The Woodward 5464-414 is a high-precision digital microprocessor-based speed sensor module engineered for critical prime mover control. This module facilitates advanced speed monitoring and overspeed protection for industrial turbines, reciprocating engines, and large-scale compressors. By providing real-time digital signal processing of magnetic pickup or proximity probe inputs, it delivers high-resolution speed data with minimal jitter, ensuring optimal governor performance and preventing mechanical failure in power generation, maritime, and oil and gas applications.
Features
- Advanced digital microprocessor architecture for precise frequency-to-speed conversion.
- Integrated filtering algorithms to suppress signal noise and electromagnetic interference (EMI).
- Supports redundant sensor configurations for high-availability and fault-tolerant systems.
- Seamless integration with Woodward MicroNet and 505/505E control platforms.
- Continuous self-diagnostic routines monitoring sensor health and wiring integrity.
Applications
This module is designed for demanding industrial environments including:
- Power generation turbine control systems.
- Maritime propulsion and auxiliary engine monitoring.
- Midstream oil and gas compression stations.
- Critical overspeed protection and governor feedback loops.
Technical Specifications
| Model |
5464-414 |
| Brand |
Woodward |
| Module Type |
Digital Speed Sensing Module |
| Processor |
High-speed Digital Microprocessor |
| Operating Temperature |
0 to 60 deg C |
| Weight |
1.96 kg |
Installation Guidelines
- Ensure the control system power is disconnected before installing or removing the module from the rack.
- Use shielded cabling for all speed sensor inputs to minimize noise pickup in high-EMI environments.
- Verify that the module is properly seated in the backplane to ensure reliable communication with the control platform.
- Maintain adequate airflow around the module to ensure operation within the specified 0-60 deg C temperature range.
- Follow standard ESD (Electrostatic Discharge) handling procedures when touching internal circuitry or connectors.
FAQ
Is this module compatible with Woodward 505 controllers?
Yes, the 5464-414 is designed for seamless integration with Woodward 505/505E and MicroNet control platforms.
Does this module support redundant sensor inputs?
Yes, the hardware architecture supports redundant sensor configurations to enhance reliability in fault-tolerant control applications.
