The Woodward 5466-353 is a Netcon Main Chassis Transceiver Module designed for high-speed data transmission within Woodward Netcon and MicroNet turbine control systems. This module serves as a critical interface component, facilitating reliable network communication and seamless connectivity across industrial control environments.
Features
- Designed for integration with the Netcon Main Chassis.
- Equipped with a 24-character LED display for local diagnostics and status monitoring.
- Supports redundancy configurations directly on the IOTA (Input/Output Terminal Assembly).
- Engineered for high-speed data transmission with low latency.
- Includes robust power supply transient protection rated at 900 Vdc.
Applications
This transceiver module is primarily utilized in power generation and industrial turbine control applications, specifically within the Woodward Netcon and MicroNet control platforms. It is essential for maintaining network communication integrity in complex control architectures.
Technical Specifications
| Model |
5466-353 |
| Input Voltage |
24 Vdc |
| Max Operating Current |
12 A |
| Signal Input Impedance |
33K Ohms |
| Operating Temperature |
-40 degC to +85 degC |
| Transient Protection |
900 Vdc |
| Display |
24-character LED |
Installation Guidelines
- Ensure the system power is disconnected before installing or removing the module from the chassis.
- Verify that the slot is clean and free of debris to ensure proper pin alignment and electrical contact.
- Handle the module using standard ESD (Electrostatic Discharge) protection practices to prevent damage to internal circuitry.
- Ensure all cabling is properly shielded and routed away from high-EMI sources to maintain signal integrity.
- Confirm that the IOTA configuration matches the system requirements for redundant operation if applicable.
