The Bently Nevada 3300 Series delivers precise rotor and machinery monitoring. Our inventory provides sensors, probes, and spare parts for both current and legacy systems.
Bently Nevada 3300 Series
-
Bently Nevada Bently Nevada 3300/16 Dual Vibration Monitor
Bently Nevada 3300/16 Dual Vibration Monitor The Bently Nevada 3300/16, also cataloged as the 3300/16 Dual Vibration Monitor, operates as a dedicated hardware component for continuous rotor vibration monitoring within machinery protection systems. It accepts dual independent proximitor transducer inputs and provides analog outputs, alarm relays, and front-panel display for real-time condition assessment. Hardware Specifications Parameter Specification ModelBrand Bently Nevada 3300/16 Origin USA Weight 1.1 kg (2.4 lbs) Dimensions Standard 19-inch rack-mount width, 3U height (approximate) OperatingTemp 0 degC to +65 degC StorageTemp -40 degC to +85 degC RelativeHumidity Up to 95%, non-condensing PowerConsumption Typical <10 W TransducerInputs 2 channels, 5mm/8mm/11mm Proximitor systems InputImpedance 10 kOhm nominal BufferedOutputs Coaxial front panel, terminal block rear panel, 100 Ohm impedance, short-circuit protected RecorderOutputs 4-20 mA or 1-5 Vdc per channel FrequencyResponse Standard: 4 Hz to 4 kHz; Optional Low-Freq: 1 Hz to 4 kHz (-3 dB) Accuracy ±0.5% of full scale at 25 degC AlarmSetpoints Alert/Danger, 0-100% full scale, programmable time delay 0.1–6 s RelayOutputs SPDT, 5 A @ 120 Vac / 24 Vdc resistive, epoxy/hermetic/pneumatic options FrontPanelDisplay Digital LED, bar graph, gap voltage monitoring Rotordynamics & GapVoltage Validation The 3300/16 monitor includes eddy-current probe scaling for precise rotor vibration measurement. Gap voltage validation supports direct measurement against -10 Vdc reference targets to confirm probe-to-shaft clearance. Cross-talk suppression circuits isolate each channel to reduce interference between dual proximitor inputs, maintaining integrity of rotordynamic analysis. Frequently Asked Questions Q: Does the 3300/16 support hot-swap of transducer modules?A: No, the module requires system power-down before input transducer replacement to avoid signal damage. Q: What is the maximum load on recorder outputs?A: Buffered 4-20 mA outputs are rated for standard 500 Ohm maximum load; voltage outputs maintain 1-5 Vdc over typical 1 kOhm load. Q: Can firmware updates be applied in the field?A: The 3300/16 is a legacy analog monitor; firmware is fixed and not field-upgradable. Field Installation Guidelines Mount the monitor on a stable, vibration-free panel or 19-inch rack. Ensure all proximitor cabling is shielded and grounded at one end to minimize electrical noise. Maintain separation between analog signal wiring and high-voltage or digital communication lines. Verify proper orientation of the front panel to facilitate gap voltage measurement access. Install relays according to current ratings; use external suppression diodes if driving inductive loads. Confirm environmental limits: avoid condensation and direct exposure to high heat sources.
$200.00 $100.00
-
Bently Nevada Bently Nevada 3300/15-03-01-01-00-00-00 Dual Vibration Monitor
Bently Nevada 3300/15-03-01-01-00-00-00 Dual Vibration Monitor The Bently Nevada 3300/15-03-01-01-00-00-00, also cataloged as the 3300/15 Dual Vibration Monitor, operates as a dedicated hardware component for continuous radial vibration measurement across dual Proximitor channels within the 3300 Machinery Monitoring System. It provides real-time signal acquisition, relay actuation, and 4-20 mA recorder output for industrial machinery monitoring loops. Hardware Specifications Parameter Specification ModelBrand Bently Nevada Origin United States Weight 1.0 kg (2.2 lbs) Dimensions 221 mm x 24.4 mm x 295 mm OperatingTemp 0 degC to 65 degC StorageTemp -40 degC to 85 degC RelativeHumidity Up to 95% non-condensing PowerConsumption 6 W typical SignalInput 2 independent proximity probe channels InputImpedance >10 kOhm FrequencyResponse 4 Hz to 5 kHz (-3 dB) FullScaleRange 0-5 mils pp AlarmOutputs Alert and Danger SPDT relays, 5 A @ 120 VAC / 28 VDC RecorderOutput 4-20 mA DC proportional to full scale Display 4-digit LCD with backlight LEDIndicators OK (green), ALERT (yellow), DANGER (red), BYPASS (red) Rotordynamics & Eddy-Current Probe Scaling The monitor supports eddy-current probe scaling with configurable millivolt-per-unit displacement calibration. Gap voltage validation is maintained at -10 VDC targets to ensure rotor displacement linearity. Cross-talk suppression circuitry reduces signal interference between adjacent channels, supporting precise vibration measurement for high-speed rotating machinery and dynamic imbalance detection. Frequently Asked Questions Q: What is the maximum loop current for recorder output?A: The recorder output supports standard 4-20 mA DC current proportional to the configured full-scale vibration range. No additional amplification is required. Q: Can the 3300/15 be hot-swapped in a live 3300 rack?A: The monitor requires powering down the rack slot before replacement. It is not designed for hot-swap operation. Q: How does the monitor respond to sensor failure or gap loss?A: The OK LED will turn off, and both Alert and Danger relays will default according to preprogrammed safe-state configuration. Field Installation Guidelines Mount the unit in a standard 3300 single-slot rack with proper mechanical fastening. Ensure proximity probe cabling is shielded and grounded at one end only to avoid ground loops. Maintain separation from high-current power cables to minimize EMI pickup. Connect relay outputs to dry-contact circuits rated for 5 A maximum; avoid exceeding voltage or current ratings. Verify that the 4-20 mA loop is configured for the correct full-scale range and polarity. Avoid inserting the unit while the rack is energized; use static protection measures when handling connectors. Periodically inspect BNC transducer outputs and internal connections for corrosion or loose terminations.
$200.00 $100.00
-
Bently Nevada DC Power Supply Module | Bently Nevada 3300/14
Bently Nevada 3300/14 DC Power Supply Module Configured for power distribution within Bently Nevada 3300 rack system, the Bently Nevada 3300/14 (3300/14 DC Power Supply Module) provides direct electrical execution. The unit converts external DC input into regulated rack supply rails used by 3300 series monitor modules and proximity measurement channels, supporting backplane power distribution within a single-slot rack position. The module occupies Slot 1 of the 3300 rack and operates as the sole power source for a fully populated configuration of monitoring modules and associated transducer interfaces. Protection functions include input polarity protection, regulated output control, and internal filtering against conducted line disturbances. Suffix Breakdown & Model Matrix The 3300/14 is a single fixed-order module designation. No extended suffix segmentation or functional sub-variant matrix is defined within the provided specification. All electrical and mechanical characteristics apply uniformly to the base model. Hardware Specifications Parameter Specification ModelBrand Bently Nevada 3300/14 Weight approx 2.04 kg Dimensions approx 5.2 cm x 33 cm x 20.5 cm OperatingTemp 0 degC to 65 degC PowerConsumption Derived from input: 20 to 34 VDC @ 5.5 A max or 90 to 140 VDC @ 1.5 A max Output Voltage -24 VDC or -18 VDC selectable via internal jumpers Rack Capacity Up to 12 monitors with associated transducers Relay Output SPDT OK relay, 5 A @ 28 VDC / 120 VAC / 220 VAC Bently Nevada Mechanical Signal Integrity Interface Behavior Within Bently Nevada 3300 architecture, power stability directly affects eddy-current probe signal conditioning and gap voltage validation referenced at approximately -10 VDC operating targets in proximity measurement chains. Supply rail noise attenuation contributes to reduced cross-talk between adjacent vibration monitor channels, particularly in high-density rack configurations where multiple proximity transducer scaling circuits operate concurrently. The regulated DC rail supports consistent rotor dynamics measurement integrity by maintaining stable excitation conditions for downstream monitor electronics. Frequently Asked Questions Q: Can the 3300/14 support hot-swap operation during rack energization?A: The module is intended for fixed Slot 1 installation. Removal under energized conditions can interrupt backplane power distribution to all installed monitor modules. Q: Does the power supply isolate individual monitor channels on the backplane?A: Channel-to-channel isolation is implemented at the monitor module level. The 3300/14 provides centralized regulated DC distribution only. Q: What is the expected behavior under input undervoltage conditions?A: The module disables regulated output and de-energizes the OK relay when input voltage falls outside specified operating thresholds. Field Installation Guidelines Install the module exclusively in Slot 1 of the 3300 rack. Ensure DC input polarity is verified before energization. Maintain shield continuity for rack grounding to minimize conducted interference across monitor backplane lines. Route input power conductors away from proximity probe cabling to reduce coupled noise into measurement circuits. Verify OK relay state transitions during initial power-up before connecting field transducer loads.
$200.00 $100.00
-
Bently Nevada AC Power Supply | Bently Nevada 3300/12
Bently Nevada 3300/12 AC Power Supply The Bently Nevada 3300/12, also cataloged as the 3300/12 AC Power Supply, operates as a dedicated hardware component for regulated DC power distribution within 3300 series machinery monitoring racks. It provides direct electrical execution for up to 12 3300 series monitors and their connected transducers. Hardware Specifications Parameter Specification ModelBrand Bently Nevada 3300/12 Origin Manufactured for Bently Nevada 3300 series systems Weight Approximately 1.0 kg (2.2 lbs) Dimensions 83 mm (3.25 in) vertical height OperatingTemp 0 degC to +65 degC StorageTemp -40 degC to +85 degC RelativeHumidity 95% non-condensing InputVoltage 95-125 Vac, 50/60 Hz or 190-250 Vac, 50/60 Hz PowerConsumption Nominal 1.5 W (varies with rack load) OutputVoltage Regulated DC for 3300 series monitors and transducers Eddy-Current ProbeScaling & Signal Integrity The 3300/12 module includes integrated filtering for line noise suppression, supporting eddy-current probe scaling and gap voltage validation down to -10 VDC targets. Its architecture minimizes cross-talk between channels, preserving rotordynamics monitoring fidelity across multiple transducers in a single rack configuration. Frequently Asked Questions Q: VnA: Can the 3300/12 be hot-swapped while the rack is powered?A: No. The power supply must be installed with the rack de-energized to avoid transient voltage spikes affecting connected monitors. Q: VnA: What is the maximum number of monitors supported?A: The 3300/12 provides regulated DC power for up to 12 monitors with associated transducers. Q: VnA: Does the module support backplane current sharing for redundant racks?A: Only one 3300/12 supply is intended per rack. Parallel operation of multiple units is not supported. Field Installation Guidelines Mount the 3300/12 in Position 1 (leftmost slot) of the 3300 rack. Ensure proper grounding to the rack chassis to reduce electrical noise coupling. Route input AC power with separation from signal cables to prevent EMI. Verify ambient temperature within 0 degC to +65 degC and humidity below 95% non-condensing. Tighten connectors to manufacturer torque specifications; avoid stress on DC output terminals.
$200.00 $100.00
-
Bently Nevada 3300/05-24-00-00 Rack Module | Bently Nevada
Bently Nevada 3300/05-24-00-00 Rack Module Configured for physical housing and backplane distribution in the 3300 Machinery Monitoring System, the Bently Nevada 3300/05-24-00-00 (3300/05 Rack) provides direct physical/electrical execution within Bently Nevada 3300 rack-based monitoring architecture. The unit implements an 8-slot instrument chassis with integrated power supply and system monitor placement for backplane signal routing and module interconnection. Hardware Specifications Parameter Specification ModelBrand Bently Nevada 3300/05-24-00-00 Origin USA Dimensions 19-inch rack form factor, 8-slot chassis OperatingTemp 0 degC to +65 degC PowerConsumption Not specified Slot Capacity 8 monitor module slots (excluding PSU/system monitor position) Mounting Type Panel mount Cable Termination Top and bottom entry Eddy Current Probe Scaling and Backplane Signal Integrity Control The Bently Nevada 3300/05 rack structure supports stable routing of eddy-current probe inputs through its backplane interconnect system. Signal channels derived from proximity probe drivers are routed via controlled impedance paths to minimize cross-channel interference during vibration and position measurement acquisition. Backplane layout is designed to maintain consistent scaling reference alignment between probe gap voltage conversion stages and monitoring modules. Cross-talk suppression is achieved through physical separation of channel traces and defined grounding topology across the rack frame, ensuring stable -10 VDC nominal gap voltage validation reference behavior at the module interface level. Frequently Asked Questions Q: Can 3300/05 rack support hot-swap of monitoring modules?A: Module insertion and removal are not designed for energized backplane operation. Power removal is required to maintain stable bus voltage conditions. Q: What is the backplane current distribution limit behavior?A: Current distribution is handled through the integrated rack power rail. Load is shared across installed modules; total consumption is limited by the system power supply rating rather than individual slots. Q: Does the rack introduce signal delay on vibration channels?A: The rack backplane operates as a passive interconnect system; propagation delay is negligible and primarily dependent on external module processing. Field Installation Guidelines Ensure the rack is mounted in a mechanically rigid 19-inch panel cutout with sufficient rear clearance for top and bottom cable routing. Maintain separation between signal wiring and power conductors to reduce induced noise coupling. All shielded cable terminations should be grounded at a single-point chassis reference to avoid ground loop formation. Verify that the system power supply is de-energized prior to module insertion. Torque all rack mounting fasteners to standard industrial enclosure practice to prevent vibration-induced loosening.
$200.00 $100.00
-
Bently Nevada 3300/05-22-00-00 3300 System Monitor Rack | Bently Nevada
Bently Nevada 3300/05-22-00-00 3300 System Monitor Rack Configured for modular machinery condition monitoring in 3300 System architectures, the Bently Nevada 3300/05-22-00-00 (3300/05 System Monitor Rack) provides direct backplane-based execution of multi-channel vibration and process signal acquisition across insertable monitor modules. Suffix Breakdown & Model Matrix 3300/05: Rack chassis series designation 22: 12-inch, 8-slot panel mount configuration 00: Left-position system monitor and power supply placement 00: No agency certification option pre-assigned Hardware Specifications Parameter Specification ModelBrand Bently Nevada 3300/05-22-00-00 Origin USA Weight 2.7 kg Dimensions 27.9 cm x 45.7 cm x 58.4 cm OperatingTemp 0 degC to 65 degC PowerConsumption Not specified (depends on installed modules and PSU type) Rack Architecture 8-slot modular backplane system Slot Type Insertable monitoring modules Mounting Style Panel mount Communication Internal backplane signal routing Eddy Current Probe Scaling and Cross-Talk Suppression (Bently Nevada TS Interface Domain) Within the Bently Nevada Bently Nevada 3300 architecture, input conditioning stages support eddy-current proximity probe scaling via standardized gap voltage conversion, typically referenced against calibrated -10 VDC full-scale displacement targets. Signal integrity is maintained through backplane isolation design, limiting inter-channel cross-talk during high-density vibration monitoring. The system architecture enforces deterministic separation between adjacent monitor modules, reducing phase distortion in multi-channel rotor dynamic measurements and stabilizing synchronous amplitude tracking under variable shaft speed conditions. Frequently Asked Questions Q: Can 3300/05 rack modules be hot-swapped during operation?A: Hot-swap is not supported for signal processing modules under energized backplane conditions. Power isolation is required prior to insertion or removal to avoid transient bus disturbances. Q: What is the backplane current limitation for full 8-slot configuration?A: Backplane loading is defined by the installed power supply module. Total current draw scales with monitor density and transducer interface types. Q: Does the rack support mixed vibration and position modules simultaneously?A: Yes. The backplane architecture supports heterogeneous module population, including vibration, thrust, and radial position monitoring cards. Field Installation Guidelines Ensure the rack is mounted on a rigid panel structure with controlled mechanical vibration isolation. Maintain minimum clearance around the chassis for airflow across installed modules. Shielded cabling must be routed with single-point grounding at the cabinet entry to minimize ground loop formation across proximity probe return paths. Backplane connectors must remain free of contamination during installation, and module seating force must be applied evenly to avoid pin misalignment or partial engagement. Power supply wiring should follow industrial control cabinet segregation rules, separating low-level sensor wiring from power conductors to preserve signal integrity.
$200.00 $100.00
-
Bently Nevada Bently Nevada 3300/03 System Monitor Module
Bently Nevada 3300/03 System Monitor Configured for rack-level signal conditioning and multi-channel monitor interconnection in the 3300 monitoring system, the Bently Nevada 3300/03 System Monitor (3300/03 System Monitor) provides direct physical/electrical execution within 3300 monitor rack architectures. Suffix Breakdown & Model Matrix No validated suffix segmentation is defined beyond the base ordering designation 3300/03 System Monitor. No internal subcode decomposition is assumed. Hardware Specifications Parameter Specification Model 3300/03 System Monitor Brand Bently Nevada Origin United States (Bently Nevada product line) OperatingTemp Not specified (system dependent rack environment) PowerConsumption 2 W (4.6 W with interface options) Keyphasor Inputs Up to 4 proximity probe signals Input Impedance 10 k ohm (Keyphasor inputs) RS422 Baud Rate Up to 19.2 k baud (SDI), 38.4 k baud (DDI) RS232 Baud Rate Up to 19.2 k baud Signal Conditioning Range Up to 10 kHz (software selectable) Dynamic Accuracy ±0.3% full-scale typical at 25 degC Phase Accuracy ±0.2 deg typical at 25 degC Output Type Buffered Keyphasor outputs (4 coaxial) Bently Nevada Eddy-Current Signal Conditioning & Gap Validation Logic The Bently Nevada 3300/03 System Monitor integrates eddy-current probe scaling logic for Keyphasor processing, maintaining proportional conversion between mechanical shaft displacement and conditioned voltage output. Gap voltage validation routines support negative bias operating windows (0 to -24 VDC / 0 to -18 VDC), ensuring stable probe linearization across rotor dynamic operating ranges. Cross-channel signal interaction is minimized through isolated impedance domains and buffered coaxial output stages, reducing crosstalk propagation in multi-rack installations. Frequently Asked Questions Q: Can the 3300/03 System Monitor interface directly with external control systems?A: Yes. It supports RS422 and RS232 communication channels for SDI/DDI data transmission to external processors or compatible monitoring systems. Q: What is the maximum Keyphasor input capacity?A: The module accepts up to four proximity probe Keyphasor inputs with 10 k ohm input impedance and conditioned signal routing. Q: Does the module perform internal signal conditioning?A: Yes. It provides software-selectable frequency conditioning up to 10 kHz with dynamic and phase accuracy specified at 25 degC reference conditions. Field Installation Guidelines The 3300/03 System Monitor shall be installed within a compatible 3300 monitor rack backplane assembly with verified connector seating integrity. RS422/RS232 communication wiring must maintain controlled impedance routing and separation from high-noise power conductors. Keyphasor coaxial outputs require shield termination at a single-point ground to prevent ground loop formation. Probe input cabling should follow standard eddy-current extension practices, ensuring continuous shield integrity from probe head to termination module. Backplane insertion force must be applied evenly to avoid connector pin deformation.
$200.00 $100.00
-
Bently Nevada Bently Nevada 3300/01 System Monitor Module
Bently Nevada 3300/01 System Monitor Module Configured for system diagnostics, Keyphasor signal distribution, and rack-level control functions in the Bently Nevada 3300 Machinery Protection System, the Bently Nevada 3300/01 (3300/01 System Monitor Module) provides direct physical and electrical execution. The module occupies the second rack slot from the left, interfaces with rack power and backplane circuits, processes up to two Keyphasor inputs, and supports optional serial communication functions for supervisory systems and data acquisition platforms. Hardware Specifications Parameter Specification Model 3300/01 Brand Bently Nevada Origin Not specified Product Type System Monitor Module Rack Position Second slot from left, adjacent to power supply module Power Consumption Nominal 3.6 W (with serial interface option) Power Source Regulated DC power from 3300 rack backplane Keyphasor Inputs Up to 2 proximity transducer inputs Keyphasor Frequency Range 60 to 30,000 cpm (1 Hz to 500 Hz) Minimum Input Amplitude 0.5 Vp-p DC Signal Range 0 to -24 VDC or 0 to -18 VDC Buffered Outputs 4 front-panel Keyphasor outputs Output Impedance 50 Ohm Dynamic Signal Accuracy +/-0.3% of full scale typical Phase Accuracy +/-0.2 degrees typical at 25 degC RPM Accuracy +/-1 rpm typical Communication Interfaces RS-232 or RS-422 (optional) Supported Protocols Modbus RTU, SDI, DDI Maximum Baud Rate 19.2 kbaud (RS-232), 38.4 kbaud (RS-422) Operating Temp -20 degC to +70 degC Storage Temp -40 degC to +85 degC Relative Humidity Up to 95% non-condensing Weight Approximately 0.6 kg to 0.7 kg Dimensions Approximately 5.1 cm x 20.3 cm x 33.0 cm Front Panel Functions RESET, UP/DOWN setpoint adjustment Rear Terminal Functions Rack Inhibit, Trip Multiply, Remote Alarm Reset Eddy-Current Probe Interface and Rotor Dynamic Signal Distribution The 3300/01 module accepts Keyphasor signals generated by proximity probe systems and distributes phase-reference information through the rack backplane. Signal conditioning supports rotational speed measurements from 1 Hz to 500 Hz while maintaining phase accuracy for vibration, position, and rotor dynamic monitoring functions. For installations using eddy-current proximity transducers, probe system validation commonly includes verification of probe gap voltage against the target surface. During commissioning, signal integrity should be confirmed before Keyphasor references are utilized by rack-mounted monitoring modules. The front-panel buffered outputs provide direct access to conditioned Keyphasor signals for diagnostic instrumentation and waveform verification. Frequently Asked Questions Q: Does the 3300/01 support hot replacement while the rack is energized?A: The supplied documentation does not specify hot-swap capability. Module replacement procedures should follow the applicable 3300 system maintenance instructions and site isolation requirements. Q: How many Keyphasor reference signals can the module process?A: The module accepts up to two Keyphasor inputs and distributes the reference information through the rack backplane for use by compatible monitoring modules. Q: What communication options are available on the 3300/01?A: Optional communication boards provide RS-232 or RS-422 interfaces supporting Modbus RTU and Bently Nevada SDI/DDI communication protocols for host-system integration. Field Installation Guidelines Install the module only in the designated System Monitor position immediately to the right of the rack power supply. Verify all rack supply voltages through the front-panel and internal status indicators before commissioning connected monitor modules. Route Keyphasor signal cables separately from high-energy power conductors to minimize induced electrical noise. Maintain proper shield termination practices according to plant grounding standards and proximity transducer installation requirements. Confirm correct operation of Rack Inhibit, Trip Multiply, and Remote Alarm Reset wiring before placing the machinery protection system into service. Use the front-panel buffered Keyphasor outputs when validating phase-reference quality, rotational speed signals, or diagnostic measurements. Inspect communication interface settings and protocol configuration before connecting supervisory computers, PLCs, or monitoring software.
$200.00 $100.00
-
Bently Nevada Bently Nevada 10513-02 Clamp Drawer Module
Bently Nevada 10513-02 Clamp Drawer Module The Bently Nevada 10513-02 serves as the primary 10513-02 Clamp Drawer Module utilized to execute machinery condition signal processing across 3300 Series Monitoring System platforms. The module interfaces with vibration, position, temperature, pressure, and overspeed monitoring channels while maintaining continuous online machinery protection functions under API 670 operating requirements. Suffix Breakdown & Model Matrix The provided documentation references a fixed hardware configuration identified as 10513-02. No manufacturer-defined suffix variants or configurable ordering matrix were specified. Hardware Specifications Parameter Specification Model 10513-02 Brand Bently Nevada Module Type Clamp Drawer Module System Compatibility 3300 Series Monitoring System Input Voltage 24 VDC Communication Protocol DeviceNet Monitoring Functions Vibration, position, temperature, pressure, overspeed Enclosure Rating IP65 Weight 0.5 kg Dimensions 2.6 x 25.3 x 24 cm Operating Temp -40 deg C to +85 deg C Origin USA Compliance Standard API 670 Power Consumption Not specified Rotor Dynamics and Cross-Talk Suppression The 10513-02 module supports continuous machinery monitoring circuits where rotor dynamic response behavior must remain electrically stable during transient shaft loading conditions. Signal routing architecture within the 3300 monitoring platform assists in minimizing cross-talk propagation between adjacent vibration and position channels. For eddy-current proximity monitoring applications, stable gap voltage validation relative to standard -10 VDC reference targets is required to maintain probe linearity and calibrated displacement scaling. Ground continuity and shield integrity directly affect low-level transducer signal stability during operation near rotating equipment and high-energy electrical systems. The module communication interface permits integration with supervisory monitoring layers while maintaining dedicated local signal acquisition pathways for machinery protection functions. Frequently Asked Questions Q: Does the 10513-02 module support hot insertion into an energized rack?A: Hot-swap capability was not defined in the supplied documentation. Power isolation before module insertion or removal is recommended unless specifically permitted by the associated rack system manual. Q: What type of communication interface is supported by the module?A: The module is specified for DeviceNet communication integration. Q: What installation practice is recommended for vibration signal wiring?A: Shielded instrumentation cable with single-point grounding is typically used for vibration and proximity transducer circuits to reduce electromagnetic interference and ground loop current flow. Field Installation Guidelines Install the module within a properly grounded enclosure maintaining separation between low-level transducer wiring and higher-energy power conductors. DeviceNet communication cabling should be routed independently from motor feeder circuits and variable frequency drive output wiring. Inspect edge connectors and drawer engagement hardware before insertion into the monitoring rack. Improper seating may introduce intermittent channel communication or unstable signal reference conditions. Maintain shield continuity across all transducer extension wiring and avoid multi-point shield grounding practices that may introduce common-mode electrical noise into shaft vibration and axial position measurements.
$200.00 $100.00
-
EMERSON Emerson KJ3222X1-BA1 S-Series Dual DC/DC Power Supply Module
Product Description Overview The Emerson KJ3222X1-BA1 is a dual-output DC/DC power supply engineered for DeltaV S-series power carriers. It converts standard 24 VDC system power into regulated voltages for LocalBus and I/O modules. Designed for redundancy, it can operate in a 1+1 hot-standby configuration, ensuring uninterrupted power delivery to mission-critical process control systems. Key Features Redundant Operation: Supports 1+1 redundancy with load-sharing and oring diode circuitry for seamless backup in case of failure. Stable Voltage Output: Maintains regulated power to LocalBus and I/O cards even with input fluctuations from 18 VDC to 32 VDC. Galvanic Isolation: Protects downstream electronics from electrical noise and transient spikes. Fault Protection: Includes short-circuit and overcurrent safeguards to protect modules and the carrier backplane. Status Monitoring: Front-panel LEDs indicate power and fault conditions, while the DeltaV system provides software alerts for module health, over-temperature, or input loss. Durable Construction: Conformal-coated electronics resist humidity and corrosive contaminants; shock and vibration rated for industrial environments. Technical Specifications Feature Specification Module Type Dual DC/DC Power Supply Compatible Series DeltaV S-Series Input Voltage 24 VDC Nominal Input Range 18–32 VDC Output Voltage 12 VDC LocalBus Power Output Power Up to 8 A LocalBus, 6.5 A Bussed Field Efficiency > 85% at full load Operating Temperature -40°C to +70°C (-40°F to 158°F) Storage Temperature -40°C to +85°C (-40°F to 185°F) Relative Humidity 5–95%, Non-condensing Shock & Vibration 10g, 11 ms sinewave; 1 mm p-p 2–13.2 Hz, 0.7 g 13.2–150 Hz Hazardous Area Rating ATEX Zone 2 / Class 1 Div 2 Weight 1.13 kg (approx.) Mounting DeltaV S-series Power Carrier Slot Applications The KJ3222X1-BA1 is ideal for powering S-series I/O nodes in: Continuous process plants, including chemical and petrochemical operations. Power generation facilities requiring stable control system power during fluctuations. Large-scale I/O configurations across multiple carriers needing centralized redundant power. FAQ Q: Can two KJ3222X1-BA1 modules run in parallel for redundancy?A: Yes, they support 1+1 redundancy to provide hot-standby power. Q: How does it handle input voltage variations?A: The module maintains stable 12 VDC LocalBus output across 18–32 VDC input. Q: What environmental conditions can it withstand?A: Rated for -40°C to +70°C, with full shock, vibration, and corrosive contaminant protection. Q: Which I/O modules are compatible?A: Fully compatible with DeltaV S-series LocalBus and I/O modules. Q: Is it suitable for hazardous areas?A: Yes, certified for ATEX Zone 2 and Class 1 Div 2 installations.
$200.00 $100.00
-
Bently Nevada Bently Nevada 3300/45 Dual Differential Expansion Monitor
Overview The 3300/45 Dual Differential Expansion Monitor from Bently Nevada’s 3300 series delivers precise vibration data for machinery health diagnostics. It supports predictive maintenance by identifying early signs of imbalance, misalignment, or bearing wear. Technical Specifications Specification Details Model Number 3300/45 Manufacturer Bently Nevada Product Series 3300 Module Type Dual Differential Expansion Monitor Dimensions 15 x 10 x 5 cm Weight 1 kg System Compatibility TSI Communication Interface Ethernet Router HS Code 8537101190 Product Origin USA Condition Brand New Lead Time In Stock MOQ 1 Discontinued Status Active Key Features The 3300/45 module captures dual-channel vibration signals for real-time analysis. Its compact 15x10x5 cm form factor allows easy integration into control cabinets. Weighing 1 kg, it offers a balance of durability and installation flexibility. Ethernet connectivity enables centralized monitoring and rapid fault detection. Advanced sensor technology ensures consistent performance in harsh environments.
$200.00 $100.00
-
Bently Nevada Bently Nevada 1900/55 Transducer Interface Module
Overview The 1900/55 Transducer Interface Module from Bently Nevada delivers real-time vibration diagnostics for industrial machinery. It belongs to the 3300 series, offering scalable architecture and centralized data acquisition. Operators rely on its precision sensors to detect imbalance, misalignment, and bearing wear before failures occur. Technical Specifications Specification Detail Model Number 1900/55 Series 3300 Manufacturer Bently Nevada Module Type Transducer Interface Module Dimensions 2.2 x 12.4 x 12.6 cm Weight 1.32 kg System TSI HS Code 8537101190 Origin USA Condition Brand New Lead Time In Stock MOQ 1 Communication Ethernet router
$200.00 $100.00
-
Bently Nevada Bently Nevada 146031-02 Transient Data Interface Module
Overview The 146031-02 Transient Data Interface Module from Bently Nevada enhances control system performance with high-speed sampling and real-time data exchange. As part of the 3300 series, this industrial-grade module supports seamless communication between devices, improving automation precision and reducing downtime. Technical Specifications Specification Detail Model Number 146031-02 Series 3300 Manufacturer Bently Nevada Module Type Transient Data Interface Module Dimensions 25 x 23.5 x 4.1 cm Weight 0.38 kg System TSI HS Code 8537101190 Origin USA Condition Brand New Lead Time In Stock Discontinued Active MOQ 1 Communication Ethernet router
$200.00 $100.00
-
Bently Nevada Bently Nevada 3300/16 Dual Vibration Monitor
Overview The 3300/16 dual vibration monitor from Bently Nevada’s 3300 series delivers real-time diagnostics for vibration, displacement, and temperature. This compact unit measures 15 × 10 × 5 cm and weighs 1 kg, making it suitable for control panels and tight enclosures. Engineered for industrial reliability, the 3300/16 supports Ethernet router communication and integrates seamlessly into TSI systems. Its scalable design adapts to evolving operational needs, ensuring long-term value in predictive maintenance programs. Technical Specifications Parameter Value Model Number 3300/16 Series 3300 Manufacturer Bently Nevada Module Type Dual Vibration Monitor Dimensions 15 × 10 × 5 cm Weight 1 kg System Compatibility TSI Communication Ethernet Router HS Code 8537101190 Condition Brand New Origin USA Availability In Stock MOQ 1 Unit Key Features The 3300/16 monitors vibration, displacement, and temperature in real time. Its dual-channel design supports simultaneous diagnostics across multiple machine components. Ethernet router interface enables fast data transmission and remote access. Compact form factor simplifies installation in space-constrained environments. Scalable architecture allows customization for specific operational requirements.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330101-00-17-10-02-CN Proximity Probe
Overview The 330101-00-17-10-02-CN proximity probe from Bently Nevada’s 3300 XL series delivers high-precision vibration and position monitoring. Its 8 mm eddy current sensor ensures accurate, non-contact measurements for rotating machinery. This model features a slim 122 cm body with a 1.5 cm diameter, making it ideal for tight installations. The probe weighs just 0.06 kg, offering lightweight handling without compromising durability. It connects via Ethernet router, supporting seamless integration into TSI systems. Technical Specifications Parameter Value Model Number 330101-00-17-10-02-CN Series 3300 XL Manufacturer Bently Nevada Module Type Proximity Probe Sensor Diameter 8 mm Dimensions 122 × 1.5 × 1.3 cm Weight 0.06 kg System Compatibility TSI Communication Ethernet Router HS Code 8537101190 Condition Brand New Origin USA Availability In Stock MOQ 1 Unit Key Features The 330101-00-17-10-02-CN uses eddy current sensing for reliable non-contact vibration detection. Its compact form factor simplifies installation across various industrial setups. The probe supports both static and dynamic measurements for full-spectrum diagnostics. Ethernet router interface ensures fast, stable communication with monitoring systems. Interchangeable components reduce maintenance time and improve operational efficiency.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330103-12-25-10-01-00 Proximity Transducer
Overview The 330103-12-25-10-01-00 proximity transducer from Bently Nevada’s 3300 XL series offers precise vibration and displacement monitoring. Its 8 mm sensing capability supports both static and dynamic measurements in rotating machinery. This model features a miniature coaxial ClickLoc connector with a protector and standard cable. The secure interface ensures stable data transmission in high-vibration environments. Its slim profile and extended length simplify installation in tight or complex setups. Technical Specifications Parameter Value Model Number 330103-12-25-10-01-00 Series 3300 XL Manufacturer Bently Nevada Module Type Proximity Transducer Sensor Diameter 8 mm Dimensions 112 × 2 × 1.6 cm Weight 0.14 kg Connector Type Miniature Coaxial ClickLoc Cable Included Standard System Compatibility TSI Communication Ethernet Router HS Code 8537101190 Condition Brand New Origin USA Availability In Stock MOQ 1 Unit Key Features The 330103-12-25-10-01-00 measures vibration and displacement without physical contact. Its 112 cm probe length suits deep or hard-to-reach installations. The ClickLoc connector ensures a secure fit and protects against signal loss. Ethernet router support enables fast integration into digital monitoring systems. The 0.14 kg weight balances durability with ease of handling.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330101-00-76-05-01-00 Proximity Probe
Overview The 330101-00-76-05-01-00 proximity probe from Bently Nevada’s 3300 series delivers precise, non-contact vibration and position sensing. Designed for industrial-grade reliability, it supports critical machinery like turbines and compressors. This model integrates seamlessly into TSI systems and supports Ethernet router communication. Its compact form factor and rugged build make it ideal for harsh environments such as power plants and chemical facilities. Technical Specifications Parameter Value Model Number 330101-00-76-05-01-00 Series 3300 XL Manufacturer Bently Nevada Module Type Proximity Probe Sensor Type Eddy Current, 8 mm Dimensions 7.8 × 1.2 × 1.2 cm Weight 0.1 kg System Compatibility TSI Communication Ethernet Router HS Code 8537101190 Condition Brand New Origin USA Availability In Stock MOQ 1 Unit Key Features The 330101-00-76-05-01-00 uses non-contact eddy current sensing to reduce wear and extend lifespan. Its modular design simplifies maintenance and supports fast integration into existing systems. The probe maintains high accuracy even in high-temperature or high-vibration environments. Flexible mounting options allow installation across various machine configurations.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330101-24-35-10-02-00 Proximity Transducer
Overview The 330101-24-35-10-02-00 Proximity Transducer from Bently Nevada is a high-precision eddy current sensor designed for vibration and position monitoring. As part of the 3300 XL series, it supports critical machinery diagnostics and integrates seamlessly into TSI systems. Its extended 112 cm cable and slim 1.5 × 1.2 cm probe head allow flexible installation across various equipment layouts. Weighing only 0.06 kg, the 330101-24-35-10-02-00 offers lightweight durability and long-term reliability in harsh industrial environments. Technical Specifications Specification Details Model Number 330101-24-35-10-02-00 Manufacturer Bently Nevada Module Type Proximity Transducer System Compatibility TSI Product Range 3300 Series Condition Brand New Dimensions 112 × 1.5 × 1.2 cm Weight 0.06 kg HS Code 8537101190 Communication Ethernet Router Lead Time In Stock Minimum Order Qty 1 Origin USA Discontinued Status Active Features The 330101-24-35-10-02-00 uses eddy current technology for accurate vibration detection. Slim probe head fits tight spaces and supports versatile mounting configurations. Long 112 cm cable enables remote sensor placement across large machinery setups. Lightweight 0.06 kg design simplifies handling and reduces structural load. Built to endure heat, chemicals, and mechanical stress in industrial environments.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330980-70-05 3300 NSv Proximity Sensor
Overview The 330980-70-05 Proximity Sensor from Bently Nevada is a precision component in the 3300 XL NSv series. It converts analog probe signals into linearized outputs for accurate machinery condition monitoring. Designed for TSI systems, this sensor supports long-distance signal transmission without degradation. Its compact 20.5 × 22.5 × 3.5 cm housing and lightweight 0.2 kg build simplify installation in tight industrial spaces. The 330980-70-05 offers advanced signal conditioning and protective features to ensure reliable performance in harsh environments. Technical Specifications Specification Details Model Number 330980-70-05 Manufacturer Bently Nevada Module Type Proximity Sensor System Compatibility TSI Product Range 3300 Series Condition Brand New Dimensions 20.5 × 22.5 × 3.5 cm Weight 0.2 kg HS Code 8537101190 Communication Ethernet Router Lead Time In Stock Minimum Order Qty 1 Origin USA Discontinued Status Active Features The 330980-70-05 amplifies and linearizes probe signals for accurate data interpretation. Compact design fits easily into rack-mounted monitoring systems and control panels. Lightweight 0.2 kg module reduces installation complexity and structural load. Operates reliably across wide environmental conditions and industrial settings. Built-in surge protection and calibration options enhance system safety and usability.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330101-00-50-10-02-00 Proximity Probe
Overview The Bently Nevada 330101-00-50-10-02-00 Proximity Probe delivers precise vibration and position measurements for rotating machinery. Its 8 mm eddy current sensor ensures accurate data collection in critical monitoring applications. With a compact 20.5 x 22.4 x 3.3 cm footprint and 0.14 kg weight, this probe installs easily across diverse industrial setups. Technical Specifications Specification Details Model Number 330101-00-50-10-02-00 Manufacturer Bently Nevada Module Type Proximity Probe System Compatibility TSI Product Range 3300 XL Series Sensor Type Eddy current, 8 mm tip Dimensions 20.5 x 22.4 x 3.3 cm Weight 0.14 kg HS Code 8537101190 Communication Ethernet router Minimum Order 1 unit Product Origin USA Availability In Stock Discontinued Status Active Features & Benefits Monitor vibration and shaft position with high-resolution eddy current sensing. Install easily using flexible mounting options for varied machinery layouts. Operate reliably in harsh environments with rugged construction and stable output. Integrate seamlessly with Bently Nevada 3300 XL monitoring systems. Simplify maintenance using interchangeable probe components and modular design. Support predictive maintenance strategies with continuous real-time data feedback.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330101-00-12-10-01-CN Proximity Probe
Product Overview The Bently Nevada 330101-00-12-10-01-CN proximity probe from the 3300 XL series delivers precise vibration monitoring and shaft position measurement. Its compact dimensions and lightweight build ensure reliable performance in demanding industrial environments. Technical Specifications Parameter Value Model Number 330101-00-12-10-01-CN Product Series 3300 XL Module Type Proximity Probe Manufacturer Bently Nevada Condition Brand New Dimensions 1.6 × 1.4 × 122 cm Weight 0.06 kg HS Code 8537101190 Origin USA Minimum Order Quantity 1 System TSI Communication Service Ethernet Router Design and Features The 330101-00-12-10-01-CN probe integrates seamlessly into monitoring systems and supports flexible mounting options. Its modular design reduces downtime and simplifies component replacement. The 8 mm eddy current sensor ensures consistent accuracy, while the slim 122 cm length allows installation in restricted machinery spaces. Applications and Compatibility The Bently Nevada 330101-00-12-10-01-CN proximity probe suits turbines, compressors, and pumps across energy, petrochemical, and manufacturing industries. Compatibility with the 3300 XL series ensures smooth integration into existing monitoring setups. Professionals rely on it to safeguard machinery health and extend equipment lifespan. Key Benefits Compact 1.6x1.4x122 cm dimensions for versatile installation. Lightweight 0.06 kg design simplifies handling and setup. Ethernet communication capability enhances monitoring efficiency. Rugged construction ensures durability in harsh environments. Modular components reduce maintenance time and cost.
$200.00 $100.00
-
Bently Nevada Bently Nevada 3300/30 Position Monitor Module
Overview The 3300/30 Position Monitor Module from Bently Nevada delivers real-time data for vibration, position, and temperature monitoring. Built for the 3300 series, it supports predictive maintenance and integrates easily with industrial control systems. Its 5x20x33cm enclosure and 0.65kg weight allow efficient installation in control cabinets. The module features Ethernet communication and advanced diagnostics, helping operators detect wear trends and prevent equipment failure. Technical Specifications Parameter Value Model Number 3300/30 Manufacturer Bently Nevada Product Series 3300 series Module Type Position Monitor Module System TSI Communication Ethernet router Monitoring Vibration, position, temperature Dimensions 5 x 20 x 33 cm Weight 0.65 kg HS Code 8537101190 Condition Brand New Lead Time In Stock Minimum Order 1 unit Origin USA Discontinued Active Features & Benefits The 3300/30 continuously tracks vibration, position, and temperature with high precision. Its diagnostic tools help identify early signs of wear and support predictive maintenance. Engineers benefit from Ethernet connectivity for fast data exchange and centralized monitoring. The compact design simplifies installation and supports scalable system configurations. Rugged construction ensures reliable operation in power, oil, and manufacturing environments.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330101-00-50-20-02-CN Proximity Probe
Product Overview The Bently Nevada 330101-00-50-20-02-CN proximity probe belongs to the 3300 XL series and ensures accurate vibration monitoring. Engineers use its eddy current sensor to measure shaft position and maintain machinery reliability. Its compact 23x23x2 cm dimensions and 0.12 kg weight make it practical for industrial environments. Technical Specifications Parameter Value Model Number 330101-00-50-20-02-CN Product Series 3300 XL Module Type Proximity Probe Manufacturer Bently Nevada Condition Brand New Dimensions 23 × 23 × 2 cm Weight 0.12 kg HS Code 8537101190 Origin USA Minimum Order Quantity 1 System TSI Communication Service Ethernet Router Design and Features The 330101-00-50-20-02-CN probe integrates seamlessly into monitoring systems and supports flexible mounting options. Its modular design reduces downtime and simplifies component replacement. The 8 mm eddy current sensor ensures consistent accuracy, while its rugged build withstands harsh industrial conditions. Applications and Compatibility The Bently Nevada 330101-00-50-20-02-CN proximity probe suits turbines, compressors, and pumps across energy, petrochemical, and manufacturing industries. Compatibility with the 3300 XL series ensures smooth integration into existing monitoring setups. Professionals rely on it to safeguard machinery health and extend equipment lifespan. Key Benefits Compact 23x23x2 cm dimensions for versatile installation. Lightweight 0.12 kg design simplifies handling and setup. Ethernet communication capability enhances monitoring efficiency. Rugged construction ensures durability in harsh environments. Modular components reduce maintenance time and cost.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330101-00-30-10-02-05 Proximity Probe
Product Overview The Bently Nevada 330101-00-30-10-02-05 proximity probe belongs to the 3300 XL series and ensures precise vibration monitoring. Engineers rely on its eddy current sensor to measure shaft position and maintain machinery reliability. Its slim 119 cm length and lightweight 0.08 kg build make it suitable for installations with limited space. Technical Specifications Parameter Value Model Number 330101-00-30-10-02-05 Product Series 3300 XL Module Type Proximity Probe Manufacturer Bently Nevada Condition Brand New Dimensions 1.5 × 1.2 × 119 cm Weight 0.08 kg HS Code 8537101190 Origin USA Minimum Order Quantity 1 System TSI Communication Service Ethernet Router Design and Features The 330101-00-30-10-02-05 probe integrates seamlessly into monitoring systems and supports flexible mounting options. Its modular design reduces downtime and simplifies component replacement. The 8 mm eddy current sensor ensures consistent accuracy, while its compact dimensions allow installation in restricted machinery spaces. Applications and Compatibility The Bently Nevada 330101-00-30-10-02-05 proximity probe suits turbines, compressors, and pumps across energy, petrochemical, and manufacturing industries. Compatibility with the 3300 XL series ensures smooth integration into existing monitoring setups. Professionals rely on it to safeguard machinery health and extend equipment lifespan. Key Benefits Slim 1.5x1.2x119 cm dimensions for versatile installation. Lightweight 0.08 kg design simplifies handling and setup. Ethernet communication capability enhances monitoring efficiency. Rugged construction ensures durability in harsh environments. Modular components reduce maintenance time and cost.
$200.00 $100.00
