Description
Product Overview
The GE Fanuc IC200PNS001 VersaMax PROFINET Scanner Module delivers advanced networking for distributed I/O systems. Its compact 13.3x13x6.8cm design and 0.26kg weight simplify installation while supporting robust communication. With dual RJ45 ports and embedded switch functionality, the IC200PNS001 ensures efficient integration into industrial PLC environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC200PNS001 |
| Module Type |
Scanner Module |
| Manufacturer |
GE Fanuc |
| Product Range |
VersaMax |
| Condition |
Brand New |
| Dimensions |
13.3 × 13 × 6.8 cm |
| Weight |
0.26 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System Compatibility |
PLC |
| Communication Service |
Ethernet Router |
| Status |
Active |
Functional Description
The IC200PNS001 supports Profinet Slave Version 2.2 Class A I/O devices, enabling seamless distributed I/O architecture. It handles up to 2880 bytes of data, split evenly between 1440 input and 1440 output bytes. Operators configure update rates from 1ms to 512ms, ensuring flexible performance.
Two RJ45 ports allow linear, star, or ring Ethernet topologies, while transmission speeds reach 10/100 Mbps. The IC200PNS001 consumes 3 Watts from a 5 VDC backplane supply and supports cable distances up to 100 meters per segment. Diagnostic features include 32 input status bits and 32 output control bits, enhancing monitoring and fault detection.
Applications and Compatibility
The GE Fanuc IC200PNS001 integrates with VersaMax I/O modules and PACSystems RX3i and RX7i controllers. Engineers deploy it in industrial automation requiring reliable PROFINET communication, remote node management, and real-time diagnostics.
Its hot-swappable power supply support, CIDR subnetting, and firmware updates via USB make the IC200PNS001 versatile for modern PLC systems. Operating temperatures from 0 to 60°C ensure durability in demanding environments.
