Description

Overview

The 9905-760 from Woodward is a precision-engineered digital synchronizer and load control module designed for generator synchronization and power management. It ensures accurate frequency and phase matching before grid connection, using advanced microprocessor technology to maintain system stability and protect equipment.

Technical Specifications

Specification	Detail
Model Number	9905-760
Manufacturer	Woodward
Product Series	Woodward
Module Type	Digital Synchronizer
Dimensions (L×W×H)	28 × 12 × 21 cm
Weight	0.96 kg
Operation Modes	Automatic / Manual
Control Functions	Load sharing, output regulation
Monitoring Features	Overload, overheating protection
Cabinet Requirements	Six-sided metal enclosure
RF Shielding	≥20 dB attenuation (windowed)
Cable Entry	Top or bottom (≤152 mm aperture)
System Compatibility	PLC
Communication Interface	Ethernet Router
HS Code	8537101190
Condition	Brand New
Origin	USA
Lead Time	In Stock
Minimum Order Quantity	1
Discontinued Status	Active

Key Features

• The Woodward 9905-760 synchronizes generators with precise frequency and phase control.

• Microprocessor-based design delivers fast response and stable output regulation.

• Dual operation modes support flexible control strategies in dynamic environments.

• Advanced protection features prevent overload and thermal damage to generators.

• RF shielding and grounding requirements ensure safe operation near transmitters.

• Compact dimensions simplify installation in control cabinets with limited space.

Specifications

• Dimensions: 28 × 12 × 21 cm
• Brand: Woodward

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
