Description
Overview
The EGCP-3 8406-113 from Woodward is a microprocessor-based control operator interface designed for precise generator synchronization and load sharing. It features dual backlit LCD displays, real-time diagnostics, and robust communication protocols for seamless integration into industrial power systems.
Technical Specifications
| Specification |
Detail |
| Model Number |
EGCP-3 8406-113 |
| Manufacturer |
Woodward |
| Product Series |
Woodward |
| Module Type |
Control Operator Interface |
| Dimensions (L×W×H) |
35.8 × 28.2 × 13.5 cm |
| Weight |
4.28 kg |
| Input Voltage Range |
18–32 V DC |
| Operating Temperature |
-20°C to +70°C |
| Display Type |
Dual backlit LCD (8+4 lines) |
| Control Modes |
Local + Remote (ServLink) |
| Communication Software |
Watch Window |
| Status Menus |
9 diagnostic and control menus |
| System Compatibility |
PLC |
| Communication Interface |
Ethernet Router |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| Lead Time |
In Stock |
| Minimum Order Quantity |
1 |
| Discontinued Status |
Active |
Key Features
-
The Woodward EGCP-3 8406-113 supports parallel generator synchronization.
-
Dual LCD screens display operational and configuration data simultaneously.
-
Real-time monitoring includes engine status, power factor, and load metrics.
-
Initial setup uses a First Time Startup Menu for streamlined configuration.
-
Nine status menus simplify diagnostics and performance tracking.
-
ServLink protocol enables remote access via Watch Window software.
-
Rugged design withstands industrial temperatures and environmental stress.
