HIMA racks and mounting accessories enable secure and organized installation of safety controllers and I/O modules. They ensure system stability, accessibility, and efficient maintenance.
HIMA Racks & Mounting
-
Hima Hima B9302 I/O Slot Rack
Product Overview The HIMA B9302 is a modular I/O Slot Rack Assembly Kit designed for the H51q safety system, offering robust integration for industrial automation and process control. This 4-unit-high, 19-inch rack includes essential components for streamlined I/O module installation and power distribution. Key Features Rack Type: FK1406, 4U height, 19" width, integrated cable tray Coupling Module: F7553 installed in slot 17 Flat Cable Options: BV7032, available in 0.5 m (B9302-0,5), 1 m (B9302-1), or custom (B9302-X) I/O Capacity: Slots 1–16 reserved for I/O modules Optional Modules: Up to 4 × F7133 fused power distribution units (slots 18–21) Fault Monitoring: Series-wired fuse monitoring with neutral contact signaling Bypass Logic: Jumper bypass for unused distribution modules Bus Length: Max total bus length of 30 m Technical Specifications Attribute Value Manufacturer HIMA Part Number B9302 System H51q Voltage 24 VDC Current 5 A Dimensions 47.8 cm × 30.5 cm × 17.8 cm Weight 3 kg Ordering Codes B9302-0,5 / B9302-1 / B9302-X
$200.00 $100.00
