The ABB BDFC-01C Fan Control Panel is a versatile digital frequency converter program designed for ACS880 drive systems. ABB engineered this module to deliver precise braking control, enhanced flexibility, and reliable performance in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
BDFC-01C |
| Manufacturer |
ABB |
| Module Type |
Fan Control Panel |
| Product Range |
ACS880 Drive Systems |
| Condition |
Brand New |
| Dimensions |
23.3 × 18.3 × 5.3 cm |
| Weight |
0.6 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
Sweden |
| System |
DCS |
| Communication Interface |
Ethernet Router |
| Status |
Active |
| Modulation Frequency |
1 kHz |
| Phase Shift |
120° |
| Protection Features |
Overcurrent, DC overvoltage, IGBT overtemperature, module overheating, resistor overheating |
Functional Description
The ABB BDFC-01C connects directly to the DC link of the drive and regulates braking power through precise pulse control of IGBTs. Its 1 kHz modulation frequency and 120° phase shift minimize DC voltage ripple, ensuring stable operation. Engineers benefit from continuous monitoring of phase currents, DC voltage, and module temperature, which enhances system safety and reliability. The compact 23.3 cm length and 5.3 cm thickness simplify installation, while the 0.6 kg weight reduces mechanical load.
Applications and Compatibility
The ABB BDFC-01C integrates seamlessly into ACS880 drive systems and supports parallel module connections for increased braking capacity. Manufacturers deploy this fan control panel in heavy machinery, energy plants, and automated production lines. Its IP65-rated design ensures protection against dust and water ingress, making it suitable for harsh industrial environments.
Key Advantages
-
Compact dimensions optimize cabinet space utilization.
-
Lightweight design simplifies installation and handling.
-
1 kHz modulation frequency ensures precise braking control.
-
Continuous monitoring protects against multiple system faults.
-
IP65 protection guarantees reliability in harsh environments.
