Overview
The ABB PFEA112-20 3BSE050091R20 Tension Controller delivers precise web tension management for continuous manufacturing processes. Engineers integrate this compact module into Distributed Control Systems to achieve fast response times, seamless PROFIBUS-DP communication, and reliable performance across diverse industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
PFEA112-20 3BSE050091R20 |
| Manufacturer |
ABB |
| Module Type |
Tension Controller |
| Dimensions |
8.5 × 13.6 × 5.2 cm |
| Weight |
0.3 kg |
| HS Code |
8537101190 |
| System Compatibility |
DCS |
| Accuracy |
±0.1% with dual load cells |
| Outputs |
0–10 VDC, 4–20 mA |
| Response Time |
≤1 ms |
| Display |
2×16 character LCD |
| Power Supply |
24 VDC (±10%) or 100–240 VAC |
| Power Consumption |
≤10 W |
| Enclosures |
IP20 DIN-rail, IP65 NEMA 4 |
| Operating Temperature |
0°C to +55°C |
| Humidity Tolerance |
5–95% non-condensing |
| Interfaces |
PROFIBUS-DP, Ethernet router |
| Origin |
Sweden |
| Condition |
Brand New |
| Status |
Active |
Functional Highlights
The ABB PFEA112-20 3BSE050091R20 processes signals from dual load cells with ±0.1% accuracy, ensuring precise tension control. Its lightning-fast ≤1ms response time supports real-time monitoring, while analog outputs provide flexible connectivity. The LCD display shows sum, difference, and individual load cell values, and configuration keys simplify parameter adjustments.
Applications and Compatibility
The PFEA112-20 3BSE050091R20 Tension Controller integrates seamlessly into ABB automation systems and Distributed Control Systems. Engineers deploy it in converting, printing, textile, and packaging industries where precise web tension management is critical. Its PROFIBUS-DP interface enables Industry 4.0 integration, while IP20 and IP65 enclosures ensure adaptability across clean and harsh environments.
Benefits
-
Compact dimensions (8.5×13.6×5.2cm) simplify installation in control panels.
-
Lightweight design (0.3kg) ensures easy handling and mounting.
-
Dual load cell inputs deliver ±0.1% accuracy for precise tension control.
-
PROFIBUS-DP interface enhances communication and system integration.
-
Fast ≤1ms response time supports real-time monitoring and control.
-
Rugged enclosures ensure reliable operation in diverse industrial conditions.
