Description

Product Overview

The Woodward 5464-643 is a robust 48-channel discrete input module engineered for MicroNet™ Digital Control Systems. Designed to interface with field switches and relays, each input channel is optically isolated to protect internal circuitry and ensure accurate signal transmission.

Key Features

• Model: 5464-643

• Series: MicroNet Digital Control

• Input Channels: 48 optically isolated discrete inputs

• Signal Source: Field switches and relays

• Isolation: Optical isolators per channel

• Interface: VME bus for CPU data retrieval

• Fault Diagnostics: LED indicators per module

• FTM Connectivity:

  • J1: Channels 1–24

  • J2: Channels 25–48

• Installation:

  • Card guide mounting

  • Dual screw retention

  • Toggle handles for safe disengagement

• Software Mapping: Channel labels match application software indexing

Technical Specifications

Specifications

• Dimensions: 160 mm × 160 mm × 12 mm
• Brand: Woodward

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
