The ABB AI810 3BSE008516R1 Analog Input Module provides high-precision signal acquisition for industrial automation. Engineers configure each of its eight channels for voltage or current inputs, ensuring flexibility across diverse sensor and transducer applications.
Technical Specifications
| Parameter |
Value |
| Model Number |
AI810 3BSE008516R1 |
| Module Type |
Analog Input Module |
| Manufacturer |
ABB |
| Condition |
Brand New |
| Range of Product |
Advant-800xA / S800 I/O |
| Dimensions |
18.5 × 8.5 × 30.5 cm |
| Weight |
1.08 kg |
| HS Code |
8537101190 |
| System |
DCS |
| Communication Service |
Ethernet Router, HART Protocol |
| Product Origin |
Sweden |
| MOQ |
1 |
| Lead Time |
In Stock |
| Status |
Active |
Functional Description
The ABB AI810 3BSE008516R1 supports voltage ranges of 0–10V or 2–10V and current ranges of 0–20mA or 4–20mA. Engineers benefit from its 12-bit resolution with ±0.1% full-scale accuracy, ensuring precise measurements. Channel-to-channel isolation rated at 2500V prevents interference, while built-in short-circuit protection and input shunt resistors safeguarded up to 30V enhance reliability.
Design and Build
The ABB AI810 3BSE008516R1 measures 18.5x8.5x30.5cm and weighs 1.08kg, making it compact yet durable. Its IP20-rated enclosure ensures safe operation within -20°C to +60°C. LED indicators simplify diagnostics, while robust construction guarantees dependable performance in electrically noisy environments.
Applications and Compatibility
The ABB AI810 3BSE008516R1 Analog Input Module integrates seamlessly with Advant-800xA and S800 I/O systems. Engineers deploy it in process control, machine automation, test measurement, and data acquisition projects requiring accurate analog signal processing. Its HART communication capability supports smart instrument integration and advanced diagnostics.
Key Benefits
-
Eight configurable channels for voltage or current inputs.
-
12-bit resolution ensures high accuracy in signal acquisition.
-
2500V isolation prevents interference between channels.
-
Compact IP20-rated design supports harsh industrial environments.
