Overview
The SAl143-S53 from Yokogawa is a high-precision analog input module designed for industrial applications requiring reliable, isolated signal acquisition. Featuring 16 channels, the module supports standard 4 to 20 mA signals and ensures stable operation in harsh environments. Its compact form factor and user-friendly design allow seamless integration into existing control systems.
Technical Specifications
-
Model: SAl143-S53
-
Module Type: Analog Input Module
-
Channels: 16 isolated analog input channels
-
Signal Type: 4 to 20 mA
-
Accuracy: ±0.1% of full scale
-
Resolution: 16 bits
-
Input Impedance: 100 kOhm
-
Temperature Range: -25 to 70 degrees Celsius
-
Electromagnetic Immunity: Compliant with IEC 61000-4-3, IEC 61000-4-4
-
Withstanding Voltage: 1.5 kVAC between input and system for 1 minute
-
Power Supply: 24 VDC ±10%
-
Dimensions: 25 mm x 123 mm x 98 mm (0.98 x 4.84 x 3.86 inches)
-
Weight: 0.5 kg
Key Features
-
High Accuracy and Resolution: Delivers precise analog measurements across all channels
-
Wide Operating Temperature: Suitable for a variety of industrial environments
-
Dual-Redundant Configuration: Enhances system reliability
-
EMI and RFI Resistant: Stable performance even in electrically noisy environments
-
Easy Installation: Compact design for straightforward integration
Applications
-
Process control and monitoring
-
Factory automation systems
-
Remote signal acquisition
-
Environmental monitoring
FAQ
Q: Can this module handle signals outside the 4–20 mA range?
A: The SAl143-S53 is optimized for 4–20 mA signals. Using signals outside this range may compromise accuracy and safety.
Q: Is the module suitable for outdoor use?
A: The operating temperature range is -25 to 70 degrees Celsius. Additional protective housing is recommended for outdoor environments with extreme weather.
Similar Models Comparison
-
SAl143: Standard 16-channel AI module
-
SAl144: High-speed sampling version, lower input impedance
-
SAl145: Expanded channel version with enhanced EMI immunity
