Description
Yokogawa SAV144-S33 Signal Adapter Module
The Yokogawa SAV144-S33, also cataloged as the SAV144 Signal Adapter Module, operates as a dedicated hardware component for analog signal interface and channel-to-channel isolation within CENTUM VP and ProSafe-RS platforms.
Hardware Specifications
Parameter
Specification
ModelBrand
Yokogawa SAV144-S33
Origin
Japan
Weight
0.4 kg (approximate)
Dimensions
Standard DIN-rail module size (approx. 100 mm x 60 mm x 25 mm)
OperatingTemp
-20 degC to 70 degC
PowerConsumption
2.5 W
Number of Channels
16 single-ended / 8 differential
Input Range
±10 V, ±20 V, ±50 V
Accuracy
±0.05%
Noise Floor
<2 μV
Input Impedance
100 Ω
Supply Voltage
12 to 30 VDC
Isolation
500 V AC between channels and ground for 1 min
Connector Type
Screw terminals or spring-clamp field connections
DCS Process Control Features
The SAV144-S33 provides channel-to-channel isolation and supports 4-20 mA HART loop protocol integration. It accommodates analog signals with cold-junction compensation (CJc) and ensures consistent signal transmission between field instruments and Yokogawa I/O modules. Isolation minimizes cross-talk effects in multi-channel configurations.
Frequently Asked Questions
Q: Does the SAV144-S33 support hot-swap installation? A: No. Field replacement requires system power down to maintain channel integrity and isolation compliance.
Q: What is the maximum load per channel on the backplane? A: Each analog channel adheres to standard CENTUM VP I/O module current consumption limits; excessive parallel loading is not recommended.
Q: Can firmware updates be applied to the module directly? A: No. The SAV144-S33 does not contain firmware; signal handling is purely hardware-based.
Field Installation Guidelines
Mount the module on a standard DIN rail or designated sub-plate, ensuring no mechanical stress is applied to the connectors.
Route field wiring to minimize interference; maintain separation from high-power conductors.
Ensure proper grounding of the module housing and shielded signal cables to reduce noise and cross-talk.
Verify supply voltage polarity and channel connections prior to energizing the system.
Avoid connecting or disconnecting terminals while the system is powered to maintain isolation integrity.
