ABB TK811V150 S800 ModuleBus Optical Cable Configured for optical ModuleBus communication in ABB S800 systems, the ABB TK811V150 (TK811V150 Duplex Plastic Optical Fiber Cable) provides a 15 m physical optical link between compatible ModuleBus nodes. Hardware Specifications Parameter Specification Model TK811V150 Product ID 3BSC950107R3 Brand ABB Series S800 Product Type Duplex Plastic Optical Fiber Cable Application Optical ModuleBus connection Fiber Type Plastic Optical Fiber (POF) Cable Length 15 m Cable Configuration Duplex Connector Prefabricated connectors Cable Diameter 5 mm Weight 0.125 kg Dimensions 15 m cable length; 5 mm cable diameter Mechanics S800 Optical ModuleBus Communication The TK811V150 carries ModuleBus communication through a duplex plastic optical fiber path. Therefore, the communication link uses optical transmission rather than a copper electrical signal path. The POF construction provides electrical isolation between connected nodes. In addition, the optical path does not form a conductive signal path for electromagnetic interference. Consequently, the cable can separate the communication medium from electrical noise sources associated with industrial control wiring. The 15 m cable length defines the physical connection supplied by this model. Furthermore, the prefabricated construction reduces field termination work and preserves the specified connector arrangement. For S800 installations, the cable functions as a physical ModuleBus interconnection component. However, the supplied data does not specify communication velocity, optical attenuation, wavelength, or receiver sensitivity, so these values should not be inferred from the model number. Frequently Asked Questions (FAQ) Q: Does the TK811V150 require an electrical power connection? A: No. The TK811V150 is a passive optical cable and has no specified power consumption. Q: What is the physical cable length? A: The TK811V150 has a specified cable length of 15 m. Q: Can the cable length or optical performance be extended by field splicing? A: The supplied data identifies the product as a prefabricated cable. It does not specify field splicing procedures or permitted modifications. Therefore, installation should retain the supplied cable and connector configuration. Field Installation Guidelines Verify the complete ABB part number, 3BSC950107R3, before installation. Confirm that both connected devices support the required optical ModuleBus interface. Route the cable away from mechanical pinch points, sharp edges, and excessive bending. Do not pull the cable by its optical connectors during installation. Keep connector interfaces clean and protected from dust before mating. Maintain the factory-installed connector configuration unless ABB documentation explicitly permits modification. Avoid routing practices that place continuous mechanical stress on the fiber cable. After installation, verify that both optical connectors are fully seated and mechanically latched. If communication faults occur, inspect connector seating, cable routing, visible damage, and fiber continuity before replacing system hardware. Do not assign an operating temperature, minimum bend radius, attenuation, or optical transmission limit unless the applicable ABB installation documentation specifies the value

Read more less

ABB BDM000150R1 TK 821F Serial Cable The ABB BDM000150R1, also cataloged as the TK 821F Serial Cable, provides a two-channel serial connection between the FI 820F interface and TB 870F terminal block. The cable incorporates integral connectors and has a specified length of 0.5 m. Hardware Specifications Parameter Specification Model BDM000150R1 Product ID 3BDM000150R1 ABB Type Designation TK 821F Brand ABB Product Type Prefabricated Cable Cable Function Serial Cable, 2 channel Cable Length 0.5 m Connectors Integral connectors Connection FI 820F to TB 870F Compatible Terminal Block TB 870F Equivalent Part DFA 021 Voltage Classification Not specified Weight Not specified; ABB database lists 0 kg Dimensions Length: 0.5 m; other dimensions not specified WEEE Category Product Not in WEEE Scope HS Code 854442 Customs Tariff Number 85444210 Serial Interface and Cable Configuration The TK 821F uses a prefabricated two-channel cable assembly with integral connectors. It connects the FI 820F interface directly to the TB 870F terminal block. Therefore, the cable provides the physical serial interconnection without requiring field termination of individual conductors. The specified cable length is 0.5 m. ABB also identifies the DFA 021 as an identical cable designation. Because the supplied documentation does not define conductor allocation, pin assignment, shielding construction, or electrical interface levels, those parameters should be verified against the associated FI 820F and TB 870F documentation before replacement or wiring work. Frequently Asked Questions (FAQ) Q: What equipment does the ABB TK 821F connect? A: The cable connects an FI 820F interface to a TB 870F terminal block and supports two serial channels. Q: Does the TK 821F require field-installed connectors? A: No. The supplied description specifies integral connectors as part of the prefabricated cable assembly. Q: Is the TK 821F RoHS compliant? A: No. The supplied ABB data explicitly identifies the product as not RoHS compliant. Field Installation Guidelines Verify the cable designation, product ID, and connector configuration before installation. Confirm that the receiving equipment is the specified FI 820F interface and TB 870F terminal block. Isolate system power according to the applicable site maintenance procedure before making or removing connections. Inspect both integral connectors for mechanical damage, contamination, or bent contacts. Route the serial cable separately from high-current power conductors where practical to reduce electromagnetic interference. Avoid sharp bends, excessive tensile loading, crushing, or repeated mechanical movement of the cable. Do not modify the prefabricated connector assembly unless ABB documentation explicitly permits modification. After installation, verify connector engagement and cable routing before restoring system power. Check serial communication after installation and confirm that both intended channels operate correctly. Use the applicable ABB wiring documentation to verify pin assignments and shielding or grounding requirements because those details are not specified in the supplied product data.

Read more less

ABB TK821V020 Battery Cable Configured for battery power connection within ABB prefabricated cable assemblies, the ABB TK821V020 (TK821V020 Battery Cable) provides a direct physical connection between the battery circuit and the associated ABB control hardware. The cable has a specified length of 2.0 m and is supplied as a prefabricated cable. Hardware Specifications Parameter Specification Model TK821V020 Product ID 3BSC950202R1 Brand ABB Product Type Prefabricated Cable Cable Function Battery Cable Cable Length 2.0 m Origin Sweden / Germany Product Net Weight 0.1 kg Gross Weight 0.1 kg Dimensions Cable length: 2.0 m; other dimensions not specified Operating Temp Not specified in supplied data Power Consumption Passive cable; no power consumption specified Customs Tariff Number 85389099 UNSPSC 39120000 WEEE Category Product Not in WEEE Scope Minimum Order Quantity 1 piece Order Multiple 1 piece Product Status New Made To Order No Selling Unit piece ABB Industrial Control and Cable Integration The TK821V020 is a passive battery cable, so it does not perform signal processing, protocol conversion, or active control functions. Instead, it provides the physical electrical path required by the associated ABB hardware. Because the supplied documentation does not specify conductor size, connector type, pin assignment, insulation rating, or maximum current, these values should be verified against the applicable ABB system documentation before installation. The cable length is specified as 2.0 m. Therefore, installation should maintain the cable route without introducing unnecessary mechanical tension, excessive bending, or interference with adjacent power and signal wiring. Frequently Asked Questions (FAQ) Q: What is the specified cable length of the ABB TK821V020? A: The specified cable length is 2.0 m. Q: Does the TK821V020 consume electrical power? A: No active power consumption is specified because the TK821V020 is a passive prefabricated battery cable. Q: Are the conductor size and connector pinout specified in the supplied data? A: No. The supplied ABB data identifies the product as a Battery Cable but does not specify conductor size or connector pin assignment. Refer to the applicable system wiring documentation before termination or replacement. Field Installation Guidelines Confirm the complete part number 3BSC950202R1 / TK821V020 before installation. Verify the cable destination against the applicable ABB system wiring diagram. Confirm connector orientation and mating compatibility before applying electrical power. Route the cable away from sources of mechanical abrasion and avoid sharp bends. Do not apply tensile load to the cable or connector during installation. Keep battery wiring separated from high-current switching conductors where the system installation rules require separation. Inspect connectors and cable insulation for mechanical damage before energizing the circuit. Verify polarity and electrical continuity according to the applicable ABB wiring documentation. Do not substitute a cable with different conductor, connector, or length specifications unless ABB documentation permits the substitution.

Read more less

ABB TK850V007 3BSC950192R1 CEX-Bus Extension Cable The ABB TK850V007 3BSC950192R1, also cataloged as the TK850V007 CEX-Bus Extension Cable, provides a 0.7 m physical connection for CEX-Bus extension within ABB control hardware. The cable uses prefabricated construction and requires a TK851 CEX-Bus terminator when installed. Hardware Specifications Parameter Specification Model TK850V007 3BSC950192R1 Brand ABB Product Type Prefabricated Cable Function CEX-Bus Extension Cable CEX-Bus Requirement TK851 CEX-Bus terminator required Cable Length 0.7 m Product Net Depth / Length 700 mm Product Net Height 6 mm Product Net Width 13 mm Product Net Weight 0.2 kg HS Code 854442 Customs Tariff Number 85444210 WEEE Category Product Not in WEEE Scope ABB CEX-Bus Extension Characteristics TK850V007 provides the physical cable path required for CEX-Bus extension between compatible ABB control-system components. The supplied cable length is 0.7 m, while the documented physical dimensions are 700 mm x 13 mm x 6 mm. The cable is supplied as a prefabricated assembly. Therefore, field fabrication of the cable connection is not part of the specified product configuration. Furthermore, ABB specifies the use of a TK851 CEX-Bus terminator with TK850V007. The cable itself is a passive interconnection component. Consequently, it has no separately specified power-consumption rating. Frequently Asked Questions Q: What is the specified cable length of TK850V007 3BSC950192R1?A: The specified cable length is 0.7 m, corresponding to a product net length of 700 mm. Q: Is a terminator required when using TK850V007?A: Yes. The supplied ABB data specifies that TK850V007 requires a TK851 CEX-Bus terminator. Q: Does TK850V007 consume electrical power?A: No. TK850V007 is a passive prefabricated cable and has no separately specified power-consumption requirement. Field Installation Guidelines Verify the cable part number before installation: TK850V007, 3BSC950192R1. Confirm that the connected equipment supports the ABB CEX-Bus interface. Install the TK851 CEX-Bus terminator as specified for the TK850V007 configuration. Route the cable without excessive bending, crushing, or mechanical tension. Keep the cable separated from sources of strong electromagnetic interference where practical. Do not modify the prefabricated cable assembly unless the applicable ABB installation documentation explicitly permits modification. Verify connector seating before energizing the associated control hardware. Maintain the specified cable routing and mechanical clearance required by the installed ABB equipment.

Read more less

ABB TK850V007 3BSC950192R1 CEX-Bus Extension Cable Configured for CEX-Bus signal extension, the ABB TK850V007 3BSC950192R1 (TK850V007 CEX-Bus Extension Cable) provides a direct cable connection for CEX-Bus network expansion. The assembly has a specified length of 0.7 m and supports low-voltage CEX-Bus communication within ABB control hardware. Hardware Specifications Parameter Specification Model TK850V007 3BSC950192R1 Product Type CEX-Bus Extension Cable Brand ABB Origin Sweden Spare Model 3BSC950192R1 Cable Length 0.7 m Voltage Rating < 24 VDC Current Rating < 50 mA typical Operating Temp -25 deg C to +70 deg C Bend Radius Minimum 5 x cable diameter Weight 0.3 kg Manufacturer ABB CEX-Bus Communication and Cable Characteristics The TK850V007 provides the physical cable path for CEX-Bus extension between compatible ABB control system components. Therefore, installation should preserve the specified electrical connection and mechanical routing conditions. The cable operates below 24 VDC and has a typical current rating below 50 mA. In addition, the specified operating temperature range extends from -25 deg C to +70 deg C. The 0.7 m cable length supports short-distance CEX-Bus extension. Furthermore, installers should maintain a minimum bend radius of 5 x the cable diameter to prevent excessive mechanical stress on the cable assembly. This component should be applied only where the connected ABB hardware specifies TK850-series CEX-Bus cable compatibility. The supplied data does not define a separate firmware requirement, communication speed, shielding termination, or connector pinout. Frequently Asked Questions Q: What is the rated cable length of the ABB TK850V007? A: The specified cable length is 0.7 m. Q: What electrical limits are specified for the TK850V007? A: The supplied specifications state a voltage rating below 24 VDC and a typical current rating below 50 mA. Q: What bend radius should be maintained during installation? A: Maintain a minimum bend radius of 5 x the cable diameter. Field Installation Guidelines Verify the TK850V007 part number and 3BSC950192R1 spare model against the equipment documentation before installation. Connect the cable only to compatible CEX-Bus interfaces specified by the ABB system documentation. Route the cable without sharp bends, crushing, twisting, or excessive tensile loading. Maintain the minimum bend radius of 5 x the cable diameter throughout the cable route. Keep the cable away from mechanical movement and sources of electrical interference where practical. Do not exceed the specified voltage and current limits. Inspect the connectors and cable jacket before energizing the connected equipment. Do not modify the cable assembly, connector termination, or conductor arrangement unless ABB documentation explicitly permits the modification.

Read more less

ABB TK851V010 Connection Cable Configured for RCU link and BC810 interconnection functions, the ABB TK851V010 (TK851V010 Connection Cable) provides a prefabricated 1 m physical connection between compatible ABB system components. Hardware Specifications Parameter Specification Model TK851V010 Product ID 3BSC950262R1 Brand ABB Product Type Prefabricated Cable Function RCU Link Cable; BC810 Interconnection Cable Cable Length 1 m Dimensions 1000 mm x 10 mm x 10 mm Weight 0.45 kg Product Net Depth / Length 1000 mm Product Net Height 10 mm Product Net Width 10 mm HS Code 854442 Customs Tariff Number 85444210 WEEE Category Product Not in WEEE Scope SCIP No SVHC present Switzerland ABB Industrial Interconnection Characteristics The TK851V010 provides a dedicated cable path for RCU link and BC810 interconnection functions. Therefore, installation should preserve the specified cable routing and connector orientation for the connected ABB hardware. Because the supplied documentation does not state conductor assignment, shielding construction, connector pinout, or electrical ratings, these parameters should be verified against the applicable ABB system documentation before installation. For industrial control cabinets, route the cable separately from high-energy power conductors where practical. Also, avoid excessive bending, tensile loading, crushing, or mechanical stress at the connector ends. Frequently Asked Questions (FAQ) Q: What equipment functions does the TK851V010 support?A: ABB specifies the cable for RCU Link Cable and BC810 Interconnection Cable applications. Q: What is the physical cable length?A: The specified cable length is 1 m, with a product net length of 1000 mm. Q: Is power consumption applicable to the TK851V010?A: No. The product is a passive prefabricated connection cable, so power consumption is not specified as an operating parameter. Field Installation Guidelines Confirm that the installed cable is ABB TK851V010, Product ID 3BSC950262R1, before connection. Verify the mating interfaces and connector configuration against the applicable ABB hardware documentation. Install the cable without excessive bending, pulling, twisting, or compression. Keep the cable routing clear of mechanical interference from cabinet doors, mounting rails, and adjacent hardware. Separate the cable from high-current or high-voltage wiring where the cabinet layout permits. Do not modify the cable, connector, shielding, or conductor arrangement unless ABB documentation specifically permits the modification. Inspect connector seating before system commissioning and verify that no connector is mechanically stressed by cable routing.

Read more less

ABB TK852V010 Shielded FTP CAT 5e Cross-Over Cable Configured for shielded Ethernet cross-over communication in ABB Advant Master process control systems, the ABB TK852V010 (TK852V010 Shielded FTP CAT 5e Cross-Over Cable) provides a prefabricated cable assembly for direct network interconnection. The product ID is 3BSC950342R1. Its specified construction is shielded FTP CAT 5e, with a product net length of 970 mm. Hardware Specifications Parameter Specification Model TK852V010 Product ID 3BSC950342R1 Brand ABB Product Type Prefabricated Cable Cable Type Shielded FTP CAT 5e Cross-Over Network Function Ethernet cross-over interconnection Cable Length 970 mm Weight 0.04 kg Dimensions 970 mm length; height and width not specified Shielding FTP, shielded construction Connector Configuration Fitted cable assembly; specific connector type not specified HS Code 854442 Customs Tariff Number 85444290 WEEE Status Product not in WEEE scope Industrial Ethernet Cable Characteristics The TK852V010 uses shielded FTP CAT 5e construction for Ethernet signal transmission. Therefore, the cable should maintain appropriate shielding continuity through the installed communication path. The cross-over configuration changes the conductor pairing arrangement between cable ends. Consequently, installers should verify the required interface wiring before replacing a straight-through Ethernet cable. The supplied data identifies the assembly as a prefabricated cable rather than an active network device. It therefore has no specified power consumption, firmware, or configurable communication parameters. For ABB Advant Master installations, maintain the cable routing and shielding practices specified by the applicable system documentation. Avoid unnecessary parallel routing with high-energy power conductors, and maintain physical separation where the installation environment requires it. Frequently Asked Questions Q: Is TK852V010 an active Ethernet communication module?A: No. TK852V010 is a passive prefabricated Shielded FTP CAT 5e cross-over cable. Q: What is the specified cable length?A: The product net depth / length is specified as 970 mm. Q: Does the supplied data specify an operating temperature range?A: No. The provided ABB data does not specify an operating temperature range for TK852V010. Field Installation Guidelines Verify that the required network connection uses a cross-over configuration before installation. Confirm connector compatibility with the connected ABB communication interfaces. Maintain shield continuity according to the applicable ABB installation documentation. Route the cable away from high-voltage and high-current conductors where practical. Avoid excessive mechanical tension, sharp bends, or crushing of the cable jacket. Inspect both cable ends for connector damage before commissioning. Verify Ethernet communication after installation using the applicable system diagnostics. Record the installed cable identification as TK852V010 / 3BSC950342R1 for maintenance documentation.

Read more less

ABB TK853V020 Modem Cable Configured for serial modem communication between TC562 and TP830, the ABB 3BSC950201R1 (TK853V020 Modem Cable) provides a prefabricated 2 m physical connection for the TP830 serial interface. Hardware Specifications Parameter Specification Model 3BSC950201R1 ABB Type Designation TK853V020 Brand ABB Product Type Prefabricated Cable Cable Function Modem cable for serial interfaces on TP830 Connection TC562 modem to TP830 Cable Length 2 m Product Length 2000 mm Product Width 7 mm Product Height 7 mm Weight 0.14 kg Operating Temp Not specified in supplied data Power Consumption Not applicable HS Code 854442 Customs Tariff Number 85444210 WEEE Category Product Not in WEEE Scope ABB Industrial Serial Interface Characteristics The TK853V020 provides a fixed physical connection between the TC562 modem and the TP830 serial interface. Therefore, installation should preserve the cable routing and connector orientation specified for the associated ABB hardware. Because the supplied documentation identifies this item as a prefabricated cable, the cable itself does not provide programmable communication functions, protocol conversion, or independent power processing. Instead, it carries the serial interface connection between the designated devices. Frequently Asked Questions Q: What equipment does the TK853V020 connect?A: The cable connects the TC562 modem to the serial interface on the TP830. Q: What is the specified cable length?A: The cable length is 2 m, with a listed product length of 2000 mm. Q: Does the cable have a specified power consumption?A: No. The supplied data identifies it as a prefabricated modem cable, so no independent power consumption is specified. Field Installation Guidelines Verify the cable identification before installation and confirm the required TC562 and TP830 connection points. Route the cable without excessive mechanical tension, sharp bends, or compression. Keep the serial cable separated from high-current power conductors where practical to reduce electrical interference. Ensure connectors are fully seated before commissioning the serial communication path. Do not modify the prefabricated cable or alter its connector termination. Inspect the cable jacket and connectors for mechanical damage before installation. Confirm serial communication after connection using the applicable TP830 and TC562 commissioning procedure.

Read more less

ABB TK854V030 Communication Interface Module Configured for physical interface and system-level communication within an ABB industrial control architecture, the ABB TK854V030 (TK854V030 Communication Interface Module) provides hardware-level connectivity between the associated system components. The supplied data does not identify a specific protocol, electrical interface, or backplane specification. Hardware Specifications Parameter Specification Model TK854V030 Brand ABB Product Type Communication / Interface Module Application ABB industrial automation and control systems System Compatibility System-dependent; supplied data references Advant OCS, Freelance, and System 800xA environments Communication Protocol Not specified in supplied data Electrical Interface Not specified in supplied data Operating Temp 0 deg C to +55 deg C Storage Temp -40 deg C to +70 deg C Mounting Type DIN rail or rack mounting, depending on associated housing Protection Class Typically IP20, according to supplied information RoHS Status Compliant with applicable environmental directives ABB Industrial Control Interface Characteristics The TK854V030 functions as a hardware interface component, so the associated system determines its actual communication path and electrical assignment. Therefore, installers should verify the compatible rack, terminal arrangement, and system documentation before energizing the module. ABB control architectures may use dedicated backplane or system-bus communication between controllers, interface modules, and I/O assemblies. However, the supplied TK854V030 information does not define a specific bus speed, protocol, connector pinout, or firmware compatibility range. Consequently, these parameters should not be assumed from the model number alone. For system integration, confirm the hardware revision and the target ABB platform. Then verify the mating connector, rack position, power source, and communication interface against the applicable ABB hardware documentation. Frequently Asked Questions Q: Does the supplied specification confirm a specific communication protocol for TK854V030? A: No. The supplied information identifies the unit as a communication/interface module but does not specify a protocol or network standard. Q: Can the TK854V030 be installed directly on a DIN rail? A: The supplied information lists DIN-rail or rack mounting, depending on the associated housing or sub-rack design. The applicable mounting arrangement must therefore be confirmed from the system hardware documentation. Q: What is the specified power consumption of TK854V030? A: The supplied data does not provide a power-consumption value. The system-specific hardware manual should be used to determine the required supply and backplane load. Field Installation Guidelines Confirm the exact TK854V030 hardware revision before installation. Verify the compatible ABB rack, mounting carrier, or DIN-rail assembly. Isolate system power before connecting or removing the module. Inspect connectors for contamination, mechanical damage, or bent contacts. Route communication wiring separately from high-voltage and high-current conductors where practical. Maintain appropriate cable shielding and connect shields according to the ABB system grounding scheme. Avoid unnecessary cable loops and excessive mechanical stress at connectors. Confirm terminal assignments and connector orientation from the applicable ABB installation manual. Check the enclosure protection level when the module operates outside a controlled cabinet environment. After installation, verify module seating, power status, communication status, and system diagnostics before placing the control system into service.

Read more less

ABB TB810 ModuleBus Optical Port The ABB TB810 3BSE008560R1, also cataloged as the TB810 ModuleBus Optical Port, provides fiber optic communication between S800 I/O ModuleBus segments. It operates at 10 Mbit/s and supports single-mode fiber transmission over distances up to 2 km. Hardware Specifications Parameter Specification Model TB810 3BSE008560R1 Spare Model 3BSE008560R1 Brand ABB Product Type ModuleBus Optical Port Series ABB S800 I/O Origin Sweden Weight 0.02 kg Dimensions 2 x 5.2 x 4.2 cm shipping size Operating Voltage 24 VDC Data Rate 10 Mbit/s (10 Mbps) Transmission Distance Up to 2 km (1.24 miles) Interface Type Fiber optic ModuleBus interface Fiber Type Single-mode Tariff Code 8537101190 Manufacturer ABB Shipment Origin Xiamen, China ABB S800 I/O ModuleBus Communication The TB810 converts the ModuleBus communication path to an optical fiber interface. Therefore, the unit supports optical transmission between compatible ABB S800 I/O ModuleBus sections where electrical bus cabling is not suitable. The specified communication rate is 10 Mbit/s. In addition, the supplied data specifies a maximum transmission distance of up to 2 km when using single-mode fiber. Because the interface uses optical transmission, the fiber path should remain physically separated from electrical power wiring and high-noise conductors. Installers should also maintain the specified fiber bend radius and protect optical connectors from contamination during installation. The 24 VDC operating supply must be connected with correct polarity and appropriate industrial wiring practices. The TB810 should be installed only with compatible ABB S800 I/O equipment and ModuleBus configurations. Frequently Asked Questions Q: What communication medium does the TB810 use?A: The TB810 uses a fiber optic ModuleBus interface and the supplied specification identifies single-mode fiber as the supported fiber type. Q: What is the specified communication speed?A: The specified ModuleBus optical communication rate is 10 Mbit/s (10 Mbps). Q: What is the specified maximum transmission distance?A: The supplied specification states a transmission distance of up to 2 km (1.24 miles). Actual installation performance depends on the selected fiber and optical link conditions. Field Installation Guidelines Verify the TB810 model and 3BSE008560R1 spare number before installation. Confirm that the available supply is 24 VDC and matches the system wiring requirements. Install the unit within the compatible ABB S800 I/O ModuleBus architecture. Route optical fiber separately from power and high-current conductors. Keep fiber connectors clean and capped until connection. Avoid excessive bending, pulling, or mechanical loading of the optical cable. Check the fiber type before connection; the supplied specification identifies single-mode fiber. Inspect the optical path and connectors if communication faults occur. Confirm ModuleBus communication after installation before placing the associated I/O segment into service.

Read more less

ABB TU831V1 3BSE013235R1 Extended Module Termination Unit Configured for field I/O termination and ModuleBus distribution in the ABB S800 I/O system, the ABB TU831V1 3BSE013235R1 (TU831V1 Extended Module Termination Unit) provides physical connections for up to 8 I/O channels. The unit distributes ModuleBus signals to the I/O module and the next MTU while generating the required module address position signals. Hardware Specifications Parameter Specification Model TU831V1 3BSE013235R1 Spare Model 3BSE013235R1 Brand ABB Product Type Extended Module Termination Unit Series S800 I/O Origin Sweden Weight 0.2 kg Dimensions Estimated shipping size: 12.7 x 11.6 x 6.6 cm Connection Terminal block Channels 8 I/O channels Maximum Rated Voltage 250 V Maximum Current per I/O Channel 3 A Process Connections 16 connections for up to 8 I/O channels I/O Configuration Single I/O Mounting Standard DIN rail; mounting in both directions Dielectric Test Voltage 2000 V AC Operating Temp 0 to +55 deg C; approvals issued for +5 to +55 deg C Storage Temp -40 to +70 deg C Relative Humidity 5 to 95 %, non-condensing ABB S800 I/O ModuleBus and I/O Density The TU831V1 distributes the ModuleBus connection between the installed I/O module and the adjacent MTU. It also shifts outgoing position signals to generate the correct address for the next I/O position. Furthermore, the MTU provides 16 process connections for 8 I/O channels. Each channel supports a maximum rated current of 3 A and a maximum rated voltage of 250 V. The single I/O configuration does not provide redundant I/O termination. Therefore, system designers should match the MTU configuration with the selected S800 I/O module and field wiring arrangement. Frequently Asked Questions Q: How many I/O channels can the TU831V1 support?A: The TU831V1 supports up to 8 I/O channels with 16 process connections. Q: What electrical rating applies to each I/O channel?A: Each I/O channel has a maximum rated voltage of 250 V and a maximum current of 3 A. Q: Does the TU831V1 provide redundant I/O termination?A: No. The supplied specifications identify the TU831V1 as a single I/O termination unit. Field Installation Guidelines Mount the TU831V1 on a compatible DIN rail and secure the mechanical latch before wiring. Install the MTU in the specified mounting orientation and maintain adequate clearance for terminal access. Verify the installed I/O module compatibility with the TU831V1 before applying field power. Route field wiring separately from high-current switching conductors where practical to reduce electrical interference. Use appropriate terminal wiring practices and verify conductor sizes against the connected field circuit requirements. Confirm polarity and circuit voltage before connecting field devices to the terminal block. Inspect terminal connections for secure mechanical engagement before energizing the I/O assembly. Maintain the specified operating temperature range of 0 to +55 deg C and relative humidity range of 5 to 95 %, non-condensing. Observe the 250 V maximum rated voltage and 3 A maximum current per I/O channel during system design. Verify dielectric isolation requirements before performing commissioning or insulation testing.

Read more less

ABB TU831V1 Extended Module Termination Unit Configured for field termination and ModuleBus distribution in the ABB S800 I/O system, the ABB TU831V1 3BSE013235R1 (TU831V1 Extended Module Termination Unit) provides physical connections for compatible digital I/O modules. It supports up to 8 I/O channels, with a maximum rated voltage of 250 V and maximum current of 3 A per channel. Hardware Specifications Parameter Specification Model TU831V1 Article Number 3BSE013235R1 Brand ABB Product Type Extended Module Termination Unit Series S800 I/O Origin Not specified in supplied data Weight 0.22 kg (0.48 lbs) Dimensions 126 mm W x 64 mm D x 110 mm H Installed Width 120.5 mm edge to edge Channels Up to 8 I/O channels Process Connections 16 terminals, 2 terminals per channel Maximum Rated Voltage 250 V Maximum Current per I/O Channel 3 A Connection Terminal block I/O Configuration Single Compatible I/O Modules DI820, DI821, DO820, DO821 Mounting Standard DIN rail Mounting Direction Both directions ModuleBus Distribution To the I/O module and next MTU Address Generation Position signal shifting to the next MTU Wire Size, Solid 0.2 - 6 mm2 Wire Size, Stranded 0.2 - 4 mm2, 24 - 10 AWG Recommended Terminal Torque 0.5 - 0.6 Nm Wire Stripping Length 7 mm Dielectric Test Voltage 2000 V AC Operating Temperature 0 to +55 deg C (+32 to +131 deg F) Approved Operating Temperature +5 to +55 deg C Storage Temperature -40 to +70 deg C (-40 to +158 deg F) Relative Humidity 5 to 95 %, non-condensing Pollution Degree Degree 2, IEC 60664-1 Corrosion Protection ISA-S71.04: G3 Protection Class IP20 according to IEC 60529 Mechanical Conditions IEC/EN 61131-2 EMC EN 61000-6-4, EN 61000-6-2 Overvoltage Categories IEC/EN 60664-1, EN 50178 Equipment Class Class I according to IEC 61140 CE Mark Yes Electrical Safety EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 Marine Certifications ABS, BV, DNV-GL, LR RoHS EN 50581:2012 WEEE Directive 2012/19/EU ABB S800 I/O ModuleBus and I/O Density The TU831V1 distributes the ModuleBus from the mounted I/O module toward the next MTU. It also shifts outgoing position signals so the following MTU receives the corresponding module address position. The eight-channel configuration provides a compact termination arrangement for compatible S800 I/O modules. Each channel uses two process terminals, giving 16 process connections for the complete eight-channel arrangement. The MTU does not function as an independent I/O processing module. Instead, it provides the mechanical, electrical, termination, and ModuleBus interface required by the supported I/O modules. Therefore, module compatibility must be checked before installation. Frequently Asked Questions Q: How many I/O channels does the ABB TU831V1 support?A: The TU831V1 supports up to 8 I/O channels and provides 16 process connections, with two terminals assigned to each channel. Q: What I/O modules are specified for use with the TU831V1?A: The supplied data identifies DI820, DI821, DO820, and DO821 as compatible I/O modules. Q: What is the maximum electrical rating per I/O channel?A: Each I/O channel has a maximum rated voltage of 250 V and a maximum current rating of 3 A. Field Installation Guidelines Mount the TU831V1 on a suitable standard DIN rail and engage the mechanical latch fully. Verify the MTU orientation and terminal accessibility before connecting field wiring. Confirm that the selected I/O module is one of the specified compatible types. Keep field wiring separated from high-energy switching conductors where the installation requires signal-noise control. Route signal wiring to minimize unnecessary parallel runs with power conductors. Use conductor sizes within the specified 0.2 - 6 mm2 solid or 0.2 - 4 mm2 stranded range. Apply the specified 0.5 - 0.6 Nm terminal torque during wiring. Strip approximately 7 mm of insulation from conductors before termination. Verify protective earth arrangements according to the applicable installation standard because the equipment is Class I. Inspect terminal connections before energization and verify that no conductor strands contact adjacent terminals. Confirm the ModuleBus path and MTU position before commissioning the connected I/O module. Do not exceed the specified 250 V maximum voltage or 3 A maximum current per I/O channel. Maintain the specified environmental limits during installation and operation.

Read more less

ABB TU830V1 Extended Module Termination Unit Configured for field wiring termination, process voltage distribution, and ModuleBus signal routing in the ABB S800 I/O system, the ABB TU830V1 (TU830 Extended Module Termination Unit) provides the physical interface between field circuits and the I/O module. Hardware Specifications Parameter Specification Model TU830V1 Base Model TU830 Brand ABB Product Type Extended Module Termination Unit (MTU) Part Number / Catalog Code 3BSE013234R1 System Compatibility ABB S800 I/O system I/O Channels Up to 16 Maximum Rated Voltage 50 V Maximum Rated Current per Channel 2 A Process Voltage Connections 2 individually isolated groups, UP1 and UP2 Group Fuse Rating 6.3 A time-lag fuse, 5 x 20 mm ModuleBus Function Distributes ModuleBus and shifts position signals for I/O module addressing Wire Size, Solid 0.2 - 4 mm2 Wire Size, Stranded 0.2 - 2.5 mm2, 24 - 12 AWG Terminal Tightening Torque 0.5 - 0.6 Nm Mechanical Keying 36 coding combinations Mounting Standard DIN rail Grounding Built-in system grounding mechanism Operating Temp 0 deg C to 55 deg C ModuleBus and I/O Density The TU830V1 distributes ModuleBus communication through the S800 I/O termination structure. It also shifts outgoing position signals so that the connected I/O module receives the corresponding hardware position address. Furthermore, the MTU supports up to 16 I/O channels while maintaining separate process voltage groups. The two groups provide individual isolation and fuse protection for connected field circuits. The 36 available mechanical coding combinations restrict incompatible I/O module insertion. Therefore, the selected coding must correspond to the intended I/O module before installation. Frequently Asked Questions Q: Does the TU830V1 provide I/O signal conversion? A: No. The TU830V1 functions as a termination and distribution unit. The connected S800 I/O module performs the actual signal processing. Q: What process voltage protection does the TU830V1 provide? A: The unit provides two individually isolated process voltage groups. Each group uses a 6.3 A time-lag fuse according to the supplied specifications. Q: Can the TU830V1 support more than 8 I/O channels? A: Yes. The supplied data specifies a maximum of 16 I/O channels for the TU830V1. Field Installation Guidelines Mount the TU830V1 securely on the specified DIN rail before connecting field wiring. Verify the mechanical coding before inserting the associated S800 I/O module. Separate process voltage wiring from communication and low-level signal wiring where cabinet design permits. Maintain correct polarity and terminal identification for every field circuit. Tighten field terminals to 0.5 - 0.6 Nm where the supplied specification applies. Select conductor sizes within the stated 0.2 - 4 mm2 solid or 0.2 - 2.5 mm2 stranded range. Connect the grounding arrangement according to the S800 installation design and cabinet grounding scheme. Verify both process voltage groups independently before energizing the connected I/O circuits. Inspect fuse installation and confirm that the installed fuse type matches the specified protection arrangement. Do not exceed 50 V rated voltage or 2 A rated current per I/O channel.

Read more less

ABB TU833 Extended Module Termination Unit The ABB TU833 3BSE038726R1, also cataloged as the TU833 Extended Module Termination Unit, provides field termination, process voltage distribution, and ModuleBus signal routing for ABB S800 I/O modules. It supports up to 16 I/O channels and two individually isolated process voltage groups. Hardware Specifications Parameter Specification Model TU833 3BSE038726R1 Brand ABB Product Type Extended Module Termination Unit Article Number 3BSE038726R1 Weight 0.28 kg (0.6 lbs) Dimensions 126 mm W x 105 mm H x 64 mm D, including connector and terminals Operating Temp 0 to +55 deg C (+32 to +131 deg F); approvals issued for +5 to +55 deg C Storage Temp -40 to +70 deg C (-40 to +158 deg F) Power Consumption Not specified in supplied data Number of Channels 16 I/O channels Maximum Rated Voltage 50 V Maximum Current per I/O Channel 2 A Maximum Current Process Connection 5 A Process Voltage Groups 2 individually isolated groups Process Voltage Fuse 6.3 A fuse per group Connection Type Crimp Snap-in connector Process Connections 56 I/O Connections 2 terminals per channel ZP Connections 1 ZP connection per channel Process Power Connections 4 x 6.3 A Process Power 0 V Connections 10 x 2 Mounting Standard DIN rail Mounting Direction Both directions Mounting Lock Mechanical DIN rail latch Single/Redundant I/O Single Acceptable Wire Size Solid: 0.2 - 2.5 mm2, 24 - 12 AWG; Stranded: 0.2 - 2.5 mm2, 24 - 12 AWG Terminal Wiring One wire per terminal Wire Stripping Length 6 mm Dielectric Test Voltage 500 V AC Protection Class IP20 according to IEC 60529 Pollution Degree Degree 2, IEC 60664-1 Relative Humidity 5 to 95 %, non-condensing Corrosion Protection ISA-S71.04: G3 Mechanical Conditions IEC/EN 61131-2 EMC EN 61000-6-4, EN 61000-6-2 Electrical Safety EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 Hazardous Location C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2 Marine Certification DNV-GL, BV, LR Equipment Class Class I according to IEC 61140, earth protected RoHS EN 50581:2012 WEEE Directive 2012/19/EU Compatible I/O Modules AI810, AI815, AI820, AI830, AI830A, AI835, AI835A, AI843, AI845, AO810, AO810V2, AO815, AO820, AO845, AO845A, DI810, DI811, DI814, DI830, DI831, DI840, DI880, DI885, DO810, DO814, DO815, DO840, DO880, DP820, DP840 ABB S800 ModuleBus and I/O Architecture The TU833 distributes the ModuleBus from the installed I/O module to the next MTU. It also generates the required module address by shifting outgoing position signals toward the next MTU. Furthermore, the 16-channel configuration provides two I/O terminals per channel and one ZP connection per channel. This arrangement supports direct field termination while maintaining the physical addressing sequence across the S800 I/O installation. The TU833 also separates process voltage connections into two individually isolated groups. Each group uses a 6.3 A fuse, while the maximum rated current remains 2 A per I/O channel. Therefore, the application should select fuse ratings according to the actual load requirements and system power design. The MTU supports a defined set of ABB S800 I/O modules, including analog input, analog output, digital input, digital output, and related interface modules. Consequently, engineers should verify the installed I/O module against the specified compatibility list before commissioning. Frequently Asked Questions (FAQ) Q: How many I/O channels does the ABB TU833 support? A: The TU833 supports up to 16 I/O channels. Each channel provides two I/O connections and one ZP connection. Q: How does the TU833 handle process voltage distribution? A: The TU833 provides two individually isolated process voltage groups. Each group has a 6.3 A fuse, while the maximum rated voltage is 50 V. Q: How does the TU833 generate the I/O module address? A: The MTU shifts the outgoing position signals to the next MTU. This process generates the correct address for the connected S800 I/O module. Field Installation Guidelines Mount the TU833 on a standard DIN rail and engage the mechanical latch before wiring. Confirm that the mounting direction and available cabinet clearance match the installation arrangement. Connect field wiring according to the assigned channel and terminal configuration. Use solid or stranded conductors within the specified 0.2 - 2.5 mm2 wire range. Use only one wire per terminal and maintain the specified 6 mm stripping length. Verify the process voltage group assignment before connecting field power. Check the fuse arrangement for each isolated process voltage group against the application load. Route process wiring separately from high-noise power conductors where the cabinet design permits. Verify protective earth and cabinet grounding according to the applicable installation standard. Confirm the connected I/O module appears in the specified compatible module list. Check ModuleBus continuity and the physical MTU sequence before commissioning. Inspect all crimp snap-in connections for secure mechanical engagement before energizing the system. Do not exceed the 50 V maximum rated voltage or 2 A maximum current per I/O channel. Verify operating ambient temperature remains within the specified range during normal operation.

Read more less

ABB TU835V1 Extended Module Termination Unit The ABB TU835V1, also cataloged as the TU835V1 Extended Module Termination Unit, provides field termination, ModuleBus distribution, and position-address generation for ABB S800 I/O modules. It supports up to 8 I/O channels with a maximum rated voltage of 50 V and maximum current of 2 A per channel. Hardware Specifications Parameter Specification Model TU835V1 Article Number 3BSE013236R1 Brand ABB Product Type Extended Module Termination Unit Origin Not specified in supplied data Weight 0.26 kg Dimensions 126 mm W x 110 mm H x 64 mm D, including connector and terminals Operating Temp 0 to +55 deg C Storage Temp -40 to +70 deg C Channels 8 I/O channels Maximum Rated Voltage 50 V Maximum Current per I/O Channel 2 A Maximum Current at Process Connection 8 A Connection Terminal block Mounting Standard DIN rail Mounting Direction Both directions Supported I/O AI810, AI815, AI845 Process Connections 16 I/O terminals, 4 process power terminals, 4 process power 0 V terminals I/O Configuration Single I/O Wire Size, Solid 0.2 - 4 mm2 Wire Size, Stranded 0.2 - 2.5 mm2, 24 - 12 AWG Recommended Terminal Torque 0.5 - 0.6 Nm Wire Stripping Length 7 mm Dielectric Test Voltage 500 V AC Relative Humidity 5 - 95 %, non-condensing Protection Class IP20 according to IEC 60529 Pollution Degree Degree 2, IEC 60664-1 Corrosion Protection ISA-S71.04: G3 Mechanical Conditions IEC/EN 61131-2 EMC EN 61000-6-4, EN 61000-6-2 Overvoltage Category IEC/EN 60664-1, EN 50178 Equipment Class Class I according to IEC 61140 Power Consumption Not specified in supplied data CE Mark Yes Electrical Safety EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 Hazardous Location Approval C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2 Marine Certification ABS, BV, DNV-GL, LR RoHS Compliance EN 50581:2012 WEEE Compliance Directive 2012/19/EU ABB S800 ModuleBus and Address Distribution The TU835V1 distributes the ModuleBus from the connected I/O module to the next MTU in the installation. At the same time, it generates the appropriate I/O module address by shifting outgoing position signals toward the next MTU. The MTU supports mechanical configuration through two keys. Each key provides six positions, producing 36 possible mechanical configurations. This keying mechanism physically configures the MTU for compatible I/O module types without changing the electrical functionality of either the MTU or I/O module. The unit supports AI810, AI815, and AI845 modules according to the supplied technical data. Therefore, the mechanical key positions should match the applicable I/O module configuration before installation. Frequently Asked Questions (FAQ) Q: How many I/O channels does the TU835V1 support? A: The TU835V1 supports up to 8 I/O channels. Each channel has a maximum rated current of 2 A and a maximum rated voltage of 50 V. Q: How does the TU835V1 generate the I/O module address? A: The MTU generates the appropriate address by shifting the outgoing position signals to the next MTU. Q: Does the mechanical key configuration change the electrical function of the MTU? A: No. The two mechanical keys provide physical configuration for different I/O module types. The selected key positions do not change the electrical functionality of the MTU or I/O module. Field Installation Guidelines Mount the TU835V1 on a compatible standard DIN rail and verify that the mechanical latch fully locks the unit. Release the DIN rail latch with a screwdriver when removing the MTU. Confirm that the two mechanical keys match the intended I/O module configuration before installation. Connect field wiring according to the terminal assignment and supported process connections. Keep wiring within the specified solid and stranded conductor ranges. Apply the specified terminal torque of 0.5 - 0.6 Nm during field wiring. Maintain the specified 7 mm conductor stripping length. Separate signal wiring from high-current or high-noise conductors where the installation requires electromagnetic interference control. Route shields and protective earth connections according to the plant grounding design and applicable electrical installation standards. Verify the 50 V maximum rated voltage and 2 A maximum current per I/O channel before energizing the circuit. Confirm that the ambient temperature remains within 0 to +55 deg C during operation. Inspect the terminal connections and mechanical latch before commissioning.

Read more less

ABB TU836V1 3BSE013237R1 Extended Module Termination Unit Configured for physical I/O termination and field connection in ABB S800 I/O systems, the ABB TU836V1 3BSE013237R1 (TU836V1 Extended Module Termination Unit) provides an 8-channel terminal interface with a maximum rated voltage of 250 V and 3 A per I/O channel. Hardware Specifications Parameter Specification Model TU836V1 3BSE013237R1 Spare Model 3BSE013237R1 Brand ABB Product Type Extended Module Termination Unit Origin Sweden Weight 0.4 kg Dimensions Estimated shipping size: 12.7 x 7.6 x 15.2 cm Operating Temp 0 to +55 deg C; approvals issued for +5 to +55 deg C Storage Temp -40 to +70 deg C Power Consumption Not specified in the supplied data Connection Terminal block Number of Channels 8 Maximum Rated Voltage 250 V Maximum Current per I/O Channel 3 A Maximum Current Process Connection 10 A Dielectric Test Voltage 2000 V AC Mounting Both directions Type Extended ABB S800 I/O Termination and Backplane Interface The TU836V1 provides the physical termination point between field wiring and the associated ABB S800 I/O module. Its eight channels support up to 250 V and 3 A per I/O channel according to the supplied specifications. The terminal-block connection establishes the field-side electrical interface. Therefore, installers should separate field conductors according to voltage class, signal type, and applicable cabinet wiring requirements. The 10 A maximum process connection rating applies to the process connection as specified. Meanwhile, the 2000 V AC dielectric test voltage defines the stated insulation test level rather than a continuous operating voltage. Because the supplied data does not specify ModuleBus current consumption or communication velocity, those values should be taken from the applicable S800 I/O module and system documentation rather than inferred from the TU836V1 rating. Frequently Asked Questions Q: How many I/O channels does the TU836V1 support?A: The TU836V1 provides 8 I/O channels. Q: What are the maximum voltage and current ratings?A: The maximum rated voltage is 250 V, while the maximum current is 3 A per I/O channel. The specified maximum process connection current is 10 A. Q: What dielectric test voltage does the TU836V1 specify?A: The supplied specification lists a dielectric test voltage of 2000 V AC. Field Installation Guidelines Mount the TU836V1 on the designated DIN rail or compatible mounting arrangement and verify that the mechanical latch engages correctly. Provide adequate cabinet clearance around the terminal area so technicians can access field wiring without excessive conductor bending. Route power and signal conductors according to the required separation rules for the installation voltage classes. Verify terminal identification before connecting field conductors. Do not exceed the specified 250 V voltage rating or 3 A per-channel current rating. Keep protective earth, signal reference, and shield connections consistent with the cabinet grounding design. Avoid creating unintended ground loops through cable shields. Inspect conductor termination for secure mechanical engagement before energizing the associated I/O circuit. Confirm operating temperature remains within 0 to +55 deg C. For storage, maintain the specified -40 to +70 deg C range. Before dielectric or insulation testing, isolate the module and connected electronics according to the applicable ABB system procedure. Do not apply test voltage to energized electronic circuits.

Read more less

ABB TU837 / TU837V1 S800 I/O Module Termination Unit Configured for field signal termination and ModuleBus interconnection in the ABB S800 I/O system, the ABB TU837V1 (TU837 Module Termination Unit) provides direct electrical termination between field wiring and the installed I/O module. The unit supports DIN rail mounting and defined conductor sizes for signal and return connections. Hardware Specifications Parameter Specification Model TU837 / TU837V1 Brand ABB Product Type Module Termination Unit (MTU) Series S800 I/O Function Field signal termination and ModuleBus interconnection Mounting Standard DIN rail Signal Connection, Solid Wire 0.2 - 6 mm2 Signal Connection, Stranded Wire 0.2 - 4 mm2 Return Connection, Solid Wire 0.2 - 4 mm2 Return Connection, Stranded Wire 0.2 - 2.5 mm2 Signal Wire Stripping Length 8 mm Return Wire Stripping Length 7 mm Recommended Screw Torque 0.5 - 0.6 Nm Protection Class IP20 Operating Temp -40 deg C to +70 deg C Relative Humidity 5% to 95%, non-condensing System Compatibility ABB S800 I/O system ABB S800 I/O ModuleBus and Termination Characteristics The TU837V1 provides the physical termination interface between field conductors and the associated S800 I/O module. It also participates in the ModuleBus connection through the MTU assembly. Furthermore, the termination unit separates field wiring operations from the electronic I/O module interface. This arrangement allows technicians to perform module replacement without removing the field conductors where the installed S800 I/O configuration supports hot-swap operation. The TU837V1 accepts solid signal conductors from 0.2 - 6 mm2 and stranded signal conductors from 0.2 - 4 mm2. Return terminals accept solid conductors from 0.2 - 4 mm2 and stranded conductors from 0.2 - 2.5 mm2. The DIN rail mounting arrangement supports horizontal or vertical cabinet installation. Therefore, cabinet layout can accommodate the MTU according to available wiring access and module orientation. Frequently Asked Questions (FAQ) Q: What conductor sizes does the TU837V1 support for signal wiring?A: The signal terminals accept 0.2 - 6 mm2 solid wire and 0.2 - 4 mm2 stranded wire. Q: What screw torque should technicians apply to the TU837V1 terminals?A: The supplied specification recommends a screw torque of 0.5 - 0.6 Nm. Q: Does the TU837V1 consume electrical power?A: The supplied data does not specify power consumption. The TU837V1 functions as a passive Module Termination Unit rather than an electronic I/O processing module. Field Installation Guidelines Mount the TU837V1 securely on the specified DIN rail before connecting field conductors. Verify the installed MTU and I/O module combination against the S800 I/O system configuration. Route signal wiring separately from high-voltage or high-current conductors where cabinet design permits. Strip signal conductors to 8 mm and return conductors to 7 mm before terminal insertion. Apply 0.5 - 0.6 Nm terminal torque according to the supplied specification. Ensure each conductor is fully seated and mechanically secured before commissioning. Maintain appropriate segregation between signal, power, and grounding conductors. Connect cable shields according to the system grounding design and applicable cabinet wiring practices. Confirm that the terminal arrangement matches the assigned I/O channel before energizing the field circuit. Inspect the IP20 enclosure condition and terminal area after installation. Do not infer hot-swap capability solely from the MTU design; verify the complete S800 I/O configuration and applicable module documentation before live replacement.

Read more less

ABB TU837V1 3BSE013238R1 Extended Module Termination Unit Configured for ModuleBus distribution, I/O addressing, and field terminal interfacing, the ABB TU837V1 3BSE013238R1 (TU837V1 Extended Module Termination Unit) provides the physical connection between compatible S800 I/O modules and process wiring. It supports up to 8 I/O channels, with a maximum rated voltage of 250 V and maximum current of 3 A per channel. Hardware Specifications Parameter Specification Model TU837V1 Article Number 3BSE013238R1 Brand ABB Product Type Extended Module Termination Unit Origin Not specified in supplied data Module Type Extended Connection Terminal block Channels 8 Maximum Rated Voltage 250 V Maximum Current per I/O Channel 3 A Maximum Current Process Connection 10 A Process Connections 28; up to 8 I/O channels with 2 terminals per channel; 2 x 6 power common terminals I/O Configuration Single Compatible I/O DO820, DO821 ModuleBus Function Distributes ModuleBus to the I/O module and next MTU Address Function Generates the I/O module address by shifting outgoing position signals Mounting Standard DIN rail, both directions Mechanical Latch DIN rail locking latch, screwdriver release Mechanical Keys 2 keys, 6 positions each; 36 possible configurations Dielectric Test Voltage 2000 V AC Weight 0.26 kg Dimensions 126 mm W x 64 mm D x 110 mm H, including connectors and terminals Installed Width 120.5 mm edge to edge Operating Temperature 0 to +55 deg C; approvals issued for +5 to +55 deg C Storage Temperature -40 to +70 deg C Relative Humidity 5 to 95 %, non-condensing Pollution Degree Degree 2, IEC 60664-1 Corrosion Protection ISA-S71.04: G3 Protection Class IP20, IEC 60529 Mechanical Conditions IEC/EN 61131-2 EMC EN 61000-6-4, EN 61000-6-2 Electrical Safety EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 Overvoltage Category IEC/EN 60664-1, EN 50178 Equipment Class Class I according to IEC 61140 Marine Certification ABS, BV, DNV-GL, LR CE Mark Yes RoHS Compliance EN 50581:2012 WEEE Compliance Directive 2012/19/EU ModuleBus Distribution and I/O Addressing The TU837V1 distributes the ModuleBus from the connected I/O module toward the next MTU. It also generates the correct module address through mechanical position signaling. The MTU shifts outgoing position signals to the next termination unit. Therefore, the physical MTU position contributes to the I/O module addressing sequence. The unit supports up to 8 I/O channels and provides two terminals per channel. Additionally, two groups of six power common terminals support the specified process connection arrangement. The TU837V1 uses two mechanical configuration keys. Each key provides six selectable positions, producing 36 possible mechanical configurations. These keys identify the intended I/O module arrangement mechanically and do not alter the electrical functionality of the MTU or I/O module. Mechanical Installation and Wiring The MTU mounts directly on a standard DIN rail. A mechanical latch secures the unit to the rail, while a screwdriver releases the latch during removal. For signal wiring, the specified conductor ranges are: Solid signal conductor: 0.2 to 6 mm2 Stranded signal conductor: 0.2 to 4 mm2 Signal conductor range: 24 to 10 AWG Signal terminal torque: 0.5 to 0.6 Nm Signal stripping length: 8 mm Solid return conductor: 0.2 to 4 mm2 Stranded return conductor: 0.2 to 2.5 mm2 Return conductor range: 24 to 12 AWG Return terminal torque: 0.5 to 0.6 Nm Return stripping length: 7 mm Frequently Asked Questions (FAQ) Q: How many I/O channels does the TU837V1 support? A: The TU837V1 supports up to 8 I/O channels, with a maximum rated current of 3 A per channel. Q: How does the TU837V1 generate the I/O module address? A: The MTU shifts outgoing position signals to the next MTU, thereby generating the correct address according to its physical position. Q: Do the two mechanical keys change the electrical operation of the I/O module? A: No. The two keys provide mechanical configuration only. Each key has six positions, giving 36 possible mechanical configurations without changing electrical functionality. Field Installation Guidelines Mount the TU837V1 on a compatible standard DIN rail and verify that the mechanical latch fully engages. Release the DIN rail latch with a screwdriver when removing the MTU. Configure the two mechanical keys according to the intended I/O module arrangement. Verify the selected key positions before installing the compatible I/O module. Connect signal and return conductors within the specified conductor-size ranges. Apply 0.5 to 0.6 Nm terminal torque to the specified signal and return connections. Maintain the specified stripping lengths of 8 mm for signal connections and 7 mm for return connections. Route field wiring separately from high-energy switching conductors where the installation requires noise reduction. Verify the ModuleBus connection between the I/O module, TU837V1, and adjacent MTU before energizing the assembly. Confirm that the installation environment remains within the specified temperature, humidity, pollution, EMC, and IP20 conditions.

Read more less

ABB TU838 3BSE008572R1 Extended Module Termination Unit Configured for direct field termination and process connection distribution, the ABB TU838 3BSE008572R1 (TU838 Extended Module Termination Unit) provides physical I/O termination for ABB automation systems. It supports 16 channels, 50 V rated voltage, and up to 3 A per I/O channel. The unit uses terminal block connections and supports mounting in both directions. Hardware Specifications Parameter Specification Model TU838 3BSE008572R1 Brand ABB Product Type Extended Module Termination Unit Type Extended Origin Sweden Weight 0.3 kg Dimensions Estimated shipping size: 12.7 x 7.6 x 12.7 cm Operating Temp 0 to +55 deg C; approvals issued for +5 to +55 deg C Storage Temp -40 to +70 deg C Relative Humidity 5 to 95 %, non-condensing Connection Terminal block Rated Voltage 50 V I/O Channels 16 Mounting Both directions I/O Configuration Single I/O Maximum Current per I/O Channel 3 A Maximum Current at Process Connection 10 A Dielectric Test Voltage 500 V AC Marine Certification ABS, BV, DNV-GL, LR ABB I/O Termination and Channel Density The TU838 provides 16 physical I/O channels through terminal block connections. Therefore, the unit accommodates a relatively high number of field connections within its extended termination configuration. Each I/O channel permits a maximum current of 3 A, while the process connection has a maximum current rating of 10 A. The 50 V rating defines the stated process-side voltage limit. In addition, the 500 V AC dielectric test voltage specifies the supplied insulation test level. The single I/O configuration does not indicate a redundant termination arrangement in the supplied specifications. The unit supports mounting in both directions, which allows the installer to select the orientation appropriate to the cabinet or mounting arrangement. Marine approvals include ABS, BV, DNV-GL, and LR. Frequently Asked Questions Q: How many I/O channels does the ABB TU838 provide? A: The TU838 provides 16 I/O channels through terminal block connections. Q: What current can each I/O channel handle? A: Each I/O channel has a maximum specified current of 3 A. The maximum current at the process connection is 10 A. Q: What environmental temperature range does the TU838 support? A: The specified operating range is 0 to +55 deg C. Storage temperature ranges from -40 to +70 deg C. Approval conditions are specified for +5 to +55 deg C. Field Installation Guidelines Install the TU838 in the specified cabinet or mounting location with adequate mechanical support. Verify terminal identification before connecting field wiring, and keep signal wiring separated from high-voltage or high-current conductors where applicable. Use wiring and protective devices suitable for the connected load and the stated 50 V rating. Do not exceed the 3 A maximum current per I/O channel or the 10 A process connection limit. Maintain appropriate separation between signal conductors and power conductors to reduce electromagnetic interference. Where shielded cables are used, terminate shields according to the system grounding design and avoid unintended ground loops. Before energization, inspect terminal tightness, conductor routing, polarity, and insulation condition. Confirm that the installed temperature and humidity conditions remain within the specified operating limits.

Read more less

ABB TU839 Extended Module Termination Unit The ABB TU839 3BSE046966R1, also cataloged as the TU839 Extended Module Termination Unit, distributes ModuleBus signals to the installed I/O module and the next MTU while providing eight I/O channels and two isolated sensor-power groups. Hardware Specifications Parameter Specification Model TU839 Article Number 3BSE046966R1 Brand ABB Product Type Extended Module Termination Unit Type Extended Connection Terminal block Channels 8 I/O channels I/O Connections 2 connections per channel Process Connections 28 total; 8 I/O channels plus 2 x 6 process power terminals Sensor Power Distribution 2 individually isolated groups Sensor Power Fuse 200 mA per group Maximum Rated Voltage 250 V Maximum Current per I/O Channel 1 A Maximum Current Process Connection 10 A I/O Compatibility DI820, DI821, DI825 I/O Configuration Single I/O ModuleBus Distribution To the I/O module and the next MTU Address Generation Outgoing position signals shifted to the next MTU Mounting Standard DIN rail Mounting Direction Both directions DIN Rail Retention Mechanical latch Mechanical Keying 2 keys, 6 positions each Keying Configurations 36 possible mechanical configurations Acceptable Wire Size Stranded: 24-14 AWG; 0.2-2.5 mm2 solid or stranded Recommended Terminal Torque 0.5 Nm Dielectric Test Voltage 2300 V AC channel to ground; 1350 V AC channel to channel Operating Temperature 0 to +55 deg C; approvals issued for +5 to +55 deg C Storage Temperature -40 to +70 deg C Relative Humidity 5 to 95 %, non-condensing Pollution Degree Degree 2, IEC 60664-1 Corrosion Protection ISA-S71.04: G3 Protection Class IP20 according to IEC 60529 EMC EN 61000-6-4, EN 61000-6-2 Electrical Safety EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 Overvoltage Category IEC/EN 60664-1, EN 50178 Equipment Class Class I according to IEC 61140 Mechanical Conditions IEC/EN 61131-2 CE Mark Yes RoHS Compliance EN 50581:2012 WEEE Compliance DIRECTIVE/2012/19/EU Width 126 mm including connector; 120.5 mm edge to edge installed Depth 64 mm including terminals Height 110 mm Weight 0.28 kg ModuleBus Distribution and Mechanical Addressing The TU839 distributes the ModuleBus from the I/O module to the following MTU. It also generates the I/O module address by shifting the outgoing position signals toward the next MTU. Two mechanical keys configure the MTU for different I/O module types. Each key provides six selectable positions, resulting in 36 possible mechanical configurations. This keying function provides physical configuration only and does not change the electrical functionality of the MTU or I/O module. Furthermore, the MTU uses a mechanical DIN rail latch for retention. Installers can mount the unit on a standard DIN rail in either supported direction. Sensor Power Distribution The TU839 provides two individually isolated process-voltage groups for sensor power distribution. Each group incorporates a 200 mA fuse. Each of the eight I/O channels provides two I/O connections. The channel rating permits a maximum current of 1 A, while the maximum process-connection current is specified as 10 A. The fuse rating should match the actual application load and connected sensor requirements. Do not select the fuse solely from the maximum channel rating. Frequently Asked Questions (FAQ) Q: How many I/O channels does the TU839 support?A: The TU839 supports up to 8 I/O channels, with 2 I/O connections assigned to each channel. Q: How does the TU839 generate the I/O module address?A: The MTU shifts the outgoing position signals to the next MTU, thereby generating the corresponding I/O module address. Q: What is the purpose of the two mechanical keys?A: The keys provide physical configuration for different I/O module types. Each key has 6 positions, creating 36 possible mechanical configurations without changing MTU functionality. Field Installation Guidelines Mount the TU839 on a compatible standard DIN rail and engage the mechanical latch fully. Verify the mechanical key positions before installing the associated I/O module. Connect the ModuleBus according to the intended MTU sequence and verify the outgoing connection toward the next MTU. Separate process wiring from high-energy switching and power conductors where practical to reduce electrical interference. Maintain correct polarity and termination for all connected process circuits. Select the sensor-power fuse rating according to the actual application load and circuit requirements. Keep the two sensor-power groups electrically separated as specified by the installation design. Use acceptable conductor sizes from 24-14 AWG or 0.2-2.5 mm2. Apply the specified 0.5 Nm terminal torque when terminating field wiring. Verify protective earth and enclosure arrangements according to the applicable installation standard. Confirm that the installation remains within the specified 0 to +55 deg C operating range. Maintain the IP20 protection requirements of the installed assembly. Inspect channel-to-ground and channel-to-channel insulation requirements before energizing the process connections.

Read more less

ABB TU840 3BSE020846R1 Termination Unit Configured for redundant I/O termination in the ABB Modulebus architecture, the ABB TU840 3BSE020846R1 (TU840 Termination Unit) provides the physical and electrical interface for a 1+1 TB840 configuration. It includes a power supply connector and TB807 Modulebus terminator interface. Hardware Specifications Parameter Specification Model TU840 3BSE020846R1 Base Model TU840 Spare Model 3BSE020846R1 Product Type Termination Unit Manufacturer ABB Origin Sweden Weight 0.42 kg Dimensions Estimated shipping size: 18.5 x 12.2 x 4.7 cm Application For 1+1 TB840 I/O Configuration Supports redundant I/O Communication Protocol Modulebus Power Input 24 VDC Mounting Vertical or horizontal Modulebus Current Distribution Maximum 5 V, 1.5 A; 24 V, 1.5 A Mechanical Keys 36 different combinations Rated Insulation Voltage 50 V Dielectric Test Voltage 500 VAC Power Dissipation 2.0 W Operating Temperature 0 to +55 deg C; approvals issued for +5 to +55 deg C Storage Temperature -40 to +70 deg C Relative Humidity 5 to 95 %, non-condensing Tariff Code 8537101190 Place of Shipment Xiamen, China ABB Modulebus and Redundant I/O Interface The TU840 terminates and distributes electrical connections associated with a 1+1 TB840 redundant I/O arrangement. The unit provides a dedicated power supply connector and accepts the TB807 Modulebus terminator. Furthermore, the specified Modulebus current distribution reaches 1.5 A at 5 V and 1.5 A at 24 V. Therefore, installation planning should keep the connected module load within these stated distribution limits. The mechanical keying system provides 36 different combinations. This feature controls physical module positioning and helps prevent incompatible module or termination-unit combinations during installation. Frequently Asked Questions Q: What TB840 configuration does the TU840 support?A: The TU840 is specified for a 1+1 TB840 configuration and supports redundant I/O. Q: What power distribution does the TU840 provide?A: The specified maximum Modulebus current distribution is 1.5 A at 5 V and 1.5 A at 24 V. Q: What mounting orientations are permitted?A: The supplied specification permits both vertical and horizontal mounting. Field Installation Guidelines Verify the complete part number TU840 3BSE020846R1 before installation. Confirm that the termination unit matches the intended 1+1 TB840 redundant configuration. Install the unit in the specified vertical or horizontal orientation. Connect the 24 VDC power input with correct polarity and suitable industrial wiring practices. Keep the connected Modulebus load within the specified 5 V and 24 V current distribution limits. Install the TB807 Modulebus terminator at the designated interface. Use the mechanical keying arrangement to prevent an incorrect module combination. Route power and communication wiring to minimize unnecessary coupling with high-current or high-noise conductors. Verify terminal tightness and connector seating before energizing the assembly. Confirm that the installation environment remains within the specified temperature and humidity limits.
