Description
Overview
The GE IC200ALG264 Analog Current Input Module is part of the VersaMax I/O family, designed for precise current measurement in industrial automation. Engineers use this compact module to process 15 analog input channels with high-resolution ADCs, ensuring accurate conversion of signals for PLC systems. Its lightweight design and robust construction make it ideal for distributed control environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC200ALG264 |
| Module Type |
Analog Current Input Module |
| Manufacturer |
GE Fanuc |
| Product Range |
VersaMax |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Weight |
0.12 kg |
| Dimensions |
11 x 5.8 x 6.5 cm |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
PLC |
| Status |
Active |
| Communication Service |
Ethernet router |
| Input Channels |
15 |
| Input Ranges |
0–20 mA, 4–20 mA |
| Resolution |
15-bit ADC |
| Accuracy |
±0.3% at 25°C, ±0.5% full scale |
| Update Time |
7.5 ms |
| Isolation Rating |
350 V AC continuous, 1500 V AC for 1 min |
| Backplane Consumption |
100 mA |
| Diagnostics |
Power loss, open wire detection |
| Indicators |
“OK” LED for initialization |
Functional Description
The GE IC200ALG264 supports both 0–20 mA and 4–20 mA input signals, with jumper-based configuration for flexible operation. Each channel includes a 15-bit ADC, providing fine resolution of 0.5 µA per count in 4–20 mA mode and 0.625 µA per count in 0–20 mA mode. Engineers benefit from diagnostic features such as open wire detection and internal power monitoring, which communicate directly to the CPU for real-time system feedback.
The GE IC200ALG264 ensures fast data processing with a 7.5 ms update time, while its isolation rating of 350 V AC continuous enhances safety. The module’s “OK” LED confirms successful initialization, simplifying installation and troubleshooting.
Applications and Compatibility
The GE IC200ALG264 Analog Current Input Module suits industrial automation projects requiring precise current monitoring and reliable diagnostics. It integrates seamlessly with VersaMax PLC systems and supports SCADA or HMI interfaces for real-time monitoring. Typical applications include process control, energy management, and distributed I/O systems where accuracy and efficiency are critical.
