Description
Product Overview
The Woodward 5466-258 Discrete I/O Module is engineered for integration into MicroNet Digital Control systems. It connects directly to the motherboard via card guides and secures with dual front-panel screws. Two ergonomic handles allow safe disengagement from the chassis without damaging connectors.
This module supports real-time node replacement, minimizing system downtime. It mounts on a DIN rail and accepts discrete inputs powered by either internal or external 24 Vdc sources.
Installation Notes
Set the module address using rotary switches before mounting. Ensure network cables remain connected during node replacement. To replace a faulty node, remove terminal blocks and the module, match address settings on the new unit, and reinsert. Reset the node via the application program to resume communication.
Technical Specifications
| Parameter |
Specification |
| Manufacturer |
Woodward |
| Model Number |
5466-258 |
| Series |
MicroNet Digital Control |
| Input Voltage |
24 Vdc |
| Operating Current |
4 mA |
| Dimensions |
16 cm × 16 cm × 12 cm |
| Weight |
0.8 kg |
| Mounting |
DIN rail |
| Address Configuration |
Rotary switches (x2) |
| Node Replacement |
Real-time, hot-swappable |
Application & Compatibility
The Woodward 5466-258 module is ideal for industrial automation systems requiring discrete input handling. It supports fault-tolerant architectures and is compatible with MicroNet chassis configurations.
Its hot-swappable design and addressable node setup make it suitable for mission-critical environments such as energy plants, manufacturing lines, and process control systems.
