The Woodward 5463-581 is a specialized input module designed for industrial control applications. This unit functions as a 4-20mA isolated input module, providing reliable signal conditioning and isolation for critical process control loops. As a component within Woodward control systems, it ensures signal integrity by preventing ground loops and electrical interference from affecting sensitive measurement data.
Features
- Provides isolated 4-20mA analog input signal processing.
- Designed for integration into Woodward control architectures.
- Robust construction suitable for demanding industrial environments.
- Compatible with legacy Woodward systems requiring 4-20mA signal isolation.
Applications
This module is typically utilized in power generation, turbine control, and engine management systems where precise analog signal monitoring is required. It is commonly deployed in applications involving pressure, temperature, or flow transmitters that output a standard 4-20mA signal.
Technical Specifications
| Manufacturer |
Woodward |
| Model Number |
5463-581 |
| Alternate/Spare Models |
1897179, 3077-205 |
| Input Type |
4-20mA Isolated Input |
| Status |
Discontinued by Manufacturer |
Installation Guidelines
- Ensure the control system is powered down before installing or removing the module from the rack.
- Handle the module using proper ESD (Electrostatic Discharge) protection practices to prevent damage to internal circuitry.
- Verify that all field wiring is properly shielded and grounded to minimize EMI/RFI interference.
- Ensure the module is securely seated in the designated slot to maintain reliable backplane communication.
- Check for proper ventilation in the control cabinet to maintain optimal operating temperatures.
FAQ
Is the Woodward 5463-581 still in production?
No, this model has been discontinued by the manufacturer. We provide high-quality surplus or refurbished units to support legacy systems.
What are the compatible spare model numbers for this unit?
The 5463-581 is cross-referenced with spare model numbers 1897179 and 3077-205.
