Woodward spare parts and accessories support system maintenance and upgrades. From replacement modules to specialized components, these parts help reduce downtime, extend equipment life, and ensure reliable operation.
Woodward Other Parts
-
Woodward Woodward 9905-970 LinkNet 6-Channel Analog Input Module
Scalable Analog Monitoring for Turbine Control Systems The Woodward 9905-970 is a precision analog input module from the LinkNet 9900 Series, designed to deliver up to six high-accuracy analog signals to turbine control systems. Manufactured by Woodward Inc., this module enables real-time monitoring of critical parameters such as temperature, pressure, and flow rate, allowing for optimized turbine performance and safe operation. Key Features Six analog input channels for simultaneous multi-parameter monitoring Supports 0–10 V and 0–20 mA input ranges for flexible sensor integration High measurement accuracy ensures reliable turbine control decisions Plug-and-play installation with user-friendly configuration Scalable design compatible with other LinkNet components Ideal for turbine systems requiring dynamic performance adjustments Technical Specifications Specification Details Manufacturer Woodward Inc. Series LinkNet 9900 Series Model 9905-970 Voltage 24 Vdc Current 4 mA Input Channels 6 Input Range 0–10 V / 0–20 mA Dimensions 160 mm × 160 mm × 12 mm Weight 0.8 kg Product Catalog LinkNet 6-Channel Input Module
$200.00 $100.00
-
Woodward Woodward 5466-355 NetCon Remote Chassis Transceiver
Product Overview The Woodward 5466-355 NetCon Remote Chassis Transceiver is a high-speed communication module designed for MicroNet Digital Control Systems using CPU 68040 architecture. Engineered for robust data exchange across remote I/O chassis, this transceiver ensures reliable transmission of control, data, and address signals via differential line drivers operating at VME bus speeds. Key Features Model: 5466-355 Series: MicroNet Digital Control System Compatibility: CPU 68040 only Interface: High-speed differential line drivers VME transmission rate Parallel bus communication Connectors: Dual 100-pin Micro-D metal shell connectors Robust cable interface for reliable signal integrity Installation Notes: No switches or LEDs Must be installed in Slot 1 of each expansion chassis Use termination resistor variant only in the last chassis Signal Safety: Prevents signal distortion and reflection Supports IOLOCK logic via chassis decoder activation Cable Guidelines: 0.9 m cables for T-Module connections 3 m cables for Main Chassis and final expansion links Troubleshooting: Check and replace cables if module malfunctions Replace module if issues persist Technical Specifications Specification Value Part Number 5466-355 Voltage Input 24 Vdc Current Draw 4 mA Dimensions 160 mm × 160 mm × 120 mm Weight 0.8 kg Product Catalog MicroNet Digital Control
$200.00 $100.00
-
Woodward Woodward 5501-471 NetCon SIO Module
Product Overview The Woodward 5501-471 NetCon SIO Module is a precision-engineered serial interface module designed for 9900 Series Turbine Control Systems. Built to facilitate seamless communication between the control system and field devices, this module ensures accurate data exchange for safe and efficient turbine operation. Key Features Model: 5501-471 Series: NetCon / 9900 Series Interface Type: Serial Input/Output (SIO) Supported Protocols: RS-232, RS-485, Modbus Mounting: Screw post for secure chassis integration Application Scope: Turbine speed, temperature, and power regulation Real-time sensor data acquisition Actuator command transmission Device Compatibility: Sensors: temperature, pressure, vibration, flow Actuators: valves, dampers, control elements Conversion Logic: Serial-to-control system format and vice versa System Integration: Enables safe, efficient turbine operation through continuous data exchange Technical Specifications Specification Value Part Number 5501-471 Voltage Input 24 Vdc Current Draw 4 mA Dimensions 160 mm × 160 mm × 120 mm Weight 0.8 kg Product Catalog NetCon SIO Module
$200.00 $100.00
-
Woodward Woodward 5503-335 MicroNet 5200 CPU Module
Product Overview The Woodward 5503-335 MicroNet 5200 CPU Module is a compact, high-performance embedded controller designed for gas turbine control systems and industrial automation environments. Built around the Intel Atom processor, this module delivers a powerful balance of performance and energy efficiency, making it ideal for real-time control and monitoring applications. Key Features Model: 5503-335 Series: MicroNet 5200 Processor: Intel Atom – optimized for industrial performance and low power consumption Memory: Up to 4GB DDR3 – supports complex computational loads I/O Interfaces: Multiple serial ports Ethernet USB Operating System Support: Windows Embedded Standard Windows Embedded Compact Linux Industrial Protocols: Modbus CANbus PROFIBUS Design Attributes: Compact form factor for easy integration Rugged connectors Shock and vibration resistance Wide operating temperature range Application Scope: Gas turbine control Industrial automation Real-time sensor and actuator management Technical Specifications Specification Value Part Number 5503-335 Voltage Input 24 Vdc Current Draw 4 mA Dimensions 160 mm × 160 mm × 120 mm Weight 0.8 kg Product Catalog MicroNet 5200 CPU Module
$200.00 $100.00
-
Woodward Woodward 5437-672 NetCon Field Terminal Module
Product Overview The Woodward 5437-672 NetCon Field Terminal Module from the 5400 Series offers a compact, high-reliability interface for turbine control systems. Designed for distributed control systems (DCS) and programmable logic controllers (PLC), this module simplifies field device integration with robust signal conditioning and protocol conversion. Key Features Organizes field wiring with localized, streamlined connections Reduces signal interference via short cable runs Supports secure, stable terminal connections for fast setup Includes protective circuitry to prevent short-circuit damage Enables real-time communication with control systems Optimized for turbine control and industrial automation environments Technical Specifications Parameter Specification Manufacturer Woodward Part Number 5437-672 Series 5400 Series Product Type NetCon Field Terminal Module Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 15.9 cm × 8.9 cm × 6.3 cm Weight 0.3 kg Connector Type 37-pin terminal
$200.00 $100.00
-
Woodward Woodward 9905-972 LINKnet 6-Channel Analog Output Module
The Woodward 9905-972 is a high-performance analog output module from the LINKnet series, designed to deliver six independent 4–20 mA outputs for industrial automation and control applications. Manufactured by Woodward Inc., this module ensures reliable signal transmission and system integrity through integrated watchdog monitoring and real-time feedback. Key Features Six independent 4–20 mA analog outputs for flexible control Output current monitored via onboard A/D converter Watchdog disables drivers after 1.2 seconds of communication loss Hot-replacement capability for minimal downtime Rotary address switches for easy configuration DIN rail mounting for streamlined installation Technical Specifications Specification Details Manufacturer Woodward Inc. Series LINKnet Model 9905-972 Voltage 24 Vdc Current 4 mA Power Supply Input 18–32 Vdc Power Consumption 6.0 W at 24 Vdc Output Channels 6 Output Range 0–25 mA Dimensions 330 mm × 80 mm × 40 mm Weight 1.5 kg
$200.00 $100.00
-
Woodward Woodward 5437-173 NetCon Field Terminal Module
Product Overview The Woodward 5437-173 NetCon Field Terminal Module is engineered for seamless integration with MicroNet control I/O modules. Designed to replace traditional interposing terminal blocks, this module connects directly to subminiature D-type connectors and offers cage-clamp terminals for secure field wiring. Key Features Connects field wiring to MicroNet I/O modules via D-type interface Cage-clamp terminals support 1×12 AWG or 2×18 AWG wires EMI protection and shield termination ensure clean signal transmission DIN rail mountable for fast, organized installation Wire stripping length: 0.312 inches (8 mm) for optimal clamp fit Eliminates need for separate interposing terminal blocks Technical Specifications Parameter Specification Manufacturer Woodward Part Number 5437-173 Series NetCon Product Type Field Terminal Module Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 15.9 cm × 8.9 cm × 6.3 cm Weight 0.3 kg Terminal Type Cage-clamp Wire Compatibility 1×12 AWG or 2×18 AWG Mounting 35 mm DIN Rail
$200.00 $100.00
-
Woodward Woodward 5437-053 NetCon Field Terminal Module
Product Overview The Woodward 5437-053 NetCon Field Terminal Module is a robust and compact solution for terminating field wiring in industrial control systems. Designed for seamless integration with Woodward control platforms, this module simplifies wiring, reduces installation errors, and ensures reliable performance in demanding environments. Applications Power generation control systems Industrial automation panels Process control and monitoring Energy and utility system integration Engine and turbine control systems Technical Specifications Attribute Details Manufacturer Woodward Part Number 5437-053 Product Type NetCon Field Terminal Module Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 18 cm × 12 cm × 5 cm Weight 0.2 kg Mounting 35 mm DIN Rail Terminal Type Cage-clamp Product Catalog Field Termination Module
$200.00 $100.00
-
Woodward Woodward 9906-707 EGS TE Control Module
The Woodward 9906-707 is a high-precision control module from the EGS Trim System, designed to optimize industrial gas engine performance across a wide range of fuel qualities. Developed by Woodward Inc., this module delivers full authority over spark, fuel, and air, while integrating advanced diagnostics for detonation, misfire, and engine health monitoring. Key Features Closed-loop control for regulated emissions and consistent engine output Full authority over ignition, fuel metering, and air intake Integrated diagnostics: knock detection, misfire, and engine protection Scalable architecture for engines from 300 kW to 2000 kW (400–2700 hp) Compatible with FireFly™ Knock Detection, SmartCoils, IC-920/IC-922, and easYgen™ power management systems Supports both EGS TrimLITE and EGS TrimAdvanced configurations Technical Specifications Specification Details Manufacturer Woodward Inc. Series EGS Trim System Model 9906-707 Voltage 24 Vdc Current 5 A Dimensions 160 mm × 160 mm × 12 mm Weight 0.8 kg Engine Range 300 kW to 2000 kW (400–2700 hp)
$200.00 $100.00
-
Woodward Woodward 9905-204 DSM Synchronizer Module
Product Overview The Woodward 9905-204 DSM Synchronizer Module delivers precise, automated synchronization of generator speed and voltage to a live bus, ensuring seamless integration in power generation systems. Designed for steam and gas turbine applications, this module sends raise/lower signals to both speed controls and voltage regulators, enabling smooth transitions and minimizing system stress. Applications Steam and gas turbine generator systems Power generation and utility synchronization Industrial automation requiring generator-to-bus matching Electronic control systems with raise/lower contact inputs Integration with Woodward digital controllers and NetCon® platforms Technical Specifications Attribute Details Manufacturer Woodward Part Number 9905-204 Product Type DSM Synchronizer Module Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 160 mm × 160 mm × 12 mm Weight 0.8 kg Compatibility Woodward 501, 503, 509, 505, NetCon® Operating Modes 4 selectable modes Breaker Commands 2 independent outputs
$200.00 $100.00
-
Woodward Woodward 9905-760 Link Termination Resistor
Digital Synchronizer & Load Control Module for Generator Systems The Woodward 9905-760 is a precision-engineered module designed to synchronize and regulate multiple generators or power sources within industrial power systems. As part of Woodward’s Digital Synchronizer and Load Control series, it ensures seamless parallel operation and stable power output, making it a critical component in high-demand environments. Technical Specifications Attribute Value Manufacturer Woodward Inc. Part Number 9905-760 Product Catalog Digital Synchronizer and Load Control Description Link Termination Resistor Voltage 24 Vdc Current 4 mA Dimensions 160 mm × 160 mm × 12 mm Weight 0.8 kg Application Scope Power plants and industrial facilities with multiple generators Systems requiring precise synchronization and load balancing Environments with RF interference concerns Integration into automated or manual control architectures
$200.00 $100.00
-
woodward woodward 5464-836 Remote Transceiver
Product Overview The Woodward 5464-836 Remote Transceiver is a high-performance PLC module designed for integration into MicroNet Plus control systems. With programmable logic capabilities and multi-protocol communication support, this module enables real-time control, rapid data processing, and seamless coordination across industrial automation architectures. MicroNet Plus Integration VME Bus Standard – Ensures high-speed data transfer and modular connectivity Etched-Circuit Motherboard – Links logic and power slots for streamlined architecture Slot-Specific Configuration – Modules must match software-assigned slots for proper operation Field Termination Modules (FTMs) – I/O connections routed via front-facing cables to FTMs Applications Industrial automation and process control Power generation and turbine systems Remote monitoring and distributed control Sensor and actuator interfacing Fault diagnostics and system health monitoring Technical Specifications Attribute Details Manufacturer Woodward Part Number 5464-836 Product Catalog Programmable Logic Controller Module Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 16 cm × 16 cm × 12 cm Weight 0.8 kg Communication Ethernet, RS-232/485, Discrete I/O I/O Type Analog & Digital Bus Standard VME (VERSAmodule Eurocard) System Compatibility MicroNet Plus chassis
$200.00 $100.00
-
woodward woodward 5464-843 NetCon CPU Module
Product Overview The Woodward 5464-843 NetCon CPU Module is a powerful processing unit designed for the MicroNet™ and Vertex-Pro Motor-Driven Compressor Control Systems. Featuring a Motorola MPC5200 processor, 128 MB DDR RAM, and 64 MB flash memory, this module delivers fast, deterministic control for complex industrial applications. Applications Motor-driven compressor control systems MicroNet™ and NetCon® digital control platforms Distributed control systems (DCS) Real-time industrial automation Redundant system architectures requiring VMEbus coordination Technical Specifications Attribute Details Manufacturer Woodward Part Number 5464-843 Product Catalog MicroNet Digital Control Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 16 cm × 16 cm × 12 cm Weight 0.8 kg Processor Motorola MPC5200 (40 MHz) RAM / Flash 128 MB DDR / 64 MB Flash Ports 2 Ethernet, 2 Real-Time Network, 2 CAN, RS232, Service Port Display Support Video, Keyboard, Monitor Bus Standard VMEbus Architecture Support Simplex / TMR
$200.00 $100.00
-
Woodward Woodward 5466-253 MicroNet Analog Combo
Product Overview The Woodward 5466-253 MicroNet Analog Combo (TMR) module is a versatile, high-density I/O solution designed for demanding industrial control environments. Engineered for Triple Modular Redundant (TMR) systems, this module integrates speed sensing, analog I/O, and proportional actuator control into a single compact unit—streamlining installation and enhancing system reliability. Applications Power generation and turbine control Oil and gas process automation Petrochemical plant instrumentation Rotating machinery speed monitoring Valve and motor control via proportional actuators Technical Specifications Attribute Details Manufacturer Woodward Part Number 5466-253 Product Catalog MicroNet Digital Control Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 16 cm × 16 cm × 12 cm Weight 0.8 kg Speed Inputs 4 (magnetic pick-up / proximity probe) Analog Inputs 8 (4–20 mA) Analog Outputs 4 Actuator Drivers 2 (4–20 mA or 20–160 mA configurable) Architecture Triple Modular Redundant (TMR)
$200.00 $100.00
-
Woodward 5466-258 | Woodward Discrete I/O Module
Product Overview The Woodward 5466-258 Discrete I/O Module is engineered for integration into MicroNet Digital Control systems. It connects directly to the motherboard via card guides and secures with dual front-panel screws. Two ergonomic handles allow safe disengagement from the chassis without damaging connectors. This module supports real-time node replacement, minimizing system downtime. It mounts on a DIN rail and accepts discrete inputs powered by either internal or external 24 Vdc sources. Installation Notes Set the module address using rotary switches before mounting. Ensure network cables remain connected during node replacement. To replace a faulty node, remove terminal blocks and the module, match address settings on the new unit, and reinsert. Reset the node via the application program to resume communication. Technical Specifications Parameter Specification Manufacturer Woodward Model Number 5466-258 Series MicroNet Digital Control Input Voltage 24 Vdc Operating Current 4 mA Dimensions 16 cm × 16 cm × 12 cm Weight 0.8 kg Mounting DIN rail Address Configuration Rotary switches (x2) Node Replacement Real-time, hot-swappable Application & Compatibility The Woodward 5466-258 module is ideal for industrial automation systems requiring discrete input handling. It supports fault-tolerant architectures and is compatible with MicroNet chassis configurations. Its hot-swappable design and addressable node setup make it suitable for mission-critical environments such as energy plants, manufacturing lines, and process control systems.
$200.00 $100.00
-
Woodward Woodward 5466-329 NetCon Actuator Driver Module
Product Overview The Woodward 5466-329 NetCon Module is a high-precision actuator driver designed for use in MicroNet Digital Control Systems. This module receives digital commands from the CPU and generates four proportional actuator-driver signals, each scalable to either 0–25 mAdc or 0–200 mAdc, enabling fine-tuned control of industrial actuators. Applications Industrial actuator control Process automation and turbine systems Valve and motor current regulation Real-time control systems requiring precise current output Fault-sensitive environments with high reliability demands Installation Notes Slides into card guides and plugs directly into the motherboard Secured with top and bottom screws on the front panel Toggle handles allow safe disengagement from motherboard connectors Designed for easy replacement and minimal downtime Technical Specifications Attribute Details Manufacturer Woodward Part Number 5466-329 Product Catalog MicroNet Digital Control Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 16 cm × 16 cm × 12 cm Weight 0.8 kg Output Channels 4 Output Range 0–25 mAdc or 0–200 mAdc Interface VME-bus Calibration EEPROM-based Fault Detection Per-channel monitoring + FAULT LED
$200.00 $100.00
-
Woodward Woodward 5466-341 NetCon Module
Product Overview The Woodward 5466-341 NetCon Module is a precision-engineered fuel control solution designed for advanced gas turbine applications. Featuring adaptive combustion tuning and dual-fuel optimization, this module enables seamless operation across natural gas and hydrogen blends—making it ideal for hybrid and combined-cycle power plants. Typical Use Cases Industrial Gas Turbine Optimization – Dynamic valve control for large-scale turbines Hybrid Power Plant Fuel Switching – Smooth transitions between NG and H₂ blends (up to 30% H₂) Low-Emission Power Generation – Supports sustainability goals with intelligent NOx control Combined-Cycle Plant Integration – Enhances flexibility and fuel efficiency Technical Specifications Attribute Details Manufacturer Woodward Part Number 5466-341 Product Catalog MicroNet Digital Control Voltage 24 Vdc Current 4 mA Dimensions (L×W×H) 16 cm × 16 cm × 12 cm Weight 0.8 kg Fuel Compatibility Natural Gas / Hydrogen blends Emission Control Real-time NOx reduction (up to 18%) Accuracy ±0.25% fuel flow Environmental Rating IP65
$200.00 $100.00
-
Woodward Woodward 5466-346 NetCon Module – MicroNet Actuator Driver
Product Overview The Woodward 5466-346 NetCon Module converts digital CPU commands into four proportional actuator signals. Each channel delivers either 0–25 mAdc or 0–200 mAdc, depending on system configuration. The module uses dual-port memory via VME-bus for output scheduling and data exchange. A dedicated microcontroller scales outputs using EEPROM calibration constants and monitors voltage and current levels. It detects channel faults and load anomalies, triggering the FAULT LED when necessary. The system can disable individual drivers to isolate issues without halting operation. Installation Notes Slide the 5466-346 module into card guides and secure it with two front-panel screws. Use the top and bottom handles to disengage the board from the motherboard connectors safely. Technical Specifications Parameter Specification Manufacturer Woodward Model Number 5466-346 Series MicroNet Digital Control Input Voltage 24 Vdc Operating Current 4 mA Output Channels 4 (Proportional Actuator Signals) Output Range 0–25 mAdc or 0–200 mAdc Dimensions 16 cm × 16 cm × 12 cm Weight 0.8 kg Memory Interface VME-bus, dual-port memory Calibration Storage EEPROM Fault Indicator FAULT LED Application & Compatibility The Woodward 5466-346 module suits actuator control in high-reliability automation systems. It integrates seamlessly with MicroNet Digital Control platforms and supports proportional output for turbine governors, industrial drives, and process actuators. Its fault detection and channel isolation features make it ideal for aerospace, energy, and safety-critical environments. Use part number 5466-346 when ordering from authorized Woodward distributors.
$200.00 $100.00
You have seen 42 out of 42 products
