Product Description
Overview
The CP330D S3 processor module by Yokogawa is a high-capacity CPU designed for CENTUM VP and CENTUM CS distributed control systems. Positioned at the core of compatible Field Control Units (FCUs), it executes real-time control logic, manages deterministic communication, and coordinates I/O data processing in demanding industrial environments. Built for continuous operation, the CP330D S3 supports dual CPU redundancy for seamless fault tolerance and online maintenance without disrupting plant operations. Its robust hardware complies with SAG3 environmental standards, making it suitable for electrically harsh and mission-critical installations.
Key Features
-
Dual CPU redundancy for high system availability
-
Online replacement capability in redundant configurations
-
Deterministic real-time control execution
-
Integrated system diagnostics and watchdog supervision
-
Compatible with CENTUM VP software revisions R5.01 through R6.04
Technical Specifications
General
System Compatibility
-
Field Control Units: AFV30, AFV40, A2FV50, A2FV70
-
Interfaces directly with I/O modules, Vnet/P communication networks, and system engineering tools
Reliability
-
Designed for continuous industrial operation
-
Supports dual-redundant CPU architectures
-
Meets SAG3 environmental standards for high-electrical-stress locations
Applications
Ideal for mission-critical process control in chemical plants, power generation, and industrial manufacturing. Its dual-redundant architecture ensures uninterrupted operations in high-availability systems, making it suitable for safety-critical installations.
FAQ
Q: Can the CP330D S3 be replaced online without shutting down the system?
A: Yes, online replacement is supported in redundant configurations to avoid plant downtime.
Q: Which FCUs are compatible with this processor module?
A: Compatible units include AFV30, AFV40, A2FV50, and A2FV70.
Q: What software versions does the module support?
A: CENTUM VP revisions R5.01 to R6.04 with dedicated patches.
