Bachmann I/O modules enable seamless interaction between field devices and control systems. With flexible configuration options, these modules support digital and analog signals, helping businesses achieve efficient and scalable automation solutions.
Bachmann I/O Modules
-
Bachmann Bachmann DIO248 Digital Input/Output Module
Overview The Bachmann DIO248 Digital Input/Output Module offers high-density I/O performance in a compact 11x5.3x11.8 cm form factor. Weighing just 0.38 kg, this PLC-compatible module supports 48 channels, with 16 configurable as either inputs or outputs. Engineers rely on the DIO248 for its robust signal handling and flexible automation capabilities. Technical Specifications Specification Details Model Number DIO248 Manufacturer Bachmann Module Type Digital Input/Output System Compatibility PLC Channel Count 48 total (16 configurable) Voltage Range 18–34V DC Protection Reverse polarity Indicators Individual LED per channel Dimensions 11 x 5.3 x 11.8 cm Weight 0.38 kg HS Code 8537101190 Communication Ethernet router Minimum Order 1 unit Product Origin USA Availability In Stock Discontinued Status Active Features & Benefits Configure 16 channels dynamically for input or output control. Use built-in 32-bit counters for frequency measurement and event tracking. Monitor system status instantly with per-channel LED indicators. Connect directly to sensors and valves using galvanic isolation and input filtering. Operate reliably in industrial environments with wide voltage tolerance and durable housing. Save cabinet space with high channel density and no need for extra potential rails.
$200.00 $100.00
-
Bachmann Bachmann AIO288 Analog Input/Output Module
Overview The AIO288 Analog Input/Output Module from Bachmann delivers precise signal processing for industrial automation. Designed for PLC systems, it supports eight analog inputs and eight analog outputs, enabling seamless integration with sensors and actuators. Technical Specifications Specification Detail Model Number AIO288 Manufacturer Bachmann Module Type Analog Input/Output Module Product Range Others System Compatibility PLC Communication Interface Ethernet Router Product Condition Brand New Product Origin USA Dimensions (L×W×H) 5.3 × 5.8 × 11.8 cm Weight 0.22 kg HS Code 8537101190 Minimum Order Quantity 1 Availability In Stock Product Status Active Performance & Features The AIO288 module supports single-ended and differential inputs, handling voltage, current, and resistance signals. It interfaces with up to four Pt100/Pt1000 temperature sensors using 2-wire or 4-wire configurations. Built-in wire break detection enhances reliability for voltage and temperature inputs. The AIO288 also powers up to four potentiometers and includes overload protection to prevent damage from excessive current draw.
$200.00 $100.00
