Description

ABB DI803 3BSE022362R1 Digital Input Module

The ABB DI803 3BSE022362R1, also cataloged as the DI803 Digital Input Module, provides eight-channel digital input processing for 230 V field signals within ABB industrial control systems. The module accepts discrete electrical states and transfers input status to the control system through its I/O interface.

Hardware Specifications

Parameter	Specification
Model	DI803 3BSE022362R1
Spare Model	3BSE022362R1
Brand	ABB
Product Type	Digital Input Module
Channel Count	8 channels
Input Type	Digital input
Rated Input Voltage	230 V
Origin	Sweden
Weight	0.24 kg
Dimensions	9.3 x 13.6 x 5.7 cm shipping size

ABB Industrial I/O Architecture

The DI803 processes discrete field states through eight digital input channels. Each channel monitors the connected field circuit and reports its electrical state to the control system. Therefore, correct field wiring and terminal identification must match the installed I/O configuration.

The 230 V input rating distinguishes this module from low-voltage digital input variants. Consequently, technicians must verify the field circuit voltage before connecting the module. The supplied documentation does not specify channel isolation, input current, switching thresholds, or backplane current consumption, so these parameters require confirmation from the applicable ABB hardware documentation.

Frequently Asked Questions

Q: How many digital input channels does the ABB DI803 3BSE022362R1 provide?
A: The module provides 8 digital input channels.

Q: What field voltage does the DI803 support according to the supplied specification?
A: The supplied product marking identifies the module as a 230 V digital input device.

Q: Does the supplied data specify the DI803 operating temperature and power consumption?
A: No. The provided data does not state either parameter, so installation should follow the applicable ABB system documentation.

Field Installation Guidelines

• Verify the module identification as DI803 3BSE022362R1 before installation.
• Confirm that the connected field circuits match the specified 230 V digital input application.
• Isolate field power before wiring or removing field connections.
• Route field wiring separately from high-current power conductors where practical.
• Maintain clear terminal identification to prevent cross-connection between input channels.
• Apply the applicable ABB grounding and cabinet bonding practices for the installed I/O system.
• Inspect conductors and terminal connections for mechanical security before energizing the circuit.
• After installation, verify each input channel using the actual field switching condition.
• Do not apply unspecified voltages or signal types to the module.
• Confirm environmental limits and system-specific installation requirements from the relevant ABB documentation before commissioning.

Specifications

• Brand: ABB

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
