The DS200SNPAH1ABB Protocol Interface Daughterboard from General Electric belongs to the Mark VIE LS2100 Series. This compact board weighs 0.06 kg and measures 2.5 x 13.2 x 5.5 cm, making it suitable for integration into control cabinets. Engineers rely on its isolated RS-484 and RS-232C communication to ensure stable data transmission between DSPC boards and Series 90-30 PLC systems.
Technical Specifications
| Parameter |
Value |
| Model Number |
DS200SNPAH1ABB |
| Module Type |
Protocol Interface Daughterboard |
| Manufacturer |
GE |
| Product Range |
Mark VIE / LS2100 |
| Condition |
Brand New |
| Weight |
0.06 kg |
| Dimensions |
2.5 x 13.2 x 5.5 cm |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
| Communication Service |
Ethernet router |
| Interfaces |
RS-484, RS-232C |
| Compatible Modules |
DS200DSPC, DS200ADMA
|
| PCB Coating |
Conformal for durability |
Functional Description
The DS200SNPAH1ABB board integrates with the DS200DSPC Digital Signal Processor Control Motherboard and the DS200ADMA Analog-to-Digital Module. It operates within a VMEbus rack, ensuring efficient communication between control modules and Series 90-30 PLC systems. Engineers benefit from its conformal PCB coating, which enhances durability in industrial environments.
This daughterboard supports isolated RS-484 and RS-232C interfaces, enabling reliable data exchange. Its compact design allows easy installation inside GE control cabinets. The product number encodes LS2100 classification, manufacturing origin, and revision details, helping users verify compatibility before deployment.
Applications and Compatibility
The DS200SNPAH1ABB Protocol Interface Daughterboard suits legacy LS2100 systems requiring stable communication with Series 90-30 PLCs. It integrates seamlessly with GE Mark VIE and Speedtronic MKVI assemblies, ensuring compatibility across industrial automation networks. Engineers deploy it in turbine control, excitation systems, and heavy industry applications where reliable protocol interfacing is essential.
