Description

Product Overview

The Woodward 5464-659 Digital Speed Sensor is a precision module designed for MicroNet™ Digital Control Systems, supporting modular integration via 8-position baseplates. It enables accurate speed signal acquisition for turbine and prime mover control applications, interfacing seamlessly with FBMs/FCMs in high-density enclosures.

Key Features

• Model: 5464-659

• Series: MicroNet Digital Control

• Function: Digital speed sensing for turbine control

• Baseplate Compatibility:

  • Supports 8-position modular baseplates

  • Mounts up to 32 FBMs per enclosure

  • DIP switch for baseplate identification

• Signal Range: 4–20 mA analog output

• Voltage Input: 24 Vdc

• Installation:

  • Modular card guide mounting

  • Standard chassis integration

• System Integration: Compatible with FBMs/FCMs in MicroNet architecture

Technical Specifications

Specifications

• Dimensions: 160 mm × 160 mm × 12 mm
• Brand: Woodward

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
