Description
Overview
The AAP135-S00 S2 Pulse Input Module from Yokogawa delivers fast and accurate signal acquisition for industrial automation systems. It supports both 2-wire and 3-wire configurations, including contact ON/OFF, voltage pulse, and current pulse inputs.
This compact module offers eight isolated input channels, each protected with 500 V AC isolation for one minute. Yokogawa designed the AAP135-S00 S2 to handle high-speed signals with a minimum pulse width of 40 µs.
Technical Specifications
| Specification |
Details |
| Model Number |
AAP135-S00 S2 |
| Manufacturer |
Yokogawa |
| Module Type |
Pulse Input Module |
| Dimensions |
3.3 × 10.7 × 13 cm |
| Weight |
0.3 kg |
| Input Channels |
8 isolated channels |
| Input Frequency Range |
0 to 10 kHz |
| Minimum Pulse Width |
40 µs |
| Data Update Period |
2 milliseconds |
| Pull-up Resistance |
68 kΩ |
| Current Consumption |
300 mA @ 5 V DC / 400 mA @ 24 V DC |
| Communication Interface |
Ethernet router |
| System Compatibility |
DCS |
| HS Code |
8537101190 |
| Product Origin |
Japan |
| Condition |
Brand New |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
| Discontinued Status |
Active |
Features & Performance
The AAP135-S00 S2 ensures noise-resistant signal processing through channel isolation. Its rapid 2 ms update rate supports real-time control system communication. The module consumes low power while maintaining high-speed performance.
Yokogawa built the AAP135-S00 S2 for easy integration into control panels. Its lightweight design and small footprint simplify installation in tight industrial spaces.
