General Electric GE IS210BAPAH1A Analog Processor Module
GE IS210BAPAH1A Analog Processor Module The GE IS210BAPAH1A, also cataloged as the IS210BAPA Analog Processor Module, operates as a dedicated hardware component for analog signal acquisition, conditioning, and processing within the GE Mark VI/Mark VIe Speedtronic turbine control system. The module receives field sensor inputs including temperature, pressure, vibration, and dynamic pressure signals for real-time control processing. Hardware Specifications Parameter Specification Model IS210BAPAH1A Brand GE Origin United States Functional Acronym BAPA Module Type Analog Processor Module / Safety I/O Pack System Compatibility Mark VI / Mark VIe Speedtronic Processor AMD G-Series dual-core, 1.6 GHz Memory 2 GB DDR3-1066 SDRAM Storage 128 GB Operating System QNX Neutrino RTOS Input Voltage 125 VDC Output Voltage 24 VDC Analog Input Channels 16 differential channels, configurable for 4-20 mA, +/-10 V, TC, RTD Analog Output Channels 8 channels, 0-20 mA A/D Resolution 14-bit Signal Sampling Rate 1 kHz per channel Communication Interfaces 2 x RJ45 Modbus TCP, 1 x RS-485 Mounting DIN-rail PCB Coating Conformal Coating Weight 0.8 kg Operating Temp -30 to +65 deg C Profinet / EtherNet/IP Deterministic Networks and Analog Processing The IS210BAPAH1A integrates analog processing functions within the GE Mark VI/Mark VIe control platform. The module performs signal filtering, scaling, and analog-to-digital conversion before transferring processed values through the controller communication architecture. The module supports firmware flash compatibility within the Mark VIe control environment and provides processor-based execution for real-time analog measurement handling. Its I/O density scaling capability allows multiple sensor input types to be processed through configurable differential channels. For turbine control applications, the BAPA module can process dynamic pressure and acoustic monitoring signals from combustion monitoring sensors. Signal conditioning functions remove unwanted DC components and prepare AC signal content for digital analysis. Frequently Asked Questions Q: What type of field signals can the IS210BAPAH1A process?A: The module supports differential analog inputs including 4-20 mA, +/-10 V, thermocouple, and RTD signal types. Q: What mounting method is specified for the IS210BAPAH1A?A: The module is designed for DIN-rail mounting within the Mark VIe control hardware configuration. Q: What communication interfaces are available on the IS210BAPAH1A?A: The module provides Ethernet communication through 2 x RJ45 interfaces supporting Modbus TCP and an RS-485 interface. Field Installation Guidelines Install the IS210BAPAH1A on the designated DIN-rail mounting location and verify power polarity before applying 125 VDC input power. Connect analog field wiring according to the configured channel assignment and signal type. Use shielded cables for low-level analog sensor connections where required. Ground cable shields according to cabinet grounding practices and route analog signal wiring separately from high-current switching conductors. Verify communication cable termination and network addressing before controller integration.
$200.00 $100.00
-
General Electric GE IS200EPCTG1A Exciter PT/CT Terminal Board
GE IS200EPCTG1A Exciter PT/CT Terminal Board Configured for generator PT/CT signal acquisition and conditioning in the GE EX2100 Excitation Control System, the GE IS200EPCTG1A (IS200EPCT Exciter PT/CT Terminal Board) provides direct physical/electrical execution for voltage and current feedback interface functions. The board receives three-phase PT and CT measurement signals, performs signal conditioning, and transfers isolated measurement outputs to the excitation control rack. Hardware Specifications Parameter Specification Model IS200EPCTG1A Brand GE Origin United States Board Type Exciter PT/CT Terminal Board Series EX2100 Excitation Control System Input Signals 2 x 3-phase PT inputs, 2 x CT inputs PT Input Rating 115 V rms, 50/60 Hz CT Input Rating 1 A / 5 A Analog Output 0-10 V or 4-20 mA Input Burden <= 1 VA Signal Isolation 500 Vrms Power Supply Voltage 28 VDC Weight 0.98 kg Dimensions 33.1 cm x 11.5 cm x 4.5 cm Operating Temp -30 to +65 deg C Power Consumption Not specified Firmware Flash Compatibility and Excitation Control Interface The IS200EPCTG1A operates as an EX2100 excitation system terminal interface board, providing PT/CT measurement routing between generator sensing devices and the excitation controller. The board supports industrial control signal conditioning through dedicated analog input paths and isolated output channels. The module integrates with GE excitation control assemblies using backplane communication structures. Its design supports firmware flash compatibility within the EX2100 control platform and allows I/O density scaling through coordinated terminal board configurations. The PT/CT interface maintains measurement signal integrity by applying input scaling, electrical isolation, and signal filtering. Differential signal handling reduces interference from field wiring environments and supports stable generator voltage and current regulation loops. Frequently Asked Questions Q: What measurement signals are connected to the IS200EPCTG1A?A: The board accepts generator PT voltage feedback signals and CT current feedback signals from excitation system sensing circuits. Q: What isolation function is provided by the IS200EPCTG1A?A: The board provides electrical isolation between PT/CT field measurement circuits and the excitation control electronics to limit fault transfer. Q: What EX2100 system role does this board perform?A: The IS200EPCTG1A functions as a PT/CT terminal interface board for generator voltage and current feedback processing within the EX2100 excitation control system. Field Installation Guidelines Install the IS200EPCTG1A in the designated EX2100 chassis backplane position and verify terminal assignments before connecting PT and CT field wiring. Use properly rated wiring for generator measurement circuits and maintain separation between analog measurement cables and high-current power conductors. Connect cable shields according to the excitation cabinet grounding design to reduce EMI/RFI interference. Confirm CT polarity, PT phase sequence, and signal reference points before system energization. Verify all terminal connections and isolation requirements during commissioning.
$200.00 $100.00
-
General Electric IS200TSVCH2A GE Servo Terminal Board
GE IS200TSVCH2A Servo Terminal Board The GE IS200TSVCH2A, also cataloged as the IS200TSVC Servo Terminal Board, provides physical signal interfacing for electro-hydraulic servo valve control within the GE Mark VI Speedtronic turbine control system. The board processes analog servo command signals and LVDT feedback connections to execute closed-loop actuator positioning through dedicated servo channels. Hardware Specifications Parameter Specification Model IS200TSVCH2A Brand GE Origin United States Board Type Servo Terminal Board System Compatibility Mark VI Speedtronic turbine control system Signal Type Analog servo control signals Servo Channels 4 independent servo channels Operating Voltage 24 VDC / 125 VDC Output Voltage Range -10 V to +10 V Output Current +/-100 mA per channel Communication Interface VMEbus / backplane bus Weight 0.45 kg Dimensions 200 mm x 150 mm x 35 mm Operating Temp -20 to +65 deg C Power Consumption Approx. 15 W Industrial Control Signal Conditioning and Servo Interface The IS200TSVCH2A integrates with the GE Mark VI Speedtronic architecture through backplane communication and dedicated terminal connections. The board supports analog servo command output, LVDT feedback signal processing, and electro-hydraulic actuator loop control. The servo interface uses differential signal paths and signal conditioning circuits to reduce electrical noise influence in actuator feedback loops. The board supports servo valve current regulation through independent channels and provides connection points for turbine fuel valves, inlet guide vane actuators, and steam admission valve systems. The module design supports GE turbine control configurations using redundant control architectures. Firmware flash compatibility and backplane bus communication functions allow integration with Mark VI controller assemblies. Frequently Asked Questions Q: What type of actuator signals does the IS200TSVCH2A process?A: The board processes analog servo control signals for electro-hydraulic servo valves and interfaces with LVDT feedback devices for closed-loop positioning. Q: How many servo control channels are available on the IS200TSVCH2A?A: The module provides 4 independent servo channels for actuator control and feedback signal termination. Q: Can the board be replaced during system operation?A: Hot replacement depends on the Mark VI rack configuration and operating procedure. Servo loops should be placed in an appropriate maintenance state before module replacement. Field Installation Guidelines Install the IS200TSVCH2A in the designated Mark VI control rack location and verify correct terminal assignments before connecting field wiring. Use shielded twisted-pair cables for analog servo and feedback signals where required by the installation design. Terminate cable shields according to the turbine control cabinet grounding practice to reduce EMI/RFI coupling. Separate low-level analog signal wiring from high-current power conductors and switching circuits. Verify actuator loop polarity, feedback direction, and terminal identification before energizing the control system.
$200.00 $100.00
-
General Electric GE IS200SPROH1ADD Backup Protection Terminal Board
GE IS200SPROH1ADD Backup Protection Terminal Board The GE IS200SPROH1ADD, also cataloged as the IS200SPROH1A Backup Protection Terminal Board, operates as a dedicated hardware component for independent voltage sensing and relay interfacing within the GE Mark VI Speedtronic turbine control system. Hardware Specifications Parameter Specification Model IS200SPROH1ADD Brand GE (General Electric) Origin United States Product Type Backup Protection Terminal Board System Compatibility Mark VI Speedtronic Turbine Control System Board Function Backup protection, voltage sensing, relay interfacing Input Voltage 24 VDC power supply Relay Channels 12 Generator and Bus Voltage Sensors 2 Magnetic Speed Pickup Sensitivity 27 mV Magnetic Speed Pickup Pulse Rate Range 2 Hz Protection Rating IP20 Mounting DIN-rail or panel-mounted Weight 0.5 kg Operating Temp -30 to 65 deg C GE Mark VI Speedtronic Protection Interface Characteristics The IS200SPROH1ADD provides backup protection functions through independent signal acquisition and relay interface circuits. The terminal board supports voltage monitoring paths, magnetic speed pickup input processing, and relay channel execution for turbine protection sequences. The board incorporates galvanic relay interfacing to maintain electrical separation between field signals and control circuits. Relay state monitoring and isolated signal paths reduce unwanted switching caused by electrical interference within turbine control environments. The hardware architecture supports fail-safe state execution by maintaining independent protection paths when primary controller communication or processing functions are unavailable. Signal conditioning circuits process magnetic speed pickup inputs with defined sensitivity characteristics for protection logic evaluation. Frequently Asked Questions Q: What type of signals does the IS200SPROH1ADD process?A: The board processes voltage sensing inputs, relay interface signals, and magnetic speed pickup signals for turbine protection functions. Q: How many relay channels are available on this terminal board?A: The IS200SPROH1ADD provides 12 relay channels for protection-related switching and interface functions. Q: What installation methods are supported for this board?A: The board supports DIN-rail or panel-mounted installation depending on system cabinet configuration. Field Installation Guidelines Install the IS200SPROH1ADD in a suitable control cabinet environment with correct mechanical fixation and electrical clearance. Verify terminal assignments before connecting field wiring. Use shielded cables for low-level sensing and speed pickup circuits where electromagnetic interference is present. Connect cable shields according to the grounding practices defined for the Mark VI Speedtronic control cabinet. Separate signal wiring from high-current power conductors and relay switching lines to reduce electrical noise coupling. Confirm power polarity, grounding continuity, and relay interface wiring before energizing the protection circuit.
$200.00 $100.00
-
General Electric GE IS200JPDDG1AAA Mark VI DC Power Distribution Board
GE IS200JPDDG1AAA Mark VI DC Power Distribution Board The GE IS200JPDDG1AAA, also cataloged as the IS200JPDDG1AAA DC Power Distribution Board, operates as a dedicated hardware component for redundant DC power distribution and protection within the GE Mark VI/Mark VIe turbine control platform. It distributes DC supply inputs to controllers, I/O packs, and auxiliary devices through fused output channels. Hardware Specifications Parameter Specification Model IS200JPDDG1AAA Brand GE Product Type DC Power Distribution Boards System Platform Mark VI / Mark VIe Speedtronic Turbine Control System Board Type Jumper Power Distribution Dual (JPDD) Board Input Voltage 24 VDC nominal (20 to 30 VDC); variants support 48 VDC or 125 VDC Redundancy Dual or triple redundant input feeds with automatic failover Outputs 10 to 16 fused output channels Output Current Up to 8 A per channel, 32 A total continuous Fuse Type Replaceable OEM 5 x 20 mm fast-blow fuses Diagnostic Feedback Fault telemetry to IS220PPDA modules Isolation 2500 VAC galvanic separation between power and feedback circuits Mounting DIN rail or rack-mounted Protection Features Conformal coating and surge suppression Microprocessor Intel Celeron 300 MHz Operating System QNX Operating Temp -40 to +70 deg C Storage Temp -40 to +85 deg C Humidity 5% to 95% non-condensing Weight 0.9 kg Industrial Control Power Distribution Characteristics The GE IS200JPDDG1AAA provides DC power distribution functions within the Mark VI/Mark VIe turbine control cabinet architecture. The board accepts redundant DC input sources and distributes protected power through individually fused output branches for controllers, I/O packs, trip solenoids, and auxiliary monitoring devices. The JPDD board supports industrial control power architecture through I/O density scaling and structured DC branch distribution. Diagnostic feedback circuits provide status information including fuse loss, undervoltage conditions, and ground fault monitoring through compatible IS220PPDA interface modules. The AAA suffix configuration includes conformal coating for environmental protection against dust, humidity, and oil mist exposure. Hardware replacement requires verification of controller configuration and firmware flash compatibility within the Mark VI/Mark VIe platform. Frequently Asked Questions Q: What input voltage ranges are supported by the IS200JPDDG1AAA?A: The board supports 24 VDC nominal input operation, with variants available for 48 VDC and 125 VDC supply configurations. Q: How are output faults isolated on this power distribution board?A: Individual fused output channels isolate branch faults to prevent a single output fault from affecting the complete DC distribution bus. Q: What diagnostic information can be transmitted from the board?A: The board provides diagnostic feedback including fuse status, undervoltage conditions, and ground fault indications through compatible PPDA modules. Field Installation Guidelines Install the IS200JPDDG1AAA in the designated Mark VI/Mark VIe turbine control cabinet location using the specified DIN rail or rack mounting hardware. Verify DC input polarity and redundant supply connections before energizing the board. Route DC power wiring separately from low-level signal cables to reduce electromagnetic interference. Use appropriate grounding methods for the cabinet structure and verify protective earth connections. Check all output fuse ratings, field wiring assignments, and connected device power requirements before commissioning. Confirm diagnostic communication with the IS220PPDA interface and verify power distribution status after installation.
$200.00 $100.00
-
General Electric GE IS200EACFG1BAA EX2100 Exciter AC Feedback Board
GE IS200EACFG1BAA EX2100 Exciter AC Feedback Board The GE IS200EACFG1BAA, also cataloged as the IS200EACFG1BAA Exciter AC Feedback Board, operates as a dedicated hardware component for generator AC signal acquisition and feedback conditioning within the GE EX2100 excitation control system. It processes PT and CT inputs and transfers scaled feedback signals to the excitation controller. Hardware Specifications Parameter Specification Model IS200EACFG1BAA Brand GE Product Type Exciter AC Feedback Boards System Platform EX2100 Excitation Control System Board Type Exciter AC Feedback Board Input Signals Generator PT and CT feedback signals Voltage Input 115 V rms nominal Current Input 1 A or 5 A CT input Analog Output Scaled signals to EMIO, 0-10 V or 4-20 mA Isolation 500 Vrms channel-to-earth Mounting Exciter chassis backplane Protection Features Conformal coating and EMI shielding Compliance UL 508, IEC 61010-1, RoHS 3 Operating Temp -30 to +65 deg C Storage Temp -40 to +85 deg C Humidity 5% to 95% non-condensing Origin United States Industrial Control Interface and Firmware Compatibility The GE IS200EACFG1BAA performs AC feedback signal acquisition and conditioning within the EX2100 excitation architecture. The board receives generator voltage and current feedback from PT and CT circuits, converts these signals into scaled analog outputs, and transfers measurement data through the EMIO interface. The module supports deterministic signal exchange within GE excitation control hardware. Its signal conditioning circuitry provides channel isolation and feedback scaling for excitation regulation calculations. The EX2100 platform requires correct hardware identification and firmware flash compatibility when installing replacement boards. I/O configuration parameters must match the installed controller setup before operation. Frequently Asked Questions Q: What type of electrical feedback signals are connected to the IS200EACFG1BAA?A: The board accepts generator PT voltage feedback and CT current feedback signals for excitation regulation processing. Q: What analog outputs are provided by the board?A: The board provides scaled feedback signals to the EMIO interface using 0-10 V or 4-20 mA signal formats. Q: How is the board installed in the EX2100 system?A: The IS200EACFG1BAA is installed in the exciter chassis backplane and interfaces with the EMIO board and exciter controller. Field Installation Guidelines Install the IS200EACFG1BAA in the designated EX2100 exciter chassis backplane position and verify all backplane connections before energizing the system. Connect PT and CT feedback wiring according to the excitation cabinet drawings. Maintain proper separation between low-level analog feedback cables and high-energy excitation conductors to reduce electromagnetic interference. Use shielded signal wiring where required and terminate shields according to the cabinet grounding scheme. Verify CT polarity, PT wiring orientation, and isolation requirements before commissioning. Confirm controller configuration, I/O scaling parameters, and hardware compatibility before placing the excitation system into service.
$200.00 $100.00
-
General Electric GE IS200ERQCH1A EX2100 Exciter Regulator Quick Connect Board
GE IS200ERQCH1A EX2100 Exciter Regulator Quick Connect Board The GE IS200ERQCH1A, also cataloged as the IS200ERQCH1A Exciter Regulator Quick Connect Board, operates as a dedicated hardware component for excitation signal termination and connector interface processing within the GE EX2100 excitation control system. It provides plug-in termination paths for auxiliary contacts, relay outputs, and analog feedback circuits. Hardware Specifications Parameter Specification Model IS200ERQCH1A Brand GE Product Type Exciter Regulator Quick Connect Boards System Platform EX2100 Excitation Control System Board Type Exciter Regulator Quick Connect Board Inputs Auxiliary contact inputs Contact Wetting Voltage 70 VDC (63 to 84 VDC range) Relay Outputs Trip relays and general-purpose Form-C relays Analog Signals PT/CT feedback signals for generator voltage and current Control Voltage 24 VDC Customer Power 125 VDC Isolation 500 VDC channel-to-earth isolation for relay contacts Mounting Quick-connect chassis interface Protection Features Conformal coating and EMI shielding Operating Temp 0 to +60 deg C Storage Temp -40 to +85 deg C Humidity 5% to 95% non-condensing Origin United States Industrial Control Interface and Firmware Compatibility The GE IS200ERQCH1A provides a quick-connect termination interface between EX2100 controller assemblies and external excitation system wiring. The board supports connection of auxiliary contact inputs, relay command circuits, and analog generator feedback signals through dedicated plug-in termination points. Within the EX2100 platform, the board interfaces with ERIO and EMIO assemblies to maintain configured I/O signal paths. The hardware design supports I/O density scaling through structured connector termination and reduces field wiring complexity during cabinet installation. Firmware flash compatibility and hardware revision matching must be verified when integrating the board into an existing EX2100 excitation controller configuration. Frequently Asked Questions Q: What type of signals are terminated through the IS200ERQCH1A?A: The board provides termination interfaces for auxiliary contact inputs, trip relay outputs, general-purpose Form-C relay circuits, and PT/CT analog feedback signals. Q: What is the specified contact wetting voltage for auxiliary inputs?A: Auxiliary contact inputs use 70 VDC wetting voltage with an operating range of 63 to 84 VDC. Q: How is the IS200ERQCH1A connected within the EX2100 system?A: The board uses a quick-connect chassis interface and communicates through connected ERIO/EMIO boards within the excitation control architecture. Field Installation Guidelines Install the IS200ERQCH1A on the designated EX2100 chassis interface location and verify connector engagement before system startup. Confirm all auxiliary input, relay output, and analog feedback wiring assignments according to the cabinet wiring documentation. Maintain separation between analog signal cables and high-current excitation conductors to minimize electromagnetic interference. Apply shield grounding practices according to the control cabinet grounding design. Verify control voltage, customer power connections, and relay contact isolation requirements before energizing the excitation system. Confirm hardware configuration and I/O mapping after installation.
$200.00 $100.00
-
General Electric GE IS200ERIOH1ACB EX2100 Exciter Regulator I/O Board
GE IS200ERIOH1ACB EX2100 Exciter Regulator I/O Board Configured for excitation system signal termination and relay interface execution in the GE EX2100 excitation control platform, the GE IS200ERIOH1ACB (IS200ERIOH1ACB Exciter Regulator I/O Board) provides direct physical/electrical execution between controller hardware and external contact, relay, and analog feedback circuits. Hardware Specifications Parameter Specification Model IS200ERIOH1ACB Brand GE Product Type Exciter Regulator Main I/O Board System Platform EX2100 Excitation Control System Board Type Exciter Regulator I/O Board Inputs Multiple auxiliary contact inputs Contact Wetting Voltage 70 VDC (63 to 84 VDC range) Relay Outputs Trip relays and general-purpose Form-C relays Analog Signals Generator PT/CT voltage and current feedback signals Control Voltage 24 VDC Customer Power 125 VDC Isolation 500 VDC channel-to-earth isolation for relay contacts Mounting Exciter chassis backplane Revision Total 3 revisions Backward Compatibility First two revisions compatible Operating Temp 0 to +60 deg C Storage Temp -40 to +85 deg C Humidity 5% to 95% non-condensing Industrial Control Interface and Firmware Compatibility The GE IS200ERIOH1ACB operates as an I/O expansion and termination interface within the EX2100 excitation control architecture. The board provides electrical connection points for auxiliary contact monitoring, relay command circuits, and generator feedback signals exchanged with the exciter controller. The board interfaces with the EMIO board and supports deterministic signal transfer within the excitation control hardware structure. Revision compatibility must be verified before replacement installation, as only the first two revisions maintain backward compatibility. The EX2100 platform uses configured I/O mapping and firmware-based hardware identification. Proper firmware flash compatibility checking is required when integrating the board into an existing controller assembly. Frequently Asked Questions Q: What field signals can be connected to the IS200ERIOH1ACB?A: The board supports auxiliary contact inputs, trip relay outputs, general-purpose Form-C relay outputs, and analog feedback signals from generator PT/CT circuits. Q: What is the contact wetting voltage specification for this board?A: The auxiliary contact inputs use 70 VDC wetting voltage with an operating range of 63 to 84 VDC. Q: How many revisions exist for the IS200ERIOH1ACB?A: The board has three revisions, with the first two revisions specified as backward-compatible. Field Installation Guidelines Install the IS200ERIOH1ACB in the designated EX2100 exciter chassis backplane position and secure the board using the specified mechanical mounting hardware. Verify all field wiring assignments before connecting contact, relay, and analog signal terminals. Route analog feedback wiring separately from high-current excitation conductors to reduce electromagnetic interference. Use appropriate shield termination practices according to cabinet grounding design requirements. Confirm board revision compatibility, controller configuration parameters, and I/O mapping before system energization. Check relay contact wiring polarity and isolation requirements before applying customer power connections.
$200.00 $100.00
-
General Electric IS200VRTDH1DAA GE Mark VI RTD Input Board
GE IS200VRTDH1DAA Mark VI RTD Input Board The GE IS200VRTDH1DAA, also cataloged as the IS200VRTDH1DAA RTD Input Board, operates as a dedicated temperature acquisition hardware component for RTD signal conversion within the GE Mark VI VME control platform. It accepts 16 three-wire RTD inputs, performs 14-bit analog-to-digital conversion, and transfers temperature data through the VME backplane for turbine control monitoring. Hardware Specifications Parameter Specification Model IS200VRTDH1DAA Brand GE Product Type RTD Input Board System Platform Mark VI Speedtronic VME Control System Inputs 16 three-wire RTD channels Sensor Type Platinum RTD sensors, including Pt100 Excitation Current 10 mA DC multiplexed A/D Resolution 14-bit Mounting VME rack with front-panel screws Indicators 3 LED status indicators Isolation Channel-to-earth isolation Operating Temp -30 to +65 deg C Storage Temp -40 to +85 deg C Humidity 5% to 95% non-condensing RTD Signal Processing and VME Interface Characteristics The IS200VRTDH1DAA provides RTD measurement acquisition through multiplexed excitation and digital conversion circuitry. The board processes resistance variations from platinum RTD elements and outputs digitized temperature values through the Mark VI VME backplane communication path. The board supports simplex and TMR (Triple Modular Redundancy) configurations within Mark VI architectures. Firmware revision compatibility must be verified when replacing boards, as the D-rated revision and A-rated revisions have defined backward compatibility limitations. The hardware design includes conformal coating, EMI shielding, and vibration resistance features for turbine control cabinet installation. LED indicators provide local status information for board health monitoring. Firmware and Industrial Control Compatibility The GE Mark VI platform uses deterministic VME backplane communication for controller-to-I/O data exchange. The IS200VRTDH1DAA integrates with the Speedtronic control architecture through configured I/O addressing and board-level firmware functions. The board supports industrial control requirements including I/O density scaling within VME racks and compatibility verification across Mark VI hardware revisions. Proper firmware matching is required when integrating replacement modules into existing controller configurations. Frequently Asked Questions Q: How many RTD input channels are available on the IS200VRTDH1DAA?A: The board provides 16 three-wire RTD input channels for temperature signal acquisition. Q: What type of RTD sensors can be connected to this board?A: The module is designed for platinum RTD sensors, including Pt100 type sensors, with multiplexed 10 mA DC excitation. Q: Can the board operate in redundant configurations?A: The IS200VRTDH1DAA supports simplex and TMR configurations within GE Mark VI control architectures. Field Installation Guidelines Install the IS200VRTDH1DAA in the designated GE Mark VI VME rack location using the front-panel mounting hardware. Verify that RTD wiring is correctly terminated at the associated terminal boards before connecting field cables. Use shielded instrumentation wiring for RTD signal connections where required by site electrical standards. Maintain separation between low-level RTD signal cables and high-current power conductors to reduce electromagnetic interference. Confirm controller configuration, board revision compatibility, and I/O addressing before commissioning. Ensure grounding paths follow the cabinet design requirements for channel-to-earth isolation performance.
$200.00 $100.00
-
General Electric GE IS200EPCTG1AZZ Exciter PT/CT Terminal Board
GE IS200EPCTG1AZZ Exciter PT/CT Terminal Board The GE IS200EPCTG1AZZ, also cataloged as the IS200EPCT Exciter PT/CT Terminal Board, operates as a dedicated hardware component for generator voltage and current signal acquisition within GE EX2100 excitation control systems. The board receives PT/CT feedback, performs signal conditioning and isolation, and transfers scaled analog signals to the EMIO interface. Suffix Breakdown & Model Matrix Model Element Description IS200 GE Mark VI/EX2100 control hardware family EPCT Exciter PT/CT Terminal Board functional designation G1 Board hardware revision identifier AZZ Factory configuration and ordering suffix The IS200EPCTG1AZZ is configured as an EPCT terminal interface board for EX2100 excitation applications. The available configuration supports generator feedback measurement through PT and CT input circuits and provides conditioned outputs for excitation regulation processing. Hardware Specifications Parameter Specification Model IS200EPCTG1AZZ Brand GE Origin United States Weight 0.5 kg Dimensions 232 mm x 165 mm x 89 mm Operating Temp -40 deg C to +85 deg C Power Consumption Low-power signal conditioning and interface processing Module Type Exciter PT/CT Terminal Board Series EX2100 PT Inputs 2 x three-phase PT inputs, 115 V rms, 50/60 Hz CT Inputs 2 x CT inputs, 1 A or 5 A Analog Output 0-10 V or 4-20 mA Input Burden <= 1 VA Signal Isolation 500 Vrms Mounting Type EX2100 chassis backplane mount Wiring Capacity Up to #10 AWG Maximum Cable Length Up to 1000 ft Humidity Range 5%-95% non-condensing Compliance UL 508, IEC 61010-1, RoHS 3 Profinet and Industrial Control Signal Interface Characteristics The IS200EPCTG1AZZ provides generator feedback interface functions within the GE EX2100 excitation control architecture. The board converts PT voltage measurements and CT current feedback signals into conditioned analog outputs for EMIO board processing. The module applies signal isolation between measurement circuits and control interfaces. Its analog output scaling supports 0-10 V and 4-20 mA transmission formats used for excitation regulation feedback paths. The hardware design supports deterministic signal transfer between field measurement devices and the excitation controller. The EPCT board supports I/O density scaling within EX2100 configurations by providing multiple three-phase PT input channels and CT measurement inputs on a single terminal interface assembly. The module can be integrated into simplex and TMR excitation system configurations depending on system architecture requirements. Frequently Asked Questions Q: What type of feedback signals can the IS200EPCTG1AZZ process?A: The board processes generator PT voltage inputs and CT current inputs, providing conditioned analog outputs for excitation control processing. Q: What analog output signals are available from the EPCT board?A: The IS200EPCTG1AZZ provides scaled analog outputs in 0-10 V or 4-20 mA formats. Q: What isolation level is provided between signal circuits?A: The board provides 500 Vrms signal isolation between measurement circuits and interface paths. Field Installation Guidelines Install the IS200EPCTG1AZZ on the designated EX2100 chassis mounting location and verify terminal assignments before connecting PT and CT field wiring. Use appropriately rated wiring for generator voltage and current measurement circuits. Maintain separation between PT/CT signal cables and high-current power conductors to reduce electromagnetic interference. Terminate cable shields according to excitation cabinet grounding practices. Verify CT polarity, PT phase sequence, and terminal tightness before energizing the excitation system. Inspect board connectors, terminal blocks, and conformal-coated surfaces during installation. Confirm that wiring routing follows cabinet clearance and thermal management requirements.
$200.00 $100.00
-
General Electric IS200ECTBG2A GE EX2100 Exciter Contact Terminal Board
GE IS200ECTBG2A Exciter Contact Terminal Board Configured for contact signal termination and relay control execution in GE EX2100/EX2100e excitation control systems, the GE IS200ECTBG2A (IS200ECTB Exciter Contact Terminal Board) provides direct physical/electrical execution for auxiliary contact inputs, trip relay outputs, and general-purpose relay interfaces in simplex excitation architectures. Hardware Specifications Parameter Specification Model IS200ECTBG2A Brand GE Origin United States Weight 0.34 kg Dimensions 150 x 76 x 90 mm Operating Temp 0 deg C to +60 deg C Power Consumption Relay and contact interface board power consumption Module Type Exciter Contact Terminal Board (ECTB) Series EX2100 Operating Mode Simplex mode only Form Factor Exciter cabinet chassis-mounted terminal board Relay Control Voltage 24 VDC Customer Power Input 125 VDC Wetting Voltage 70 VDC (63-84 VDC range) Relay Configuration 2 Form-C trip relays and 4 Form-C general-purpose relays Auxiliary Inputs 6 powered/wetted auxiliary contact inputs Relay Contact Isolation 500 VDC channel-to-earth isolation Protection Features Conformal coating and LED status indicators EtherNet/IP and Industrial Control Signal Interface Characteristics The IS200ECTBG2A is designed for GE EX2100 excitation control architectures and performs discrete signal termination between field contacts, relay circuits, and the excitation controller interface. The board routes auxiliary contact inputs and relay outputs associated with generator breaker monitoring, lockout functions, and auxiliary sequencing circuits. The EX2100 ECTB interface uses dedicated relay and contact circuits rather than analog measurement channels. The board supports simplex execution only, with the G2 configuration identifying single-channel operation. Relay outputs include two Form-C trip relays for protection-related circuits and four Form-C general-purpose relays for auxiliary control functions. The module follows GE industrial control hardware practices including conformal PCB coating, electrical isolation between relay circuits and earth reference, and compatibility with excitation cabinet wiring structures. The contact interface design supports discrete I/O density scaling within the EX2100 excitation platform. Frequently Asked Questions Q: What operating architecture is supported by the IS200ECTBG2A?A: The IS200ECTBG2A supports simplex mode operation only and is configured for single-channel EX2100 excitation system installations. Q: What type of relay outputs are provided on the ECTB board?A: The board provides two Form-C trip relay outputs and four Form-C general-purpose Form-C relay outputs for discrete control circuits. Q: What field input signals can be connected to the IS200ECTBG2A?A: The board supports six powered/wetted auxiliary contact inputs, including monitored signals such as generator breaker and lockout status contacts. Field Installation Guidelines Install the IS200ECTBG2A in the designated EX2100 excitation cabinet location and verify terminal assignments against the GEH-6632 instruction manual before field wiring. Use properly rated field wiring for 125 VDC customer power circuits and relay contact connections. Separate low-level signal wiring from high-current switching conductors to reduce electrical interference. Terminate cable shields according to cabinet grounding practices where shielded wiring is applied. Verify relay contact polarity, auxiliary input wiring, and protective earth connections before applying system power. Inspect terminal blocks, board connectors, and conformal-coated surfaces during installation to ensure no mechanical damage or contamination is present.
$200.00 $100.00
-
GE IS210SAMBH2AA GE Mark VI Servo Amplifier Module
GE IS210SAMBH2AA Mark VI Servo Amplifier Module The GE IS210SAMBH2AA, also cataloged as the IS210SAMB Servo Amplifier Module, operates as a dedicated hardware component for hydraulic actuator current control within the GE Speedtronic Mark VI turbine control system. The module converts digital commands into proportional servo valve drive current with LVDT feedback processing. Hardware Specifications Parameter Specification Model IS210SAMBH2AA Brand GE Origin United States Weight 0.35 kg Operating Temp -30 to +65 deg C Power Consumption Supplied by +28 VDC nominal input Product Type Servo Amplifier Modules Function Servo amplifier for hydraulic actuators Inputs LVDT feedback signals, up to 2 channels Outputs +/-200 mA current drive for servo valves Resolution 16-bit digital-to-analog conversion Accuracy +/-0.1% of full scale Communication Interface Mark VI controller backplane interface Mounting Rack mount, Mark VI chassis compatible PCB Protection Conformal coating Deterministic Servo Control and Actuator Feedback Processing The IS210SAMBH2AA applies GE Mark VI industrial control architecture for closed-loop hydraulic actuator control. The module receives digital control signals from the controller, converts them into proportional current outputs, and drives servo valves connected to turbine actuators. The Mark VI platform supports deterministic controller communication and I/O density scaling through modular hardware structures. The servo amplifier module processes LVDT feedback signals to maintain actuator position control loops. Firmware flash compatibility must correspond with the installed Mark VI controller hardware revision and system configuration. Frequently Asked Questions Q: What type of actuator interface does the IS210SAMBH2AA provide?A: The module provides proportional current drive outputs for hydraulic servo valves, with outputs rated at +/-200 mA. Q: How does the module process valve position feedback?A: The IS210SAMBH2AA accepts LVDT feedback signals and integrates them into closed-loop actuator control functions. Q: Is the module compatible with redundant Mark VI configurations?A: The module supports Mark VI system architectures including simplex and TMR (Triple Modular Redundancy) configurations. Field Installation Guidelines Install the IS210SAMBH2AA in the assigned Mark VI rack position and verify proper mechanical seating with the chassis backplane connector. Check servo valve wiring polarity, LVDT feedback connections, and actuator loop configuration before system startup. Keep feedback and current drive wiring separated from high-voltage switching circuits to reduce electrical interference. Use shielded cables where required and terminate cable shields according to site grounding practices. Inspect rack mounting, backplane engagement, and grounding continuity before applying operating power.
$200.00 $100.00
-
General Electric IS210AEBIH2B GE Mark VI AE Bridge Interface Module
GE IS210AEBIH2B AE Bridge Interface Module The GE IS210AEBIH2B, also identified as the IS210AEBI AE Bridge Interface Module, provides hardware-level communication interface functions within GE Mark VI/Mark VIe turbine control platforms. The module performs data routing, synchronization, and diagnostic signal exchange between controllers, I/O subsystems, and the VME backplane through a 24 VDC powered industrial PCB assembly. Hardware Specifications Parameter Specification Model IS210AEBIH2B Brand GE Origin United States Weight 0.7 kg Dimensions 160 mm x 100 mm x 80 mm Operating Temp -40 deg C to +70 deg C Power Consumption Low-power communication/interface processing module Module Type AE Bridge Interface Module (AEBI) System Platform GE Mark VI / Mark VIe Speedtronic control system Form Factor VME rack-mounted PCB module Operating Voltage 24 VDC system supply Communication Interface VME backplane and internal turbine control network Isolation Galvanic isolation and EMI protection Cooling Method Passive convection cooling PCB Protection Conformal coating Configuration Support Simplex, redundant, and TMR configurations Humidity Range 5%-95% non-condensing Industrial Control Network Interface Characteristics The IS210AEBIH2B operates as an AE Bridge Interface Module within the GE Mark VI/Mark VIe architecture. The board manages communication paths between control processors, turbine I/O assemblies, and the VME backplane. Its hardware design supports synchronization and diagnostic data transfer required for coordinated turbine control operations. The module supports simplex, redundant, and triple modular redundancy (TMR) configurations. In redundant control architectures, the AEBI interface maintains communication availability between processing units and distributed control elements through coordinated data exchange paths. The PCB assembly incorporates conformal coating and EMI shielding features for operation in industrial electrical environments. The module design supports signal integrity by reducing the effects of contamination, moisture exposure, and electromagnetic interference on board-level communication circuits. Frequently Asked Questions Q: What communication interfaces are supported by the IS210AEBIH2B?A: The module communicates through the GE Mark VI/Mark VIe VME backplane and internal turbine control network interfaces for controller and I/O subsystem data exchange. Q: Does the IS210AEBIH2B support redundant control configurations?A: Yes. The module supports simplex, redundant, and TMR system configurations within compatible GE Speedtronic control architectures. Q: What protection features are included on the PCB assembly?A: The module includes conformal coating, EMI shielding provisions, and passive convection cooling design for industrial control cabinet installation. Field Installation Guidelines Install the IS210AEBIH2B in the designated GE Mark VI/Mark VIe VME rack position according to the system hardware configuration. Verify that the backplane connector is correctly aligned before insertion and avoid mechanical stress on the PCB assembly. Use shielded signal wiring where applicable and maintain separation between communication cables and high-voltage power conductors to reduce electromagnetic interference. Ensure cabinet grounding provides a low-impedance path for shield termination and equipment protective bonding. Before replacement or maintenance work, confirm system power isolation procedures are completed. Inspect the module edge connectors, rack contacts, and cooling airflow paths for contamination or physical damage prior to installation.
$200.00 $100.00
-
General Electric GE IS420ESWAH2A Ethernet Switch Assembly Module
GE IS420ESWAH2A Ethernet Switch Assembly Module The GE IS420ESWAH2A, also cataloged as the IS420ESWAH2A Ethernet Switch Assembly Module, operates as a dedicated hardware component for managed Ethernet communication routing within the GE Mark VIe turbine control system. It provides physical network switching between controllers, I/O packs, and operator interface devices. Hardware Specifications Parameter Specification Model IS420ESWAH2A Brand GE Origin United States Weight 0.45 kg Operating Temp -30 to +65 deg C Power Consumption Powered by 24 VDC nominal supply Product Type Ethernet Switch Assembly Modules System Platform GE Mark VIe Speedtronic Control System Switch Type Managed industrial Ethernet switch Ethernet Ports 8 x 10/100 Mbps RJ-45 ports Supported Protocols TCP/IP, Modbus TCP, GE proprietary I/O bus Redundancy Features Dual power supply inputs and redundant communication paths Mounting Method DIN rail or panel mounting PCB Protection Conformal coating for dust and humidity resistance Humidity Range 5-95% non-condensing GE Mark VIe Industrial Ethernet Communication Characteristics The IS420ESWAH2A provides managed Ethernet switching functions for Mark VIe deterministic network architectures. The module supports Ethernet communication paths between controller assemblies, distributed I/O packs, and operator interface systems through configured network connections. The switch assembly supports industrial control network expansion through Ethernet port density scaling and redundant communication path management. Firmware flash compatibility allows the module to maintain supported configuration functions within the Mark VIe platform. Network traffic handling includes TCP/IP, Modbus TCP, and GE proprietary I/O bus communication protocols. Dual power inputs and redundant communication structures provide continuous network connectivity during configured fault conditions. Frequently Asked Questions Q: How many Ethernet ports are available on the IS420ESWAH2A?A: The module provides 8 RJ-45 Ethernet ports supporting 10/100 Mbps communication. Q: What power supply configuration does the IS420ESWAH2A support?A: The switch assembly operates with a 24 VDC nominal supply and supports dual power supply inputs for redundant configurations. Q: Can the IS420ESWAH2A communicate with Mark VIe I/O packs?A: Yes. The module provides Ethernet switching between Mark VIe controllers, I/O packs, and connected operator interface devices. Field Installation Guidelines Install the IS420ESWAH2A on the designated DIN rail or panel mounting location inside the Mark VIe control cabinet. Verify that Ethernet cables are connected to the correct network ports according to the cabinet wiring documentation. Use industrial Ethernet cables with appropriate shielding and maintain separation between communication wiring and high-voltage power conductors. Connect cable shields according to the site grounding standard to reduce electromagnetic interference. Verify 24 VDC power polarity before energizing the module. Confirm Ethernet link status, communication paths, and controller network recognition through the Mark VIe diagnostic interface before system operation.
$200.00 $100.00
-
General Electric GE IS220PTCCH2A Thermocouple Input Pack Module
GE IS220PTCCH2A Thermocouple Input Pack Module Configured for thermocouple signal acquisition in the GE Mark VIe turbine control system, the GE IS220PTCCH2A (IS220PTCCH2A Thermocouple Input Pack Module) provides direct physical/electrical execution for temperature signal conditioning, conversion, and isolated communication with Mark VIe controller networks. Hardware Specifications Parameter Specification Model IS220PTCCH2A Brand GE Origin United States Weight 0.35 kg Operating Temp -30 to +65 deg C Power Consumption Powered by +28 VDC nominal supply Product Type Thermocouple Input Pack Modules System Platform GE Mark VIe Speedtronic Control System Input Channels 12 thermocouple inputs Supported Thermocouple Types Type E, J, K, N, R, S, T, B A/D Conversion Resolution 16-bit Temperature Accuracy +/- 1 deg C typical Cold Junction Compensation Integrated automatic CJC Isolation Channel-to-channel and channel-to-system isolation Communication Interface Ethernet connection to Mark VIe controller Mounting Method DIN rail or panel mounting PCB Protection Conformal coating GE Mark VIe Thermocouple Signal Processing Characteristics The IS220PTCCH2A performs thermocouple signal conditioning through integrated analog processing, cold junction compensation (CJC), and digital conversion functions. The module transfers processed temperature data through Ethernet communication to the Mark VIe controller architecture. The module supports industrial control network configurations with simplex and TMR (Triple Modular Redundancy) operation. The onboard identification chip provides automatic hardware recognition during controller configuration. Firmware flash compatibility allows the input pack to maintain configuration consistency within supported Mark VIe control environments. The 12-channel I/O density supports multi-point temperature monitoring with isolated measurement paths for thermocouple field circuits. Frequently Asked Questions Q: What thermocouple types are supported by the IS220PTCCH2A?A: The module supports Type E, J, K, N, R, S, T, and B thermocouple inputs. Q: Does the IS220PTCCH2A provide cold junction compensation?A: Yes. The module includes integrated automatic cold junction compensation for thermocouple measurement processing. Q: Can the IS220PTCCH2A operate in redundant Mark VIe configurations?A: Yes. The module supports simplex and TMR system configurations within the Mark VIe control architecture. Field Installation Guidelines Install the IS220PTCCH2A on the designated DIN rail or panel mounting location according to the Mark VIe cabinet layout. Connect thermocouple field wiring to the assigned input terminals while maintaining correct polarity and sensor type configuration. Use shielded signal cables where required by site grounding practices. Separate thermocouple wiring from high-voltage power cables and high-current switching circuits to reduce electrical interference. Verify Ethernet communication connections and module identification before system commissioning. Confirm that the field wiring configuration matches the configured thermocouple type before enabling temperature measurement functions.
$200.00 $100.00
-
General Electric IS210AEBIH1B GE Mark VI Analog Expansion Board
GE IS210AEBIH1B Mark VI Analog Expansion Board Module The GE IS210AEBIH1B, also cataloged as the IS210AEBI Analog Expansion Board Module, operates as a dedicated hardware component for analog channel expansion and signal conversion within the GE Speedtronic Mark VI turbine control system. The module provides additional analog input and output processing through the controller backplane interface. Hardware Specifications Parameter Specification Model IS210AEBIH1B Brand GE Origin United States Weight 0.35 kg Operating Temp -30 to +65 deg C Power Consumption Supplied by +28 VDC nominal input Product Type Analog Expansion Modules Analog Inputs 8 channels, configurable for 4-20 mA or +/-10 VDC Analog Outputs 4 channels, 4-20 mA Resolution 16-bit A/D and D/A conversion Accuracy +/-0.1% of full scale Isolation Channel-to-channel and channel-to-system isolation Communication Interface Mark VI controller backplane interface Mounting Rack mount, Mark VI chassis compatible PCB Protection Conformal coating Industrial Control Backplane and I/O Density Scaling The IS210AEBIH1B extends analog signal capacity within the GE Mark VI control architecture. The module performs signal conditioning, conversion, and electrical isolation between field instrumentation and controller processing units. The Mark VI platform uses modular I/O expansion structures to increase channel availability. The AEBI module supports I/O density scaling through additional analog channels while maintaining communication through the controller backplane. Firmware flash compatibility must match the installed Mark VI hardware revision and controller configuration. Frequently Asked Questions Q: What is the primary function of the IS210AEBIH1B module?A: The IS210AEBIH1B provides additional analog input and output capacity for the GE Mark VI control system, including signal conditioning and conversion functions. Q: Which analog signals are supported by this module?A: The module supports configurable analog inputs of 4-20 mA and +/-10 VDC, with 4-20 mA analog outputs. Q: Does the IS210AEBIH1B support redundant Mark VI configurations?A: The module is designed for Mark VI system configurations supporting simplex and TMR (Triple Modular Redundancy) architectures. Field Installation Guidelines Install the IS210AEBIH1B module in the specified Mark VI rack position and confirm correct mechanical alignment with the chassis interface before energizing the system. Verify analog channel configuration, field wiring polarity, and terminal assignments according to the system drawings. Keep analog signal cables separated from high-current switching lines and power conductors to reduce electromagnetic interference. Use shielded instrumentation cables where required and connect cable shields according to the site grounding standard. Check rack mounting hardware, backplane engagement, and grounding continuity during installation inspection.
$200.00 $100.00
-
General Electric IS200SSCAH1ABA GE Mark VI Analog Module
GE IS200SSCAH1ABA Mark VI Static Source Control Analog Module Configured for analog signal conditioning and conversion in GE Speedtronic Mark VI control systems, the GE IS200SSCAH1ABA (IS200SSCA Analog Module) provides direct physical/electrical execution for field signal acquisition, isolation, and output processing. The module handles current and voltage channels through VME backplane communication with Mark VI controllers. Suffix Breakdown & Model Matrix The IS200SSCAH1ABA model is identified as a GE Mark VI Static Source Control Analog (SSCA) module. The available provided data defines the complete ordering code only; no additional manufacturer-published suffix expansion is specified. Model Description IS200SSCAH1ABA Static Source Control Analog module IS200SSCA Base module family identifier Mark VI GE Speedtronic turbine control platform Hardware Specifications Parameter Specification Model IS200SSCAH1ABA Brand GE Origin United States Weight 0.35 kg Operating Temp -30 to +65 deg C Power Consumption Supplied by +28 VDC nominal input Product Type Analog Interface Modules Analog Inputs 8 channels, configurable for 4-20 mA or +/-10 VDC Analog Outputs 4 channels, 4-20 mA Resolution 16-bit A/D and D/A conversion Accuracy +/-0.1% of full scale Isolation Channel-to-channel and channel-to-system isolation Communication Interface VME backplane interface to Mark VI controller Mounting Mark VI rack mount chassis compatible PCB Protection Conformal coating Mark VI Analog Signal Processing and I/O Scaling The IS200SSCAH1ABA applies GE industrial control architecture for analog I/O processing within the Mark VI platform. The module performs signal conditioning, analog conversion, and electrical isolation between field devices and controller processing circuits. The Mark VI system supports I/O density scaling through modular hardware configurations. The SSCA module communicates through the VME backplane structure, maintaining deterministic data exchange between analog channels and the controller layer. Firmware flash compatibility must follow the installed Mark VI controller configuration and approved hardware revision requirements. Frequently Asked Questions Q: What type of field signals can the IS200SSCAH1ABA process?A: The module processes analog current and voltage signals, including 4-20 mA and +/-10 VDC configurable inputs with 4-20 mA outputs. Q: Does the IS200SSCAH1ABA provide electrical isolation for analog channels?A: Yes. The module provides channel-to-channel and channel-to-system isolation for analog signal separation. Q: What communication interface connects this module to the controller?A: The IS200SSCAH1ABA uses a VME backplane interface for communication with the GE Mark VI controller. Field Installation Guidelines Install the IS200SSCAH1ABA in the designated Mark VI rack position and verify mechanical engagement with the chassis connector before system power application. Confirm field wiring configuration, signal polarity, and channel assignments according to the control system drawings. Route analog signal cables separately from high-voltage and high-current conductors to reduce electromagnetic interference. Use shielded instrumentation wiring where required and terminate cable shields according to the site grounding practice. Verify backplane connections, rack seating, and grounding continuity before commissioning the module.
$200.00 $100.00
-
General Electric IS230PCAAH1A GE Mark VIe Analog I/O Module
GE IS230PCAAH1A Mark VIe Pack Control Analog Module The GE IS230PCAAH1A, also cataloged as the IS230PCAA Pack Control Analog Module, operates as a dedicated hardware component for analog signal acquisition and output execution within the GE Mark VIe Speedtronic control system. The module provides 4-20 mA and voltage signal processing through isolated analog I/O channels, supporting field device interfacing for turbine control loops. Hardware Specifications Parameter Specification Model IS230PCAAH1A Brand GE Origin United States Weight 0.35 kg Operating Temp -30 to +65 deg C Power Consumption Supplied by +28 VDC nominal input Product Type Analog I/O Module Analog Inputs 8 channels, configurable for 4-20 mA or +/-10 VDC Analog Outputs 4 channels, 4-20 mA Signal Conversion 16-bit A/D and D/A conversion Accuracy +/-0.1% of full scale Isolation Channel-to-channel and channel-to-system isolation Communication Interface Mark VIe controller backplane interface Mounting Type DIN rail or panel mount PCB Protection Conformal coating Deterministic Analog Processing and Mark VIe Interface The IS230PCAAH1A integrates with GE Mark VIe controller architecture through a dedicated backplane communication interface. The module performs analog signal conditioning, conversion, and isolated transmission between field wiring and controller processing units. Its 16-bit conversion capability supports measurement and command signals for turbine subsystem control circuits. The GE industrial control platform uses deterministic network and backplane communication structures for I/O synchronization. The module supports analog I/O density scaling within Mark VIe configurations where multiple signal acquisition points are required. Frequently Asked Questions Q: What analog signal types are supported by the IS230PCAAH1A module?A: The module supports configurable analog inputs for 4-20 mA and +/-10 VDC signals, with analog outputs provided as 4-20 mA channels. Q: Does the IS230PCAAH1A provide electrical isolation between channels?A: Yes. The module provides channel-to-channel and channel-to-system isolation for analog signal separation. Q: What controller interface is used by this module?A: The IS230PCAAH1A communicates with the GE Mark VIe controller through the system backplane interface. Field Installation Guidelines Install the IS230PCAAH1A in the designated Mark VIe I/O mounting location according to system hardware documentation. Verify that field wiring polarity, signal type selection, and terminal assignments match the configured analog channels. Route analog signal cables separately from high-current power conductors and switching circuits to reduce electrical interference. Use shielded instrumentation cable where required, with shield termination following the site grounding standard. Confirm that the module seating, backplane connection, and mounting hardware are mechanically secure before applying power.
$200.00 $100.00
-
General Electric GE IS200AEPCH1A Auxiliary Electronic Printed Circuit Module
GE IS200AEPCH1A Auxiliary Electronic Printed Circuit Module Configured for auxiliary signal conditioning and interface processing in GE Speedtronic Mark VI/Mark VIe turbine control systems, the GE IS200AEPCH1A (IS200AEPCH1A Auxiliary Electronic Printed Circuit Module) provides direct physical/electrical execution for analog and digital I/O handling within turbine control cabinets. Hardware Specifications Parameter Specification Model IS200AEPCH1A Brand GE Origin United States Weight 0.5 kg Operating Temp -20 to +60 deg C Power Consumption <= 25 W Module Type Auxiliary Electronic Printed Circuit (AEPC) Module System Platform GE Speedtronic Mark VI / Mark VIe Supply Voltage 24 VDC +/-10% Processor 32-bit industrial microprocessor, 400 MHz Memory 128 MB RAM, 64 MB Flash Digital Inputs 8 channels Digital Outputs 8 channels Analog Inputs 4 channels, 4-20 mA Communication Protocols Modbus TCP/IP, Ethernet/IP, Profibus DP Ethernet Ports 2 x 10/100 Base-T Ethernet Profibus Interface 1 port Mounting Type Rack mount, Mark VI chassis compatible Protection Rating IP20 PCB Protection Conformal coating Humidity Range 5-95% non-condensing GE Mark VIe Industrial Control Communication and I/O Processing The IS200AEPCH1A module performs auxiliary subsystem signal processing through configurable analog and digital channels. The module interfaces with turbine auxiliary circuits including lubrication, sealing, cooling, and emergency shutdown related signals. The module supports Ethernet/IP, Modbus TCP/IP, and Profibus DP communication interfaces for data exchange with Mark VI/Mark VIe control networks. Firmware flash compatibility and memory resources support module configuration management within the Speedtronic control architecture. Frequently Asked Questions Q: What type of field signals can the IS200AEPCH1A process?A: The module provides 8 digital inputs, 8 digital outputs, and 4 analog input channels configured for 4-20 mA signal acquisition. Q: What communication interfaces are available on the IS200AEPCH1A?A: The module provides two 10/100 Base-T Ethernet ports and one Profibus interface, supporting Ethernet/IP, Modbus TCP/IP, and Profibus DP communication protocols. Q: What installation considerations apply to this module?A: The module should be installed in a compatible Mark VI chassis with correct rack alignment, grounding connection, and verified power supply polarity before system energization. Field Installation Guidelines Install the IS200AEPCH1A module into the designated GE Mark VI or Mark VIe rack position with the control cabinet power isolated. Verify chassis compatibility, connector alignment, and supply voltage polarity before applying power. Maintain separation between analog signal wiring, communication cables, and high-current conductors to minimize electrical interference. Use shielded cables for low-level analog circuits and terminate shields according to the cabinet grounding design. Ensure mounting hardware provides proper mechanical retention and grounding continuity through the conductive mounting points. Confirm communication link status and I/O channel operation after installation using the turbine control system diagnostic functions.
$200.00 $100.00
-
General Electric IS215AEPCH1B GE Alternative Energy Pitch Control
GE IS215AEPCH1B Alternative Energy Pitch Control Module The GE IS215AEPCH1B, also cataloged as the IS215AEPCH1B Alternative Energy Pitch Control (AEPC) Module, operates as a dedicated hardware component for closed-loop blade pitch positioning, hub sensor signal processing, and pitch drive communication within the GE Mark VIe Speedtronic control system. Hardware Specifications Parameter Specification Model IS215AEPCH1B Brand GE Origin United States Weight 0.5 kg Dimensions 180 x 120 x 40 mm Operating Temp -30 to +65 deg C Power Consumption 8 W maximum Module Type Alternative Energy Pitch Control (AEPC) Module System Platform GE Mark VIe Speedtronic Form Factor 6U VMEbus single slot Input Voltage 5 VDC backplane or 24 VDC depending on revision Communication Interface VMEbus and 10/100 Mbps Ethernet Base-TX Pitch Drive Protocol CANopen Feedback Inputs Quadrature encoder channels Digital I/O 8 configurable channels PCB Protection Industrial conformal coating Storage Temperature -40 to +85 deg C Humidity Range 5-95% non-condensing Certifications CE, UL 508, cULus, RoHS GE Mark VIe Pitch Control Communication and I/O Processing The IS215AEPCH1B module processes blade pitch feedback signals and controls communication between turbine hub sensors and pitch drive assemblies. The module uses CANopen communication for pitch drive control and provides encoder feedback acquisition through quadrature input channels. The module operates as a VMEbus-based controller within the Mark VIe architecture. Its Ethernet interface supports 10/100 Mbps Base-TX communication for system-level data exchange. Configurable digital I/O channels provide additional interface capability for turbine auxiliary signals. Frequently Asked Questions Q: What communication protocols are supported by the IS215AEPCH1B module?A: The module supports VMEbus system communication, 10/100 Mbps Ethernet Base-TX communication, and CANopen protocol for pitch drive interfaces. It does not support Modbus communication for pitch drive control. Q: What type of feedback signals can the module process?A: The IS215AEPCH1B processes quadrature encoder feedback channels for closed-loop blade pitch position monitoring and control. Q: Is the module designed for cold climate turbine installations?A: The module supports an operating temperature range from -30 to +65 deg C and uses industrial conformal coating for PCB protection in harsh environmental conditions. Field Installation Guidelines Install the IS215AEPCH1B module into the designated GE Mark VIe VMEbus rack slot with power removed from the control chassis. Verify backplane compatibility and revision-specific voltage requirements before installation. Route CANopen, Ethernet, and encoder signal wiring separately from high-current power cables to reduce electromagnetic interference. Use shielded cables for low-level feedback signals and terminate cable shields according to the turbine control cabinet grounding design. Inspect connectors, card guides, and mounting hardware before energizing the system. Confirm firmware compatibility and perform communication checks between the AEPC module, pitch drives, and turbine controller after installation.
$200.00 $100.00
-
General Electric GE IS215VCMIH2CB VME Communication Interface Module
GE IS215VCMIH2CB VME Communication Interface Module The GE IS215VCMIH2CB, also cataloged as the IS215VCMIH2CB VME Communication Interface Module, operates as a dedicated hardware component for deterministic data communication and synchronization within the GE Mark VI Speedtronic turbine control system. It manages communication paths between VME controllers and I/O boards through the system backplane. Hardware Specifications Parameter Specification Model IS215VCMIH2CB Brand GE (General Electric) Origin United States Weight 0.5 kg Dimensions 6U VME module form factor Operating Temp -30 deg C to +65 deg C Power Consumption Not specified Product Type VME Communication Interface Modules Series Mark VI Speedtronic Processor Embedded communication processor with real-time OS Memory 16 MB SDRAM, 4 MB Flash Interfaces Dual Ethernet ports (10/100 Mbps), VME backplane interface Communication Protocols TCP/IP, GE proprietary I/O bus Synchronization Input IRIG-B time code input and system clock distribution Redundancy Dual-module hot-swap capability Power Supply +5 VDC from VME backplane Protection Features Triple-layer conformal coating Deterministic Network Communication and Control Synchronization The IS215VCMIH2CB provides the communication interface layer between the Mark VI controller and distributed I/O hardware. The module manages VME backplane data exchange, timing synchronization, and communication scheduling for connected control modules. The module supports deterministic networks through GE proprietary I/O communication protocols and Ethernet interfaces. Its communication processor manages real-time data transfer between controller resources and field interface modules while maintaining system timing coordination. The VME bus communication structure supports backplane communication velocity management for coordinated transfer between multiple I/O boards. The IRIG-B time code interface provides clock synchronization for event sequencing, timestamping, and turbine protection logic execution. Firmware and Industrial Control Compatibility The IS215VCMIH2CB includes onboard SDRAM and Flash memory for embedded firmware execution and configuration storage. Firmware flash compatibility allows the communication module to operate within supported Mark VI control system revisions. The dual-module configuration supports redundancy management, allowing paired VCMI modules to maintain communication availability through coordinated operation. The hot-swap capability enables module replacement procedures within supported system configurations. Frequently Asked Questions Q: What communication interfaces are available on the IS215VCMIH2CB?A: The module provides dual Ethernet ports with 10/100 Mbps communication capability and a VME backplane interface for Mark VI system communication. Q: Does the IS215VCMIH2CB support redundant operation?A: Yes. The module supports dual-module redundant configurations with hot-swap capability in compatible Mark VI architectures. Q: What is the function of the IRIG-B input on this module?A: The IRIG-B input provides time synchronization data used for system clock distribution, event timestamping, and sequence coordination. Field Installation Guidelines Install the IS215VCMIH2CB in the designated GE Mark VI VME rack slot and verify correct mechanical insertion before applying system power. Inspect the VME connector condition and ensure proper seating of the module. Ethernet communication cables should be routed separately from high-voltage power conductors and high-frequency switching sources. Maintain cabinet grounding practices and verify shielding connections for communication wiring. Confirm module addressing, firmware compatibility, and redundancy configuration before system commissioning. Follow GE Mark VI installation documentation for VME rack configuration, communication network setup, and module replacement procedures.
$200.00 $100.00
-
General Electric IS200TPROH1C GE Mark VI Thermocouple Input Board
GE IS200TPROH1C Thermocouple Input Terminal Board The GE IS200TPROH1C, also cataloged as the IS200TPROH1C Thermocouple Input Terminal Board, operates as a dedicated hardware component for thermocouple signal conditioning within the GE Mark VI Speedtronic turbine control system. It provides physical interface paths for turbine temperature sensors, converting millivolt-level thermocouple signals into controller-readable measurement data. Hardware Specifications Parameter Specification Model IS200TPROH1C Brand GE (General Electric) Origin United States Weight 0.5 kg Operating Temp -30 deg C to +65 deg C Power Consumption Not specified Product Type Thermocouple Input Terminal Board Series Mark VI Speedtronic Input Channels Up to 24 thermocouple channels Thermocouple Types J, K, T, E and compatible types Signal Range +/-100 mV typical Signal Conversion 12-bit A/D conversion Cold Junction Compensation Integrated CJC function Power Supply 24 VDC Mounting Type Rack/cabinet slot installation Thermocouple Signal Processing and Mark VI Interface The IS200TPROH1C provides multi-channel thermocouple termination and signal conditioning for GE Mark VI control architectures. The board accepts low-level thermocouple millivolt signals and transfers processed temperature information through the associated I/O pack interface. The integrated cold junction compensation function maintains temperature measurement accuracy by compensating for terminal reference temperature variations. The input design supports thermocouple fault monitoring functions including open-circuit and short-circuit detection. For Mark VI system integration, the terminal board connects with compatible I/O packs such as PTCC modules and exchanges control data through the VME-based controller architecture. Frequently Asked Questions Q: What thermocouple inputs are supported by the IS200TPROH1C?A: The board supports multiple thermocouple types including J, K, T, and E sensors, with input configuration determined by the connected Mark VI control system setup. Q: Does the IS200TPROH1C provide cold junction compensation?A: Yes. The board includes integrated cold junction compensation for thermocouple reference temperature correction. Q: What power supply is required for the IS200TPROH1C?A: The terminal board operates with a 24 VDC supply within the Mark VI control system cabinet configuration. Field Installation Guidelines Install the IS200TPROH1C in the designated GE Mark VI cabinet slot location and verify mechanical alignment before securing the board connections. Use shielded thermocouple wiring with appropriate grounding practices to reduce electrical interference on low-level millivolt signals. Keep thermocouple cables separated from high-current power wiring, motor cables, and switching circuits. Confirm that the thermocouple type configuration matches the connected field sensors before commissioning. Check terminal connections, sensor polarity, and cable continuity during installation and maintenance procedures. Follow GE Mark VI cabinet grounding, shielding, and I/O wiring documentation for final field termination and system integration.
$200.00 $100.00
-
General Electric GE IS200JPDMG1A Mark VI Mark VIe Power Distribution Board
GE IS200JPDMG1A Mark VI Mark VIe Power Distribution Board Configured for regulated DC power distribution in GE Mark VI/Mark VIe Speedtronic turbine control systems, the GE IS200JPDMG1A (IS200JPDMG1A Power Distribution Board) provides direct physical/electrical execution for supplying isolated 24-28 VDC power buses to connected I/O packs and control terminal assemblies. Hardware Specifications Parameter Specification Model IS200JPDMG1A Brand GE (General Electric) Origin United States Weight 0.8 kg Dimensions 130 mm x 25 mm x 250 mm Operating Temp -30 to +65 deg C Power Consumption 24-28 VDC input power distribution; board consumption not specified Product Type Power Distribution Board Series Mark VI / Mark VIe Speedtronic Input Power 24-28 VDC from external power converters Output Configuration Multiple isolated R, S, T power buses Fuse Protection 10 A, 250 V fuses for controller and board outputs; 3.75 A resettable auxiliary protection Surge Protection Integrated transient voltage suppression per channel Mounting Method DIN-rail mounting or cabinet installation Deterministic Power Bus Distribution and Network Integration The IS200JPDMG1A is designed for GE industrial control architectures requiring controlled DC power distribution between system modules. The board provides isolated power paths for R, S, and T buses, supporting redundant power arrangements within Mark VI/Mark VIe cabinets. The module incorporates fuse protection, channel-level surge suppression, and status indication functions for monitoring power distribution conditions. Its power routing structure supports I/O density scaling when additional terminal assemblies and compatible PPDA I/O packs are installed. Compatibility between the JPDM board configuration, connected I/O modules, and cabinet power architecture must be verified before system energization. Frequently Asked Questions Q: Can the IS200JPDMG1A be removed while the system is energized?A: No. The board is not specified for hot-swapping. Power must be removed before installation or removal to prevent electrical arcing and equipment damage. Q: What type of power inputs and outputs are supported by the IS200JPDMG1A?A: The board receives 24-28 VDC input power and distributes it through isolated R, S, and T output buses to compatible Mark VI/Mark VIe control components. Q: What protection functions are integrated into the board?A: The module includes fuse protection and channel-level surge suppression for DC power distribution circuits. Field Installation Guidelines Install the IS200JPDMG1A on the designated DIN-rail or cabinet mounting location according to the GE Mark VI/Mark VIe cabinet layout. Verify mechanical locking and terminal connections before applying power. Connect DC supply wiring with correct polarity and maintain separation between power distribution wiring and low-level signal cables. Use appropriate grounding practices for cabinet chassis and protective earth connections. Before startup, inspect fuse conditions, verify connected bus assignments, and confirm compatibility with installed PPDA I/O packs and associated control modules. Remove system power before replacing fuses or modifying board wiring.
$200.00 $100.00
-
General Electric GE IS200TCATH1ABA Mark V Mark VIe Analog Terminal Board
GE IS200TCATH1ABA Mark V Mark VIe Analog Terminal Board Configured for thermocouple and analog sensor signal conditioning in GE Mark V/Mark VIe Speedtronic turbine control systems, the GE IS200TCATH1ABA (IS200TCATH1ABA Analog Terminal Board) provides direct physical/electrical execution between field measurement devices and turbine control processing modules. Hardware Specifications Parameter Specification Model IS200TCATH1ABA Brand GE (General Electric) Origin United States Weight 0.5 kg Dimensions 150 mm x 240 mm x 350 mm Operating Temp -40 to +70 deg C Power Consumption 24 VDC +/-10% supply input Product Type Analog Terminal Board Series Mark V / Mark VIe Speedtronic Input Types Thermocouples J/K/T/E, 4-20 mA analog signals, LVDT signals, +/-10 VDC vibration inputs Output Types 4-20 mA analog outputs, digital relay trip signals, alarm signals Resolution 12-bit analog signal resolution Communication Interface GE COREBUS protocol Signal Function Sensor signal conditioning and turbine parameter monitoring COREBUS Signal Processing and Industrial Control Integration The IS200TCATH1ABA operates as a field signal interface board within GE Mark V and Mark VIe control architectures. It conditions temperature, vibration, and position feedback signals before transferring processed values through the COREBUS communication structure. The module supports industrial control signal processing functions including channel monitoring, diagnostic checking, and alarm/trip signal generation. The board configuration supports I/O density scaling within the Mark platform through connection with compatible terminal and control modules. Firmware and hardware compatibility must match the installed Mark control configuration to maintain correct communication behavior and signal scaling parameters. Frequently Asked Questions Q: What field signals can the IS200TCATH1ABA process?A: The board processes thermocouple inputs, 4-20 mA analog signals, LVDT position feedback, and vibration-related voltage signals according to configured Mark V/Mark VIe system parameters. Q: What communication method is used by the IS200TCATH1ABA?A: The module communicates through GE proprietary COREBUS communication architecture for data exchange with compatible turbine control modules. Q: What power supply is required for the terminal board?A: The module requires a 24 VDC supply input with a tolerance of +/-10% according to the available technical specification. Field Installation Guidelines Install the IS200TCATH1ABA according to the GE Mark V/Mark VIe cabinet wiring configuration. Verify terminal assignments before connecting thermocouple, LVDT, vibration, and current loop field wiring. Use shielded instrumentation cables for low-level analog signals. Connect cable shields according to the cabinet grounding practice to reduce electrical noise coupling. Separate analog signal wiring from high-current power conductors and switching circuits. Confirm sensor type configuration before commissioning. Thermocouple polarity, LVDT excitation wiring, and analog loop connections must match the configured I/O channel definitions. Inspect terminal connections and communication interfaces before applying system power.
$200.00 $100.00
