The ABB SDCS-CON-H01 3ADT320000R1501 Control Circuit Board delivers precise motor control and system monitoring for DCS800 drive systems. Engineers integrate this microprocessor-based module into Distributed Control Systems to achieve efficient energy use, seamless communication, and reliable performance in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
SDCS-CON-H01 3ADT320000R1501 |
| Manufacturer |
ABB |
| Module Type |
Control Circuit Board |
| Dimensions |
31.5 × 26 × 6 cm |
| Weight |
2.1 kg |
| HS Code |
8537101190 |
| System Compatibility |
DCS, DCS800 Drive Systems |
| Power Inputs |
+5 V, +12 V |
| Current Consumption |
|
| Interfaces |
RS-232, RS-485, MODBUS |
| Redundancy |
Dual-channel design |
| Operating Temperature |
0°C to +50°C |
| Storage Temperature |
-20°C to +70°C |
| Humidity Tolerance |
5% to 85% non-condensing |
| Origin |
Sweden |
| Condition |
Brand New |
| Status |
Active |
Functional Highlights
The ABB SDCS-CON-H01 3ADT320000R1501 operates on +5V and +12V inputs with efficient current consumption under 2A. Its dual-channel redundant design minimizes downtime, while RS-232 and RS-485 interfaces enable real-time communication. Advanced diagnostics and fault detection enhance reliability, and the compact design simplifies installation in space-constrained control cabinets.
Applications and Compatibility
The SDCS-CON-H01 3ADT320000R1501 Control Circuit Board integrates seamlessly into ABB DCS800 drive systems and Distributed Control Systems. Engineers deploy it in metal processing, cranes, and mining equipment where precise motor control and robust monitoring are essential. MODBUS compatibility ensures smooth integration with modern industrial automation networks.
Benefits
-
Large dimensions (31.5×26×6cm) provide robust housing for industrial environments.
-
Moderate weight (2.1kg) ensures durability and stable installation.
-
Dual redundancy design enhances system uptime and reliability.
-
RS-232/RS-485 interfaces support seamless industrial communication.
-
Advanced diagnostics improve fault detection and system monitoring.
-
Rugged construction ensures long-term performance in harsh conditions.
