Description
Product Overview
The GE Fanuc IC200MDD841 High-speed Counter Module from the VersaMax series delivers precise counting for industrial automation. Engineers rely on its 12 discrete outputs and 20 discrete inputs, configurable for multiple functions. The module supports counters operating at 80kHz, ensuring reliable performance in demanding PLC applications.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC200MDD841 |
| Module Type |
High-speed Counter |
| Manufacturer |
GE Fanuc |
| Product Range |
VersaMax |
| Condition |
Brand New |
| Dimensions |
10.8 × 6.3 × 5.7 cm |
| Weight |
0.1 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System Compatibility |
PLC |
| Communication Service |
Ethernet Router |
| Status |
Active |
Functional Description
The IC200MDD841 module integrates four high-speed counter pairs and eight standard outputs. It operates on 24 Volts DC and consumes 30 milliamps from the 5-Volt backplane supply. External devices require independent power sources, ensuring flexible integration.
Error detection mechanisms enhance reliability, while onboard LEDs provide clear operational feedback. The IC200MDD841 displays status data in up to 13 words, supporting efficient monitoring. Configurable I/O settings include pulse width modulation, ramping pulse trains, and standard pulse trains.
Applications and Compatibility
The GE Fanuc IC200MDD841 High-speed Counter Module fits seamlessly into VersaMax PLC systems. Its compact 10.8x6.3x5.7cm design and lightweight 0.1kg build simplify installation in space-constrained environments.
Industrial automation engineers deploy the IC200MDD841 in manufacturing plants, energy facilities, and process control systems requiring rapid counting. Compatibility with Ethernet router communication ensures smooth integration into distributed control networks.
