Description

Product Overview

The HIMA B9302 is a modular I/O Slot Rack Assembly Kit designed for the H51q safety system, offering robust integration for industrial automation and process control. This 4-unit-high, 19-inch rack includes essential components for streamlined I/O module installation and power distribution.

Key Features

• Rack Type: FK1406, 4U height, 19" width, integrated cable tray

• Coupling Module: F7553 installed in slot 17

• Flat Cable Options: BV7032, available in 0.5 m (B9302-0,5), 1 m (B9302-1), or custom (B9302-X)

•  I/O Capacity: Slots 1–16 reserved for I/O modules

• Optional Modules: Up to 4 × F7133 fused power distribution units (slots 18–21)

• Fault Monitoring: Series-wired fuse monitoring with neutral contact signaling

• Bypass Logic: Jumper bypass for unused distribution modules

• Bus Length: Max total bus length of 30 m

Technical Specifications

Specifications

• Dimensions: 47.8 cm × 30.5 cm × 17.8 cm
• Brand: Hima

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
