Description

Product Overview

The HIMA F3322 is a robust 16-channel output module designed for H41q/H51q safety systems, supporting both resistive and inductive loads up to 500 mA (12 W) per channel. Engineered for high-availability applications, it features short-circuit protection, safety isolation, and parallel switching without external diodes.

Key Features

• Channel Count: 16 outputs

• Load Capacity:

  • Resistive/Inductive: up to 500 mA (12 W)

  • Lamp connection: up to 12 W

• Safety Isolation: No output signal if L– supply is interrupted

• Short-Circuit Proof: Response threshold > 550 mA

• Parallel Switching: Safe without external diodes

• Inductive Load Handling: No coil diode required, but recommended for noise suppression

• LED Status: Independently controlled per channel

• Space Requirement: 4 TE

• Actuator Wiring: Two-pole plug simplifies earth fault detection

• No Time Limit: Operable even with defective output module

Technical Specifications

Specifications

• Dimensions: 20.3 cm × 12.7 cm × 2.5 cm
• Brand: Hima

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
