Description

Product Overview

The Woodward 5437-1124 Protection Module is a panel-mounted unit designed for integration into the ProTech-GII System, supporting critical overspeed and safety functions. Each ProTech-GII system includes three internal modules (A, B, C), and this module accepts either dual high-voltage (HV) inputs or a combination of HV and low-voltage (LV) inputs, depending on system configuration.

Key Features

• Model: 5437-1124

• Manufacturer: Woodward

• Series: ProTech-GII System

• Power Inputs: Dual HV or HV + LV (model-dependent)

• LED Indicator: Confirms power-on status

• Mounting Type: Panel-mount with vertical orientation

• Installation Steps:

  • Guided slot insertion

  • Retaining screw fixation

  • Back panel and terminal block setup

  • Power application and LED verification

• Environmental Compliance: IEC 721-3-3 Class 3C2

• Max Purge Pressure: 4 psi

Technical Specifications

Specifications

• Dimensions: 361 mm × 162 mm × 140 mm
• Brand: Woodward

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
