Description
Overview
The PR6423/00R-101 CON031 Eddy Current Sensor Module is part of EMERSON’s EPRO monitoring line and is designed to condition and process signals from non‑contact eddy current probes. It provides stable, calibrated output suitable for displacement, proximity, and vibration measurement in machinery protection and diagnostic systems. Its compact form factor and durable construction make it suitable for long‑term operation in demanding industrial environments.
Functional Characteristics
This module converts raw analog probe signals into conditioned outputs optimized for DCS and PLC integration. Its internal circuitry incorporates noise‑suppression filtering, temperature‑compensation elements, and drift‑control techniques to maintain measurement accuracy under varying operating conditions. The module supports real‑time monitoring of shaft movement, bearing behavior, and structural vibration.
Technical Specifications
| Parameter |
Specification |
| Model |
PR6423/00R-101 CON031 |
| Product Type |
Eddy Current Sensor Module |
| Brand |
EMERSON |
| Series |
EPRO |
| Condition |
Brand New |
| Weight |
0.16 kg |
| Dimensions |
16 × 15 × 2 cm |
| Origin |
USA |
| System Compatibility |
DCS |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
| Communication Interface |
Ethernet service port (service access only) |
Performance Attributes
-
Converts non‑contact eddy current probe signals into stable conditioned outputs
-
Low‑noise signal path for high‑resolution displacement and vibration monitoring
-
Temperature‑compensated electronics for long‑term measurement stability
-
Robust housing suitable for harsh industrial environments
-
Compatible with EMERSON/EPRO probe systems
-
Supports predictive maintenance and machinery protection applications
Application Scenarios
-
Shaft displacement and vibration monitoring in rotating machinery
-
Proximity measurement in turbines, compressors, and high‑speed equipment
-
Condition monitoring systems requiring high‑precision non‑contact sensing
-
Integration into EPRO‑based monitoring racks and DCS architectures
Model Comparison
| Model |
Output Type |
Typical Use Case |
| PR6423/00R-101 CON031 |
Conditioned signal |
Standard displacement and vibration monitoring |
| PR6423/010-100-CN |
8 mm probe module |
Medium‑range proximity measurement |
| PR6423/013-130 CON021 |
Digital output |
High‑precision DCS integration |
FAQ
Q: Is this module compatible with all EMERSON eddy current probes? It is designed for use with EPRO‑series probes within the same calibration range.
Q: Does the Ethernet port provide measurement data? No, it is intended for service and configuration only.
Q: Can this module operate in high‑temperature environments? It includes temperature‑compensation circuitry, but installation must follow EMERSON environmental specifications.
