Product Description
Overview
The Yokogawa NFPW442-50 is a robust power supply module engineered for Yokogawa STARDOM series and other compatible industrial control systems. It provides reliable DC power with high stability, fast startup, and built-in protection features, ensuring consistent operation under demanding conditions.
Technical Specifications
-
Model: Yokogawa NFPW442-50
-
Product Type: Power Supply Module
-
Manufacturer: Yokogawa Electric Corporation
-
System Compatibility: Yokogawa STARDOM series and other industrial controllers
Input Specifications
-
Rated Input Voltage: 220 to 240 VAC
-
Input Voltage Range: 170 to 264 VAC RMS
-
Input Frequency: 47 to 66 Hz
-
Maximum Input Current: 0.7 A
-
Inrush Current: 90 A for 5 ms or less
-
Insulation Resistance: 50 MOhm at 500 VDC
-
Withstanding Voltage: 500 VAC for 1 minute
Output Specifications
-
Rated Output Voltage: +5.1 VDC
-
Output Current Range: 0 to 7.8 A
-
Peak Current: 11.8 A
-
Total Output Power: 40 W (60 W peak)
-
Startup Time After Power-On: Maximum 100 ms
-
Overvoltage Protection: Maximum 7 V
-
Overcurrent Protection: Minimum 105% (automatic shutdown after 4 to 14 seconds of overcurrent)
Physical Characteristics
Applications
The NFPW442-50 is suitable for:
-
Powering Yokogawa STARDOM controllers and I/O modules
-
Providing stable DC supply for industrial control networks
-
Replacement or upgrade for existing power modules in automation systems
-
Laboratory or field deployment requiring fast response and protection features
FAQ
Q: Can this module operate in environments with fluctuating voltage?
A: Yes, it supports a wide input voltage range of 170 to 264 VAC, ensuring stable operation.
Q: What protection mechanisms are included?
A: The module includes overvoltage protection up to 7 V and overcurrent protection with automatic shutdown between 4 to 14 seconds.
Q: How fast is the startup after power-on?
A: The module powers up in under 100 milliseconds, supporting rapid system initialization.
