Product Overview
The CP401-10 serves as a core computational unit within the Yokogawa CENTUM CS 3000 Distributed Control System (DCS). While often misidentified in basic listings as a simple power unit, this module is a high-performance Field Control Station (FCS) processor designed for real-time process control and high-speed data acquisition. It facilitates seamless communication between I/O modules and the supervisory network, ensuring deterministic control in demanding industrial environments such as chemical processing, refining, and power generation.
Technical Specifications
The following data represents the electrical and environmental performance standards for the CP401-10 unit:
-
Model Identification: CP401-10
-
System Compatibility: CENTUM CS 3000 R3 / CENTUM VP
-
Redundancy Support: Dual-redundant configuration capable
-
Power Consumption: 24V DC input (Internal bus powered)
-
Maximum Current Draw: 0.5A at 24V DC
-
Processor Architecture: 32-bit RISC Processor
-
Memory Capacity: 16 MB Main Memory with ECC support
-
Communication Interface: V net / VL net
-
Mounting Requirement: Installed in a Field Control Unit (FCU) rack
-
Heat Dissipation: 12W maximum
-
Cooling System: Natural convection (No fans required)
-
Ambient Operating Temperature: 0 to 50 degrees Celsius
-
Storage Temperature Range: -20 to 70 degrees Celsius
-
Ambient Humidity: 5 to 95 percent RH (Non-condensing)
-
Weight: 0.45 kg
-
Regulatory Compliance: CE Mark, UL, and CSA standards
Functional Comparison: CP401-10 vs. CP451-10
-
CP401-10: Designed for V net communication in standard CS 3000 environments. Ideal for legacy system maintenance and standard process control loops.
-
CP451-10: Enhanced version designed for Vnet/IP high-speed Ethernet-based control networks, offering higher throughput for data-intensive applications.
