Emerson EPRO modules offer reliable spare and replacement parts for DeltaV, Ovation, and other Emerson automation systems. They help maintain system uptime, support legacy installations, and ensure smooth industrial operations.
Emerson EPRO
-
EMERSON Emerson PR6424/003 16mm Eddy Current Sensor | Shaft Displacement
Product Description OverviewThe PR6424/003 from Emerson is a 16 mm non-contact eddy current sensor designed for high-precision monitoring of critical rotating machinery. It delivers reliable measurement of radial and axial shaft displacement, eccentricity, speed, and key positioning, suitable for turbines, compressors, pumps, and industrial fans. Mechanical and Electrical Specifications Sleeve Thread: M18 × 1.5 Armored Cable: Not included Total Sensor Length: 60 mm Adaptor Plug: Not included Cable Length: 8 m, PTFE-insulated Cable End: LEMO connector Material: Stainless steel sleeve, PTFE cable Weight (sensor + 1 m cable, no armor): ~200 g Dynamic Performance Sensitivity / Linearity: 4 V/mm (101.6 mV/mil), ≤ ±1.5% Nominal Air Gap: 2.7 mm (0.11 in) Static Measurement Range: ±2 mm (0.079 in) Dynamic Range: 0–1 000 µm (0–0.039 in) Long-Term Drift: <0.3% Target Compatibility Material: Ferromagnetic steel (42CrMo4 standard) Maximum Surface Speed: 2,500 m/s Minimum Shaft Diameter: 80 mm Environmental Tolerance Operating Temperature: –35 to 150 °C (–31 to 302 °F) Temperature Error: <4% per 100 K (API 670 compliant) Pressure Resistance (Sensor Head): up to 10,000 hPa (145 psi) Shock & Vibration: 5 g at 60 Hz, 25 °C ApplicationsThe PR6424/003 is ideal for monitoring critical rotating machinery where non-contact precision sensing is required. Common applications include: steam turbines, gas turbines, hydro turbines, industrial compressors, high-speed pumps, and large axial or radial fan systems. FAQQ: Can this sensor operate in high-temperature environments?A: Yes, it supports –35 to 150 °C and maintains API 670-compliant temperature accuracy. Q: Is the sensor suitable for armored cable installations?A: The current configuration comes without armored cable. Armored versions are available for harsh environments. Similar Models Comparison PR6424/002: 50 mm sensor length, armored cable optional PR6424/004: 80 mm sensor length, includes adaptor plug Technical Specifications Table Parameter Specification Sensor Diameter 16 mm Sleeve Thread M18 × 1.5 Total Sensor Length 60 mm Cable Type PTFE Cable Length 8 m Cable End LEMO Armored Cable No Adaptor Plug No Sensitivity 4 V/mm Air Gap 2.7 mm Static Range ±2 mm Dynamic Range 0–1 000 µm Operating Temp –35 to 150 °C Pressure Resistance 10,000 hPa Weight ~200 g
$200.00 $100.00
-
EMERSON Emerson PR6423/10R-040-HT CON021 High-Temperature Eddy Current Sensor
Product Description OverviewThe PR6423/10R-040-HT paired with the CON021 signal conditioner is a high-temperature eddy current measurement system designed for continuous monitoring of rotor dynamics in extreme thermal environments. This assembly combines a rugged 8 mm proximity probe with a matched converter unit, delivering precise vibration and shaft displacement feedback in demanding rotating machinery applications. Its stable performance under severe heat makes it ideal for turbine sections and other high-temperature mechanical zones where conventional proximity systems lose calibration stability. Technical Specifications Probe Unit – PR6423/10R-040-HT Sensor Type: Eddy Current Proximity / Displacement Probe Probe Diameter: 8 mm Linear Measuring Range: 2 mm (80 mils nominal window) Recommended Installation Air Gap: ~0.5 mm Sensitivity: 8 V/mm ±5% (calibrated at 0–45°C) Linearity Deviation: ±0.025 mm within calibrated range Minimum Shaft Diameter: ≥25 mm Target Material: Ferromagnetic steel (e.g., 42CrMo4 / AISI 4140 equivalent) Thermal & Environmental Performance Operating Temperature Range: –35°C to +220°C (extended high-temperature design) Protection Rating: IP66 (dust tight and resistant to high-pressure water jets) Long-term Operation: Optimized for sustained exposure in high-heat turbine zones Converter Unit – CON021 Signal Bandwidth: 0–20 kHz (–3 dB) Response Time: <15 μs rise time Supply Voltage: 23–32 V DC (dual output scaling supported) Output Signal Ranges: –4 V to 20 V or –2 V to 18 V Housing Material: Die-cast aluminum alloy (GD-AISi9Cu3) Protection Rating: IP65 Weight: 0.6 kg Applications This assembly is engineered for high-reliability monitoring of rotordynamics in: Gas and steam turbines Turbo-compressors and high-speed rotors High-temperature industrial zones where conventional probes fail Critical machinery requiring continuous displacement and vibration feedback FAQ Q: Can this probe be used on non-ferromagnetic shafts?A: No, it is optimized for ferromagnetic steels such as 42CrMo4 or AISI 4140. Performance on non-ferromagnetic materials will not be accurate. Q: What is the maximum temperature the probe can withstand?A: The PR6423/10R-040-HT operates reliably up to 220°C continuous exposure. Q: Are the output ranges configurable?A: Yes, the CON021 converter supports dual output ranges: –4 V to 20 V or –2 V to 18 V. Q: How does this system compare to lower-temperature eddy current probes?A: Unlike standard probes, the PR6423/10R-040-HT maintains calibration stability and sensitivity in extreme heat, making it suitable for turbine and high-thermal zones.
$200.00 $100.00
-
EMERSON EPRO PR6423/01M-010 CON021 Eddy Current Displacement Sensor System
Product Description OverviewThe PR6423/01M-010 paired with CON021 constitutes a high-precision eddy current measurement system, purpose-built by EPRO for continuous shaft monitoring in rotating machinery. Designed for non-contact displacement tracking, the system ensures stable, reliable measurement in demanding industrial environments. Engineered to withstand vibration, thermal stress, and exposure to oil or contaminants, this assembly combines a high-temperature-resistant proximity probe with a signal conditioning converter to deliver accurate, linear outputs directly proportional to surface displacement. Key Features and Technical Specifications System Type: Eddy current displacement measurement assembly Probe Model: PR6423/01M-010 Converter Model: CON021 signal conditioning unit Measurement Principle: Electromagnetic eddy current induction Probe Diameter: 8 mm Cable Length: 10 m, integrated shielded coaxial cable Measurement Range: Approx. 2–4 mm (dependent on calibration) Sensitivity: ~8 mV/µm (typical; varies by configuration) Linearity: ≤ ±1% full scale Frequency Response: DC up to 10 kHz (sensor chain dependent) Converter Bandwidth: 0–20 kHz (-3 dB) Output Signal: Analog voltage proportional to displacement Supply Voltage: ±15 V DC via CON021 module Operating Temperature: -35°C to +180°C Protection Rating: IP67 (probe), IP20 (converter) Weight: 0.22 kg ApplicationsIdeal for vibration analysis, axial and radial displacement monitoring, and real-time shaft dynamics assessment in turbines, motors, pumps, and compressors. Its high durability makes it suitable for harsh mechanical environments and high-temperature operations. FAQ Q: Can the probe operate in continuous high-temperature conditions?A: Yes, the PR6423/01M-010 is rated for continuous operation up to +180°C. Q: Is the output compatible with standard data acquisition systems?A: The analog voltage output is directly proportional to displacement and compatible with most DAQ or PLC systems. Q: How does this model compare to PR6422?A: Compared to the PR6422, PR6423/01M-010 offers higher thermal resistance and a wider frequency response, enhancing measurement stability under vibration and ther
$200.00 $100.00
-
EMERSON Emerson EPRO CON021 + PR6423/01C-010 8mm Eddy Current Sensor
Product Description OverviewThe CON021 + PR6423/01C-010 from Emerson EPRO is an 8 mm non-contact eddy current sensor designed for precision monitoring of critical turbomachinery. It accurately measures radial and axial shaft displacement, position, eccentricity, and speed in demanding applications including steam, gas, and hydro turbines, compressors, gearboxes, pumps, and fans. Its compact design and rugged construction ensure reliable performance in harsh industrial environments. Technical Specifications Performance Linear Measurement Range: 2 mm (80 mils) Initial Air Gap: 0.5 mm (20 mils) Incremental Scale Factor (ISF): ISO: 8 V/mm (203.2 mV/mil) ±5% @ 0 to 45°C (32 to 113°F) Deviation from Best Fit Straight Line (DSL): ±0.025 mm (±1 mil) @ 0 to 45°C (32 to 113°F) Measuring Target Minimum Shaft Diameter: 25 mm (0.79") Target Material: 42CrMo4 (AISI/SAE 4140) standard, other ferromagnetic steel available on request Environmental & General Protection Class: IP66, IEC 60529 Operating Temperature Range: Sensor with 1 m Cable: -35 to +180°C (-31 to 356°F) Cable & Connector: -35 to +150°C (-31 to 302°F) Material: Sensor Tip – PEEK (Polyether Ether Ketone), Case – Stainless Steel, Cable – PTFE, Connector – Nickel-plated Brass Weight (Sensor with 1 m Cable): Approx. 100 g (3.53 oz) ApplicationsOptimized for continuous monitoring of rotating machinery, the CON021 + PR6423/01C-010 supports predictive maintenance and condition monitoring to prevent downtime. Suitable for high-speed turbines, industrial compressors, and pumps, it ensures accurate vibration and displacement measurement under extreme conditions. FAQ Q: Can this sensor handle high-temperature operations?A: Yes, the sensor tip can operate up to 180°C and the cable assembly up to 150°C, supporting harsh industrial environments. Q: Is it compatible with other monitoring systems besides Emerson Ovation?A: Yes, standard output signals make it compatible with most DCS and condition monitoring platforms. Q: How does it compare with other PR6423 variants?A: The 01C-010 version is optimized for smaller shaft diameters and offers IP66 protection, while other PR6423 models may vary in cable length or temperature tolerance.
$200.00 $100.00
-
EMERSON Emerson EPRO CON021 + PR6423/017-030-CN Vibration Sensor System
Product Description OverviewThe CON021 + PR6423/017-030-CN from Emerson EPRO is a high-precision eddy current vibration monitoring solution engineered for rotating machinery protection and predictive maintenance. This integrated system combines a signal processing module with a proximity probe, providing reliable real-time vibration and displacement data for industrial control and monitoring systems. Technical Specifications General Information Brand: Emerson EPRO Model/Part Number: CON021 + PR6423/017-030-CN Function: Eddy Current Sensor System (Controller + Probe) CON021 Module Purpose: Signal processing and communication interface Compatibility: Supports multiple EPRO proximity probes Output: Delivers real-time vibration data to Emerson Ovation and other DCS platforms Performance: Ensures high-speed data acquisition with stable signal quality in demanding industrial environments PR6423/017-030-CN Probe Type: Eddy Current Proximity Probe for vibration and shaft displacement measurement Cable Length: 17 m (suffix -017) Variant: O30-CN – China-specific configuration for compliance and local installation requirements Accuracy: High precision with minimal drift for reliable long-term monitoring Environmental Tolerance: Designed for harsh industrial conditions, including temperature fluctuations and mechanical vibration Integration & Compatibility Interfaces seamlessly with Emerson Ovation and other condition monitoring systems Supports predictive maintenance and machinery protection applications ApplicationsSuitable for turbines, compressors, generators, and other critical rotating equipment. The system provides continuous shaft vibration monitoring, displacement detection, and predictive fault analysis to reduce downtime and improve equipment safety. FAQ Q: Is this system compatible with non-Emerson monitoring platforms?A: Yes, the CON021 + PR6423/017-030-CN outputs standard analog signals compatible with most industrial DCS and monitoring platforms. Q: What environments can the probe operate in?A: The probe is rated for harsh industrial conditions and maintains stable performance under temperature extremes and vibration. Q: How does this model compare to CON021 + PR6423/011-110-CN?A: The 017-030-CN variant includes a longer 17 m cable and a China-specific compliance configuration. Both models provide precise non-contact measurement, but the 017-030-CN is optimized for local regulatory requirements and extended installation flexibility.
$200.00 $100.00
-
EMERSON Emerson EPRO CON021 + PR6423/011-110-CN Eddy Current Sensor
Product Description OverviewThe CON021 + PR6423/011-110-CN from Emerson EPRO is a high-precision eddy current measurement system designed for continuous monitoring of rotating machinery. This integrated solution combines a proximity sensor and signal converter to provide accurate, non-contact measurement of shaft displacement, vibration, and position. The converter delivers stable analog outputs, making the system compatible with machinery protection systems and condition monitoring platforms in demanding industrial environments. Technical Specifications Model & Configuration Model Combination: CON021 + PR6423/011-110-CN Manufacturer: Emerson EPRO Product Type: Eddy Current Converter with Proximity Sensor Dynamic Performance Frequency Range: 0 – 20 kHz (-3 dB) Rise Time: <15 μs Sensor Details Sensor Model: PR6423/011-110-CN Measurement Principle: Eddy Current (non-contact) Probe Tip Diameter: 8 mm Probe Dimensions (approx.): 240 × 210 × 40 mm Sensor Weight: ~0.22 kg Electrical Characteristics Supply Voltage: -23 VDC to -32 VDC Output Signal Options: 4 V to 20 V 2 V to 18 V Environmental Conditions Operating Temperature: -30 °C to +100 °C Shock and Vibration Resistance: Up to 5 g at 60 Hz Protection Class: IP20 (converter housing) Mechanical Properties (Converter Unit) Enclosure Material: Aluminum Alloy (LMgSi 0.5 F22) Mounting: 4 × M5 screws ApplicationsIdeal for real-time shaft monitoring in turbines, compressors, generators, and other critical rotating equipment, the system ensures reliable condition assessment and vibration analysis for preventive maintenance and machinery protection. FAQ Q: Can the sensor operate in high-temperature environments?A: Yes, the converter supports continuous operation up to 100 °C, suitable for most industrial installations. Q: Are the output signals compatible with standard monitoring systems?A: Yes, both 4–20 V and 2–18 V analog outputs are compatible with most condition monitoring and machinery protection platforms. Q: Can similar models be compared for dynamic range?A: Models like CON022 provide similar frequency ranges but with extended output options. CON021 focuses on precision with fast rise times for high-speed shaft monitoring.
$200.00 $100.00
-
EMERSON Emerson CON021 & PR6423/010-040-CN Eddy Current Sensor Signal Converter
Product Description Overview The Emerson PR6423/010-040-CN Eddy Current Displacement Sensor paired with the CON021 Signal Converter provides a high-precision solution for monitoring critical rotating machinery. Designed for reliability in harsh industrial environments, this measurement chain enables non-contact detection of shaft vibration, axial displacement, and rotational position. Ideal for integration with Turbine Supervisory Instrumentation (TSI) systems, the setup ensures real-time monitoring of shaft dynamics to prevent mechanical failures. How It Works The system operates using the eddy current principle. The PR6423/010-040-CN sensor emits a high-frequency electromagnetic field. When a conductive shaft moves within this field, eddy currents are induced, altering the sensor coil’s impedance. The CON021 converter drives the sensor and translates these impedance variations into a stable, linear voltage signal suitable for PLCs or condition monitoring systems. Key Features Linear output directly proportional to shaft displacement for accurate readings across the measurement range High-temperature resistance up to 180°C, suitable for turbine housings Pressure-sealed sensor housing to maintain integrity under high-pressure lubrication systems Wide frequency response up to 20 kHz to detect early-stage bearing faults Plug-and-play compatibility with matched cable lengths for consistent field performance Robust, IP68-rated sensor with IP20-rated cabinet-mount converter Technical Specifications Feature Specification Sensor Model PR6423/010-040-CN Converter Model CON021 Measuring Range 4.0 mm (10 mm tip diameter) Output Signal -2 V to -18 V standard voltage loop Sensitivity 4.0 V/mm (100 mV/mil) Target Material Ferromagnetic steel (standard: 42CrMo4) Frequency Response Up to 20 kHz Temperature Rating -40°C to +180°C Protection Class Sensor: IP68, Converter: IP20 Cable/Connector Integrated with robust industrial connector Applications Radial Shaft Vibration Monitoring: Detects shaft orbiting within bearings Axial Shaft Positioning: Measures longitudinal displacement to prevent mechanical collisions Shaft Eccentricity Detection: Identifies bending or bow during startup Speed & Phase Reference (Keyphasor): Provides accurate RPM and phase timing for machinery diagnostics FAQ Q: Can the PR6423 sensor operate in high-temperature turbine environments?A: Yes, the sensor tip is rated for continuous operation up to 180°C. Q: Are CON021 and PR6423 interchangeable with other AMS/EPRO components?A: They are designed for plug-and-play compatibility with matching cable lengths; mixing with other models may require recalibration. Q: What shaft materials are compatible?A: Standard calibration is for ferromagnetic steel such as 42CrMo4; non-ferrous targets require adjustments. Q: What is the typical frequency response for vibration analysis?A: The system reliably captures vibration signals up to 20 kHz, sufficient for early fault detection in bearings and rotors. Q: Can the sensor be submerged in oil or other industrial fluids?A: Yes, the PR6423 is pressure-sealed and rated IP68 for full immersion.
$200.00 $100.00
-
EMERSON Emerson CON021+PR6423/010-000-CN 8mm Eddy Current Sensor High-Precision
Product Description OverviewThe Emerson CON021+PR6423/010-000-CN is a non-contact eddy current sensor engineered for high-performance turbomachinery applications. Designed to deliver precise radial and axial shaft displacement measurements, this sensor is ideal for monitoring critical components in steam, gas, and hydro turbines, compressors, gearboxes, pumps, and fans. Key Features Non-contact operation ensures minimal wear and extended sensor lifespan Accurate detection of shaft position, eccentricity, and speed Compact 8mm sensor diameter suitable for confined installations Technical Specifications Parameter Specification Linear Measurement Range 2 mm (80 mils) Initial Air Gap 0.5 mm (20 mils) Incremental Scale Factor (ISF) 8 V/mm ±5% (ISO standard) @ 0–45°C (203.2 mV/mil) Deviation from Best Fit Line (DSL) ±0.025 mm (±1 mil) @ 0–45°C Minimum Shaft Diameter 25 mm (0.98 in) Target Material 42CrMo4 (AISI/SAE 4140) Ferromagnetic Steel; other materials available on request Protection Class IP66 (IEC 60529) Operating Temperature Sensor + 1m cable: -35 to +180°C (-31 to +356°F); Cable & Connector: -35 to +150°C (-31 to +302°F) Sensor Materials Tip: PEEK; Case: Stainless Steel Cable Material PTFE Connector Material Brass, nickel-plated Weight Approx. 100 g (3.53 oz) Applications Steam, gas, and hydro turbines Industrial compressors and gearboxes Pumps, fans, and other rotating machinery Shaft monitoring for vibration, eccentricity, and speed control FAQQ: Can this sensor be used with shafts smaller than 25 mm?A: The minimum recommended shaft diameter is 25 mm to ensure measurement accuracy. Q: What types of target materials are compatible?A: Standard is 42CrMo4 steel; other ferromagnetic alloys are available upon request. Q: How resistant is the sensor to harsh environments?A: The sensor is IP66 rated, suitable for dust, water spray, and industrial conditions.
$200.00 $100.00
-
EMERSON Emerson CON021 + PR6423/00R-030 | Eddy Current Signal Converter
Product Description OverviewThe CON021 + PR6423/00R-030 from Emerson is a high-precision eddy current signal converter designed for continuous monitoring of critical rotating machinery. It delivers accurate measurements of radial and axial shaft displacement, rotor position, eccentricity, and speed/key signals, making it suitable for steam, gas, and hydro turbines, compressors, pumps, and industrial fans. Parameter Specification Housing Material LMgSi 0.5 F22 Weight ~120 g (4.24 oz) Mounting 4 screws M5×20 (included) Connections Transducer: Self-locking Lemo plug Supply/Output: Screw terminal, max 1.5 mm² wire ApplicationsIdeal for continuous condition monitoring of high-speed turbines, compressors, and pumps. This signal converter is optimized for real-time protection and predictive maintenance in critical industrial machinery. FAQ Q: What signals can the CON021 + PR6423/00R-030 measure?A: Radial and axial shaft displacement, rotor position, eccentricity, and speed/key signals depending on configuration. Q: Can it operate in high-temperature or high-vibration environments?A: Yes, it operates reliably from -30°C to +100°C and withstands shocks of 5 g at 60 Hz. Q: Is it compatible with other Emerson EPRO probes?A: It supports PR6422, PR6423, PR6424, PR6425, PR6426, and PR6453 series probes. Extended range configurations may require additional components.
$200.00 $100.00
-
EMERSON EPRO CoN021 + PR6423/00M-030 | Eddy Current Measurement System
Product Description OverviewThe EPRO CoN021 + PR6423/00M-030 is a fully integrated eddy current measurement system engineered for continuous monitoring of high-speed rotating machinery. Designed for reliability and precision, the solution delivers stable and repeatable measurements of shaft displacement, vibration, axial position, and rotor eccentricity even under extreme operating conditions. This system is ideal for critical turbomachinery applications where long-term accuracy, fast dynamic response, and mechanical durability are essential. System ArchitectureThe system is composed of three interconnected components calibrated as a matched set: Eddy current probe Extension cable Signal converter integrated with control or protection systems Using the PR6423/00M-030 probe with the CoN021 converter ensures optimal linearity, temperature stability, and signal integrity across the full operational range. EPRO CoN021 Signal ConverterThe CoN021 is a high-performance signal conditioner for rack-mounted machinery monitoring. It translates probe signals into standardized analog outputs compatible with vibration monitoring modules, PLCs, and DCS platforms. Its design supports both protection and continuous condition monitoring in demanding industrial environments. Technical Specifications Measurement Functions: radial shaft displacement, relative vibration, axial position, rotor eccentricity, and speed signals (configuration-dependent) Frequency Response: DC to 20 kHz (-3 dB), accommodating both slow-roll and high-speed dynamics Rise Time: Typically <15 μs for precise transient capture Probe Compatibility: Supports Emerson EPRO PR6422, PR6423, PR6424, PR6425, PR6426, and PR6453 series Supply Voltage: 23V to 32V with 4–20V output scaling 21V to 32V with 2–18V output scaling Operating Temperature: -30°C to +100°C for continuous operation Shock & Vibration: Rated 5g at 60 Hz Enclosure Protection: IP20 for cabinet mounting System Integration: Fully compatible with MMS 6000 and IMR6000 monitoring racks Maintenance: Supports hot-swap replacement without system downtime ApplicationsIdeal for high-speed turbines, compressors, generators, and other critical rotating equipment requiring continuous monitoring for reliability and predictive maintenance. FAQ Q: Can this system measure rotor eccentricity in real time?A: Yes, the matched probe and converter provide precise real-time rotor eccentricity readings under varying operational conditions. Q: Is the CoN021 compatible with other probe models?A: It supports Emerson EPRO probe families including PR6422, PR6423, PR6424, PR6425, PR6426, and PR6453, ensuring flexibility for system upgrades. Q: What environments can this system operate in?A: Designed for -30°C to +100°C ambient conditions with shock resistance up to 5g at 60 Hz, suitable for industrial monitoring cabinets.
$200.00 $100.00
-
EMERSON Emerson EPRO PR6423/003-040 | CON021 | Eddy Current Sensor Assembly
Product Description Overview The PR6423/003-040 paired with the CON021 signal conditioner forms a precision eddy current measurement system designed for continuous monitoring of shaft vibration and displacement in high-speed rotating machinery. This assembly ensures reliable and stable signal output under extreme mechanical stress and high-temperature conditions, making it ideal for turbines, compressors, and similar industrial equipment. Technical Specifications Probe Unit – PR6423/003-040 Sensor Type: Eddy Current Proximity/Displacement Probe Probe Diameter: 8 mm Linear Measurement Range: 2 mm (80 mils nominal) Installation Air Gap: ~0.5 mm Sensitivity: 8 V/mm ±5% (reference temperature 0–45°C) Linearity Accuracy: ±0.025 mm across calibrated range Minimum Shaft Diameter: ≥25 mm Target Material: Ferromagnetic steel (AISI 4140 / 42CrMo4 or equivalent) Environmental Performance Operating Temperature Range: -35°C to +180°C Protection Class: IP66 (dust tight and high-pressure water resistant) Designed for continuous operation in harsh turbine and compressor environments Signal Converter – CON021 Frequency Response: 0–20 kHz (-3 dB) Signal Rise Time: <15 μs Supply Voltage: 23–32 V DC (dual scaling options supported) Output Voltage Range: -4 V to 20 V or -2 V to 18 V Housing Material: Die-cast aluminum alloy (GD-AISi9Cu3) Protection Rating: IP65 Weight: 0.6 kg Applications Continuous vibration monitoring of high-speed shafts Displacement measurement for turbine and compressor machinery Real-time condition-based maintenance systems Harsh industrial environments with high temperature and dust/water exposure FAQ Q: What shaft diameters are supported by the PR6423/003-040 probe?A: Shafts with a diameter of 25 mm or larger are compatible. Q: Can the sensor operate in extreme temperatures?A: Yes, the probe supports operation from -35°C up to +180°C, suitable for turbine environments. Q: What materials are compatible with the eddy current measurement?A: The system is designed for ferromagnetic steel such as AISI 4140 or 42CrMo4. Q: Are there alternative models for comparison?A: The PR6422 series offers similar performance with smaller probe diameters and lower temperature ranges.
$200.00 $100.00
-
EMERSON Emerson CON021 | PR6423/001-011-CN | Eddy Current Shaft Sensor
Product Description Overview The Emerson CON021 signal converter coupled with the PR6423/001-011-CN eddy current displacement sensor forms a precision monitoring system for critical rotating machinery. Designed for use in turbines, compressors, and pumps, this measurement chain provides non-contact detection of shaft displacement, radial vibration, and eccentricity, ensuring reliable operation of industrial equipment. This system is part of the Emerson/AMS (formerly EPRO) product line and is engineered for high accuracy, durability, and seamless integration with advanced condition monitoring platforms such as TSI systems. System Components PR6423/001-011-CN Eddy Current Sensor High-sensitivity displacement probe for sub-micron movement detection Threaded body and pre-defined cable length for precise installation Hermetically sealed tip resistant to lubricants, oils, and high-pressure environments Operating temperature range: -35°C to +180°C "-CN" designation indicates compliance with local industrial standards in China CON021 Signal Converter Provides high-frequency excitation to the sensor Converts eddy current response into standardized analog voltage Linear voltage output: typically -2V to -18V or 0V to -20V depending on calibration DIN-rail mountable for compact cabinet integration Maintains signal integrity across a wide frequency range for static and dynamic monitoring Technical Specifications Feature Specification Measurement Principle Eddy Current (Non-Contact Inductive) Probe Tip Diameter 8.0 mm Linear Measuring Range 2.0–4.0 mm (depending on calibration) Linearity ≤ ±1% full scale Frequency Range 0 Hz to 10 kHz (up to 20 kHz possible) Operating Temperature Sensor: -35°C to +180°C; Converter: -35°C to +85°C Power Supply -24 VDC standard Environmental Resistance Pressure-sealed, corrosion-resistant Applications Turbines, Compressors, Pumps, Industrial Fans Applications This measurement chain is widely used in TSI (Turbine Supervisory Instrumentation) and condition monitoring systems: Radial Shaft Vibration: Tracks vibration in sleeve bearings to detect early faults Axial Thrust Position: Measures longitudinal shaft movement to prevent internal contact damage Phase Reference / Keyphasor: Provides rotational speed pulse and phase synchronization signals Installation Note Always ensure the sensor cable length matches the converter’s calibration. Using mismatched cable lengths can cause significant measurement errors and compromise system accuracy. FAQ Q: What is the effective measurement range of the PR6423/001-011-CN?A: The sensor provides a linear displacement range of approximately 2.0–4.0 mm depending on calibration. Q: Can the system handle high-temperature operation?A: Yes, the probe is rated for temperatures up to 180°C, while the converter operates safely up to 85°C. Q: Is this system compatible with other Emerson monitoring platforms?A: Yes, it integrates with TSI, AMS, and similar condition monitoring systems. Q: What is the output signal type?A: The CON021 provides a linear analog voltage output, typically -2V to -18V or 0V to -20V DC.
$200.00 $100.00
-
EMERSON Emerson CON021 | PR6423/000-031-CN | Shaft Vibration
Product Description Overview The Emerson CON021 signal converter paired with the PR6423/000-031-CN eddy current probe forms a high-precision monitoring solution for critical rotating machinery. Designed for integration with advanced systems such as MMS6000 and AMS 6500, this measurement chain accurately tracks radial shaft vibration, displacement, and static shaft position in turbines, compressors, pumps, and industrial fans. This system uses non-contact eddy current technology, combining mechanical robustness and electronic precision to deliver reliable performance in demanding industrial environments. Components PR6423/000-031-CN ProbeThe probe features an 8.0 mm tip diameter and is optimized for industrial deployment with: Hermetically sealed tip for high-pressure and oil-submerged applications Corrosion-resistant construction compatible with turbine oils and chemicals Operating temperature range: -35°C to +150°C Mechanical mounting and cable configuration suited for easy integration in standard monitoring setups CON021 Signal ConverterThis electronic unit supplies the probe with a high-frequency excitation signal, detects impedance variations, and converts them to a standardized analog voltage. Key features include: Linear voltage output: -2V to -18V DC High signal-to-noise ratio for sub-micron accuracy DIN-rail compatible modular design for simplified installation Wide frequency response suitable for both static measurements (axial position, thermal expansion) and dynamic monitoring (vibration, shaft runout, eccentricity) Technical Specifications Feature Specification Measurement Principle Eddy Current (Inductive) Probe Tip Diameter 8.0 mm Linear Measuring Range Approx. 2.0 mm Sensitivity 8 V/mm (200 mV/mil) Output Signal Negative Analog Voltage (-2V to -18V DC) Operating Temperature -35°C to +150°C (Probe) Frequency Response DC to several kHz Environmental Resistance Pressure-sealed, corrosion-resistant Application Turbines, Pumps, Fans, Compressors Applications Ideal for continuous monitoring of critical rotating machinery in power generation and oil & gas industries. Typical use cases include: Radial shaft vibration tracking Shaft displacement and thermal growth measurement Condition-based maintenance to prevent unplanned shutdowns FAQ Q: What is the maximum displacement range of the probe?A: The PR6423/000-031-CN provides an effective linear measuring range of approximately 2.0 mm. Q: Can this system handle high-temperature environments?A: Yes, the probe operates reliably up to 150°C without compromising accuracy. Q: Is this system compatible with standard monitoring systems?A: Yes, it integrates seamlessly with MMS6000, AMS 6500, and other industrial monitoring platforms. Q: How is the probe installed?A: The probe includes a standardized mounting and cable configuration for straightforward installation in turbines, compressors, and pumps.
$200.00 $100.00
-
EMERSON Emerson PR6426/000-130 + CON021/916-200 Sensor Converter System
Product Description OverviewThe Emerson PR6426/000-130 paired with the CON021/916-200 signal converter forms a robust displacement measurement system for large-scale rotating machinery. This combination provides precise monitoring of shaft displacement, vibration, and position, optimized for applications that demand a larger measuring range or interaction with larger target surfaces. System Components PR6426/000-130 (Eddy Current Sensor) High-performance inductive displacement probe with an 18 mm tip diameter. Designed for extended measurement ranges up to 8.0 mm, suitable for axial or radial shaft displacement. Generates a high-frequency electromagnetic field to detect distances to conductive targets. Available with configurable cable lengths to meet installation requirements. CON021/916-200 (Signal Converter) Dedicated transmitter providing power and signal linearization for the PR6426 probe. Calibrated to handle the extended range and electrical characteristics of the PR6426 series. Converts raw displacement data into a highly linear voltage output for integration into monitoring or machine protection systems. Performance Features Extended Measurement Capability Supports wider measuring spans than standard eddy current probes, ideal for large machinery gaps. High Sensitivity & Stability Maintains a strong signal-to-noise ratio even with large target surfaces, ensuring reliable displacement and vibration readings. Thermal and Mechanical Robustness Hermetically sealed probe tip for high-pressure environments. Temperature-compensated converter ensures consistent output despite thermal fluctuations. Non-Contact Measurement Eddy current principle allows maintenance-free operation without mechanical wear. Machine Protection Ready Linear output and fast response support real-time safety systems, including automatic trips in case of excessive shaft movement. Technical Specifications Feature Specification Probe Tip Diameter 18 mm Measurement Range Up to 8.0 mm Sensitivity Typically 2.0 V/mm or 4.0 V/mm (calibration-dependent) Frequency Range 0 Hz (Static) to several kHz (Dynamic) Output Type Negative voltage proportional to displacement Target Material Calibrated for ferromagnetic metals (e.g., VCL 140 / 42CrMo4) Operating Temperature -30°C to 100°C (-22°F to 212°F) Shock & Vibration 5g @ 60 Hz, 25°C (77°F) Protection Class IP20 Mounting 4 × M5x20 screws (included) Housing Material LMgSi 0.5 F22 Weight ~120 g (4.24 oz) Electrical Connections Transducer: Self-locking Lemo plug; Supply/Output: Screw terminal (max. 1.5 mm² wire) Applications Large steam turbines for axial thrust and expansion monitoring Hydroelectric generators to track shaft vibration and air gap Heavy-duty compressors for radial displacement and eccentricity detection Industrial pumps and rotating equipment requiring extended-range displacement sensing FAQ Q: Can the PR6426 operate with standard converters?A: No, the PR6426/000-130 requires the CON021/916-200 for proper linearization and extended range operation. Q: What environments can this system handle?A: It is suitable for high-temperature (-30°C to 100°C), high-pressure, and moderate vibration environments (5g at 60 Hz). Q: How does it differ from PR6423 probes?A: PR6426 has a larger tip and extended measuring range (up to 8.0 mm) for bigger shafts or target surfaces, whereas PR6423 is optimized for smaller gaps and standard industrial machinery.
$200.00 $100.00
-
EMERSON Emerson CON021 | 916-160 EPRO | High-Precision Eddy Current Converter
Product Description Overview The CON021 | 916-160 is an advanced eddy current signal converter engineered for high-speed turbomachinery monitoring. It accurately converts shaft displacement, radial position, eccentricity, and key speed signals into standardized analog outputs. Optimized for Emerson MMS6000 and IMR6000 monitoring systems, this module supports hot-swappable installation, ensuring continuous operation of critical rotating equipment without downtime. Key Technical Features Precision Signal Conversion Measures shaft displacement, radial motion, eccentricity, and speed signals with high fidelity. Supports multiple compatible sensors including PR6422, PR6423, PR6424, PR6425 (with extended range), PR6426, and PR6453. Wide Frequency Response Operates from DC up to 20 kHz (-3 dB), capturing both static and dynamic machinery behavior. Rapid response time with rise time below 15 μs ensures accurate real-time monitoring. Reliable Industrial Operation Input voltage ranges: -23 V to -32 V (output -4 V to -20 V) and -21 V to -32 V (output -2 V to -18 V). Configurable analog output for integration into monitoring systems. Operating temperature from -30°C to +100°C (-22°F to +212°F) for demanding industrial environments. Shock and vibration tolerance: 5 g at 60 Hz, 25°C. Rugged Design Housing made from LMgSi 0.5 F22 aluminum alloy. Protection class: IP20. Compact and lightweight at 120 g, rack-based mounting compatible with MMS6000/IMR6000. Hot-swappable with self-locking LEMO connectors or screw terminal connections. Technical Specifications Table Feature Specification Function Shaft displacement, radial position, eccentricity, speed/key signal conversion Compatible Sensors PR6422, PR6423, PR6424, PR6425 (extended range), PR6426, PR6453 Frequency Range 0–20,000 Hz (-3 dB) Rise Time <15 μs Input Voltage -23 V to -32 V (output -4 V to -20 V), -21 V to -32 V (output -2 V to -18 V) Output Signal Configurable analog voltage Operating Temperature -30°C to +100°C (-22°F to +212°F) Shock & Vibration 5 g @ 60 Hz @ 25°C Protection Class IP20 Housing Material LMgSi 0.5 F22 Aluminum Alloy Weight 120 g Mounting Rack-based, MMS6000/IMR6000 compatible, hot-swappable Connections Self-locking LEMO plug or screw terminals Applications Continuous shaft monitoring on steam turbines, compressors, and generators. Integration with Emerson MMS6000 or IMR6000 systems for real-time vibration and displacement tracking. Hot-swappable modules ensure no interruption during maintenance or upgrades. FAQ Q: Which sensors are compatible with the CON021 | 916-160?A: The module works with PR6422, PR6423, PR6424, PR6425 (requires extended range), PR6426, and PR6453 series sensors. Q: What is the frequency range of this converter?A: It covers DC to 20 kHz (-3 dB), suitable for both static displacement and high-speed vibration measurements. Q: Can it operate in high-shock environments?A: Yes, it tolerates 5 g shock at 60 Hz and is designed for industrial-grade machinery conditions. Q: Is hot-swapping supported?A: Yes, the CON021 | 916-160 supports hot-swappable installation in rack-mounted Emerson monitoring systems.
$200.00 $100.00
-
EMERSON Emerson CON021 | 914-100 Signal Converter PR6423/010-010-CN Sensor
Product Description Overview The CON021 | 914-100 signal converter paired with the PR6423/010-010-CN eddy current sensor provides high-precision, non-contact measurement of shaft displacement and vibration. This combination is engineered for critical rotating machinery such as steam turbines, large motors, and generators. Utilizing electromagnetic induction, the system converts subtle variations in gap distance into a linear analog voltage output, delivering reliable data for machine monitoring and protection systems. Core Technical Features High Sensitivity and Accuracy Detects sub-micron displacement and vibration variations. Essential for early fault detection in high-speed machinery. Non-Contact Measurement The eddy current probe measures shaft motion without mechanical contact. Prevents sensor wear and eliminates interference with machine operation. Exceptional Linearity The converter maintains a consistent voltage response across the full measurement range (typically 2.0 mm). Standard output range is -2V to -18V, ensuring precise correlation between physical displacement and electrical signal. Industrial Reliability Operating temperature: Probe head withstands high temperatures near bearings. Pressure-resistant design suitable for lubricated and pressurized environments. Materials resist oil, hydraulic fluids, and common industrial chemicals. Versatile Monitoring Supports both static measurements (axial shaft position) and dynamic measurements (radial vibration, eccentricity). Compatible with machine monitoring and control systems for real-time condition assessment. Technical Specifications Table Feature Specification Measurement Principle Eddy Current / Non-Contact Measurement Range 2.0 mm nominal Output Signal Analog Voltage (-8 V/mm typical sensitivity) Probe Diameter 8.0 mm Target Material Conductive metals (calibrated for 42CrMo4) Protection Rating IP66/IP68 for probe head Operating Temperature Probe: -35°C to +150°C, Converter: -20°C to +80°C Frequency Response DC to 10 kHz typical Applications Radial vibration, axial thrust, shaft eccentricity Application Note This system is widely integrated into machine monitoring systems (MMS) such as Emerson AMS 6500 and MMS6000. It provides accurate real-time data to trigger alarms or protective actions if vibration or displacement exceeds operational limits, safeguarding high-value rotating equipment. FAQ Q: Can this sensor system detect both vibration and shaft displacement?A: Yes, the PR6423/010-010-CN probe captures dynamic radial vibration and static axial displacement simultaneously. Q: What is the typical measurement range?A: The nominal measurement range is 2.0 mm, calibrated for conductive steel shafts. Q: Is the system suitable for high-temperature environments?A: The probe can operate up to +150°C, making it suitable for turbine and motor bearings. Q: Are there alternative models for different mounting or cable lengths?A: Emerson’s PR642x series offers multiple configurations to accommodate various cable lengths, connector types, and regional certifications.
$200.00 $100.00
-
EMERSON Emerson CON021 | 913-040 Signal Converter PR6424/000-000 Sensor
Product Description Overview The CON021 | 913-040 is a high-performance signal converter designed to interface with the PR6424/000-000 eddy current displacement sensor. This assembly provides precise, non-contact measurement of radial and axial motion in high-speed rotating machinery, including turbines, compressors, and industrial pumps. Operating on eddy current principles, the system detects minute changes in shaft position and converts these signals into standardized analog voltage outputs suitable for machine monitoring systems or distributed control systems. The PR6424/000-000 sensor is engineered for extreme industrial environments, offering robust resistance to temperature fluctuations, pressure, and exposure to oils or chemicals. Together, the converter and probe provide a reliable, high-resolution measurement solution for vibration and displacement monitoring. Key Technical Features High Accuracy and Linearity Detects sub-micron displacements with linear output across the calibrated range. Linearity error typically < ±1% of full scale. Non-Contact Operation Measures shaft vibration and position without physical contact, reducing wear and maintenance. Ideal for continuous operation in high-speed machinery. Environmental Robustness Operating temperature: Probe -35°C to +150°C, Converter -20°C to +80°C Resistant to industrial lubricants, coolants, and chemical exposure. Probe tip designed for high-pressure industrial environments. Dynamic and Static Measurement Capability Captures both static displacement (axial thrust) and dynamic vibration (radial motion). Wide frequency response supports high-speed rotating equipment monitoring. Standardized Industrial Output Analog voltage output proportional to gap (e.g., 0 to -20V or -2V to -18V). Compatible with Emerson MMS, DCS, and other control systems. Technical Specifications Table Feature Specification Sensor Type Eddy Current / Non-Contact Measurement Range 4.0 mm (typical for PR6424) Output Signal Analog Voltage, proportional to gap Linearity < ±1% full scale Frequency Response 0–10 kHz typical Operating Temperature Probe: -35°C to +150°C, Converter: -20°C to +80°C Mechanical Protection IP65–IP67 (sensor tip depending on mounting) Application Radial vibration, axial thrust, shaft eccentricity Applications Monitoring turbine and compressor shafts in power plants. Detecting pump shaft misalignment and imbalance. Predictive maintenance of high-speed rotating equipment. Integration into machine condition monitoring and control systems. FAQ Q: Can the sensor measure both vibration and displacement simultaneously?A: Yes, the PR6424 probe captures dynamic radial vibrations and static axial displacement concurrently. Q: What environments can the sensor withstand?A: The probe is engineered for high temperature, oil, and chemical exposure, suitable for harsh industrial machinery housings. Q: What type of output does the converter provide?A: The CON021 outputs a standardized analog voltage proportional to shaft displacement, compatible with MMS or DCS systems. Q: Are there alternative models for higher temperature ranges?A: Emerson offers variants in the PR64xx series designed for extreme heat or pressure conditions.
$200.00 $100.00
-
EMERSON Emerson EPRO CON021/913-040 + PR6423/015-000-CN Eddy Current Converter
Product Description OverviewThe CON021/913-040 + PR6423/015-000-CN assembly by Emerson EPRO provides a fully integrated solution for non-contact monitoring of shaft dynamics in high-speed rotating machinery. Combining an advanced eddy current proximity sensor with a dedicated signal conversion module, this system ensures reliable, precise, and stable measurements suitable for both protection systems and condition monitoring platforms. It is engineered for use in power generation, petrochemical, and process industries. Key Features Non-contact shaft vibration measurement High-speed response for dynamic monitoring Reliable operation in demanding industrial environments Compatible with protection relays and monitoring software Technical Specifications Model Combination Model: CON021/913-040 + PR6423/015-000-CN Manufacturer: Emerson EPRO Product Type: Eddy Current Converter with Proximity Sensor Measurement Performance Frequency range: 0–20 kHz (-3 dB) Signal rise time: <15 μs High linearity over full measurement range Sensor Details Probe type: Eddy Current Proximity Sensor Model: PR6423/015-000-CN Tip diameter: 8 mm Measurement principle: Non-contact eddy current Electrical Parameters Supply voltage: 23–32 VDC Output signal ranges: 4–20 mA 2–18 VDC Environmental Specifications Operating temperature: -30°C to +100°C Shock and vibration resistance: 5 g at 60 Hz Protection rating: IP20 (converter module) Applications High-speed turbine monitoring Industrial generator shaft vibration detection Process plant rotating equipment condition monitoring Integration with protective relays and SCADA systems FAQ Q: Can this sensor system be used in explosive environments?A: No, the standard assembly is rated IP20 and not intrinsically safe. Emerson offers optional certified versions for hazardous locations. Q: How does it compare to other models in the PR64 series?A: Compared to PR6421/PR6422 variants, PR6423/015-000-CN provides a faster response time and higher bandwidth, making it suitable for high-speed shaft applications.
$200.00 $100.00
-
EMERSON Emerson CON020/91 | TheCoNo 20/91 | Eddy Current Conditioning Module
Product Description Overview The CON020/91 by Emerson is a precision signal conditioning module engineered for use with EPRO eddy current proximity measurement systems. It functions as the electronic processing stage, converting raw probe signals into stable, calibrated electrical outputs suitable for high-fidelity vibration and displacement monitoring in rotating machinery. This module is an integral component of a three-element measurement chain and is not a standalone sensor. Measurement System Architecture A standard configuration consists of: PR642x Proximity Probe (sensing element) ECF Extension Cable (signal transmission) CON020/91 Conditioning Module (signal processing unit) This architecture ensures uniform calibration across turbines and compressors, maintaining measurement integrity under dynamic mechanical load conditions. Technical Specifications Signal Processing Generates eddy current excitation using a stabilized oscillator circuit Linearizes probe response across the operating range Low-drift signal conditioning for long-term stability Input Compatibility Compatible with PR6422, PR6423, PR6424, and PR6426 probe families Supports multiple sensitivity settings depending on system calibration Output Characteristics Provides scaled analog displacement signal (voltage or 4–20 mA current depending on integration) Typical sensitivity: 8 mV/µm (configuration dependent) Performance Parameters Measurement span: approximately ±1.0 mm to ±2.0 mm (probe dependent) Frequency response: up to 10 kHz Linearity deviation: ±1% of full-scale Electrical & Mechanical Data Power supply: 24 VDC regulated Signal output: analog voltage or 4–20 mA (system dependent) Operating temperature: –20°C to +70°C (typical industrial range) Enclosure: ruggedized for industrial applications Applications Ideal for vibration and displacement analysis in turbines, compressors, and other rotating machinery where stable, high-precision measurements are critical. FAQ Q: Can CON020/91 operate independently without a probe?A: No, it requires a compatible PR642x probe and extension cable for operation. Q: What sensitivity configurations are supported?A: Multiple sensitivities are available based on system calibration requirements. Q: How does it maintain measurement stability?A: The module features low-drift signal conditioning and linearized probe response to ensure long-term accuracy. Q: Can it handle high-frequency signals?A: Yes, the module supports frequency responses up to 10 kHz, suitable for dynamic machinery monitoring. Similar Products Comparison CON020/92: Higher output range for extended span CON020/93: Enhanced temperature tolerance for harsh environments
$200.00 $100.00
-
EMERSON Emerson CON011+PR6424/010-140 | Shaft Displacement Module
Product Description Overview The 16 mm Eddy Current Sensor by Emerson is a non-contact measurement device engineered for high-performance turbomachinery. It provides precise monitoring of radial and axial shaft displacement, position, eccentricity, and rotational speed. Designed for steam, gas, and hydro turbines, compressors, pumps, and large fans, it ensures reliable condition monitoring under demanding operational conditions. Technical Specifications Parameter Specification Sensor Type Non-contact Eddy Current Target Material Ferromagnetic Steel (42CrMo4 standard) Radial / Axial Displacement Measurement ±2 mm static; 0–1,000 µm dynamic Sensitivity / Linearity 4 V/mm (101.6 mV/mil) ≤ ±1.5% Nominal Air Gap (Center) 2.7 mm (0.11 in) Long-Term Drift <0.3% Maximum Surface Speed 2,500 m/s (98,425 ips) Minimum Shaft Diameter 80 mm Operating Temperature -35 °C to 150 °C (-31 °F to 302 °F) Temperature-Induced Error <4% per 100 K (API 670 compliant) Pressure Resistance (Sensor Head) 10,000 hPa (145 psi) Shock & Vibration 5 g at 60 Hz @ 25 °C (77 °F) Material Sleeve: Stainless Steel; Cable: PTFE Weight (Sensor + 1 m Cable, no Armor) ~200 g (7.05 oz) Key Features Non-contact eddy current measurement for precise shaft displacement and speed detection. High linearity and low long-term drift ensure stable, accurate readings. Compact 16 mm design allows integration into tight spaces. Engineered for high-speed shafts up to 2,500 m/s and shafts ≥80 mm diameter. Robust construction withstands high temperature, pressure, and mechanical shock. Applications Turbomachinery including steam, gas, and hydro turbines. Pumps, compressors, and industrial fans requiring high-precision monitoring. Condition monitoring systems aligned with API 670 standards. Predictive maintenance and shaft dynamics analysis in mission-critical environments. FAQ Q: What is the suitable air gap for this sensor?A: Nominal air gap is approximately 2.7 mm (0.11 in). Deviations should be minimized for optimal accuracy. Q: Can this sensor handle high surface speeds?A: Yes, the sensor is rated for maximum surface speeds up to 2,500 m/s (98,425 ips). Q: How does the 16 mm sensor compare with larger models?A: Its compact size allows installation in confined spaces while maintaining high sensitivity and linearity similar to larger eddy current sensors.
$200.00 $100.00
-
EMERSON Emerson CON011 | 916-120 | RoHS Compliant Sensor Component
Product Description Overview The CON011 (916-120) from Emerson is designed to meet strict China RoHS requirements. This statement provides detailed information on the presence of toxic or hazardous substances in the component, including PCBs, enclosures, and hardware, ensuring compliance with environmental and safety standards for industrial monitoring systems. Material Compliance Summary Component Lead (Pb) Mercury (Hg) Cadmium (Cd) Hexavalent Chromium (Cr VI) Polybrominated Biphenyls (PBB) Polybrominated Diphenyl Ethers (PBDE) PCB Assembly X O O O O O Enclosure O O O O O O Hardware O O O O O O Legend: O – Substance level in all homogeneous materials of this part is below the maximum limit defined in GB/T 26572. X – Substance level in at least one homogeneous material exceeds the GB/T 26572 limit. Key Features Complete RoHS compliance documentation for industrial sensors and related assemblies. Covers all major components including PCB, enclosure, and hardware. Designed for long-term environmental safety and regulatory adherence. Supports lifecycle management and environmental risk assessment. Applications Industrial monitoring and automation systems requiring regulatory compliance. Components replacement or audit processes to ensure adherence to environmental standards. Used in environments with high regulatory oversight, including China RoHS and other regional directives. FAQ Q: What does RoHS compliance indicate for the CON011 (916-120)?A: It ensures the product’s toxic or hazardous substances are within the maximum permissible limits defined by China RoHS standards. Q: Which components exceed the RoHS limits?A: The PCB assembly contains lead (Pb) in at least one homogeneous material above the limit; all other components are compliant. Q: Can this component be used worldwide?A: Yes, but specific RoHS compliance documentation is primarily for China. Additional regional certification may be needed for EU or other countries. Q: How long is this compliance valid?A: The Environmental Friendly Use Period (EFUP) applies under standard operating conditions as defined in the product manual.
$200.00 $100.00
-
EMERSON Emerson CON010 PR6424/010-040 Eddy Current Vibration Sensor Kit
Product Description OverviewThe CON010 (PR6424/010-040) from Emerson offers a fully integrated solution for precise vibration and shaft displacement monitoring. This kit combines the high-accuracy CON010 eddy current sensor module with the PR6424/010-040 proximity probe, delivering reliable diagnostics and protection for rotating machinery in challenging industrial environments. Key Features Integrated Sensor Solution: Combines module and probe for comprehensive vibration and shaft displacement monitoring. High Precision Measurement: Supports exact detection of shaft movement and vibration using eddy current technology. Compact Probe Design: 40 mm probe length ensures suitability for installations with limited space. Robust and Durable: Designed to withstand mechanical shock, vibration, and airborne contaminants. Seamless System Compatibility: Fully compatible with Emerson EPRO monitoring platforms for continuous operation in critical systems. Technical Specifications Parameter Specification Module Model CON010 Eddy Current Sensor Module Probe Model PR6424/010-040 Proximity Probe Probe Length 40 mm Measurement Type Shaft displacement and vibration via eddy current Input Type Eddy current proximity probe System Compatibility Emerson EPRO monitoring systems Voltage Supply 24 VDC (system-dependent) Operating Temperature -40°C to +70°C Shock Resistance 10 g, half-sine wave, 11 ms duration Vibration Endurance 1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz) Airborne Contaminants ISA-S71.04-1985, Class G3 Relative Humidity 5–95%, non-condensing Protection Rating IP20 ApplicationsIdeal for use in turbines, compressors, pumps, and other rotating machinery requiring continuous monitoring in industrial settings, including petrochemical, power generation, and heavy manufacturing. FAQ Q: Can this sensor kit be integrated with third-party monitoring systems?A: The CON010 (PR6424/010-040) is optimized for Emerson EPRO platforms. Third-party integration may require signal conditioning. Q: Is the probe suitable for high-temperature environments?A: The probe operates reliably from -40°C to +70°C. For higher temperatures, consult Emerson specifications. Q: How does this model differ from CON011?A: Compared to CON011, the CON010 offers a more compact probe and slightly higher vibration resistance, making it suitable for confined installations and higher shock environments.
$200.00 $100.00
-
EMERSON Emerson CON010 PR6423/010-120 Vibration & Shaft Displacement Sensor
Product Description The CON010 sensor module paired with the PR6423/010-120 proximity probe offers a comprehensive solution for precision vibration and shaft displacement measurement in demanding industrial environments. This system is engineered for reliability and accuracy in monitoring rotating machinery, enabling early detection of mechanical issues and protecting critical equipment. Technical Specifications Module Model: CON010 Eddy Current Sensor Module Probe Model: PR6423/010-120 Proximity Probe Measurement Type: Shaft displacement and vibration Probe Length: 120 mm Probe Type: Eddy current proximity sensor System Compatibility: Emerson EPRO monitoring platforms Supply Voltage: 24 VDC (dependent on system configuration) Operating Temperature: -40°C to +70°C Shock Resistance: 10 g, half-sine wave, 11 ms duration Vibration Endurance: 1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz) Airborne Contaminants: ISA-S71.04-1985, Class G3 Relative Humidity: 5–95%, non-condensing Protection Rating: IP20 Key Features Complete monitoring solution combining sensor module and probe High-precision measurement for shaft displacement and vibration Engineered for durability under shock, vibration, and airborne contaminants Seamless integration with Emerson EPRO monitoring systems Industrial-grade reliability for continuous operation in critical environments Applications Monitoring pumps, turbines, compressors, and motors Early detection of bearing wear, misalignment, and imbalance Industrial plants requiring high-accuracy rotating machinery diagnostics FAQ Q: Can the probe be used with non-Emerson monitoring systems?A: The PR6423/010-120 is optimized for Emerson EPRO platforms, though integration with other systems may require additional interface modules. Q: What is the expected service life of the sensor under continuous operation?A: Under recommended operating conditions (-40°C to +70°C, 5–95% humidity), the module and probe are designed for long-term industrial use with minimal maintenance. Q: How does this model compare with similar Emerson sensors?A: Compared to the CON011 series, the CON010 + PR6423/010-120 combination provides enhanced vibration tolerance and longer probe reach, making it suitable for larger rotating equipment.
$200.00 $100.00
-
EMERSON Emerson A6824R ModBus Rack Interface Module IMR6500 Series
Product Description Overview The A6824R from Emerson is a high-performance ModBus and rack interface module designed for the IMR6500 series machinery protection systems. Its 4TE wide, 1-slot plug-in format optimizes cabinet space, reducing the footprint by half compared to traditional 6U cards. This module supports optional redundancy, hot-swappable installation, and comprehensive self-monitoring to ensure reliable system performance in critical applications. Key Features Space-Saving Design: 4TE / 1-slot format minimizes cabinet space requirements. Redundancy Option: Supports redundant configuration for fail-safe operation. Hot-Swappable: Can be installed or replaced without powering down the rack. API 670 Compliant: Meets international standards for machinery protection systems. Secure Configuration: Password-protected settings prevent unauthorized changes. Self-Monitoring: Continuous checks on hardware status, input power, and module temperature. Multi-Rack Capability: Single module can serve multiple 19” racks, enabling flexible deployment. Easy Handling: Integrated handle allows quick removal and identification of the module and sensors. Communication & Data ModBus RTU (Serial): 19.2 kBaud, 8 data bits, even parity, 1 stop bit. Default IP Address: 192.168.255.1, Subnet Mask: 255.255.255.0. ModBus Ethernet: RJ45 socket, 10Base-T. Status Indicators: Green LED shows power supply health. Technical Specifications Feature Specification Model / Part Number A6824R Module Type ModBus Rack Interface Module Compatible Series IMR6500 Series Width 4TE Rack Size 19” Redundancy Optional Hot-Swap Capability Yes Data Output ModBus RTU Serial & ModBus Ethernet Serial Baud Rate 19.2 kBaud Data Bits / Parity / Stop Bits 8 / Even / 1 Default Network Address 192.168.255.1 Subnet Mask 255.255.255.0 Ethernet Port RJ45, 10Base-T Indicators Green LED for Power Status Self-Monitoring Hardware, Power Input, Temperature Installation Hot-Swappable / 1-Slot Plug-In Standards Compliance API 670 Machinery Protection Applications Redundant data communication in machinery protection systems. Integration with CSI 6500 and IMR6500 racks for vibration and speed monitoring. Optimized for industrial environments where rack space and hot-swap flexibility are critical. Supports secure multi-rack deployment in plant-wide monitoring networks. FAQ Q: Can this module be used in IMR6000 series racks?A: No, the A6824R is designed specifically for the IMR6500 series. A separate 6TE, non-redundant version exists for IMR6000. Q: Does the module require powering down the rack for installation?A: No, it is fully hot-swappable. Q: How is redundancy configured?A: Redundancy can be enabled through the module configuration menu, providing automatic failover between primary and backup channels. Q: What type of network interfaces are supported?A: ModBus RTU over serial and ModBus Ethernet via RJ45 10Base-T.
$200.00 $100.00
You have seen 72 out of 228 products
