. The card supports firmware flash compatibility within the Mark V control platform, allowing hardware revision management across compatible control configurations. Its analog and digital interfaces provide direct connection between field signals and the controller processing environment. Frequently Asked Questions Q: What processor architecture is used in the DS200SDCCG1AHD?A: The board uses three 16-bit microprocessors with shared dual-port RAM for control processing, I/O management, and calculation functions. Q: What feedback devices can be connected to the DS200SDCCG1AHD?A: The card supports encoder and resolver feedback inputs for speed, position, and drive regulation functions. Q: How is the board connected to the Mark V system?A: The DS200SDCCG1AHD connects through a 64-pin DIN backplane interface and front-panel headers J1-J5 for external signals. Field Installation Guidelines Install the DS200SDCCG1AHD in the designated GE Mark V rack position with system power removed before board replacement or inspection. Verify backplane connector alignment, front-panel header connections, and board seating before applying control power. Maintain separation between feedback signal wiring and high-current drive conductors to reduce electromagnetic interference. Connect cable shields according to the cabinet grounding design. Confirm analog input scaling, digital I/O assignments, and controller configuration parameters before returning the drive system to operation.
$200.00 $100.00
-
General Electric GE DS200RTBAG2AHC Relay Terminal Board
GE DS200RTBAG2AHC Relay Terminal Board The GE DS200RTBAG2AHC, also cataloged as the DS200RTBA Relay Terminal Board, operates as a dedicated hardware component for relay signal isolation and field device switching within GE Mark V Speedtronic turbine control systems. Hardware Specifications Parameter Specification Model DS200RTBAG2AHC Brand GE Origin United States Weight 0.3 kg Dimensions 23 cm x 15 cm x 1.6 mm Operating Temp 0 to +55 deg C Power Consumption Not specified; 24 VDC relay coil operation Board Type Relay Terminal Board (RTBA) System Platform GE Mark V Speedtronic turbine control system Relay Quantity 10 electromechanical relays Relay Configuration 7 DPDT relays with 2 Form-C contacts, 3 4PDT relays Coil Voltage 24 VDC Relay Contact Rating 5 A at 250 VAC / 30 VDC Response Time Approx. 10 ms typical Mechanical Life 10 million operations Electrical Life 100,000 operations at rated load Protection 130 VAC MOV protection per relay Indicators Individual relay diagnostic lamps Connectors 2 x 20-pin headers and 1 terminal block PCB Construction 4-layer FR-4 PCB with approx. 95 components and 8 ICs Mounting 4 x M4 screw holes with standoffs GE Mark V Relay Interface and Switching Characteristics The DS200RTBAG2AHC provides relay expansion and switching functions between Mark V controller logic circuits and external field devices. The relay channels isolate low-voltage control signals from actuator, solenoid, interlock, and protection circuits. The board follows GE industrial control hardware architecture with relay status indication, configurable jumper settings, and field wiring terminals. Each relay channel includes MOV-based surge suppression to reduce transient effects generated by inductive loads. The relay interface supports deterministic signal execution in Mark V control systems, where relay output states are coordinated through controller I/O processing and turbine protection logic. The board design supports I/O density scaling by adding multiple switched outputs without modifying the primary controller backplane structure. Frequently Asked Questions Q: What relay configurations are available on the DS200RTBAG2AHC?A: The board contains 10 electromechanical relays, including 7 DPDT relays with 2 Form-C contacts and 3 4PDT relays. Q: What voltage is required for relay coil activation?A: The relay coils operate at 24 VDC. Q: How are relay outputs protected from voltage transients?A: Each relay channel includes MOV protection for surge suppression associated with field switching loads. Field Installation Guidelines Install the DS200RTBAG2AHC in the designated GE Mark V cabinet location with control power removed before handling the PCB. Verify relay terminal assignments, connector seating, jumper configuration, and mounting hardware before energizing the system. Separate relay field wiring from sensitive analog signal cables and high-current conductors to reduce electrical interference. Connect cable shields according to the cabinet grounding design. Confirm external device voltage levels match the relay contact and coil specifications before commissioning. Inspect relay indicators during functional testing to verify switching status and field circuit response.
$200.00 $100.00
-
General Electric GE DS200PTBAG1AEC Protection Terminal Board
GE DS200PTBAG1AEC Protection Terminal Board Configured for turbine trip signal routing in GE Mark V Speedtronic systems, the GE DS200PTBAG1AEC (DS200PTBA Protection Terminal Board) provides direct physical/electrical execution of protective input distribution, relay output switching, and shutdown circuit interfacing within turbine control backplane architectures. Hardware Specifications Parameter Specification Model DS200PTBAG1AEC Brand GE Origin United States Weight 0.7 kg Operating Temp 0 to +70 deg C Board Type Protection Terminal Board (PTBA) System Platform GE Mark V Speedtronic turbine control system Inputs Trip signals from TCEA protection modules, overspeed/flame detection circuits, manual trip switches Outputs Relay contacts for turbine trip solenoids Relay Type Form C relay contacts, 24 VDC, 2 A Isolation Optical isolation, 2500 Vrms Connectors Backplane edge connectors and field terminal strips Diagnostics LED indicators for trip, fault, and power status Protection Onboard fuse protection for relay circuits Voting Support 2-out-of-3 voting logic with TMR protection cores GE Mark V Trip Signal and Industrial Control Integration The DS200PTBAG1AEC provides signal interface functions between external protective devices and GE Mark V turbine control logic. The board receives shutdown commands from protection circuits and transfers relay contact outputs to turbine trip actuators. The protection interface uses optical isolation and relay separation to maintain electrical isolation between field wiring and control electronics. The relay circuits support fail-safe de-energize-to-trip operation, where loss of relay energization initiates the configured shutdown path. The GE industrial control architecture uses redundant protection coordination through Mark V TMR structures. The PTBA board supports trip signal processing associated with 2oo3 voting arrangements, allowing multiple protection channels to be evaluated before final shutdown execution. Frequently Asked Questions Q: What type of signals are connected to the DS200PTBAG1AEC?A: The board receives protective trip inputs from devices such as overspeed detection, flame monitoring, and manual emergency trip circuits, then provides relay outputs for shutdown actuators. Q: Does the DS200PTBAG1AEC provide electrical isolation?A: Yes. The board uses optical isolation between field-connected protection signals and internal control circuits, with a specified isolation rating of 2500 Vrms. Q: How is trip redundancy handled in the Mark V system?A: The board supports integration with Mark V TMR protection structures using 2-out-of-3 voting logic for trip signal evaluation. Field Installation Guidelines Install the DS200PTBAG1AEC only in the designated GE Mark V rack position after removing control power from the cabinet. Verify edge connector engagement, terminal strip wiring, fuse condition, and relay circuit connections before system energization. Route trip signal wiring separately from high-current power conductors to reduce electrical interference. Connect cable shields according to the turbine control cabinet grounding design. Maintain separation between field protection wiring, relay output wiring, and switching power circuits. Confirm terminal assignments and protection logic configuration before returning the turbine control system to service.
$200.00 $100.00
-
General Electric DS200DCFBG1BLC GE DC Power Board
GE DS200DCFBG1BLC DC Power and Feedback Board The GE DS200DCFBG1BLC, also cataloged as the DS200DCFBG1BLC DC Power and Feedback Board, operates as a dedicated hardware component for DC power conversion and feedback signal processing within GE Mark V Speedtronic and EX2000 drive control systems. The board provides regulated DC rails, isolated feedback acquisition, and VCO-based signal conversion for turbine and drive control loops. Hardware Specifications Parameter Specification Model DS200DCFBG1BLC Brand GE Origin United States Weight 0.5 kg Operating Temp -30 to +70 deg C Power Consumption Not specified; provides multiple DC output rails Input Voltage 38-115 VAC, 47-63 Hz DC Outputs +5 VDC at 4 A; +15 VDC and -15 VDC at 0.8 A each; +24 VDC at 3 A / 1 A VCO Output 0-500 kHz nominal output range Feedback Inputs Armature and field shunt signals, 50-250 mV Isolation Rating 2.5 kV logic-to-power; 500 V channel-to-chassis Protection Fuse protection for fan and DC voltage rails Diagnostics LED and neon status indicators GE Mark V Power Conversion and Feedback Processing Features The DS200DCFBG1BLC integrates power conversion, signal isolation, and feedback digitization functions on a single Mark V interface board. The VCO circuit converts analog shunt feedback signals into frequency-based digital information for controller processing without requiring external A/D conversion hardware. The board supports GE Speedtronic control architectures with multiple regulated DC voltage rails used by control electronics. Its feedback channels process armature and field shunt measurements while maintaining electrical separation between power circuits and logic circuits. The board uses GE industrial control hardware characteristics including backplane signal coordination, configuration jumpers, and DIP switch settings for voltage scaling and feedback adjustment. Firmware-independent hardware configuration is performed through onboard selectable settings. Frequently Asked Questions Q: What feedback signals can the DS200DCFBG1BLC process?A: The board accepts armature and field shunt feedback signals in the 50-250 mV range and converts these analog inputs through a VCO-based conversion circuit. Q: What DC voltage rails are generated by this board?A: The DS200DCFBG1BLC generates +5 VDC, +/-15 VDC, and +24 VDC supply outputs for connected GE Mark V and EX2000 control hardware. Q: Does the board provide electrical isolation between power and control circuits?A: Yes. The board includes logic-to-power isolation and channel-to-chassis isolation to separate feedback measurement circuits from power conversion sections. Field Installation Guidelines Install the DS200DCFBG1BLC in the designated GE Mark V or EX2000 rack slot with power removed from the control cabinet before board insertion or removal. Verify connector alignment, PCB seating, and mechanical retention hardware before energizing the system. Route feedback signal wiring separately from high-current AC input conductors to reduce electromagnetic interference. Connect cable shields according to the cabinet grounding scheme. Maintain proper separation between analog feedback circuits, DC power wiring, and switching power components. Confirm fuse ratings, jumper positions, and DIP switch configurations before system startup.
$200.00 $100.00
-
General Electric GE DS200TCDAH1BHD Digital I/O Interface Board
GE DS200TCDAH1BHD Digital I/O Interface Board The GE DS200TCDAH1BHD, also cataloged as the DS200TCDA Digital I/O Interface Board, operates as a dedicated hardware component for discrete signal processing and relay interface execution within the GE Mark V Speedtronic control system. It handles dry contact inputs, relay output commands, optical isolation, and IONET backplane communication. Hardware Specifications Parameter Specification Model DS200TCDAH1BHD Brand GE Origin United States Weight 0.6 kg Operating Temp -40 deg C to +70 deg C operating; -55 deg C to +90 deg C storage Power Consumption Supplied through Mark V control rack backplane Product Type Digital I/O Interface Board Functional Acronym TCDA Product Series Mark V Speedtronic Inputs Dry contact signals, 24 VDC nominal, via DTBA/DTBB terminal boards Outputs Relay drive signals routed to TCRA boards Connectors Dual 50-pin IDC connectors (JQ/JR), JO1/JO2 outputs, JX1/JX2 IONET Processor Onboard microcontroller with PROM firmware Isolation Optical isolation, 2500 Vrms test Channel Density Approx. 32 channels, configurable as 16 inputs / 16 outputs Diagnostics 10-LED status array for power, faults, and channel indications Addressing JP1-JP8 jumpers for IONET addressing, termination, and stall timer configuration Accuracy +/-0.10% at 25 deg C, +/-0.15% over full range for HD variant PCB Coating Conformal coating Component Design 105 deg C capacitors and extended-temperature IC components GE Mark V I/O Processing and IONET Communication The DS200TCDAH1BHD provides digital signal acquisition and output interface functions within the Mark V Speedtronic architecture. The board processes field dry contact inputs from DTBA and DTBB terminal boards and generates relay drive signals for TCRA interface boards. IONET communication is executed through the JX1/JX2 connectors, providing deterministic data exchange between the digital I/O board and Mark V controller processors. The onboard microcontroller performs local I/O scanning functions, reducing direct processing demand on the main controller. Profinet / EtherNet/IP Deterministic Networks and Industrial Control Integration The DS200TCDAH1BHD belongs to the GE Mark V industrial control platform and uses dedicated rack-level I/O communication rather than open Ethernet field networks. Its local firmware execution and IONET interface maintain deterministic digital signal timing for turbine interlock processing. The high-density configuration supports I/O density scaling by increasing discrete channel capacity within the same board footprint. PROM-based firmware storage provides fixed execution parameters and supports firmware flash compatibility evaluation within the Mark V hardware revision structure. Frequently Asked Questions (FAQ) Q: What type of field signals can the DS200TCDAH1BHD process?A: The board processes dry contact discrete input signals at 24 VDC nominal levels and provides relay drive outputs through connected TCRA boards. Q: How is electrical separation between field wiring and the control backplane achieved?A: The board uses optical isolation between field signal circuits and the backplane interface, with a 2500 Vrms isolation test rating. Q: Can the DS200TCDAH1BHD be installed as a standard analog input module?A: No. The DS200TCDAH1BHD is a digital I/O interface board designed for discrete signal processing in the Mark V Speedtronic system. Field Installation Guidelines Install the DS200TCDAH1BHD only in the designated GE Mark V Q11, Q51, or Q21 digital I/O core rack position. Verify connector alignment for JQ/JR, JO1/JO2, and JX1/JX2 interfaces before insertion. Maintain separation between low-level digital signal wiring and high-current switching conductors. Use shielded cables where required by the cabinet grounding design and terminate cable shields according to the control panel grounding practice. Before operation, verify IONET addressing jumper settings, termination configuration, power rail connections, and LED diagnostic status. Confirm that all field input circuits and relay output paths match the configured turbine control logic.
$200.00 $100.00
-
General Electric GE DS200TCEAG1BRE Emergency Overspeed & Flame Detection Board
GE DS200TCEAG1BRE Emergency Overspeed & Flame Detection Board The GE DS200TCEAG1BRE, also cataloged as the DS200TCEA Emergency Overspeed & Flame Detection Board, operates as a dedicated protection hardware component for turbine overspeed and flame monitoring within the GE Mark V Speedtronic control system. It processes magnetic pickup and UV/IR detector signals through local safety logic execution and provides fail-safe trip relay outputs. Hardware Specifications Parameter Specification Model DS200TCEAG1BRE Brand GE Origin United States Weight 0.3 kg Operating Temp 0 deg C to +70 deg C, 5-95% non-condensing humidity Power Consumption Supplied from P1 backplane, 5 VDC and 24 VDC rails Processor Intel 80196 16-bit microcontroller Memory PROM sockets for firmware and safety parameters Inputs Magnetic pickup sinusoidal speed signals; UV/IR flame detector pulse inputs Outputs Fail-safe Form C trip relays, 24 VDC, 2 A Isolation 2500 Vrms optical isolation between field inputs and backplane Speed Range Configurable 100 RPM to 20,000 RPM Accuracy +/-0.1% of reading Trip Channels 2 independent overspeed trip channels Response Time <10 ms Diagnostics LED indicators for run, fault, speed, and flame status; built-in self-test Protection On-board fuses FU1-FU3 for overcurrent protection Redundancy Supports TMR 2oo3 voting logic GE Mark V Safety Logic and Protection Execution The DS200TCEAG1BRE operates within the Mark V P1 Protective Core as an independent safety processing board. The Intel 80196 microcontroller executes local overspeed and flame detection logic without depending on the main control processor execution path. The board accepts magnetic pickup sensor signals for shaft speed measurement and UV/IR detector pulse signals for flame monitoring. Dual overspeed channels provide separate trip processing paths with programmable thresholds and hysteresis functions. Hardware Protection and TMR Voting Characteristics The DS200TCEAG1BRE supports Triple Modular Redundancy (TMR) 2oo3 architecture within compatible Mark V protection configurations. The safety logic execution allows voting-based trip decisions while maintaining independent signal processing paths. Fail-safe relay operation is implemented through de-energize-to-trip logic. Loss of board power, control voltage, or internal fault conditions can drive the relay outputs toward the turbine shutdown state. Frequently Asked Questions (FAQ) Q: What input signals are processed by the DS200TCEAG1BRE?A: The board processes magnetic pickup sinusoidal signals for turbine shaft speed detection and UV/IR detector pulse signals for flame monitoring. Q: How is trip output behavior implemented during power loss?A: The board uses fail-safe relay logic where relay de-energization initiates the trip condition during power interruption or fault states. Q: Does the board operate through the main Mark V controller loop?A: No. The board executes protection logic locally through its Intel 80196 processor and maintains an independent safety execution path from the main control processors. Field Installation Guidelines Install the DS200TCEAG1BRE only in the designated GE Mark V P1 protective core rack position. Verify that the backplane connectors are clean and properly seated before insertion. Route magnetic pickup and flame detector wiring separately from high-current switching cables to reduce electrical interference. Use shielded field wiring where required, with cable shields terminated according to the turbine control cabinet grounding practice. Before commissioning, verify field input polarity, relay contact wiring, fuse conditions, and LED diagnostic indications. Confirm that trip circuits remain de-energized during simulated fault conditions and that protective logic responds according to the configured safety parameters.
$200.00 $100.00
You have seen 72 out of 713 products
