The Yokogawa AAI135-H53 is a high-precision analog I/O module designed for integration with ESB bus node units (ANB10S, ANB10D), optical ESB bus units (ANB11S, ANB11D), and field control units (AFV30S, AFV30D, AFV40S, AFV40D, AFV10S, AFV10D). This module converts field analog signals into digital data for field control stations (FCS) and translates FCS data into analog signals for output devices, ensuring seamless process control.
Technical Specifications
-
HART Communication Support: Yes, includes integrated HART modem
-
Max HART Devices per Module: 16
-
HART Variable Capacity: Up to 32 points per module
-
HART Multidrop Connection: Max 5 devices per channel
-
Data Refresh Cycle: 1 second per device; with 16 devices, total refresh is 17 seconds per ESB bus connection
-
Input/Output Signal Handling: Supports voltage and current signal conversions for analog-digital interfacing
-
Compatibility: Fully compatible with FCS internal data protocols
-
Module Function: Functions as both signal converter and HART interface
-
Mounting: Designed for ESB bus rack units
Applications
-
Industrial automation systems requiring precise analog-to-digital conversion
-
Field control stations with integrated HART devices
-
Process monitoring in manufacturing plants, chemical, and energy sectors
Similar Models for Comparison
-
AAI135-H52: Lower HART device capacity, basic analog conversion
-
AAI135-H54: Enhanced HART variable support, faster refresh cycle
FAQ
Q: Can this module handle more than 16 HART devices?
A: No, maximum supported per module is 16 devices.
Q: Does it support multidrop HART devices?
A: Yes, up to 5 devices per channel.
Q: What is the typical data refresh time?
A: 1 second per device; 17 seconds for 16 connected devices on the ESB bus.
