Product Description
Overview
The PW484-50 Power Supply Module is a high-performance 24V DC power supply designed for rack mounting, suitable for a wide range of industrial control systems. It delivers stable and reliable DC output to ensure continuous operation of critical equipment.
Technical Specifications
| Parameter |
Specification |
| Input Voltage |
24V DC ±10% |
| Maximum Output Current |
5.5A |
| Output Voltage |
24V DC ±1% |
| Power Consumption |
132W |
| Mounting Type |
Rack Mountable |
| Operating Temperature |
0 to 50°C |
| Relative Humidity |
5% to 95%, non-condensing |
| Dimensions |
Standard 19-inch rack width, depth ~200mm |
| Weight |
Approx. 1.5 kg |
| Compatible Models |
PW481, PW482 series |
Applications
This power supply module is widely used in industrial control systems, data acquisition equipment, process automation instruments, and other applications requiring stable 24V DC power. It replaces the older PW484-10 module while improving overall power stability and reliability.
FAQ
Q: What are the main differences between PW484-50 and PW484-10?
A: The PW484-50 offers higher current output, improved thermal design, and is fully compatible with existing rack mounting standards.
Q: Can it operate with different input voltages?
A: This module is designed for 24V DC input only. Using other voltage types requires an additional conversion device.
Q: What is the recommended maintenance interval?
A: Under normal operating conditions, it can run continuously for over 5 years. It is recommended to inspect connections and power stability every 12 months.
