Description
Product Description
Overview
The Liebert GXT3-700RT230 is a compact online double-conversion UPS engineered to provide continuous, clean power to critical IT, networking, and industrial systems. Its 700VA / 630W capacity delivers reliable energy, safeguarding sensitive equipment from blackouts, voltage fluctuations, and electrical noise. The 2U rack/tower convertible design ensures flexible installation in data centers, telecom rooms, or office environments.
Key Features & Functional Highlights
-
Zero Transfer Time: Instantaneous switch to battery keeps connected devices operating without interruption.
-
Pure Sine Wave Output: Protects servers, storage units, and networking devices from power anomalies and electrical noise.
-
Intelligent Battery Management: Extends battery lifespan while supporting hot-swappable replacement for maintenance without downtime.
-
LCD Interface: Provides real-time monitoring, configuration options, and system health alerts.
-
High Efficiency: ECO mode achieves up to 95% energy efficiency without compromising protection.
-
Compact Form Factor: 2U convertible design supports both rack-mounted and tower deployments, optimizing space usage.
Technical Specifications
| Specification |
Details |
| Manufacturer |
Emerson / Vertiv |
| Model |
GXT3-700RT230 |
| Product Type |
Online Double-Conversion UPS |
| Rated Capacity |
700VA / 630W |
| Power Factor |
0.9 |
| Input Voltage |
230VAC nominal (range 115–280VAC) |
| Input Frequency |
50/60 Hz auto-sensing |
| Output Voltage |
230VAC (configurable: 200/208/220/230/240VAC) |
| Output Waveform |
Pure Sine Wave |
| Transfer Time |
0 ms (instantaneous) |
| Input Connection |
IEC320-C14 |
| Output Receptacles |
6 × IEC320-C13 |
| Battery Type |
Intelligent hot-swappable VRLA (Sealed Lead Acid) |
| Battery Runtime |
~10 minutes at full load (extendable with external battery packs) |
| Recharge Time |
~3 hours to 90% capacity |
| Form Factor |
2U Rack/Tower Convertible |
| Dimensions (HxWxD) |
86 × 430 × 360 mm |
| Weight |
19 kg |
| Operating Temperature |
0°C – 40°C |
| Interfaces |
USB, RS-232, optional SNMP card |
| Certifications |
CE, UL, RoHS compliant |
Applications
Ideal for small to medium data centers, network closets, telecom equipment, and office IT infrastructure where reliable power and operational continuity are critical.
FAQ
Q: Can the UPS be installed in both rack and tower orientations?
A: Yes, the GXT3-700RT230 supports 2U rack mounting or tower placement with a rotatable LCD display for easy monitoring.
Q: Are the batteries user-replaceable?
A: Yes, the UPS includes hot-swappable internal batteries, enabling replacement without shutting down connected devices.
Q: Can I extend runtime for longer outages?
A: Optional external battery packs can be connected to increase runtime during power interruptions.
