Product Description
Overview
The Yokogawa S9564FA is a dedicated connector unit designed to interface with the ANB10D ESB Bus Node Unit. It provides essential communication links and power distribution to I/O modules within Yokogawa control systems. Compact and robust, this unit supports reliable signal transmission and modular system integration.
Key Features
-
Connector Function: Establishes physical connection between the ESB bus and I/O modules.
-
Signal Termination: Integrated termination resistor ensures proper signal integrity and prevents reflections.
-
Power Distribution: Supplies power to connected I/O modules, supporting multiple voltage configurations.
-
Rack Compatibility: Designed for standard 19-inch industrial racks.
-
Lightweight Design: Approximately 1.5 kg alone, up to 10 kg with eight I/O modules installed.
Technical Specifications
-
Model: S9564FA
-
Part/Order Number: New in Factory Bag
-
Module Type: Connector Unit / PLC I/O Module Interface
-
Compatible Bus Node: ANB10D ESB
-
Mounting Type: 19-inch Rack
-
Supported I/O Modules: Up to 8 modules
-
Power Supply Options: 100-120V AC, 220-240V AC, 24V DC
-
Power Consumption: Dependent on supplied modules and voltage selection
-
Weight: 1.5 kg (unit only); 10 kg with full I/O configuration
-
Communication Protocol: ESB bus for field I/O
-
Compliance: CE, RoHS
Functionality
-
Links ESB bus to I/O modules
-
Provides power to connected I/O modules
-
Maintains signal quality via integrated termination resistor
Applications
-
Field-to-PLC signal integration in industrial processes
-
Power and data distribution for modular I/O systems
-
Distributed I/O networks in process control and monitoring systems
FAQ
Q: Can the S9564FA be used with other Yokogawa bus nodes?
A: No, it is specifically compatible with the ANB10D ESB Bus Node Unit.
Q: How many I/O modules can this unit support?
A: Up to eight I/O modules can be connected per unit.
Q: Is the unit suitable for rack installation?
A: Yes, it fits standard 19-inch industrial racks.
Similar Model Comparison
-
S9563FA: Supports more I/O modules, larger footprint
-
S9562FA: Fewer I/O channels, lower power consumption
