Description
Overview
The 9907-018 from Woodward is a low-voltage speed control module from the 2301A series, engineered for multi-unit generator systems. It delivers precise load sharing and speed regulation for diesel, gasoline, steam, and gas turbine engines. Its compact metal housing and front-accessible potentiometers simplify field servicing and system tuning.
Technical Specifications
| Specification |
Detail |
| Model Number |
9907-018 |
| Manufacturer |
Woodward |
| Product Series |
2301A Series |
| Module Type |
Speed Control |
| Dimensions (L×W×H) |
10.8 × 20 × 6 cm |
| Weight |
0.38 kg |
| Input Voltage Range |
18–40 VDC |
| Actuator Signal Output |
0–200 mA |
| Drive Capacity |
Up to 2A |
| Control Modes |
Isochronous / Droop |
| Load Sharing Accuracy |
±2% |
| Speed Stability |
±0.25% |
| Load Sharing Signal |
0–10V / 4–20mA |
| Speed Feedback Range |
50Hz–10kHz |
| Operating Temperature |
-40°C to +85°C |
| Storage Temperature |
-50°C to +100°C |
| Certifications |
CE / CSA |
| Power Consumption |
<5W |
| System Compatibility |
PLC |
| Communication Interface |
Ethernet Router |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| Lead Time |
In Stock |
| Minimum Order Quantity |
1 |
| Discontinued Status |
Active |
Key Features
-
The Woodward 9907-018 supports precise speed control and load sharing.
-
Compatible with EG, PB, EGB, 2301, and TM actuators.
-
Front-panel potentiometers allow quick field adjustments and tuning.
-
Self-contained load sensor enhances performance and system response.
-
CE and CSA certifications ensure global safety and EMC compliance.
-
Automatic start fuel limiting reduces engine wear and emissions.
-
Robust design tolerates extreme temperatures and industrial conditions.
