Product Overview
The 7400221-100 PI2381 Pulse Input Baseplate from Triconex delivers precise pulse counting and frequency measurement for safety-critical DCS systems. Built for Tricon Systems v11, this 16-channel module supports 5–30V DC inputs with 24-bit resolution and ±0.01% frequency accuracy.
Each channel in the 7400221-100 PI2381 provides 1500V AC/DC isolation, ensuring signal integrity in noisy environments. The module handles up to 10kHz input rates, making it ideal for turbine speed monitoring and compressor control.
Its hot-swappable design allows technicians to perform maintenance without interrupting operations. The module operates across a wide -40°C to +70°C range and tolerates storage temperatures up to 85°C.
Advanced signal conditioning and noise rejection enable reliable RPM detection in electromagnetic-heavy environments. Engineers value the 7400221-100 PI2381 for its compact footprint, low power consumption, and seamless integration with TRISTATION 1131 tools.
Technical Specifications
| Parameter |
Specification |
| Model Number |
7400221-100 PI2381 |
| Manufacturer |
Triconex |
| Product Range |
Tricon Systems |
| Module Type |
Pulse Input Baseplate |
| System |
DCS |
| Channels |
16 Pulse Inputs |
| Input Voltage |
5–30V DC |
| Input Frequency |
Up to 10kHz |
| Resolution |
24-bit |
| Accuracy |
±0.01% |
| Isolation |
1500V AC/DC channel-to-channel |
| Diagnostics |
Signal conditioning, noise rejection |
| Certifications |
IEC 61508 SIL3, ATEX, cULus |
| Operating Temp. |
-40°C to +70°C |
| Storage Temp. |
Up to +85°C |
| Dimensions |
24.7 × 23 × 6 cm |
| Weight |
1.3 kg |
| HS Code |
8537101190 |
| Communication |
Ethernet Router |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Discontinued |
Active |
Applications & Compatibility
The 7400221-100 PI2381 integrates with Tricon controllers and supports:
-
Turbine and compressor speed monitoring
-
RPM measurement in noisy environments
-
Safety Instrumented Systems (SIS)
-
Oil & gas, chemical, and offshore installations
