ABB offers industrial automation solutions across drives, control systems, and robotics. Our global inventory ensures fast access to hard-to-find parts. Reduce downtime and maintain continuous production with verified ABB components.
5 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
DescriptionThe ABB FPR3315101R1032, also identified by the model designation ICSI16D1, is a remote I/O unit designed for the ABB Procontic CS31 fieldbus system. This module serves as a distributed input/output interface, allowing for the expansion of control capabilities in industrial automation environments by connecting remote sensors and actuators to the central controller via the CS31 bus protocol.Features
Designed for integration with the ABB Procontic CS31 fieldbus architecture.
Supports 24 Vdc power supply for standard industrial control loops.
Compact design optimized for space-constrained control cabinets.
Reliable data communication for distributed I/O applications.
Technical Specifications
Manufacturer
ABB
Model / Order Code
FPR3315101R1032
Spare Model
ICSI16D1
System Series
Procontic CS31
Supply Voltage
24 Vdc
Product Type
Remote I/O Unit
Tariff Code
8538907080
Installation Guidelines
Ensure the power supply is disconnected before installing or removing the module from the mounting rail.
The module should be installed in a clean, dry environment within the specified temperature range to prevent component degradation.
Maintain proper grounding practices to minimize electromagnetic interference (EMI) and ensure signal integrity on the CS31 bus.
Ensure adequate ventilation around the unit to prevent overheating during continuous operation.
Use shielded communication cables for the CS31 bus connection to reduce noise susceptibility in industrial environments.
FAQWhat is the primary function of the ICSI16D1?The ICSI16D1 is a remote I/O unit used to extend the I/O capacity of an ABB Procontic CS31 PLC system, allowing the controller to interface with field devices located at a distance from the main processor.Is this module compatible with other fieldbus systems?No, this module is specifically designed for the ABB Procontic CS31 fieldbus protocol and is not compatible with other protocols like Profibus or Modbus unless used with a specific gateway.
5 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
5 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
DescriptionThe ABB GJR2393100R1200 (88FT05C-E) is a specialized Remote-Bus Coupling Module designed for the ABB Procontrol P14 and System 800xA distributed control environments. This module serves as a critical interface, facilitating reliable communication and data exchange between local station buses and remote bus networks. It is engineered to maintain high-speed, deterministic data throughput required for complex industrial automation and safety-critical applications.Features
Designed for integration within the Procontrol P14 platform.
Functions as a station modem and bus coupling module (88TK05 compatibility).
High-speed communication interface for distributed control stations.
Robust design suitable for demanding industrial environments.
Supports seamless data exchange across remote bus architectures.
Applications
Thermal Power Plants: Distributed control systems for gas-fired power generation units.
Nuclear and Hydroelectric: Control network management for conventional islands and power generation infrastructure.
Metallurgy and Steel: Interface for blast furnaces, converters, and continuous casting equipment.
Petrochemical Industry: Distributed control for large-scale oil refining and ethylene production facilities.
Technical Specifications
Model
GJR2393100R1200 / 88FT05C-E
Manufacturer
ABB
Platform
Procontrol P14
Power Supply
24V DC +/- 20%
Power Consumption
15W (typical)
Isolation
1500V AC
Latency
<100 microseconds
Operating Temperature
-40 degC to +70 degC
Storage Temperature
-40 degC to +85 degC
Humidity
5-95% non-condensing
Installation Guidelines
Ensure the system power is completely disconnected before installing or removing the module to prevent electrical damage.
Mount the module in a clean, dry, and well-ventilated cabinet to maintain the specified operating temperature range.
Use shielded communication cables to minimize electromagnetic interference (EMI) in high-noise industrial environments.
Verify that the module is securely seated in the rack backplane to ensure proper electrical contact.
Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect internal circuitry.
FAQsWhat is the primary function of the GJR2393100R1200?This module acts as a data bridge, enabling communication between the local station bus and remote bus networks within the ABB Procontrol P14 system.Is this module compatible with System 800xA?Yes, it is designed for use within ABB Procontrol P14 and System 800xA distributed control system architectures.What are the environmental limits for this module?The module is rated for operation between -40 degC and +70 degC with a humidity range of 5-95% non-condensing.
5 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
9 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
DescriptionThe ABB CMA137 is a dedicated connection module designed for use within the Synpol D system architecture. This module serves as a critical interface component, facilitating reliable signal and power distribution within the control cabinet environment. As an original ABB spare part, the CMA137 ensures compatibility and operational consistency for legacy Synpol D installations.Features
Designed for seamless integration with Synpol D control systems.
Robust connection interface for industrial signal management.
Compact form factor for high-density cabinet mounting.
Genuine ABB spare part, ensuring system integrity.
Technical Specifications
Manufacturer
ABB
Model
CMA137
Spare Model
CMA 137/3DDE 300 417
Product Type
Connection Module
System Series
Synpol D
Weight
0.18 kg
Tariff Code
8538907080
Installation Guidelines
Ensure the control system is powered down before installing or removing the CMA137 module to prevent electrical damage.
Verify that the module is securely seated in its designated slot to ensure proper contact with the backplane or terminal interface.
Maintain proper cable management practices; use shielded cables where required to minimize EMI/RFI interference.
Ensure the installation environment is free from excessive vibration, moisture, and corrosive gases.
Handle with standard ESD (Electrostatic Discharge) precautions to protect sensitive internal circuitry.
FAQWhat is the primary function of the ABB CMA137?The CMA137 is a connection module used in the ABB Synpol D system to provide necessary signal and interface connectivity for control operations.Is this module compatible with other ABB systems?The CMA137 is specifically engineered for the Synpol D series. It is recommended to verify your specific system configuration and part numbers before installation.
9 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
9 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
DescriptionThe ABB RBIP-01 (3AUA0000030932) is a high-performance BACnet/IP Router Module designed to provide seamless connectivity for ABB ACH550 HVAC drives. This module functions as a bridge between BACnet/IP (Ethernet) and BACnet MS/TP (RS-485) networks, allowing building management systems to monitor and control drive parameters without the need for external gateways. It is a snap-on module that installs directly into the drive housing, offering a compact and integrated communication solution.Features
Designed for ABB ACH550 HVAC drive series
Supports BACnet/IP to BACnet MS/TP routing
Integrated web server for configuration and diagnostics
10/100 Mbps Ethernet transfer rate
EIA-485 serial port for MS/TP communication
Snap-on mounting for internal drive installation
Applications
Air Handling Units (AHUs): Fan speed control and ventilation management
Pumping Stations: Fluid movement control and energy monitoring
Compressors and Chillers: HVAC refrigeration cycle management
Industrial Automation: Integration of frequency converters into larger building management systems
Technical Specifications
Model
RBIP-01
Order Code
3AUA0000030932
Manufacturer
ABB
Power Supply
12...26 V DC / AC, 200 mA
Ethernet Speed
10/100 Mbps
Serial Port
1 x EIA-485 (BACnet MS/TP)
Operating Temperature
0 to 45 degC (32 to 113 degF)
Operating Humidity
20 to 80% relative humidity
Tariff Code
8537101190
Installation Guidelines
Safety Warning: Always switch off mains power and wait at least 5 minutes for the drive's intermediate circuit capacitors to discharge before installing or removing the module.
Mounting: The module is designed for snap-on installation inside the compatible ABB drive. Ensure the module is firmly seated in the designated slot.
Wiring: Use the provided 2-pin connector for power supply and the 4-pin connector for EIA-485 (B+, A-, AGND, Shield) connections.
Configuration: Use the internal web server via a standard web browser to configure IP addresses and routing parameters (BBMD or Foreign Device).
Status Indicators: Solid green indicates correct power; Ethernet link/activity is indicated by flashing or solid green on the RJ-45 port.
FAQsWhat is the primary function of the RBIP-01?The RBIP-01 acts as a BACnet router, enabling communication between Ethernet-based BACnet/IP networks and serial-based BACnet MS/TP networks for ABB ACH550 drives.Is this module compatible with older ACH550 drives?Yes, the RBIP-01 is compatible with all ABB ACH550 standard drives for HVAC, including older product generations.How do I access the module settings?The module features an internal web server that can be accessed via a standard web browser once connected to the Ethernet network to set IP addresses and view diagnostic logs.
9 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
DescriptionThe ABB DSQC 627 (3HAC020466-001) is a specialized power supply module designed for use within ABB industrial robotic systems. This unit provides reliable power distribution and voltage regulation essential for the operation of control cabinets and associated robotic controllers. It is engineered to meet the rigorous demands of industrial automation environments, ensuring stable performance for critical motion control and processing tasks.Features
Official ABB replacement component for robotic control systems.
Robust construction designed for high-vibration and industrial temperature environments.
Integrated power regulation to maintain system stability.
Designed for seamless integration with ABB controller architecture.
ApplicationsThis power supply module is primarily utilized in ABB robotic controller cabinets. It serves as a vital component for maintaining the electrical integrity of the controller, ensuring that internal logic, communication, and drive interfaces receive consistent power.Technical Specifications
Product ID
3HAC020466-001
Model
DSQC 627
Product Name
Power Supply Module
Customs Tariff Number
85044083
Net Weight
4.94 kg
Dimensions (D x H x W)
99 mm x 355 mm x 199.75 mm
Installation Guidelines
Ensure the main power supply is disconnected and locked out before attempting to install or remove the module.
Verify that the mounting surface is clean and free of debris to ensure proper heat dissipation.
Ensure all electrical connections are tightened to the manufacturer's specified torque to prevent arcing or loose contacts.
Handle the module with care to avoid damage to internal components; use ESD-safe practices when handling the unit.
Ensure adequate ventilation around the controller cabinet to prevent overheating during operation.
FAQIs this a genuine ABB part?Yes, the 3HAC020466-001 is an original ABB DSQC 627 power supply module intended for use in ABB robotic control systems.What should I do if the power supply fails?If the module fails, verify the input voltage levels and check for any tripped breakers or blown fuses in the cabinet. If the module itself is confirmed faulty, it must be replaced with an identical unit to maintain system compliance and safety.
2 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
DescriptionThe ABB AI86-16 is an analog input module designed for industrial control systems. This module is engineered to process analog signals, providing reliable data acquisition for automation processes. As a discontinued component, it remains a critical spare part for legacy ABB control systems requiring direct hardware replacements to maintain operational continuity.Features
Designed for precise analog signal processing.
Compatible with specific ABB legacy control architectures.
Robust construction suitable for industrial environments.
Direct replacement for part number 57087196.
ApplicationsThis module is typically utilized in process automation, power generation, and manufacturing control systems where analog sensor feedback (such as 4-20mA or voltage signals) is required for monitoring and regulation.Technical Specifications
Product Model
AI86-16
Spare Model / Part Number
57087196
Manufacturer
ABB
Product Type
Analog Input Module
Weight
0.34 kg
Installation Guidelines
Ensure the control system is powered down before inserting or removing the module from the rack.
Handle the module using ESD-safe practices to prevent damage to sensitive internal circuitry.
Verify that the module is fully seated in the backplane to ensure proper electrical contact.
Route signal wiring away from high-voltage power cables to minimize electromagnetic interference (EMI).
Ensure adequate ventilation in the cabinet to maintain the module within its specified operating temperature range.
FAQIs the ABB AI86-16 still in production?No, the AI86-16 has been discontinued by the manufacturer. It is currently available primarily as a spare part for legacy system maintenance.What is the alternative part number for this module?The AI86-16 is also identified by the spare part number 57087196.
2 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
7 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
DescriptionThe ABB AI620 (Order Code: 3BHT300005R1) is a high-density analog input module designed for the Advant S6000 series control systems. This module provides 16 channels of analog signal processing, enabling the integration of various field instruments into the Advant Controller 110/160 environments. As a critical component in process automation, the AI620 facilitates precise monitoring and data acquisition for industrial control loops.Features
16-channel analog input capability for high-density signal monitoring.
Designed for seamless integration with Advant S6000 and Advant Controller 110/160 systems.
Robust industrial design suitable for demanding process control environments.
Reliable signal conversion for process variables.
ApplicationsThe AI620 is typically utilized in process automation applications where multiple analog inputs are required, such as temperature, pressure, or flow monitoring within the Advant S6000 architecture. It is commonly found in power generation, chemical processing, and water treatment facilities relying on ABB Advant control platforms.Technical Specifications
Model
AI620
Order Code
3BHT300005R1
Manufacturer
ABB
System Series
Advant S6000
Input Type
Analog
Channel Count
16
Tariff Code
85389091
Installation Guidelines
Ensure the control system is powered down before inserting or removing the module to prevent electrical damage.
Verify that the module is correctly seated in the designated Advant S6000 rack slot.
Use appropriate shielded cabling for analog signals to minimize electromagnetic interference (EMI) and noise.
Ensure proper grounding of the module chassis to the system common ground to maintain signal integrity.
Maintain adequate ventilation around the controller rack to prevent overheating during operation.
FAQIs the ABB AI620 still in production?No, the AI620 (3BHT300005R1) has been discontinued by the manufacturer. We supply tested, reliable spare parts to support the continued operation of legacy Advant control systems.What system is this module compatible with?The AI620 is specifically designed for the ABB Advant S6000 series and is compatible with Advant Controller 110 and 160 units.
7 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
8 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
DescriptionThe ABB 3BHB002483R0001 (USC329AE01) is a high-performance control board designed for the AC 800PEC controller series. This module serves as a critical component in industrial automation and power electronics control systems, providing robust processing capabilities and versatile communication interfaces for real-time monitoring and control tasks.Features
Integrated communication support including RS-485 and Ethernet protocols.
Supports Modbus communication for seamless integration with third-party industrial devices.
Equipped with 4 analog input channels (configurable for 0-20mA or 4-20mA ranges).
Features 8 additional I/O channels for flexible system configuration.
Designed for reliable operation in demanding industrial environments.
Technical Specifications
Product Model
3BHB002483R0001 / USC329AE01
Manufacturer
ABB
Operating Temperature
-20 degC to +60 degC
Supply Voltage
24V DC
Communication
RS-485, Ethernet, Modbus
Weight
1.16 kg
Tariff Code
8537101190
Installation Guidelines
Ensure the control system is powered down before installing or removing the module to prevent electrical damage.
Mount the board in a clean, dry environment within an industrial enclosure to protect against dust, moisture, and extreme temperatures.
Ensure proper grounding of the module to the cabinet chassis to minimize electromagnetic interference (EMI).
Use shielded twisted-pair cabling for RS-485 and Ethernet connections to maintain signal integrity in high-noise environments.
Verify that the 24V DC power supply is stable and within the specified operating range before energizing the system.
FAQWhat is the primary function of the USC329AE01 control board?The USC329AE01 is a control board specifically designed for the ABB AC 800PEC platform, used to manage I/O signals and facilitate communication between the controller and field devices via Ethernet and Modbus protocols.Can this module be used in harsh environments?The module is rated for an operating temperature range of -20 degC to +60 degC, making it suitable for most standard industrial control room or cabinet environments.What type of input signals does this board support?The board features 4 analog channels that support 0-20mA and 4-20mA current loop signals, commonly used for process instrumentation and sensor feedback.
8 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB SD834 3BSC610067R1 Power Supply Device
Configured for 24 VDC power conversion and industrial DC supply distribution in ABB automation systems, the ABB SD834 3BSC610067R1 (SD834 Power Supply Device) provides direct electrical conversion from AC/DC input sources to a regulated 24 VDC output supply.
Hardware Specifications
Parameter
Specification
Model
SD834 3BSC610067R1
Brand
ABB
Product Type
Power Supply Device
Origin
Sweden
Weight
1.3 kg
Dimensions
15.5 x 23 x 36 cm (estimated shipping size)
Operating Temp
Not specified
Power Consumption
547/568 VA rated input power
Input Voltage
100-240 VAC or 110-150 VDC
Output Voltage
24 VDC
Rated Output Current
20 A
Rated Output Power
480 W
Efficiency
92.4/93.9 %
Application
SELV and PELV systems
ABB Industrial Power Architecture and Control System Integration
The ABB SD834 3BSC610067R1 operates as a switch-mode power supply component within ABB industrial control architectures. It converts mains AC or DC input power into a regulated 24 VDC output used for control equipment, I/O modules, and automation system components.
Furthermore, the SD834 supports SELV and PELV applications by maintaining separated low-voltage output characteristics. The module design fits ABB power distribution structures where stable DC voltage delivery and load capacity management are required.
The unit supports ABB system power configurations with high output density. Therefore, its 20 A rated output current allows connection to multiple automation devices while maintaining defined electrical load limits.
Frequently Asked Questions
Q: What input voltage ranges does the ABB SD834 3BSC610067R1 support?A: The SD834 accepts 100-240 VAC input or 110-150 VDC input sources according to the provided technical specifications.
Q: What output parameters are provided by the SD834 power supply device?A: The module provides a 24 VDC output with a rated current of 20 A and rated output power of 480 W.
Q: Can the SD834 be used for SELV and PELV applications?A: Yes. The SD834 is specified for SELV and PELV applications within compatible ABB industrial automation installations.
Field Installation Guidelines
Install the SD834 in an enclosure that provides suitable mechanical protection and environmental control.
Verify that input voltage wiring matches the specified AC or DC supply range before energizing the module.
Use appropriate cable sizing based on the 20 A output current requirement and connected load conditions.
Separate power wiring from sensitive signal cables to reduce electrical interference.
Connect protective grounding according to the applicable industrial electrical installation standards.
Confirm output polarity before connecting downstream 24 VDC devices.
Check ventilation clearance and mounting conditions according to the system cabinet design requirements.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB SD832 3BSC610065R1 Power Supply Module
Configured for 24 VDC power conversion in ABB System 800xA and AC 800M automation platforms, the ABB SD832 3BSC610065R1 (SD832 Power Supply Module) provides direct electrical power conditioning for control system devices. The module converts 100-120 VAC or 200-240 VAC input power into a regulated 24 VDC output with a rated current of 5 A.
Hardware Specifications
Parameter
Specification
Model
SD832 3BSC610065R1
Brand
ABB
Product Type
Power Supply Module
Origin
Sweden
Weight
0.48 kg
Dimensions
3.2 x 12 x 13 cm
Power Consumption
120 W rated output power
Input Voltage
100-120 VAC / 200-240 VAC, auto-select input
Input Power
240 VA / 283 VA
Output Voltage
24 VDC
Rated Output Current
5 A
Tariff Code
8537101190
Application Platform
ABB System 800xA / AC 800M automation systems
Backplane Power Integration and Industrial Control Compatibility
The ABB SD832 power supply module supports ABB industrial controller architectures by providing regulated DC power for connected control components. Therefore, correct integration with the system power distribution structure maintains stable voltage delivery across automation assemblies.
The module design follows ABB PLC and DCS power supply requirements, including controlled DC output behavior for I/O modules and communication components. Furthermore, ABB power architecture supports system configurations requiring coordinated power distribution and monitoring.
The SD832 operates as part of ABB industrial control systems where power modules connect with controller racks, I/O assemblies, and auxiliary automation devices. It provides the electrical conversion function required between AC mains sources and 24 VDC control circuits.
Frequently Asked Questions
Q: What input voltage range does the ABB SD832 3BSC610065R1 support?A: The SD832 supports 100-120 VAC and 200-240 VAC nominal input voltage through an auto-select input design.
Q: What is the rated DC output capability of the SD832 module?A: The module provides a 24 VDC output with a rated output current of 5 A and rated output power of 120 W.
Q: Can the SD832 be installed in ABB automation systems with other power modules?A: The SD832 can be integrated according to ABB system power configuration requirements. Installation must follow rack layout, wiring, grounding, and load distribution specifications.
Field Installation Guidelines
Install the SD832 module according to ABB rack and cabinet installation procedures.
Verify the AC input voltage range before connecting field power wiring.
Connect protective grounding according to industrial electrical installation standards.
Keep AC input wiring separated from low-level signal cables to reduce electrical interference.
Use properly rated conductors for AC input and 24 VDC output connections.
Check output polarity before connecting external control devices.
Maintain adequate cabinet ventilation and avoid installation conditions outside the specified environmental limits.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB SD831 3BSC610064R1 Power Supply Unit
The ABB SD831 3BSC610064R1, also cataloged as the SD831 Power Supply Unit, operates as a dedicated hardware component for converting mains input voltage into regulated 24 VDC output power within ABB industrial control system power networks.
Hardware Specifications
Parameter
Specification
Model
SD831 3BSC610064R1
Brand
ABB
Weight
430 g
Dimensions
32 mm W x 102 mm D x 124 mm H
Operating Temp
Maximum 55 deg C
Power Consumption
Rated output power 72 W, heat dissipation 10/8 W
Product Type
Power Supply Unit
Rated Output Voltage
24 VDC
Rated Output Current
3 A
Maximum Output Current
3.3 A
Rated Input Power
134/143 VA
Input Voltage Range
100-240 VAC +/-10 %, 110-300 VDC -20 % / +25 %
Mains Frequency
50-60 Hz +/-6 %
Efficiency
88/89.8 %
Output Ripple
< 50 mV peak to peak
Output Voltage Regulation
< 50 mV / < 100 mV at maximum current
Secondary Voltage Holdup Time
29/120 ms during mains blackout
Output Over Voltage Protection
< 39 V
Protection Rating
IP20 according to IEC 60529
Applications
SELV and PELV systems
Electrical Safety Standards
IEC 61131-2, UL 508, EN 50178
EMC Compliance
EN 61000-6-4 and EN 61000-6-2
Mounting Spacing
15 mm W, 40 mm H
ABB Industrial Power Network Characteristics
The ABB SD831 power supply integrates switch-mode conversion technology for industrial control power distribution. The unit accepts both AC and DC mains sources and provides a regulated 24 VDC secondary output for automation hardware.
The power supply supports non-redundant and redundant configurations. For redundant operation, ABB SS823 or SS832 diode voting units provide output selection and current path management between multiple power supply units.
The SD831 includes soft-start functionality. Therefore, power activation limits primary inrush current effects and prevents unnecessary triggering of upstream fuses or earth-fault circuit breakers.
The unit is designed for ABB automation environments requiring controlled DC power distribution, DIN-rail installation, and compatibility with SELV or PELV protection concepts.
Frequently Asked Questions
Q: Can the ABB SD831 operate in redundant power supply configurations?A: Yes. The SD831 supports redundant applications when combined with ABB SS823 or SS832 diode voting units. These units manage output power selection between parallel supply sources.
Q: Does the SD831 require an external mains filter for operation?A: No. The SD831 power supply design does not require installation of a mains filter for standard operation.
Q: What safety standards apply to the ABB SD831 power supply?A: The SD831 complies with IEC 61131-2, UL 508, and EN 50178 electrical safety requirements. The secondary output circuit is accepted for SELV and PELV applications.
Field Installation Guidelines
Install the ABB SD831 on a suitable DIN-rail mounting system with the specified mechanical spacing maintained around the enclosure. Ensure sufficient airflow around the unit to support thermal dissipation.
Connect input wiring according to the approved AC or DC supply range. Verify protective grounding connections before energizing the device.
For redundant configurations, install ABB SS823 or SS832 diode voting units according to the system architecture requirements. Keep power wiring separated from high-frequency switching cables and signal communication lines.
Check output polarity and verify the 24 VDC distribution voltage before connecting downstream automation modules. Follow cabinet grounding and EMC practices defined for ABB industrial control installations.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB TP857 Baseplate for BC810
The ABB 3BSE030192R1 TP857, also cataloged as the TP857 Module Termination Unit, provides the physical mounting interface for BC810 communication interface installation within ABB AC 800M controller hardware configurations.
Hardware Specifications
Parameter
Specification
Model
TP857 3BSE030192R1
Brand
ABB
Product Type
Module Termination Unit
Application
Baseplate for BC810 communication interface
Origin
United States / Sweden
Weight
0.27 kg
Dimensions
Width: 60 mm
Power Consumption
Passive baseplate, no external power consumption
Mounting Function
Mechanical support and electrical connection interface for BC810
Compatible Device
BC810 communication interface
Part Type
New
Minimum Order Quantity
1 piece
Backplane Bus Interface and I/O Density Scaling
The ABB TP857 is a passive termination and mounting component designed for BC810 integration in ABB controller architectures. Therefore, it does not execute control logic or process field signals directly. Instead, the baseplate provides the mechanical positioning and electrical interface required for module installation.
Furthermore, the TP857 supports ABB industrial control cabinet layouts by maintaining defined module alignment and connection stability. The component fits ABB AC 800M communication configurations where BC810 units require dedicated baseplate mounting.
The TP857 design follows ABB PLC/DCS hardware integration principles, including structured backplane connection management, module positioning accuracy, and firmware-compatible hardware configurations within supported controller assemblies.
Frequently Asked Questions
Q: What is the primary function of the ABB TP857 3BSE030192R1?A: The TP857 functions as a baseplate for BC810 communication interface installation, providing mechanical mounting and electrical interface support.
Q: Does the TP857 require an external power supply?A: No. The TP857 is a passive module termination unit and does not require independent power input.
Q: Can the TP857 be used with other ABB communication modules?A: The TP857 is specified for BC810 installation. Compatibility with other modules depends on the ABB system configuration and hardware documentation.
Field Installation Guidelines
Install the TP857 on the designated ABB controller mounting arrangement according to system hardware documentation.
Verify that the BC810 module is correctly seated before applying system power.
Maintain proper cabinet grounding practices to reduce electrical interference.
Route communication and power cables separately where possible to minimize signal coupling.
Inspect mechanical fixing points and connector interfaces before commissioning.
Confirm module alignment to prevent damage to the baseplate connection contacts.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB TP858 Baseplate Unit
The ABB TP858, also cataloged as the TP858 Baseplate Unit, provides the physical mounting and electrical interface structure for CI858 communication interface installation within ABB AC 800M controller systems.
Hardware Specifications
Parameter
Specification
Model
TP858
Brand
ABB
Product Type
Baseplate Unit
System Compatibility
ABB AC 800M controller platform with CI858 communication interface
Origin
Sweden
Operating Temp
Industrial control environment range, system dependent
Power Consumption
Supplied through associated controller communication interface assembly
Mounting Type
Controller rack / CEX-Bus mounting structure
Communication Interface
Supports CI858 module mechanical and electrical connection
Installation Method
Panel-mounted controller system installation
Backplane Bus Communication and Industrial Control Integration
The TP858 functions as the mechanical and electrical base assembly for ABB communication interface modules. Therefore, it provides the mounting position, connector alignment, and internal signal routing required for AC 800M system integration.
The unit supports ABB controller architecture through defined module positioning and backplane connection methods. Additionally, firmware and communication behavior depend on the installed CI858 interface module rather than the TP858 hardware itself.
The baseplate design maintains correct module placement for industrial control configurations. Furthermore, it supports structured installation practices for ABB CEX-Bus based communication assemblies.
Frequently Asked Questions
Q: Is the TP858 an independent communication module?A: No. The TP858 is a baseplate unit designed to mechanically and electrically support compatible ABB communication interface modules such as CI858.
Q: Does the TP858 contain configurable firmware?A: No. The TP858 does not provide independent firmware functions. Configuration parameters are managed by the installed communication interface and AC 800M controller software.
Q: Can the TP858 be installed without a compatible ABB interface module?A: The TP858 can be physically mounted, but its intended operation requires installation with the corresponding ABB communication hardware.
Field Installation Guidelines
Install the TP858 on the designated ABB controller mounting structure according to the AC 800M hardware installation manual.
Verify that the mechanical locking features engage correctly before installing the communication interface module.
Maintain proper grounding practices for the controller cabinet. Connect cable shields according to ABB system grounding requirements to reduce electrical interference.
Route communication and power wiring separately where required. Avoid placing high-current switching cables adjacent to controller communication wiring.
Inspect connectors and mounting contacts before commissioning. Ensure all modules are correctly seated before applying system power.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB TP854 3BSE025349R1 Module Termination Unit
Configured for DP-V1 communication interface baseplate installation in ABB AC 800M systems, the ABB TP854 3BSE025349R1 (TP854 Module Termination Unit) provides direct physical mounting and electrical connection support for CI854 communication interfaces.
Hardware Specifications
Parameter
Specification
Model
TP854 3BSE025349R1
Brand
ABB
Product Type
Module Termination Unit
Function
Baseplate for CI854, CI854A and CI854B PROFIBUS DP-V1 Interface
Origin
Sweden / Germany
Weight
0.234 kg
Dimensions
216 mm x 72 mm x 49.5 mm
Estimated Shipping Size
18.7 x 6.7 x 4.8 cm
Operating Temp
Not specified by manufacturer
Power Consumption
Passive termination unit, no external power consumption
Compatible Modules
CI854K01, CI854AK01, CI854BK01
Mounting Type
AC 800M controller system module termination mounting
Product Status
New
Customs Tariff Number
85369095
ABB Industrial Backplane and Interface Integration
The TP854 is a dedicated termination and mounting base unit designed for ABB CI854 communication interfaces. It provides the mechanical support structure and electrical interface connection between the CI854 module and the AC 800M control platform.
Furthermore, the unit supports ABB industrial backplane bus integration, allowing the installed communication interface to exchange control data through the controller hardware architecture. The TP854 does not operate as an active communication processor and does not contain independent firmware functions.
The module supports ABB PROFIBUS DP-V1 interface assemblies through compatible CI854 series communication modules. Therefore, system configuration depends on the installed CI854 communication unit and controller firmware compatibility.
Frequently Asked Questions
Q: What ABB communication modules can be installed with the TP854?A: The TP854 is specified for CI854, CI854A and CI854B communication interfaces, including CI854K01, CI854AK01 and CI854BK01 assemblies.
Q: Does the TP854 require an external power supply?A: No. The TP854 is a passive Module Termination Unit and does not include active electronics or independent power input requirements.
Q: Is firmware stored inside the TP854?A: No. The TP854 does not contain firmware. Communication functions are provided by the installed CI854 interface module.
Field Installation Guidelines
Install the TP854 according to ABB AC 800M hardware configuration requirements.
Verify that the CI854 interface module is correctly seated before system power application.
Maintain proper cabinet grounding and follow ABB control system wiring practices.
Keep communication wiring separated from high-voltage power cables to reduce electrical interference.
Inspect mechanical locking components before commissioning the installed communication interface.
Confirm compatibility between the TP854 base unit and the selected CI854 module version before replacement
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB CI801-eA PROFIBUS FCI S800 Interface
Configured for PROFIBUS DP-V1 communication in ABB S800 I/O systems, the ABB CI801-eA (CI801-eA Communication Interface) provides direct physical and electrical execution for fieldbus data exchange between the controller network and S800 I/O modules.
Hardware Specifications
Parameter
Specification
Model
CI801-eA
Brand
ABB
Product Type
Communication Module
Origin
Sweden
Weight
0.32 kg
Power Consumption
Supplied through S800 system interface, value not specified
Communication Interface
PROFIBUS DP-V1
System Platform
ABB S800 I/O System
Included Accessories
1 pce Power Supply Connector; 1 pce TB807 ModuleBus Terminator
Product ID
3BSE022366R2
ABB Type Designation
CI801-eA
PROFIBUS DP-V1 and S800 Bus Communication Characteristics
The CI801-eA operates as a PROFIBUS FCI (Fieldbus Communication Interface) module within the ABB S800 I/O architecture. It manages cyclic and acyclic communication between PROFIBUS DP-V1 networks and connected S800 I/O modules.
Furthermore, the interface module supports ModuleBus communication for local I/O expansion. The included TB807 ModuleBus Terminator maintains the required bus termination condition for the S800 configuration.
The ABB industrial control platform uses structured backplane communication methods, and the CI801-eA supports I/O density scaling through connection of multiple S800 I/O units. Therefore, correct ModuleBus addressing, connector installation, and firmware compatibility must be verified during system configuration.
Frequently Asked Questions
Q: What communication protocol does the CI801-eA support?A: The CI801-eA supports PROFIBUS DP-V1 communication as the fieldbus interface for ABB S800 I/O systems.
Q: What accessories are supplied with the CI801-eA?A: The module package includes one power supply connector and one TB807 ModuleBus Terminator.
Q: Can the CI801-eA be installed without ModuleBus termination?A: The ModuleBus network requires correct termination. The supplied TB807 terminator should be installed according to the S800 I/O system configuration requirements.
Field Installation Guidelines
Install the CI801-eA on the designated ABB S800 I/O mounting position according to system hardware documentation.
Verify PROFIBUS cable routing and maintain separation from high-voltage power cables to reduce electromagnetic interference.
Connect the protective shield according to the plant grounding standard and PROFIBUS installation practice.
Confirm ModuleBus termination using the supplied TB807 component before system commissioning.
Check connector seating and power supply wiring before applying system voltage.
Verify controller configuration, PROFIBUS node addressing, and communication diagnostics after installation.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB CI858K01 DriveBus Interface
The ABB 3BSE018135R1 CI858K01, also cataloged as the CI858K01 DriveBus Interface, operates as a dedicated communication hardware component for DriveBus data exchange within ABB AC 800M controller platforms.
Hardware Specifications
Parameter
Specification
Model
CI858K01
Product ID
3BSE018135R1
Brand
ABB
Product Type
Communication Module
Origin
Sweden
Weight
0.7 kg
Dimensions
127.5 mm depth x 186 mm height x 59 mm width
Communication Interface
DriveBus Interface
Package Contents
CI858 Communication Interface + TP858 Baseplate
Mounting Type
AC 800M controller expansion interface
Compliance
RoHS according to EU Directive 2011/65/EU
WEEE Category
Category 5 Small Equipment
DriveBus Communication and Industrial Network Integration
The CI858K01 provides DriveBus communication capability between ABB AC 800M controllers and connected drive systems. It performs communication processing through the controller expansion architecture and uses the TP858 baseplate for mechanical installation and electrical connection.
Furthermore, the module supports ABB industrial drive communication structures where deterministic data exchange between controller logic and drive equipment is required. The interface manages communication traffic through the AC 800M backplane environment and maintains compatibility with ABB controller engineering configurations.
The ABB CI858K01 belongs to the industrial control and drive communication category. Therefore, installation requires correct controller bus configuration, approved firmware compatibility, and proper network parameter assignment.
Frequently Asked Questions
Q: What is the primary function of the ABB CI858K01 module?A: The CI858K01 provides a DriveBus communication interface for ABB AC 800M controller systems. It transfers communication data between the controller platform and connected ABB drive equipment.
Q: Does the CI858K01 include the mounting baseplate?A: Yes. The supplied package includes the CI858 communication interface module and the TP858 baseplate.
Q: What installation considerations apply to this communication module?A: Installation requires correct placement on the AC 800M expansion architecture, proper electrical connection, and verification of controller configuration parameters.
Field Installation Guidelines
Install the CI858K01 module on the designated AC 800M controller expansion position according to ABB hardware configuration instructions.
Verify that the TP858 baseplate is mechanically secured before connecting the communication interface module.
Route communication cables separately from high-voltage power wiring to reduce electromagnetic interference.
Use appropriate grounding methods for cabinet assemblies and cable shields according to industrial installation practices.
Confirm firmware compatibility and controller configuration before placing the communication interface into operational service.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB CI869 3BSE049110R1 AF 100 Communication Interface Module
The ABB CI869 3BSE049110R1, also cataloged as the CI869 AF 100 Communication Interface Module, operates as a dedicated hardware component for Advant Fieldbus 100 communication through twisted pair (TWP) connections within AC 800M controller platforms.
Hardware Specifications
Parameter
Specification
Model
CI869 3BSE049110R1
Brand
ABB
Product Type
AF 100 Communication Interface Module
System Platform
ABB AC 800M / AC 160 / Connectivity Server
Communication Protocol
ABB Advant Fieldbus 100
Communication Role
Slave station
Connector
Twisted Pair (TWP)
Transmission Speed
1.5 Mbit/s
Line Redundancy
Supported
Module Redundancy
Supported
Hot Swap
Supported
High Integrity Controller Support
Supported
Maximum Units on CEX Bus
12
Power Supply
+24 VDC through CEX-Bus
Power Consumption
Typical 160 mA at 24 VDC
Operating Temp
0 to +55 deg C
Storage Temp
-40 to +70 deg C
Protection Class
IP20 according to EN60529 and IEC 529
Corrosion Protection
G3 compliant to ISA 71.04
CE Marking
Yes
WEEE Compliance
Directive 2012/19/EU
Weight
700 g including base
Dimensions
59 mm W x 185 mm H x 127.5 mm D
ABB CEX-Bus and AF 100 Communication Architecture
The CI869 provides the physical and logical interface between an AC 800M controller and the ABB Advant Fieldbus 100 network. The module integrates CEX-Bus communication logic, an AF 100 communication unit, and a DC/DC converter for internal voltage distribution.
The module receives +24 VDC input through the CEX-Bus and supplies the required operating voltage for the communication electronics. Additionally, the integrated twisted pair modem enables direct connection to AF 100 field devices and controller stations.
The CI869 supports redundant cable configurations and redundant communication interface arrangements. Therefore, an AC 800M controller equipped with CI869 operates as an AF 100 station that exchanges process data with other AF 100 nodes.
Backplane Bus Communication and Redundancy Functions
The CI869 uses ABB controller expansion architecture with CEX-Bus communication handling. The module supports communication interface redundancy and line redundancy configurations for continuous fieldbus operation.
Furthermore, the module supports hot swap operation, allowing replacement procedures within supported AC 800M configurations without complete system shutdown. The communication design maintains AF 100 slave station behavior while transferring data between connected control nodes.
The CI869 can also operate within AC 800M High Integrity systems where communication availability and controlled system behavior are required.
Frequently Asked Questions
Q: What communication protocol does the CI869 3BSE049110R1 support?A: The CI869 supports ABB Advant Fieldbus 100 communication through twisted pair (TWP) connections with a transmission speed of 1.5 Mbit/s.
Q: Does the CI869 support redundant communication configurations?A: Yes. The module supports both line redundancy and module redundancy functions when installed in compatible AC 800M configurations.
Q: How is the CI869 powered inside the AC 800M system?A: The CI869 receives +24 VDC supply through the CEX-Bus and uses an internal DC/DC converter to generate required operating voltages.
Field Installation Guidelines
Install the CI869 module on the designated AC 800M CEX-Bus position according to the controller hardware configuration.
Verify that the twisted pair (TWP) fieldbus wiring follows ABB fieldbus installation requirements. Maintain proper cable routing separation from high-voltage power conductors and high-frequency interference sources.
Connect the communication shield according to the site grounding standard to minimize electrical noise coupling. Confirm that redundant fieldbus cables and redundant communication interfaces are installed according to the configured system topology.
Before commissioning, verify the +24 VDC supply connection, CEX-Bus communication status, and AF 100 network addressing parameters.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB CI868K01-eA Communication Interface Module
Configured for industrial communication data exchange in ABB System 800xA and AC 800M controller networks, the ABB CI868K01-eA (CI868K01-eA Communication Interface Module) provides direct hardware execution for protocol communication and controller interface tasks.
Hardware Specifications
Parameter
Specification
Model
CI868K01-eA
Brand
ABB
Product Type
Communication Interface Module
System Compatibility
ABB System 800xA / AC 800M controller platforms
Communication Function
Industrial network interface and controller communication handling
Communication Protocols
Firmware-dependent industrial communication protocols
Mounting Type
DIN rail mounting within ABB controller hardware configuration
Power Supply
24 VDC system power supply via controller infrastructure
Operating Temp
0 deg C to +55 deg C (standard industrial operating range)
Power Consumption
Not specified by available technical data
Protection Class
IP20
ABB Industrial Communication Interface Characteristics
The CI868K01-eA operates as a dedicated communication interface component within ABB automation architectures. It manages data transmission between controller resources, communication networks, and connected field-level devices.
The module uses ABB backplane bus communication technology to exchange configuration data and process information with the host controller. Therefore, system firmware compatibility and controller configuration determine supported network functions.
In addition, the module supports industrial network integration where deterministic communication timing and controlled data transfer are required. The hardware design follows ABB controller platform standards for I/O density scaling and modular system expansion.
Diagnostic indicators provide local status information for power condition, module operation, communication activity, and fault identification. These indicators assist maintenance personnel during commissioning and troubleshooting procedures.
Frequently Asked Questions
Q: Is the CI868K01-eA compatible with ABB AC 800M controllers?A: The CI868K01-eA is designed for ABB controller environments including AC 800M systems. Exact compatibility depends on controller firmware version, System 800xA release, and installed communication software.
Q: Does the module support hot-swap replacement during controller operation?A: Hot-swap capability depends on the configured ABB system architecture. Field replacement procedures must follow the applicable ABB hardware installation manual.
Q: How does the module handle communication diagnostics?A: The module provides LED-based diagnostic indications for power status, module condition, and communication activity. Detailed diagnostic functions depend on firmware and engineering configuration.
Field Installation Guidelines
Install the CI868K01-eA on the designated ABB DIN rail mounting position according to the controller hardware configuration.
Verify that the module seating mechanism is fully engaged before applying system power. Ensure that the backplane connection remains clean and free from contamination.
Route communication cables separately from high-voltage power wiring to reduce electrical interference. Use proper cable shielding and connect shield layers according to ABB grounding recommendations.
Confirm firmware compatibility before commissioning. After installation, check module diagnostics, communication status, and controller recognition through the engineering tool.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB 3BSE013200R1 CI820 S800 Redundant Communication
Configured for redundant communication within the ABB S800 I/O system, the ABB 3BSE013200R1 (CI820 S800 Redundant Communication Interface) provides direct hardware execution for dual communication interface operation. The module integrates an AF100 modem, 0.5 FPROM, 0.5 MB SRAM, and 16 MHz processing capability for S800 system communication redundancy.
Hardware Specifications
Parameter
Specification
Model
CI820 3BSE013200R1
Brand
ABB
Product Type
S800 Redundant Communication Interface
Origin
Sweden
Weight
0.512 kg
Communication Interface
AF100 Modem
Memory
0.5 FPROM, 0.5 MB SRAM
Processor Frequency
16 MHz
System Compatibility
ABB S800 I/O System
Redundancy Configuration
Two CI820 modules required for redundant operation
Customs Tariff Number
85389091
Part Type
New Spare Part
ABB Industrial Control Communication Architecture
The CI820 module operates as a communication interface component for ABB S800 I/O installations. It provides redundant communication capability by using two CI820 units in a configured pair. Therefore, the system can maintain communication availability through a dual interface arrangement.
The module supports ABB industrial control architecture through AF100 communication technology. In addition, its onboard memory resources include 0.5 FPROM and 0.5 MB SRAM for firmware storage and operational data handling.
The CI820 belongs to the ABB PLC/DCS hardware category, where backplane bus communication velocity, firmware flash compatibility, and I/O system integration parameters define module operation. The module is designed for S800 communication network configurations rather than direct field signal acquisition.
Frequently Asked Questions
Q: How is redundancy configured for the ABB CI820 3BSE013200R1?A: Redundant communication requires two CI820 modules to be ordered and installed as a redundant pair within the S800 I/O system configuration.
Q: What communication hardware is integrated into the CI820 module?A: The CI820 includes one AF100 modem interface together with internal firmware memory and SRAM resources for communication processing.
Q: Can the CI820 operate as a standalone redundant communication module?A: The specified configuration requires two CI820 units for redundancy functions. A single module does not provide the complete redundant communication arrangement.
Field Installation Guidelines
Install the CI820 module according to the ABB S800 I/O system hardware configuration requirements.
Verify that the module position and communication connections match the approved system layout.
Use appropriate industrial wiring practices for communication cables, including proper cable routing away from high-current power conductors.
Connect cable shields according to the plant grounding design to reduce communication interference.
Confirm that both CI820 modules are correctly configured before enabling redundant communication functions.
Check firmware compatibility between the CI820 module and the associated ABB control system before commissioning.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB CI851K01 3BSE018101R1 Profibus-DP Interface Module
Configured for Profibus-DP communication in ABB automation networks, the ABB CI851K01 3BSE018101R1 (CI851K01 Profibus-DP Interface Kit) provides direct physical and electrical execution for connecting field devices through a Profibus-DP interface.
Hardware Specifications
Parameter
Specification
Model
CI851K01 3BSE018101R1
Brand
ABB
Product Type
Communication Module
Protocol Type
Profibus-DP
Interface Function
Profibus-DP Interface Kit
Communication Speed
12000 kbit/s
Number of Channels
1
Origin
Sweden
Weight
0.3 kg
Dimensions
210 mm x 160 mm x 90 mm
Battery Quantity
0
Customs Tariff Number
85389091
Minimum Order Quantity
1 piece
Part Type
New
ABB Industrial Network Communication Characteristics
The CI851K01 interface module provides Profibus-DP communication between ABB controller systems and connected field-level devices. The module supports a communication speed up to 12000 kbit/s and operates through a single Profibus-DP channel.
Additionally, the module integrates into ABB control system architectures through the designated communication interface. Its firmware and hardware design support industrial network data exchange, while backplane bus communication velocity management maintains synchronized controller and I/O data transmission.
The Profibus-DP interface uses standard industrial network practices, including shielded cable routing, proper grounding, and controlled signal termination to maintain communication integrity.
Frequently Asked Questions
Q: What communication protocol does the CI851K01 support?A: The CI851K01 supports the Profibus-DP protocol and provides one communication channel for industrial network connection.
Q: Does the CI851K01 include battery components?A: No. The module specification lists the number of batteries as 0.
Q: What installation considerations apply to the CI851K01 communication interface?A: Installation requires correct Profibus cable routing, shield grounding, and network termination according to the applicable Profibus installation guidelines.
Field Installation Guidelines
Install the CI851K01 module in the designated ABB system position according to the controller hardware configuration.
Verify that the Profibus-DP cable shielding connects correctly to the protective grounding system.
Maintain separation between communication cables and high-voltage power wiring to reduce electromagnetic interference.
Confirm Profibus network termination settings before commissioning.
Inspect connector seating and mechanical mounting conditions before applying system power.
Verify communication status through the ABB engineering configuration tools after installation.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB AI801 3BSE020512R1 Analog Input Module
The ABB AI801 3BSE020512R1, also cataloged as the AI801 Analog Input Module, provides 8-channel current signal acquisition for ABB S800 I/O system platforms. It converts 0 to 20 mA field signals into 12-bit digital values for industrial control processing.
Hardware Specifications
Parameter
Specification
Model
AI801 3BSE020512R1
Brand
ABB
Product Type
Analog Input Module
System Platform
ABB S800 I/O
Origin
Sweden
Weight
0.25 kg
Dimensions
13.5 x 9.2 x 5 cm
Operating Temp
-25 deg C to +70 deg C
Power Consumption
Not specified
Number of Input Channels
8
Input Signal Type
0 to 20 mA
Nominal Input Current
0 to 20 mA
Resolution
12-bit
Input Impedance
250 ohm
Input Voltage Drop
Maximum 5 V
Scanning Time
10 ms per channel
Accuracy
+/- 0.1% of full-scale range
Product ID
3BSE020512R1
Customs Tariff Number
8537101190
ABB S800 I/O Integration and Industrial Communication
The AI801 module operates as an ABB S800 I/O analog acquisition unit with direct integration into ABB industrial control architectures. It processes current loop signals through dedicated input channels and transfers converted values through the I/O backplane communication path.
Additionally, ABB S800 I/O modules support structured I/O density scaling through modular backplane architectures. The AI801 design allows engineering teams to configure multiple analog input points while maintaining standardized cabinet layouts and service procedures.
The module receives 0 to 20 mA signals from field transmitters and instruments. Furthermore, its 12-bit conversion resolution provides digital measurement data for controller-level monitoring and regulation functions.
Frequently Asked Questions
Q: How many analog input channels does the ABB AI801 3BSE020512R1 provide?A: The AI801 provides 8 analog input channels configured for 0 to 20 mA current signals.
Q: What input impedance does the AI801 analog input channel use?A: Each input channel has an input impedance of 250 ohm for current signal measurement.
Q: What installation conditions should be considered for this module?A: The module should be installed in an ABB S800 I/O environment with correct backplane connection, proper grounding, and suitable cabinet ventilation according to system installation requirements.
Field Installation Guidelines
Install the AI801 module on the designated ABB S800 I/O mounting unit and verify correct mechanical locking before operation.
Connect field current loops using shielded industrial wiring where required by the installation environment.
Terminate cable shields according to site grounding practices to reduce electrical interference.
Separate analog signal wiring from high-voltage power cables and switching circuits.
Verify input polarity and current loop continuity before applying system power.
Confirm controller configuration parameters match the AI801 channel settings before commissioning.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB AI809 Analog Input Module
The ABB AI809 (AI809 Analog Input Module) provides analog signal acquisition for ABB S800 I/O systems through ABB industrial control networks. The module converts field analog inputs into process data for controller execution and monitoring functions.
Hardware Specifications
Parameter
Specification
Model
AI809
Brand
ABB
Product Type
Analog Input Module
Series
ABB S800 I/O
Origin
Sweden
Operating Temp
Industrial operating range; refer to ABB system installation specifications
Power Consumption
ModuleBus supplied; value depends on system configuration
Input Type
Analog input signals; configuration depends on application setup
Channel Configuration
Multi-channel analog acquisition module
Mounting Type
DIN rail mounting through ABB Module Termination Unit (MTU)
Communication Interface
ABB ModuleBus communication
Signal Conversion
Analog-to-digital signal conversion
Backplane Bus Communication and I/O Integration
The ABB AI809 operates within the ABB S800 I/O architecture and communicates process values through the ModuleBus interface. Therefore, the module supports distributed signal acquisition where field devices connect through dedicated termination units.
The module design follows ABB industrial I/O concepts, including firmware-based configuration, controller communication, and scalable I/O density expansion. In addition, the S800 platform allows integration with ABB control systems through standardized engineering tools.
The AI809 supports analog measurement processing where signal accuracy depends on field wiring quality, grounding configuration, and selected input parameters. Furthermore, proper channel configuration ensures correct data scaling between field instruments and the control application.
Frequently Asked Questions
Q: What system platform does the ABB AI809 support?A: The AI809 is designed for ABB S800 I/O system integration and communicates process data through the ABB ModuleBus interface.
Q: Does the AI809 require a separate termination unit for installation?A: Yes. The module is installed with an ABB Module Termination Unit (MTU), which provides field connection and mechanical mounting functions.
Q: What factors affect analog signal accuracy on the AI809?A: Signal accuracy depends on field transmitter calibration, cable shielding, grounding practices, and correct module channel configuration.
Field Installation Guidelines
Install the AI809 on the specified ABB S800 I/O mounting arrangement and verify mechanical locking before system startup.
Connect field analog wiring according to ABB terminal assignment documentation. Keep analog signal cables separated from high-voltage power cables to reduce electrical interference.
Use appropriate cable shielding and connect shields according to the plant grounding design. Verify field transmitter polarity, signal range settings, and controller channel configuration before commissioning.
Confirm ModuleBus communication status after installation and check diagnostic information through the ABB engineering environment.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB AI815 3BSE052604R1 Analog Input Unit - HART
The ABB AI815 3BSE052604R1, also cataloged as the AI815 Analog Input Unit, provides 8-channel analog signal acquisition with HART pass-through communication for ABB S800 I/O system platforms. The module processes unipolar single-ended current and voltage inputs for industrial measurement loops.
Hardware Specifications
Parameter
Specification
Model
AI815 3BSE052604R1
Brand
ABB
Product Type
Analog Input Unit - HART
Origin
Sweden
Weight
0.25 kg
Dimensions
4.5 x 11 x 11.8 cm (estimated shipping size)
Input Channels
8 channels
Signal Type
Unipolar single ended
Input Signal Range
0-20 mA, 4-20 mA, 0-5 V, 1-5 V DC
Resolution
12 bit
Isolation
1 group of 8 channels isolated from ground
Transmitter Supply
Current limited supply per channel
Communication Function
HART pass-through communication
Mounting Platform
ABB S800 I/O system
Backplane Bus Communication and I/O Density Scaling
The ABB AI815 module operates within the S800 I/O architecture and exchanges process data through the I/O system backplane communication interface. Therefore, the module supports structured channel allocation for distributed control configurations.
The unit provides 8 analog input channels with single-ended unipolar signal handling. Additionally, the HART pass-through function allows communication between compatible field transmitters and higher-level control systems without separate HART multiplexing hardware.
The module design supports I/O density scaling by integrating multiple analog channels into compact S800 I/O stations. Furthermore, channel grouping and grounding isolation reduce interference between field wiring and control electronics.
Frequently Asked Questions
Q: What input signals can the ABB AI815 3BSE052604R1 process?A: The AI815 supports 0-20 mA, 4-20 mA, 0-5 V, and 1-5 V DC unipolar single-ended analog input signals.
Q: Does the AI815 provide HART communication support?A: Yes. The module provides HART pass-through communication, allowing HART field device data transmission through the analog input channels.
Q: How are the input channels isolated in the AI815 module?A: The module provides one group of 8 channels isolated from ground. Field wiring practices should maintain proper shielding and grounding requirements.
Field Installation Guidelines
Install the AI815 module according to ABB S800 I/O system mechanical and electrical installation requirements.
Verify that field signal wiring matches the configured input type, including current or voltage measurement ranges.
Use shielded cables for analog signal connections in environments with electrical noise sources.
Connect cable shields according to the site grounding standard to reduce electromagnetic interference.
Separate analog signal wiring from high-voltage power cables and switching circuits.
Confirm terminal connections before applying field power to transmitters and input loops.
Check HART communication routing after completing loop wiring and controller configuration.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
ABB AI815-eA Analog Input HART Module
Configured for analog current and voltage signal acquisition in ABB S800 I/O systems, the ABB AI815-eA 3BSE052604R2 (AI815-eA Analog Input HART Module) provides direct physical signal conversion for 4-20 mA and voltage field inputs with integrated HART communication capability.
Hardware Specifications
Parameter
Specification
Model
AI815-eA 3BSE052604R2
Brand
ABB
Product Type
Analog Input HART Module
System Platform
ABB S800 I/O System
Origin
Sweden
Weight
Approximately 0.23 kg
Dimensions
Width 45 mm, Height 119 mm, Depth 102 mm, 111 mm including connector
Number of Channels
8 channels
Channel Configuration
1 group of 8 channels, single-ended with common return
Input Signal Range
0(4) to 20 mA, 0(1) to 5 V
Resolution
12 bits
HART Communication
Integrated HART protocol interface
Transmitter Power Supply
Current-limited transmitter power distribution
Compatible MTU Units
TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838
ABB S800 I/O Signal Processing and HART Communication
The AI815-eA module processes analog field signals through 8 input channels configured for single-ended measurement with a common return path. Therefore, each channel receives standard industrial current or voltage signals and converts them into digital values for ABB S800 I/O controller processing.
Additionally, the integrated HART interface supports digital communication over standard 4-20 mA current loops. The module can exchange field device information, configuration parameters, and diagnostic data without interrupting the primary analog measurement signal.
For ABB industrial control architectures, the module supports I/O density scaling through S800 I/O station expansion and maintains communication through the system backplane bus. The hardware design allows integration with compatible MTU configurations for simplified field wiring and cabinet installation.
Frequently Asked Questions
Q: Does the AI815-eA support both current and voltage input signals?A: Yes. The module supports 0(4) to 20 mA current inputs and 0(1) to 5 V voltage inputs through its 8 analog input channels.
Q: What HART function is integrated into the AI815-eA module?A: The module provides an integrated HART protocol interface that allows digital communication over 4-20 mA analog loops for field device data exchange.
Q: Which ABB termination units are compatible with the AI815-eA?A: The module supports TU810, TU812, TU814, TU818, TU830, TU833, TU835, and TU838 termination units.
Field Installation Guidelines
Install the AI815-eA module within an ABB S800 I/O station using the specified compatible termination unit.
Verify correct terminal assignment before connecting field current or voltage loops.
Separate analog signal wiring from high-voltage power cables to reduce electromagnetic interference.
Use shielded instrumentation cables for analog and HART communication loops where required by the installation design.
Connect cable shields according to the site grounding standard to prevent signal disturbance.
Confirm field transmitter power requirements before connecting devices to the current-limited transmitter supply output.
Check module addressing and controller configuration parameters before placing the I/O channel into operation.
15 in stock
Delivery within 48 hours, pay afterwards
Mid weeks Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.
Weekends We offer no deliveries in the weekends.
International Depending on where you’re located, we offer next day delivery. Check your status on this link
