Overview
The ATA4S-00 by Yokogawa is a robust pressure clamp terminal block designed for precise signal management in complex industrial control systems. It accommodates both analog and digital signals, providing a reliable connection for up to 16 channels.
Technical Specifications
| Specification |
Details |
| Model |
ATA4S-00 |
| Manufacturer |
Yokogawa |
| Product Type |
Pressure Clamp Terminal Block |
| Number of Channels |
16 channels |
| Supported Signals |
Analog and Digital |
| Current Rating |
10 A |
| Voltage Rating |
24 VDC |
| Connection Type |
Pressure Clamp |
| Dimensions |
100 mm x 50 mm x 30 mm |
| Weight |
0.5 kg |
| Operating Temperature Range |
-20 C to +70 C |
| Storage Temperature Range |
-25 C to +85 C |
| Material (Housing) |
High-grade insulating polymer |
| Mounting Type |
DIN rail compatible |
Applications
Ideal for industrial control panels, process automation systems, and signal integration where reliable terminal connections are critical. It is suitable for both new installations and retrofitting existing control systems.
FAQ
Q: Can this terminal block handle both AC and DC signals?
A: The ATA4S-00 is optimized for DC signals up to 24 V but can safely handle compatible low-voltage AC signals within the rated current.
Q: What maintenance is required?
A: Minimal maintenance is needed. Regular inspection of clamp tension and connection integrity is recommended to ensure consistent performance.
Similar Models Comparison
-
ATA4S-01: Same size, supports 24 channels, slightly higher voltage rating.
-
ATA4S-02: Enhanced thermal resistance for high-temperature applications.
