Description
Product Overview
The 8110 High Density Main Chassis from Triconex serves as the central backbone for Tricon Systems' fault-tolerant safety architecture. Designed for demanding industrial environments, this chassis supports six RS-485 I/O expansion bus ports and dual A/B/C channel sets for high-integrity communication.
Engineers rely on the 8110 to house critical I/O and communication modules in safety instrumented systems (SIS). Its rugged construction and modular layout allow easy upgrades and maintenance without compromising system availability or safety certifications.
The chassis includes a four-position keyswitch for secure operation control and supports expansion with 8111 or 8112 RXM models. Its compatibility with analog and digital modules ensures seamless integration across oil, gas, chemical, and power generation facilities.
Built to meet stringent industrial standards, the 8110 withstands shock, vibration, and EMI, while maintaining continuous operation under extreme conditions. It plays a vital role in executing shutdown logic and processing field signals in SIL3-certified systems.
Technical Specifications
| Parameter |
Specification |
| Model Number |
8110 |
| Manufacturer |
Triconex |
| Product Range |
Tricon Systems |
| Module Type |
High Density Main Chassis |
| System |
DCS |
| Expansion Ports |
6 RS-485 I/O bus ports |
| Channel Sets |
Dual A/B/C communication channels |
| Keyswitch |
Four-position for secure control |
| Architecture |
Triple Modular Redundant (TMR) |
| Compatibility |
Supports analog/digital I/O modules |
| Certifications |
IEC 61508 SIL3, TÜV, CE, UL |
| Operating Temp. |
-40°C to +70°C |
| Dimensions |
9.3 × 30.4 × 26.5 cm |
| Weight |
3.06 kg |
| HS Code |
8537101190 |
| Communication |
Ethernet Router |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Discontinued |
Active |
Applications & Compatibility
The 8110 integrates with Tricon controllers and supports:
-
Safety Instrumented Systems (SIS)
-
Multi-rack configurations with 8111 and 8112 RXM chassis
-
High-density I/O installations in oil, gas, and chemical plants
-
SIL3-certified process control and emergency shutdown systems
