Description
Overview
The GE DS200CTBAG1ADD Analog Termination Module is a specialized terminal board designed for the Mark V Speedtronic turbine control system. Engineers use this module to ensure proper signal termination and connectivity in both gas and steam turbine applications. Its compact dimensions, lightweight build, and robust design make it a reliable choice for demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
DS200CTBAG1ADD |
| Module Type |
Analog Termination Module |
| Manufacturer |
GE |
| Product Range |
EX2100 / Mark V |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Weight |
0.22 kg |
| Dimensions |
16.3 x 10.2 x 3 cm |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
| Communication Service |
Ethernet router |
| Connectors |
2 COREBUS (JAI, JAJ), 5 vertical pin, 2 header, 9-pin serial |
| Voltage Regulation |
Supported by red-coated diodes |
| Mounting |
Drilled holes with conductive surrounds |
Functional Description
The GE DS200CTBAG1ADD features multiple connectors, including COREBUS ports, vertical pin connectors, and a 9-pin serial interface, ensuring flexible integration with turbine systems. Engineers benefit from its voltage-limiting hardware, supported by visible red-coated diodes that stabilize electrical performance.
Its long, narrow design includes drilled mounting holes at each corner and along the edges, allowing secure attachment. The GE DS200CTBAG1ADD improves upon earlier versions with significant revisions, enhancing reliability and compatibility within Mark V turbine control systems.
Applications and Compatibility
The GE DS200CTBAG1ADD Analog Termination Module suits turbine control systems requiring precise signal termination and voltage regulation. It integrates seamlessly with EX2100 and Mark V Speedtronic systems, supporting both Simplex and TMR architectures. Typical applications include gas turbine monitoring, steam turbine automation, and advanced DCS environments where stability and connectivity are critical.
