Description
Overview
The PR6423/010-100-CN CON021 from EMERSON is an 8 mm eddy current sensing module designed for precise non‑contact displacement and vibration measurement. As part of the EPRO monitoring family, this unit conditions probe signals and delivers stable output for DCS‑based machinery protection and diagnostic systems. Its compact form factor and robust electronics make it suitable for long‑term deployment in demanding industrial environments.
Functional Characteristics
This module processes analog inputs from compatible EMERSON/EPRO proximity probes and converts them into a calibrated output suitable for real‑time monitoring. Enhanced filtering, temperature‑compensation circuitry, and drift‑reduction techniques ensure consistent performance even under fluctuating ambient conditions. The design supports seamless integration into existing monitoring racks and automation architectures.
Technical Specifications
| Parameter |
Specification |
| Model |
PR6423/010-100-CN CON021 |
| Product Type |
8 mm Eddy Current Sensor Module |
| Brand |
EMERSON |
| Series |
EPRO |
| Condition |
Brand New |
| Weight |
0.36 kg |
| Dimensions |
23 × 23 × 4 cm |
| Origin |
USA |
| System Compatibility |
DCS |
| Communication Interface |
Ethernet service port |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Performance Attributes
-
Designed for 8 mm probe systems requiring high‑resolution displacement measurement
-
Stable output with low noise and minimal signal distortion
-
Temperature‑compensated electronics for long‑term accuracy
-
Suitable for shaft vibration, axial position, and proximity monitoring
-
Rugged construction for continuous operation in harsh industrial settings
-
Supports integration with PLCs, DCS, and condition‑monitoring platforms
Application Scenarios
-
Turbine and compressor shaft displacement monitoring
-
Rotating machinery vibration diagnostics
-
Proximity measurement in high‑speed equipment
-
Aerospace and automotive test benches
-
Industrial automation requiring precise non‑contact sensing
Model Comparison
| Model |
Probe Size |
Output Type |
Typical Use |
| PR6423/010-100-CN CON021 |
8 mm |
Conditioned signal |
Standard machinery monitoring |
| PR6423/005-030 |
5 mm |
Analog |
Compact machinery applications |
| PR6423/015-100 |
15 mm |
Extended range |
Large‑gap displacement systems |
FAQ
Q: Does this module support all EMERSON eddy current probes? A: It is optimized for 8 mm probe systems but compatible with most EPRO‑series probes within the same calibration range.
Q: Can it be used in high‑temperature zones? A: The electronics are temperature‑compensated, but installation must follow EMERSON environmental limits.
Q: Is the Ethernet port used for data output? A: It is intended for service and configuration, not for primary measurement output.
