Description
Product Description
Overview
The PW481-10 power supply module from Yokogawa is designed to provide reliable DC power for field control systems. Engineered for stable operation and long-term reliability, this S2-style unit ensures consistent performance under varying load conditions. Although discontinued by the manufacturer, the module remains suitable for system replacements, with Radwell providing a 2-year warranty for operational assurance.
Technical Specifications
-
Model: PW481-10
-
Input Voltage: 100 to 120 VAC
-
Input Frequency: 50 / 60 Hz
-
Output Current: 2.5 Amps maximum
-
Output Power: 60 Watts typical
-
Style: S2 Mounting
-
Protection: Basic overcurrent and short-circuit safeguards
-
Operating Temperature: 0 to 50 C
-
Storage Temperature: -20 to 70 C
-
Humidity: 10-90 percent RH non-condensing
-
Cooling Method: Natural air convection
-
Status: Discontinued by Manufacturer
-
Warranty: Radwell 2-Year Warranty
Applications
-
Replacement module for Yokogawa field control systems
-
Provides reliable DC power for small-scale control circuits
-
Suitable for control architectures requiring S2-style modules
Similar Model Comparison
-
PW481-5: Lower output current, suitable for light load systems
-
PW481-20: Higher current capacity for medium-scale control modules
FAQ
Q: Can PW481-10 replace other S2-style Yokogawa modules?
A: Yes, as long as the system voltage and current requirements match the module specifications.
Q: Is the original manufacturer warranty valid?
A: No, but Radwell provides a 2-year replacement warranty for this discontinued unit.
