Description
Product Overview
The DO2401 HS2 7400219-040 Digital Output Baseplate from Triconex delivers high-integrity safety control for critical applications. Designed for Tricon Systems, this module ensures rapid 2ms response and full channel isolation. Its triple-modular redundant (TMR) architecture enhances fault tolerance and system uptime.
Built for harsh environments, the DO2401 HS2 7400219-040 withstands extreme temperatures from -40°C to 70°C and resists vibration. The hot-swappable design allows maintenance without interrupting system operations, making it ideal for continuous process industries.
Each of the eight output channels delivers 24V DC with integrated short-circuit protection and load monitoring. The module complies with IEC 61508 SIL3, ATEX, and cULus certifications, ensuring global safety compliance.
Technical Specifications
| Parameter |
Specification |
| Model Number |
DO2401 HS2 7400219-040 |
| Manufacturer |
Triconex |
| Product Range |
Tricon Systems |
| Module Type |
Digital Output Baseplate |
| System |
DCS |
| Channels |
8 Digital Outputs |
| Output Voltage |
24V DC |
| Response Time |
2 milliseconds |
| Architecture |
Triple-Modular Redundant (TMR) |
| Isolation |
Channel-to-channel |
| Protection |
Short-circuit, Load Monitoring |
| Certifications |
IEC 61508 SIL3, ATEX, cULus |
| Operating Temp. |
-40°C to 70°C |
| Dimensions |
10.2 × 6.3 × 3 cm |
| Weight |
1.24 kg |
| HS Code |
8537101190 |
| Communication |
Ethernet Router |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Discontinued |
Active |
Applications & Compatibility
The DO2401 HS2 7400219-040 supports Tricon v10 and v11 systems, making it a reliable fit for:
-
Emergency Shutdown (ESD) systems
-
Fire & Gas detection networks
-
Offshore oil and gas platforms
-
Petrochemical and refining plants
-
Power generation facilities
