Description
Product Overview
The GE IS200EGPAG1BEC Gate Pulse Amplifier belongs to the EX2100 Excitation Control Systems Series, designed for turbine control applications. Its compact 33.1x26.9x4.3cm dimensions and 1.34kg weight simplify installation in industrial environments. Engineers rely on the IS200EGPAG1BEC for generating gate firing pulses, monitoring airflow, and providing conduction feedback, ensuring stable and efficient turbine operations.
Technical Specifications
| Parameter |
Value |
| Model Number |
IS200EGPAG1BEC |
| Module Type |
Gate Pulse Amplifier |
| Manufacturer |
GE |
| Product Range |
Multilin |
| Condition |
Brand New |
| Dimensions |
33.1 × 26.9 × 4.3 cm |
| Weight |
1.34 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System Compatibility |
DCS |
| Communication Service |
Ethernet Router |
| Status |
Active |
Functional Description
The IS200EGPAG1B collects gating commands from the ESEL board to generate firing pulses for six SCRs. It integrates two thermal switches that trigger alarms at 170°F and trip faults at 190°F, protecting the EX2100 drive assembly from overheating.
Newer EX2100 models may replace Klixon switches with RTDs, offering enhanced temperature monitoring. The IS200EGPAG1BEC also supports airflow monitoring and current conduction feedback, ensuring reliable turbine control. Its revision tags highlight continuous improvements in design and performance.
Applications and Compatibility
The GE IS200EGPAG1BEC Gate Pulse Amplifier integrates seamlessly into EX2100 turbine excitation systems. Engineers deploy it in gas, steam, and hydro turbine environments requiring precise gate pulse generation and advanced monitoring.
Its compact footprint and durable construction make the IS200EGPAG1BEC ideal for installations where space efficiency and reliability matter. Compatibility with GE Multilin series infrastructures ensures smooth integration into industrial automation systems.
