Description
Product Overview
The GE Fanuc IC200ALG320 VersaMax Analog Output Module provides four voltage outputs for precise industrial automation control. Its compact 11x5.5x6.5cm dimensions and lightweight 0.16kg build simplify installation in PLC systems. With 12-bit resolution and ±10.24V DC output range, the IC200ALG320 ensures accurate signal processing and reliable performance under demanding conditions.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC200ALG320 |
| Module Type |
Analog Output Module |
| Manufacturer |
GE Fanuc |
| Product Range |
VersaMax |
| Condition |
Brand New |
| Dimensions |
11 × 5.5 × 6.5 cm |
| Weight |
0.16 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System Compatibility |
PLC |
| Communication Service |
Ethernet Router |
| Status |
Active |
Functional Description
The IC200ALG320 operates with a ±10.24V DC output range and supports resistive loads of at least 5000 Ohms. Intelligent processing is managed by the VersaMax CPU, while built-in diagnostics detect potential power loss on field-side circuits.
This module consumes 210 milliamps from the backplane supply and requires external power for outputs. Crosstalk rejection reaches 70 dB minimum, ensuring clean signal transmission. Accuracy ranges from ±0.3 to 1 percent within 25°C to 60°C, supporting stable operation in industrial environments.
Applications and Compatibility
The GE Fanuc IC200ALG320 VersaMax Analog Output Module integrates seamlessly into PLC-based automation systems. Engineers deploy it in manufacturing plants, energy facilities, and process control environments requiring precise analog output management.
Its compact footprint and lightweight design make the IC200ALG320 ideal for installations where space efficiency matters. Compatibility with VersaMax series components ensures reliable integration into GE industrial infrastructures, reinforcing its role as a dependable analog output solution.
